Panasonic KX-TDA0187 Manuel utilisateur

ORDERNO. KMS0308824C1

F19

T-1 Trunk Card

KX-TDA0187

(for U.S.A.)

Unauthorized copying and distribution isaviolation of law.

IMPORTANT INFORMATION ABOUT LEAD FREE, (PbF),

SOLDERING

If leadfree solderwas usedinthe manufacture of this product the printedcircuit boards will be

markedPbF, Standardladed, (Pb), soldercanbe usedas usual on boards without the PbF mark.

Whenthis mark does appearplease readand followthe special instructions describedinthis

manual on the use of PbF and howit might be permissible touse Pbsolderduring service and

repairwork.

1. ABOUT LEAD FREE SOLDER (PbF: Pb Free)

Note:

Inthe information below, Pb, the symbol forleadinthe periodic table of elements, will referto

standardsolderorsolderthat contains lead.

We will use PbF solderwhendiscussing the leadfree solderusedinourmanufacturing process

whichis made fromTin, (Sn), Silver, (Ag), and Copper, (Cu).

This model, and others like it, manufacturedusing leadfree solderwill have PbF stampedon

the PCB. Forservice and repairwork we suggest using the same type of solderalthough, with

some precautions, standardPbsoldercanalsobe used.

Caution

-PbF solder has amelting point that is50° ~ 70° F, (30° ~ 40°C)

higher than Pb solder. Please use asoldering iron with

temperature control and adjust itto 700° ± 20° F, (370° ± 10°C). In

case of using high temperature soldering iron, please be careful

not to heat too long.

-PbF solder will tend to splash ifitisheated much higher than its

melting point, approximately1100°F, (600°C).

-Ifyou must use Pb solder on aPCB manufactured using PbF

solder, remove as much of the original PbF solder as possibleand

be sure that anyremaining ismelted prior to applying the Pb

solder.

-When applying PbF solder to doublelayered boards, please check

the component side for excess which mayflow onto the opposite

side (See figure, below).

1.1. SUGGESTEDPBFSOLDER

There are several types of PbF solderavailable commercially. While this product is

manufacturedusing Tin, Silver, and Copper,(Sn+Ag+Cu), you canalsouse Tinand Copper, (Sn+

Cu), orTin, Zinc, and Bismuth, (Sn+Zn+Bi). Please check the manufacturer’s specific

instructions forthe melting points of theirproducts and anyprecautions forusing theirproduct

withothermaterials. The following leadfree (PbF) solderwire gauge are recommendedfor

service of this product: 0.3mm, 0.6mm and 1.0mm.

1.2. HOWTO RECOGNIZE THATPb FREE SOLDERISUSED

2. FOR SERVICE TECHNICIANS

ICs and LSIs are vulnerable tostatic electricity.

Whenrepairing, the following precautions will helpprevent recurring malfunctions.

1. Cover the plasticpart's boxes with aluminum foil.

2. Ground the soldering irons.

3. Use aconductive mat on the worktable.

4. Donot touch the ICor LSI pins with bare fingers.

3. SPECIFICATIONS

4. NAMES AND LOCATIONS

Overview

Inside View

Note:

*Null slot is not available foranyoptional service cards.

4.1. INSTALLING/REMOVING THEOPTIONALSERVICECARDS

Slot Condition

CardType Slot Type

KX-TDA100:Free Slots 1 to5

KX-TDA200:Free Slots 1 to10 Option Slot MPR Slot

MPR Card No No Yes

CO Line Cards Yes No No

Extension Cards Yes No No

OPB3 Card Yes Yes No

CTI-LINK Card Yes Yes No

Caution:

To protect the back boardfromstatic electricity, do not touchparts on the back boardinthe

mainunit and on the optional service cards. To discharge static, touchground orwearan

earthing strap.

Function

1-port T1 CO line card. EIA/TIA standardcompliant.

Accessoryand User-suppliedItems

Accessory(included): ferrite core x 1

User-supplied(not included): RJ45 connector

Notes

-Connect thisoptional service card to the CO line through NT1; do

not connect to the CO line directly.

-T1 Card must be installed behind an FCC registered and ULor CSA-

NRTL listed CSU.

-When connecting the RJ45 connector, attach the included ferrite

core. Refer to "Attaching aFerrite Core to the RJ45 Cable".

-To confirm the CO line connection, refer to "Confirming the CO

Line Connection" in"Starting the HybridIP-PBX".

