PEERLESS PARAMOUNT PT640 and assembly Mode d’emploi

Installation and Assembly:

3215 W. North Ave. • Melrose Park, IL 60160 • (800) 865-2112 or (708) 865-8870 • Fax: (708) 865-2941 • www.peerlessmounts.com

ISSUED: 10-31-07 SHEET #: 202-9242-2 03-20-08

This product is UL Listed. It must be

installed by a qualified professional

installer.

Paramount™ Universal Tilt Wall Mount for 23" to 46"*

LCD Flat Panel Screens

*NOTE: Most 42"and larger plasma screens may

not be compatible with this mount. Use Mount Finder

to confirm compatibility.

Features:

• For 23" to 46"* LCD flat panel screens

• Universal mount fits screens with mounting hole patterns up to 17.5" W x 12.94" H

• Screen held only 2.5" from wall for a discreet installation

• Wide open wall plate design allows for total acces and a wide array of cable management options

• Universal screen mounting brackets hook onto the wall plate for quick, easy and safe installation

• Adjustable up to 15° of forward tilt and up to -5° backward tilt

• One-touch tilt for effortless adjustment

• Pre-tensioned universal tilt bracket allows for tilt angle adjustment in one easy motion.

• Easy locking handle locks the screens position into place without the use of tools

• Optional IncreLok feature offers fixed tilts at -5°, 0°, 5°, 10° and 15° increments

• Includes Sorted-For-You™ fastener packs for installation to wood studs, concrete and cinder block

• Optional horizontal adjustment of up to 6" (depending on screen model) for perfect screen placement

Model: PT640

Maximum UL Load Capacity 150 lb (68 kg)

2 of 24 ISSUED: 10-31-07 SHEET #: 202-9242-2 03-20-08

Visit Peerless website at www.peerlessmounts.com For customer care call 1-800-729-0307 or 708-865-8870

Tools Needed for Assembly

•stud finder ("edge to edge" stud finder is recommended)

•phillips screwdriver

•drill

•1/4" bit for concrete and cinder block wall

•1/2" bit for metal stud wall

•5/32" bit for wood stud wall

•level

Table of Contents

Parts List .............................................................................................................................................................................. 3

Installation to Double Wood Stud Wall .................................................................................................................................. 4

Installation to Solid Concrete or Cinder Block ....................................................................................................................... 5

Installing Tilt Brackets ........................................................................................................................................................... 6

Installing Flat Panel Screen to Wall Plate............................................................................................................................. 8

For customer care call (800) 865-2112 or (708) 865-8870.

Accessories

• ACC415 - Metal Stud Fastener Kit (Metal stud

installation is not evaluated by UL)

•PS200 - Paramount™ A/V Component Shelf

NOTE: Read entire instruction sheet before you start installation and assembly.

• Do not begin to install your Peerless product until you have read and understood the instructions and warnings

contained in this Installation Sheet. If you have any questions regarding any of the instructions or warnings, please

call Peerless customer care at 1-800-865-2112.

• This product should only be installed by someone of good mechanical aptitude, has experience with basic building

construction, and fully understands these instructions.

• Make sure that the supporting surface will safely support the combined load of the equipment and all attached hard-

ware and components.

• Never exceed the Maximum UL Load Capacity. See page one.

• If mounting to wood wall studs, make sure that mounting screws are anchored into the center of the studs. Use of an

"edge to edge" stud finder is highly recommended.

• Always use an assistant or mechanical lifting equipment to safely lift and position equipment.

• Tighten screws firmly, but do not overtighten. Overtightening can damage the items, greatly reducing their holding

power.

• This product was designed and intended to be mounted to the following supporting surfaces checked below with the

hardware included in this product as specified in the installation sheet. To mount this product to an alternative support-

ing surface, contact Peerless customer care at 1 800 865-2112.

