Ruijie RG-S6510-32CQ Switch

Hardware Installation and Reference Guide

DocumentVersion:V1.0

Date: 2022.06.09

All rights are reservedin this documentandthis statement.

Any reproduction,excerption,backup,modification,transmission,translationorcommercial useofthis document

orany portionofthis document,in anyform orby anymeans,withoutthepriorwrittenconsentofRuijieNetworks

is prohibited.

Trademark and are ownedby RuijieNetworks.

All othertrademarks orregisteredtrademarksmentioned inthisdocumentareowned bytheirrespectiveowners.

Disclaimer

The products,services,orfeatures you purchasearesubjecttocommercialcontracts andterms. Some orallof

the products,services or features describedin this documentmaynot be withinthe scopeof your purchaseor

use.Unless otherwiseagreedin thecontract,RuijieNetworks does notmakeanyexpress or implied statement

or guarantee for the content of this document.

Due to product version upgrades or other reasons, the content of this document will be updated from time to

time.RuijieNetworks reserves therightto modifythe content of the documentwithoutanynotice or prompt.

This manual is for referenceonly. Ruijie Networks endeavors to ensurecontent accuracyand will not shoulder

any responsibilityfor lossesand damagescausedduetocontent omissions,inaccuracies orerrors.

Preface

IntendedAudience

This documentis intendedfor:

Networkengineers

Technicalsupportand servicing engineers

Networkadministrators

Technical Support

Ruijie Networks Website:https://www.ruijienetworks.com/

TechnicalSupportWebsite:https://ruijienetworks.com/support

CasePortal:https://caseportal.ruijienetworks.com

Community:https://community.ruijienetworks.com

TechnicalSupportEmail:service_rj@ruijienetworks.com

Skype: service_rj@ruijienetworks.com

Conventions

1. Conversions

Convention

Description

Bold font

Commands,commandoptions,andkeywords arein bold font.

Italicfont

Arguments for which you supplyvalues are in italicfont.

[ ]

Elements in square brackets are optional.

{ x | y | z }

Alternative keywords are groupedin braces and separatedby

vertical bars.

[ x | y | z ]

Optional alternative keywords are groupedin brackets and

separatedbyvertical bars.

&<1-n>

The argumentbeforethesign(&) can be inputfor consecutive 1- n

times.

Double slashes atthe beginningofa lineof code indicate a

commentline.

2. Signs

The signs usedin this documentaredescribedas follows:

Warning

An alert that calls attention to importantrules and information thatif not understood orfollowed can resultin

data loss orequipmentdamage.

Caution

An alert that calls attention to essential information thatifnot understood orfollowed can resultin function

failure or performancedegradation.

Note

An alert that contains additional orsupplementaryinformation thatifnot understood orfollowed will notleadto

serious consequences.

Specification

An alert that contains a description ofproductor version support.

3. Note

The manual offers configuration information (including model, port type and command line interface) for

indicative purposeonly.Incaseofany discrepancyorinconsistencybetween themanualand theactualversion,

the actual versionprevails.

Hardware Installation and Reference Guide Product Overview

- 4 -

1 Product Overview

RG-S6510-32CQis a high density 50GE/100GE data center access switch, featuring 25GE/50GE/100GE access, low

latency, and complete data center features. The RG-S6510-32CQswitch provides up to 32 100GE ports and each port

can be splitintotwo 50GEports. TheRG-S6510-32CQswitchcanbe usedwithRG-N18000-X/RG-S6920-4Ctocompose

a high-performance andhigh-reliabilitydatacenter network.

Model

50GE/100GE

QSFP28

Ethernet Port

25GE/10GE

SFP28

Ethernet Port

10GBase-T

Ethernet

Port

Expansion

Module Slot

Fan

Redundancy

Power Supply

Redundancy

RG-

S6510-

32CQ

N/A

4+1

1+1

An SFP28 port is compliantwith25G/10Gbase-Rbutnotcompliantwith 1000base-X.

A QSFP28 port supports both100GE/40GEmodeand 2x 50GE/ 4 x 25GE/4 x 10GE mode.

