CYP CDPS-P313RTX Manuel utilisateur

Operation Manual

4×1 Multi-input to HDBT Live Video Streaming

Transmitter with Recording

CDPS-P313RTX

DISCLAIMERS

The information in this manual has been carefully checked and is believed

to be accurate. Cypress Technology assumes no responsibility for any

infringements of patents or other rights of third parties which may result from

its use.

Cypress Technology assumes no responsibility for any inaccuracies that

may be contained in this document. Cypress also makes no commitment to

update or to keep current the information contained in this document.

Cypress Technology reserves the right to make improvements to this

document and/or product at any time and without notice.

No part of this document may be reproduced, transmitted, transcribed,

stored in a retrieval system, or any of its part translated into any language

or computer le, in any form or by any means—electronic, mechanical,

magnetic, optical, chemical, manual, or otherwise—without express written

permission and consent from Cypress Technology.

TRADEMARK ACKNOWLEDGMENTS

All products or service names mentioned in this document are trademarks of

the companies with which they are associated.

SAFETY PRECAUTIONS

Please read all instructions before attempting to unpack, install or operate

this equipment and before connecting the power supply. Please keep the

following in mind as you unpack and install this equipment:

• Always follow basic safety precautions to reduce the risk of re,

electrical shock and injury to persons.

• To prevent re or shock hazard, do not expose the unit to rain, moisture

or install this product near water.

• Never spill liquid of any kind on or into this product.

• Never push an object of any kind into this product through any openings

or empty slots in the unit, as you may damage parts inside the unit.

• Do not attach the power supply cabling to building surfaces.

• Use only the supplied power supply unit (PSU). Do not use the PSU if it

is damaged.

• Do not allow anything to rest on the power cabling or allow any weight to

be placed upon it or any person walk on it.

• To protect the unit from overheating, do not block any vents or openings

in the unit housing that provide ventilation and allow for su󰀩cient space

for air to circulate around the unit.

• Please completely disconnect the power when the unit is not in use to

avoid wasting electricity.

VERSION HISTORY

REV. DATE SUMMARY OF CHANGE

RDV1 2020/02/04 Preliminary release

CONTENTS

1. Introduction...................................................... 1

2. Applications ..................................................... 1

3. Package Contents ........................................... 2

4. System Requirements..................................... 2

5. Features............................................................ 3

6. Operation Controls and Functions ................ 4

6.1 Front Panel.................................................. 4

6.2 Rear Panel................................................... 6

6.3 IR Cable Pinouts.......................................... 7

6.4 RS-232 Pinout and Defaults........................ 7

6.5 WebGUI Control .......................................... 8

6.5.1 Live Tab ............................................ 10

6.5.2 Video Switch Tab.............................. 11

6.5.3 EDID Setting Tab.............................. 13

6.5.4 Record Setting Tab........................... 15

6.5.5 Time Setting Tab............................... 18

6.5.6 Trigger Setting Tab ........................... 20

6.5.7 User Cong Tab................................ 21

6.5.8 System Setting Tab .......................... 21

6.6 Telnet Control ............................................ 23

6.7 Serial and Telnet Commands .................... 24

7. Connection Diagram ..................................... 39

8. Specications ................................................ 40

8.1 Technical Specications ............................ 40

8.2 Video Specications .................................. 41

8.2.1 Video Inputs ..................................... 41

8.2.2 Video Outputs................................... 43

8.3 Audio Specications .................................. 45

8.3.1 Digital Audio ..................................... 45

8.3.2 Analog Audio .................................... 45

8.4 Cable Specications.................................. 46

8.5 HDBaseT Features.................................... 47

9. Acronyms ....................................................... 48

1. INTRODUCTION

This Video Streaming Transmitter with Recording makes online broadcasting

of live video, with a locally stored archive, an easy and simple process.

Video sources from cameras, PCs, video game consoles, etc. are a breeze

to connect for immediate broadcast and recording. Video content up to 4K

UHD (4K@60Hz, 4:2:0, 8-bit) is supported and is automatically scaled to

a resolution that is more appropriate for e󰀩cient streaming. In addition to

the standard HDMI input, DisplayPort, USB-C and VGA (with paired audio)

inputs are also supported as sources. Along with the streaming and recording

functionality, an HDBaseT output is provided for local, or long distance (up to

70m at 1080p when using Cat.6A), monitoring of the selected input source

when connected to a compatible receiver.