• This product was designed to be installed on the following wall construction only;

WALL CONSTRUCTION ADDITIONAL HARDWARE REQUIRED

Wood Stud None

Wood Beam None

Solid Concrete None

Cinder Block None

Metal Stud Do not attach except with Peerless accessory kit for metal studs;

Contact Customer Service for Peerless accessory kit for metal studs.

Brick Contact Customer Service

Other or unsure? Contact Customer Service

WARNING

3 of 24 ISSUED: 10-31-07 SHEET #: 202-9242-2 03-20-08

Visit Peerless website at www.peerlessmounts.com For customer care call 1-800-729-0307 or 708-865-8870

CCAA BB DD EE

M4 x 12 mm (4)

504-9013

M4 x 25 mm (4)

504-1015

M5 x 12 mm (4)

520-1027

M5 x 25 mm (4)

520-9543

M6 x 12 mm (4)

520-1128

M6 x 25 mm (4)

520-1208

M6 x 20 mm (4)

520-9402

M6 x 30 mm (4)

510-9109

Adapter Bracket Fasteners

I.D. .26" (6.5 mm ) (4)

540-1058

I.D. .205" (5.2 mm) (4)

540-1040

Parts may appear slightly different than illustrated.

Qty. Part #

AA wall plate 1 200-P1797

BB 1 201-P1465

CC 1 201-P1467

DD 4 5S1-015-C03

EE 4 590-0097

Parts List

Description

Before you begin, make sure all parts shown are

included with your product.

alligator® anchor

left adapter bracket

right adapter bracket

#14 x 2.5" wood screw

4 of 24 ISSUED: 10-31-07 SHEET #: 202-9242-2 03-20-08

Visit Peerless website at www.peerlessmounts.com For customer care call 1-800-729-0307 or 708-865-8870

Installation to Double Wood Stud Wall

1Wall plate (AA) can be mounted to two studs that are 16" apart. Use a stud finder to locate the edges of the studs.

Use of an edge-to-edge stud finder is highly recommended. Based on their edges, draw a vertical line down each

stud’s center. Place wall plate on wall as a template. The top mounting slots should be 2.5" (65 mm) above the

desired screen center as shown in figure 1.1. Level plate, and mark the center of the four mounting holes. Make sure

that the mounting holes are on the stud centerlines. Drill four 5/32" (4 mm) dia. holes 2-1/2" (65 mm) deep. Make

sure that the wall plate is level, secure it using four #14 x 2.5" wood screws (DD) as shown in figure 1.2.

Skip to step 2.

• Installer must verify that the supporting surface will safely support the combined load of the equipment and all attached

hardware and components.

• Tighten wood screws so that wall plate is firmly attached, but do not overtighten. Overtightening can damage the

screws, greatly reducing their holding power.

• Never tighten in excess of 80 in. • lb (9 N.M.).

• Make sure that mounting screws are anchored into the center of the stud. The use of an "edge to edge" stud finder is

highly recommended.

• Hardware provided is for attachment of mount through standard thickness drywall or plaster into wood studs. Installers

are responsible to provide hardware for other types of mounting situations.

WARNING

fig. 1.1

fig. 1.2

CS = center of screen

STUD

2.5"

(65 mm)

5 of 24 ISSUED: 10-31-07 SHEET #: 202-9242-2 03-20-08

Visit Peerless website at www.peerlessmounts.com For customer care call 1-800-729-0307 or 708-865-8870

Installation to Solid Concrete or Cinder Block

1Make sure that wall plate (AA) is level, use it as a

template to mark four mounting holes. The top

mounting hole should be 2.5" (65 mm) above the

desired screen center as shown in fig. 1.1 on page 4.

Drill four 1/4" (6 mm) dia. holes to a minimum depth of

2.5" (65 mm). Insert anchors (EE) in holes flush with

wall as shown (right). Place wall plate over anchors

and secure with #14 x 2.5" screws (DD). Level, then

tighten all fasteners.