Specifications

Model

RG-S6510-32CQ

CPU

Intel Xeon D-1527

SDRAM

Two DDR4SODIMM (Maximum:32 GB; Standard: 8 GB)

BIOS

16MB, supportingBIOSbackup

System Storage

≥240GB

BMC

AST2520

Switch ASIC

Broadcom BCM56870(Trident3)

Expansion

Module Slot

Unsupported

Fan Slot

5 (4+1 redundancy.At leastfour fan modules are required.)

Fan Module

M1HFAN I-F

Power Supply

Slot

2 (1+1 redundancy)

Power Module

RG-PA550I-F

Power Supply

Input

AC input

Rated voltage range: 100 V AC to 240 VAC

Maximum voltage range: 90 V AC to 264V AC

Frequency: 50 Hz to 60 Hz

Rated current: 3.5 Ato 7.2A

HVDC input

Rated voltage range: 192V DCto 288V DC

Rated current: 3.6 A

Power

Consumption

Less than450W

SFP28 Port

Unsupported

QSFP28 Port

Supported

FC Port

Unsupported

Hardware Installation and Reference Guide Product Overview

- 5 -

10GBASE-T Port

Unsupported

Temperature

Alarming

Temperature alarming andover-temperatureprotection.

EMC Standards

GB9254-2008CLASS A

Safety Standards

GB4943-2011

Working

Temperature

0°Cto 40°C (32°F to 104°F)

Storage

Temperature

-40°C to +70°C(-40°F to +158°F)

Working Humidity

10% to 90% RH (non-condensing)

Net Weight

12 kg (26.46lbs.,with 5 fan modules and 2powermodules)

Dimensions

(W x D x H)

442mmx 560mmx 44 mm(17.40 in. x 22.05 in. x 1.73 in.), 1 RU

RG-S6510-32CQswitchis a class A product. Operation of this equipmentin a residentialenvironmentcouldcause

radio interference,in which casethe usermaybe requiredto take adequatemeasures.

The 50GE/100GE Ethernetport of the RG-S6510-32CQswitchsupportsDAC.For details,see Appendix.

Product Appearance

RG-S6510-32CQhardware includesa chassis,apowersupplysystem and a heatdissipation system.

Power supplysystem:Provides two power supplyslots,supporting1+1powersupplyredundancy. You are advised

to configure powersupplyredundancy.

Heatdissipationsystem:Providesfive fanmodule slots,supporting4+1 fan redundancy.You are advised to configure

all fans to implementredundancy.

Figure1-1 RG-S6510-32CQSwitchAppearance

Front Panel

Hardware Installation and Reference Guide Product Overview

- 6 -

Figure 1-2 Front Panel

1. USB 2.0 Port

2. Console Port

3. ManagementPort

4. QSFP+ Port LED

5. QSFP+ Port

6. System Status LED

7. PowerStatus LED

8. Fan Status LED

9. AssetTag

The S6510-32CQswitchsupports the100GEQSFP28 module.

Back Panel

Figure1-3 Back Panel

1. PowerModule Slot

2. Fan Module Slot

3. Grounding Stud

4. Anti-Static Wrist Strap Jack

Asset Tag

The assettag is inthe bottom rightcornerof the back panel.The tag is movable and can be removed from the switch.You

can markthe informationsuch as assetname,category, code,and registrationdateonthe tag for inventory control.

Figure1-4 AssetTag

Hardware Installation and Reference Guide Product Overview

- 7 -

Ports

The RG-S6510-32CQswitchprovides thefollowingports:

Universal serial bus (USB)port:This port is connectedwitha USB flashdrive to save logs,software version,alarm

and other diagnosismessages.

To protect dataand avoid equipmentdamage,use aqualifiedUSBflashdrive.The USB portis compatible withmost

USB flashdrives and mayfail to identify somebrands.

The RG-S6510-32CQ switch supports commissioning, configuration, maintenance, management and program

uploadingthrough theconsoleport.