All video content is encoded and streamed with minimal latency and high

quality making it ideal for live streaming events to a variety of popular online

streaming services or within the local network. The video may also be

recorded locally (via USB thumb drive) or to a local network drive while it is

being streamed.

A trigger input interface is also provided to allow the easy addition of a

remote control keypad, or other trigger-supporting products, which can be

installed within a podium or within a table in a conference room or classroom.

This interface can allow the user to activate functions with the simple press

of a button.

Comprehensive EDID management provides improved compatibility with

di󰀨erent sink devices. The intuitive WebGUI provides easy control of your

live event stream including source selection, resolution, bitrate and more.

This unit can be controlled and congured via front panel buttons, an intuitive

WebGUI, Triggers, RS-232, or Telnet.

2. APPLICATIONS

• Webcasting

• Social Media Broadcasting

• Live Event Streaming

• Video on Demand Streaming

• Live recording and storage

3. PACKAGE CONTENTS

• 1× 4×1 Multi-input to HDBT Live Video Streaming Transmitter with

Recording

• 1× 24V/3.75A DC Power Adapter

• 1× AC Power Cord

• 2× 5-pin Terminal Block

• 2× 4-pin Terminal Block

• 1× IR Blaster Cable

• 1× IR Extender Cable

• 1× Operation Manual

4. SYSTEM REQUIREMENTS

• HDMI, VGA, DisplayPort or USB-C source equipment such as a media

player, video game console, PC, or video camera.

• Available streaming server destination such as YouTube or Facebook or a

recording storage target such as USB thumb drive or NAS.

• A compatible HDBaseT receiver with PoH(PD) support is recommended.

• The use of Premium High Speed HDMI cables, and industry standard

Cat.6, Cat.6A or Cat.7, is highly recommended.

• Video streaming preview support within the WebGUI requires the use

of the Chrome, Internet Explorer or Safari browser with the appropriate

plugins (VLC for IE and Safari or VXG Player for Chrome) installed.

Note: The Firefox browser does not currently support the WebGUI’s video

streaming preview window.

• To view RTSP streams directly on the local network, RTSP stream

compatible video player software (such as VLC Media Player or PotPlayer)

must be used.

5. FEATURES

• 4 inputs (HDMI, DisplayPort, USB-C, and VGA)

• 1 HDBaseT output

• Digital inputs are HDCP 1.x and HDCP 2.2 compliant

Note: HDCP encrypted sources cannot be streamed over the Internet or

recorded and will be blacked out

• HDMI, DisplayPort, and USB-C inputs support resolutions up to 4K UHD

(4K@60Hz, 4:2:0, 8-bit)

• VGA input supports resolutions up to 1080p@60Hz and is paired with an

analog stereo audio input

• HDBaseT output supports resolutions up to 4K UHD (4K@60Hz, 4:2:0,

8-bit)

• Advanced H.264 video streaming and recording is provided at QVGA

(320×240), VGA (640×480), 720p, or 1080p at up to 60fps

• Recorded video can be stored on a locally inserted USB thumb drive, or to

a designated network drive

• Can act as a streaming server (using RTP/RTSP protocols) or streaming

client (using the RTMP protocol)

• Trigger Control Keypad support for easy, single-button, function activation

(Optional)

• Supports scheduled recording with an internet updated calendar

• Supports text overlays over live broadcasts

• Integrated downscaling function will convert UHD video content (up to

4K@60Hz) down to 1080p or lower for live video broadcast and recording

• Generates 4 simultaneous streams from the same video source

(1080p@60fps, 1080p@30fps, VGA@30fps, QVGA@30fps) for easy

system integration at multiple bandwidth targets

• Supports automatic input switching

• Advanced EDID management including Internal , External & User

congured EDID selections

• Control via front panel buttons, WebGUI, Triggers, Telnet, and RS-232

6. OPERATION CONTROLS AND FUNCTIONS

6.1 Front Panel

SERV. START

RECORD

STOP SOURCE AUDIODP

USB-C

HDMI VGA

PWR.