• When installing Peerless wall mounts on cinder block, verify that you have a minimum of 1-3/8" of actual concrete

thickness in the hole to be used for the concrete anchors. Do not drill into mortar joints! Be sure to mount in a solid

part of the block, generally 1" minimum from the side of the block. Cinder block must meet ASTM C-90 specifica-

tions. It is suggested that a standard electric drill on slow setting is used to drill the hole instead of a hammer drill to

avoid breaking out the back of the hole when entering a void or cavity.

• Concrete must be 2000 psi density minimum. Lighter density concrete may not hold concrete anchor.

• Make sure that the supporting surface will safely support the combined load of the equipment and all attached hard-

ware and components.

WARNING

CUTAWAY VIEW

INCORRECT

concrete

surface

Drill holes and insert anchors (EE).

CORRECT

Place plate (AA)over anchors (EE) and secure with screws (DD).

Tighten all fasteners.

wall

plate

plaster/

drywall

concrete wall plate concrete

plaster/

drywall

solid concrete cinder block

• Tighten screws so that wall plate is firmly attached,

but do not overtighten. Overtightening can damage

screws, greatly reducing their holding power.

• Never tighten in excess of 80 in. • lb (9 N.M.).

WARNING

• Always attach concrete anchors directly to load-

bearing concrete.

• Never attach concrete anchors to concrete covered

with plaster, drywall, or other finishing material. If

mounting to concrete surfaces covered with a finishing

surface is unavoidable, the finishing surface must be

counterbored as shown below. Be sure concrete

anchors do not pull away from concrete when tighten-

ing screws. If plaster/drywall is thicker than 5/8",

custom fasteners must be supplied by installer.

WARNING

6 of 24 ISSUED: 10-31-07 SHEET #: 202-9242-2 03-20-08

Visit Peerless website at www.peerlessmounts.com For customer care call 1-800-729-0307 or 708-865-8870

Attaching Tilt Brackets to Screen using Baffled Fastener Pack

To prevent scratching the screen, set a cloth on a flat, level surface that will support the weight of the screen. Place screen

face side down. Refer to screen manufacturers instructions or customer service, for removing any knobs, base, cover, or

screw(s) on the back of the screen to prepare mounting. These need to be removed to allow the adapter brackets to be

attached. Select the small, medium, large or extra large screws from the baffled fastener pack then attach adapter

brackets to screen following figure 2.1 or 2.2.

NOTE: Be sure to attach adapter brackets with handles facing outward as shown below.

NOTE: Top and bottom mounting holes on screen must be used for attaching brackets. Middle holes should also be used

where the fasteners and screens allow. Verify that all holes are properly aligned, and then tighten screws using a phillips

screwdriver.

• Tighten screws so adapter brackets are firmly attached. Do not tighten with excessive force. Overtightening can

cause stress damage to screws, greatly reducing their holding power and possibly causing screw heads to become

detached.

Tighten to 40 in. • lb (4.5 N.M.) maximum torque.

• If screws don't get three complete turns in the screen inserts or if screws bottom out and bracket is still not tightly

secured, damage may occur to screen or product may fail.

WARNING

CENTERBRACKETSVERTICALLYON BACKOF SCREEN

HANDLESFACE

OUT

Note: "X" dimensions should be equal.

NOTE: For flat back screens proceed to step 2-1. For bump-out or recessed back screen skip to step 2-2.

7 of 24 ISSUED: 10-31-07 SHEET #: 202-9242-2 03-20-08

Visit Peerless website at www.peerlessmounts.com For customer care call 1-800-729-0307 or 708-865-8870

Refer to Screen Compatibility Chart to determine the proper fastener to use. Visit www.peerlessmounts.com/1

for a full screen compatibility chart for this mount.

Begin with the shortest length screw, hand thread through washer and adapter bracket into screen as shown below.

Screw must make at least three full turns into the mounting hole and fit snug into place. Do not over tighten. If screw

cannot make three full turns into the screen, select a longer length screw from the baffled fastener pack. Repeat for

remaining mounting holes, level brackets and tighten screws.