Console port:The console portis anRS-232 port that uses an RJ45 connector.This port is used to connecta PC

directly to the switch for commissioning,configuration,maintenance,managementand program loading.

MGMT port: This is an out-bandEthernet port that uses anRJ45connector.This port is connectedto an Ethernet

port of a PC for program downloading.You can manageand maintain the switchremotely byconnecting the

managementportto the Ethernet port of a PC with an Ethernet cable.

QSFP28 port: There are 32 100GE QSFP28 ports,which supportoptical transceivers and DAC cables.Theseports

can alsoworkin 2 x 50GE and4 x 25GE mode.

LED

LED on the Panel

LED

Panel Identification

Status

Meaning

System Status LED

SYS

Off

System is not powered on.

Blinking Green

System is beinginitialized.

Solid Green

System is operatingnormally.

Solid Yellow

System is not functioning properly.

PowerStatus LED

PSU

Solid Green

The power module is operating

normally.

Solid Yellow

The powermodule is notfunctioning

properly.

Fan Status LED

FAN

Solid Green

The fan module is operating

normally.

Solid Yellow

The fan module is not functioning

properly.

LED on the Fan Module

LED

Panel Identification

Status

Meaning

Fan Status LED

Status

Off

The fan moduleis notpoweredon.

Solid Green

The fan module is operating

normally.

Solid Yellow

The fan module is not functioning

properly.

LED on the AC Power Module

LED

Panel Identification

Status

Meaning

Hardware Installation and Reference Guide Product Overview

- 8 -

PowerStatus LED

Off

The power module is off.

Solid Green

The power module is operating

normally.

Blinking Green at 1Hz

AC power(PS Off): 12 V SB

The AC power module in cold

backup mode doesnotoutputpower.

Solid Amber

1. An alarm is generated, including

fan fault, over-voltage and over-

current.

2. One of the powermodule inpower

redundancyis not plugged in with a

powercord.

Blinking Amberat 1Hz

An alarm is generated, including

over-temperature, over-current and

over-power, and slow rotation. The

power module is still operating

normally.

Port LED

LED

Panel Identification

Status

Meaning

QSFP+ Port LED

(100GE/40GE)

Link/Act

Off

No linkis detectedfor this port.

Solid Green

The port has madea successful100

Gbps link.

Blinking Green

The port is sending and receiving

data at 100 Gbps.

Solid Yellow

The port has made a successful 40

Gbps link.

Blinking Yellow

The port is sending and receiving

data at 40 Gbps.

100GE Port LED (split

into two 50GE ports)

Link/Act

Off

No linkis detectedfor this port.

Solid Yellow

Onesplitporthas made asuccessful

50 Gbps link.

Blinking Yellow

One split port is sending and

receivingdata at 50 Gbps.

Solid Green

Both split ports have made a

successful 50Gbps link.

Blinking Green

Both split ports are sending and

receivingdata at 50 Gbps.

Management Port LED

LED

Panel Identification

Status

Meaning

ManagementPort LED

Link

Off

No linkis detectedfor this port.

Solid Green

The port has made a successful

1000 Mbps link.

Hardware Installation and Reference Guide Product Overview

- 9 -

Solid Yellow

The port has made a successful

10/100 Mbps link.

Act

Blinking

The port is sending and receiving

data.

Off

The linkis down.

Power Supply

The RG-S6510-32CQswitchsupports powermodule RG-PA550I-F. The smartpowermodule supports power

management.The system canread output power,output current, and temperature in real time. The powermodule

supports hotswapping.

The RG-S6510-32CQswitch supports 1+1 power supplyredundancy. To improve the stabilityand reliabilityof the

entire system,you are advised to configure 1+1 powersupplyredundancy. When both powermodulesare working,

the switchis in the status of current sharing.

At leastone powermodule is required.Ifany slotis unoccupied,install afillerpaneltoenableproperairflow.

Heat Dissipation

The working temperature ofthe RG-S6510-32CQswitchranges from 0°Cto 40°C(32°Fto 104°F). The heatdissipation

design needs toensure equipmentstability,safety andmaintainabilityinsuch anenvironment.The RG-S6510-32CQ

switchadopts fanventilation and enforced convection to ensure the equipmentcanworknormallyin the specified

environment.Dustthe equipmenteverythree months toavoid blocking theventilationopenings.