INPUT

87654321

1PWR. LED: This LED will illuminate to indicate the unit is on and

receiving power.

2SERV. Port: Attach a standard USB thumb drive or external hard drive

for storage of recorded video. (Optional)

 Note:StoragemediamustbeformattedasFAT32orexFAT.Videoles

are stored in *.mp4 format.

3RECORD LED: This LED will blink while video recording is active.

RECORD START Button: Press this button to immediately start

recording to the designated recording target.

RECORD STOP Button: Press this button to immediately stop any

current recording session.

RECORD SOURCE Button: Press this button to sequentially switch

through the available inputs.

Note: Changing the input source will cause the video stream to restart.

Connected stream targets may need to be restarted or reconnected.

4DP INPUT Port & LED: Connect to DisplayPort source equipment such

as a PC or laptop. The LED will illuminate amber when a source is

detected and green when the source is selected.

5USB-C INPUT Port & LED: Connect to USB Type-C video source

equipment such as a PC or laptop. The LED will illuminate amber when a

source is detected and green when the source is selected.

Note: Not all devices with USB Type-C ports can support video output.

Please verify that the device supports video output from the USB Type-C

port before connecting it.

6HDMI INPUT Port & LED: Connect to HDMI source equipment such as

a media player, game console, or set-top box. The LED will illuminate

amber when a source is detected and green when the source is selected.

Table des matières

Autres manuels CYP Émetteur

CYP

CYP CH-2527TX Manuel utilisateur

CYP

CYP AVX-101F-TX Manuel utilisateur

CYP

CYP COH-RX2 Manuel d'installation

CYP

CYP PUV-1730PLTX-AVLC Manuel utilisateur

CYP

CYP PUV-1510RXWP Manuel utilisateur

CYP

CYP CH-1602RX Manuel utilisateur

CYP

CYP CH-1605TXV Manuel utilisateur

CYP

CYP Dante AU-DTI4-TX Manuel utilisateur

CYP

CYP PUV-1620S-TX Manuel utilisateur

CYP

CYP CH-331H-TX Manuel utilisateur

CYP

CYP PUV-1710LTX-AVLC Manuel utilisateur

CYP

CYP CH-1106TX & RX Manuel utilisateur

CYP

CYP PUV-1830TX-AVLC Manuel utilisateur

CYP

CYP PUV-1630TXWP-EU Manuel utilisateur

CYP

CYP CH-1103TX Manuel utilisateur

CYP

CYP CSI-8H8CV2IR Manuel utilisateur

CYP

CYP PUV-1510TX Manuel utilisateur

CYP

CYP CH-1107 TX Manuel utilisateur

CYP

CYP CH-2606TX Manuel utilisateur

CYP

CYP CH-103TX Manuel utilisateur

CYP

CYP PU-607BD-TX Manuel utilisateur

CYP

CYP PU-103 Manuel utilisateur

CYP

CYP CH-1529TXPLV Manuel utilisateur

CYP

CYP PU-305BD-TX Manuel utilisateur

Manuels Émetteur populaires d'autres marques

NIVELCO

NIVELCO EasyTREK SCA-300 Series Manuel du propriétaire

Honeywell

Honeywell 5816WMBR Manuel utilisateur

Kamstrup

Kamstrup READy MTU Mode d'emploi

Omega

Omega ZW Series Manuel utilisateur

ABB

ABB Field 264H Mode d’emploi

Alinco

Alinco DJ-V17T Manuel utilisateur

Dejero

Dejero EnGo 3x Manuel utilisateur

Rosemount

Rosemount 4600 Manuel utilisateur

Speaka Professional

Speaka Professional 2342740 Manuel utilisateur

trubomat

trubomat GAB 1000 Manuel utilisateur

Teledyne Analytical Instruments

Teledyne Analytical Instruments LXT-380 Manuel utilisateur

Rondish

Rondish UT-11 Manuel utilisateur

MG 10JRE Manuel utilisateur

Burkert

Burkert 8177 Manuel utilisateur

Firetide

Firetide HotPort 3203 Manuel

Tele Radio

Tele Radio T9-02 Manuel utilisateur

Rotronic

Rotronic HygroFlex HF3 Series Manuel utilisateur

Jamara

Jamara FCX6 Pro Tel Manuel utilisateur
