CYP CH-1106TX & RX Manuel utilisateur

CH-1106TX & RXN

HDMI over CAT5e/6 Transmitter and Receiver Set

with IR Source Control

Operation Manual

DISCLAIMERS

The information in this manual has been carefully checked and

is believed to be accurate. Cypress Technology assumes no

responsibility for any infringements of patents or other rights of third

parties which may result from its use.

Cypress Technology assumes no responsibility for any inaccuracies

that may be contained in this document. Cypress also makes no

commitment to update or to keep current the information contained

in this document.

Cypress Technology reserves the right to make improvements to this

document and/or product at any time and without notice.

No part of this document may be reproduced, transmitted,

transcribed, stored in a retrieval system, or any of its part translated

into any language or computer le, in any form or by any means—

electronic, mechanical, magnetic, optical, chemical, manual, or

otherwise—without express written permission and consent from

Cypress Technology.

Version 1.1 August 2011

TRADEMARK ACKNOWLEDGMENTS

All products or service names mentioned in this document may be

trademarks of the companies with which they are associated.

SAFETY PRECAUTIONS

Please read all instructions before attempting to unpack, install or

operate this equipment and before connecting the power supply.

Please keep the following in mind as you unpack and install this

equipment:

• Always follow basic safety precautions to reduce the risk of re,

electrical shock and injury to persons.

• To prevent re or shock hazard, do not expose the unit to rain,

moisture or install this product near water.

• Never spill liquid of any kind on or into this product.

• Never push an object of any kind into this product through any

openings or empty slots in the unit, as you may damage parts

inside the unit.

• Do not attach the power supply cabling to building surfaces.

• Use only the supplied power supply unit (PSU). Do not use the PSU

if it is damaged.

• Do not allow anything to rest on the power cabling or allow any

weight to be placed upon it or any person walk on it.

• To protect the unit from overheating, do not block any vents or

openings in the unit housing that provide ventilation and allow for

sufcient space for air to circulate around the unit.

REVISION HISTORY

VERSION NO. DATE DD/MM/YY SUMMARY OF CHANGE

VR0 29/09/11 Preliminary Release

VS1 19/04/13 Updated format/diagrams

CONTENTS

1. Introduction................................................ 1

2. Applications............................................... 1

3. Package Contents .................................... 1

4. System Requirements................................ 1

5. Features...................................................... 2

6. Operation Controls and Functions........... 3

6.1 Transmitter Front and Rear Panels ...... 3

6.2 Receiver Front and Rear Panels.......... 4

6.3 IR Cable Pin Assignment ...................... 5

6.4 RJ-45 Pin Denition................................ 5

7. Connection Diagrams............................... 6

7.1 Typical Connection Example .............. 6

7.2 Input Connection Examples ................ 7

7.3 Output Connection Examples............. 8

8. Specications ............................................ 9

8.1 Technical Specications ...................... 9

8.2 Compatible Products ......................... 10

9. Acronyms ................................................. 10

1. INTRODUCTION

This HDMI over CAT5e/6 Transmitter and Receiver Set with IR Source

Control can extend HDMI signals over dual CAT5e/6 cabling up to

45m. It has the added benet of allowing the control of a source

device with your existing Remote Control with the included IR Extender

and Blaster cables.

2. APPLICATIONS

• Showroom Display and Control

• Home Entertainment systems

• Commercial/Retail Installations

• Commercial Display

• University Lecture Hall display

3. PACKAGE CONTENTS

• 1×HDMI over CAT5e/6 Transmitter with IR Source Control

• 1×HDMI over CAT5e/6 Receiver with IR Source Control

• 1×IR Extender Cable

• 1×IR Blaster Cable

• 2×5 V/1 A DC Power Supply Adaptor

• Operation Manual

4. SYSTEM REQUIREMENTS

HDMI source device such as a DVD/Blu-ray player and HDMI equipped

display (TV or monitor), dual CAT5e/6 cables and the source device's

remote control.

5. FEATURES

• HDMI, HDCP 1.1 and DVI 1.0 compliant

• Supports high denition digital video and lossless, compressed

digital audio (Dolby TrueHD, Dolby Digital Plus and DTS-HD Master

Audio)

• Supports dual CAT5e/6 cables for Video/Audio and data/DDC

transmission

• Equalizes and recovers incoming TMDS data before re-transmitting it

in optimum quality

• Supports CEC bypass and x.v.YCC

• Includes an IR Extender and Blaster

• Supports a wide range of IR frequencies, from 30 kHz to 50 kHz

• Supports transmission of 1080p@8-bit resolution signals up to 45

meters over dual CAT5e/6 cables

• Supports HDMI input cable length of up to 6 meters and output

cable length of 10 meters at 1080p@8-bit resolution

• Supports connection to a repeater or another transmitter and

receiver set to extend the HDMI signal

Note:

1. This system was tested with CAT-6/23AWG solid core cables, results

may vary with cables of a different specication.

2. Cable distance tested with the following devices: PS3 40G, 37"

Philips 8 bit LCD TV

3. Figures provided in this manual are for reference only, actual

performance may vary depending on the source and display

devices as well as the type of cable being used.

6. OPERATION CONTROLS AND FUNCTIONS

6.1 Transmitter Front and Rear Panels

DDC VIDEO

CAT6 OUTPUT

POWER 5V

HDMI INPUT

Transmitter

RearFront

1 2 3 4 5

1IR TRANSMITTER

Connect to the supplied IR blaster cable for IR signal transmission.

Place the IR blaster in direct line of sight of the equipment to be

controlled.

2HDMI INPUT

Connect to an HDMI source such as a DVD or Blu-ray player.

3POWER 5V

Connect the 5 V DC power supply to the unit and plug the adaptor

into an AC outlet.

4DDC OUTPUT

Connect the DDC output of the transmitter to the DDC input of the

receiver using a CAT5e/6 cable.

5VIDEO OUTPUT

Connect the video output of the transmitter to the video input of

the receiver using a CAT5e/6 cable.

6.2 Receiver Front and Rear Panels

VIDEO DDC

CAT6 INPUT

POWER 5V IR

Receiver

HDMI OUTPUT

RearFront

1 2 3 4 5

1VIDEO INPUT

Connect the video output of the transmitter to the video input of

the receiver using a CAT5e/6 cable.

2DDC INPUT

Connect the DDC output of the transmitter to the DDC input of the

receiver using a CAT5e/6 cable.

3POWER 5V

Plug the 5 V DC power supply into the unit and connect the

adaptor to an AC outlet.

4HDMI OUTPUT

Connect the HDMI output to the HDMI or DVI input (with a HDMI to

DVI adaptor) of a display such as an HDTV or HD monitor.

5IR RECEIVER

Connect to the supplied IR extender cable for IR signal reception.

Ensure that remote control being used is within the direct line-of-

sight of the IR extender.

6.3 IR Cable Pin Assignment

Power 5 V

IR Blaster Signal

IR Signal

Power 5 V

Ground

IR Extender

IR Blaster

6.4 RJ-45 Pin Denition

PIN VIDEO DDC

1 TMDS2+ SCL

2 TMDS2- N/A

3 TMDS1+ SDA

4 TMDS1- Power 5V

5 TMDS0+ GND

6 TMDS0- IR

7 TMDSC+ HPD

8 TMDSC- CEC