CAUTION

T1 ports are SELV ports and shouldonlybe connected to SELV

services.

SwitchSettings

Switch Type Usage and Status Definition

A/B Slide Keepthe switchat default A position.

Donot change the position of this switch.

PinAssignments

RJ45 Connector

No. Signal Name Level [V] Function

1RX+ (+) Receive data (+)

2 RX- (-) Receive data (-)

3 Reserved - -

4TX- (-) Transmit data (-)

5TX+ (+) Transmit data (+)

6-8 Reserved - -

LED Indications

Indication Color Description

CARD STATUS Green/Red OFF: PowerOff

GreenON: Normal (all ports are idle)

GreenFlash(60 times perminute): Normal (a port is inuse)

RedON: Fault (includes reset)

RedFlash(60 times perminute): Out of Service

SYNC-ERR Red OFF: Normal

ON: Alarm

RAI Red OFF: Normal

ON: Alarm (Clock Slave)

Flash(60 times perminute): Alarm (Clock Master)

AIS Red OFF: Normal

ON: Alarm

SYNC Green OFF: Alarm

ON: Normal

Flash(60 times perminute): Normal (Clock Master)

Starting the HybridIP-PBX

CAUTION

-SDMemoryCard must be inserted inthe SDMemoryCard slot of

the MPRcard before start up.

-Before touching the System Clear Switch and the Reset Button,

discharge staticbytouching ground or wearing agrounding strap.

-Once you have started the HybridIP-PBXand ifyou unplug the

HybridIP-PBX, do not perform the following procedures to start

the HybridIP-PBXagain. Otherwise, your programmed data is

cleared. To restart the HybridIP-PBX, refer to "Using the Reset

Button".

-The HybridIP-PBXwill continue to be powered even ifthe power

switch isturned "OFF".

-The power supplycord isused as the maindisconnect device,

ensure that the socket-outlet islocated/installed near the

equipment and iseasilyaccessible.

1. Set the System Clear Switch to the "SYSTEM INITIALIZE" position.

2. Plug the AC power cord into the HybridIP-PBXand an AC outlet,

and turn on the HybridIP-PBX.

Note:

For safetyreasons, do not stretch, bend, or pinch the AC power

cord.

3. Press the Reset Button with apointed tool. (The RUN indicator

will flash.)

4. Whilethe RUN indicator isflashing (withinabout 10 s), return the

System Clear Switch to the "NORMAL" position. Depending on

the configuration, initialization takes about 1minto 3min. If

successfullyexecuted, the RUN indicator will stop flashing and be

kept lit.

All data will be clearedand the HybridIP-PBX will be initializedtothe default values. The DPTs

shouldshowthe time as 00:00.

Note:

Use the AC power cord attached to the PSUonly.

LED Indications

Indication Color Description

RUN Green OFF: PowerOff (includes normal reset)

ON: PowerOnand running (on-line)

Flash(60 times perminute): PowerOnand starting

Flash(120 times perminute): PowerOnand resetting before system

clear

ALARM Red OFF: Normal

ON: Alarm (CPU stop, alarm foreachcard)

Flash: Alarm (MPR file errorinrestarting)

Confirming the CO Line Connection

Afterinitialization, programthe HybridIP-PBX and establishCO line connection, and thenuse a

PTtoconfirm it.

To confirm, dial [ ] [3] [7] + CO line number(3 digits) orpress S-CO button (CO01 toCO64).

You will heara dial tone if CO line is available and connected.

Using the Reset Button

If the HybridIP-PBX does not operate properly, use the Reset Button. Before using the Reset

Button, trythe systemfeature againtoconfirm whetherthere definitelyis a problemornot.

Note:

1. When the System Clear Switch isset to "NORMAL", pressing the

Reset Button causes the following:

-Camp-on iscleared.

-Callson holdare terminated.

-Callson exclusive holdare terminated.

-Callsinprogress are terminated.

-Call park iscleared.

Other data stored inmemory, except the above, are not cleared.

2. When the System Clear Switch isset to the "SYSTEM INITIALIZE"

position, you must press the Reset Button with caution, because

all data stored inmemorywill be cleared bythe following

operation: (1) pressing the Reset Button and then, (2) setting the

System Clear Switch to the "NORMAL" position whilethe RUN

indicator isflashing (withinapproximately10 s).