The RG-S6510-32CQswitchsupports fan module M1HFAN I-F. The fan module features speed regulation,failure

alarming,andhotswapping.

Figure1-5 Airflow Direction

Autres manuels pour RG-S6510-32CQ

Autres manuels Ruijie Changer

Ruijie

Ruijie RG-S6510-4C Series Manuel d'installation et d'exploitation

Ruijie

Ruijie Reyee RG-ES126S-LP V2 Manuel utilisateur

Ruijie

Ruijie RG-N18000-X Series Manuel d'installation et d'exploitation

Ruijie

Ruijie Reyee RG-ES105D Series Manuel d'installation et d'exploitation

Ruijie

Ruijie RG-NBS Series Manuel utilisateur

Ruijie

Ruijie XS-S1960-24GT4SFP-UP-H Series Manuel d'installation et d'exploitation

Ruijie

Ruijie RG-N18000-E Series Manuel d'installation et d'exploitation

Ruijie

Ruijie Reyee RG-NBS5200-48GT4XS-UP Manuel d'installation et d'exploitation

Ruijie

Ruijie RG-EG210G-P Manuel utilisateur

Ruijie

Ruijie RG-S2600E Series Manuel utilisateur

Ruijie

Ruijie RG-CS83-24GT4XS-PD Manuel d'installation et d'exploitation

Ruijie

Ruijie RG-IF2920U-12GT1XS-DC Series Manuel d'installation et d'exploitation

Ruijie

Ruijie RG-S6520 Series Manuel d'installation et d'exploitation

Ruijie

Ruijie RG-S6250-48XS8CQ Series Manuel d'installation et d'exploitation

Ruijie

Ruijie RG-S6580-48CQ8QC Manuel d'installation et d'exploitation

Ruijie

Ruijie RG-CS85 Series Manuel d'installation et d'exploitation

Ruijie

Ruijie RG-S5760C-X Series Manuel d'installation et d'exploitation

Ruijie

Ruijie RG-S2900 Series Manuel utilisateur

Ruijie

Ruijie RG-S8600 Series Manuel utilisateur

Ruijie

Ruijie RG-IF2920U-12GT1XS Series Manuel d'installation et d'exploitation

Ruijie

Ruijie RG-S6580-48CQ8QC Manuel d'installation et d'exploitation

Ruijie

Ruijie RG-SF2920 Series Manuel d'installation et d'exploitation

Ruijie

Ruijie RG-N18000-XH Series Manuel d'installation et d'exploitation

Ruijie

Ruijie XS-S1920 Series Manuel d'installation et d'exploitation

Manuels Changer populaires d'autres marques

URC

URC Total Control MFS-8 Manuel utilisateur

Azbil

Azbil HPQ-D11 Manuel utilisateur

Sony

Sony DFS-900M Manuel utilisateur

SICK

SICK i17S Manuel utilisateur

F&F

F&F SZR-277 Manuel utilisateur

Shure

Shure UAMS/BK Manuel utilisateur

Dräger

Dräger X-zone Switch Off Manuel utilisateur

Asco

Asco Joucomatic 349 Series Manuel utilisateur

BT Mini Hub Manuel utilisateur

D-Link

D-Link DES-1226G Manuel utilisateur

Johnson Controls

Johnson Controls FS80-C Manuel utilisateur

Alcatel-Lucent

Alcatel-Lucent 7450 ESS-12 Manuel utilisateur

MicroNet

MicroNet SP1200A Manuel utilisateur

Altinex

Altinex DA1914SX Manuel utilisateur

MiLAN

MiLAN MIL-SM2401M Manuel utilisateur

RJM

RJM MASTERMIND PBC/6X Manuel utilisateur

Atlas

Atlas MMK-KVM8 Manuel utilisateur

Cabletron Systems

Cabletron Systems GIGAswitch GSR-16 Manuel utilisateur