NOTE: Spacers may not be used, depending upon the type of screen.

Refer to Screen Compatibility Chart to determine the proper fastener to use. Visit www.peerlessmounts.com/1

for a full screen compatibility chart for this mount.

Begin with longer length screw, hand thread through washer, adapter bracket and spacer in that order into screen as

shown below. Screw must make at least three full turns into the mounting hole and fit snug into place. Do not over

tighten. If screw cannot make three full turns into the screen, select a longer length screw from the baffled fastener

pack. Repeat for remaining mounting holes, level brackets and tighten screws.

For Flat Back Screen

For Bump-out or Recessed Back Screen

SCREEN

WASHER

SCREW

ADAPTER

BRACKET

(BB or CC)

fig. 2.2

SPACER

ADAPTER

BRACKET

(BB or CC)

SCREEN

fig. 2.1

WASHER

SCREW

2-1

2-2

If you have any questions, please call Peerless customer care at 1-800-865-2112.

8 of 24 ISSUED: 10-31-07 SHEET #: 202-9242-2 03-20-08

Visit Peerless website at www.peerlessmounts.com For customer care call 1-800-729-0307 or 708-865-8870

• Always use an assistant or mechanical lifting equipment

to safely lift and position the flat panel screen.

• Do not tighten screws with excessive force. Overtightening

can cause damage to mount.

Tighten screws to 40 in. • lb

(4.5 N.M.) maximum torque.

• Be careful not to pinch fingers when pushing screen from

the bottom.

For preset tilt angles use Increlok™ and for

custom tilt angle use ratchet handle.

INCRELOK™:The screen can be locked into a

pre-set tilt position of -5°, 0°, 5°, 10°or 15°. Use

locator hole to find tilt position hole and tilt screen

to align holes. Tighten IncreLok™ tilt locking

screws on both tilt brackets to lock tilt as shown in

detail 2.

Ratchet Handle: Loosen ratchet handle (refer to

step 3 for tension adjustment of handle). Push or

pull from top or bottom of screen to adjust tilt as

shown in fig. 4.1. The tilt can be adjusted to a

maximum of 15° forward or 5° backward.

Tension Adjustment of Ratchet Handle: Adjust

tension in tilt brackets (BB & CC) by rotating

ratchet handle. NOTE: If obstruction prevents

ratchet handle from rotating, pull handle out while

turning will allow handle to reposition without

tightening. Release and turn handle to tighten or

loosen.

Mounting Screen: Ratchet handle must be in the

up or down position or interference will occur while

hooking tilt brackets to wall plate (AA). Slowly hook

tilt brackets (BB & CC) onto wall plate (AA) and

swing screen down as shown in fig. 3.1. Tilt bracket

hooks must fully engage wall plate as shown in

detail 1. Using phillips screw driver, turn safety

screws on tilt brackets (BB & CC) clockwise till

screw tip securely contacts wall plate as shown in

cross section.

Screen Adjustment: Screen can be adjusted

horizontally by loosening safety screws on tilt

brackets (BB & CC) three full turns with phillips

screw driver. Adjust screen as shown in fig. 3.2.

Tighten safety screws on tilt brackets till screw tip

securely contacts wall plate as shown in cross

section.

Removing Screen: To remove screen from mount,

loosen safety screws, swing screen away from

mount, and lift screen off of mount.

All other brand and product names are trademarks or registered trademarks of their respective owners.

Mounting and Removing Flat Panel Screen

DETAIL 2

fig 4.1

IncreLok™

TILT LOCKING

SCREW LOCATOR

HOLE

RATCHET

HANDLE

TILT

POSITION

HOLES

fig 3.2

Adjusting the Tilt Angle of the Flat

Panel Screen

WARNING

fig 3.1

RATCHET

HANDLE

SAFETY

SCREW

DETAIL 1

BB &

CROSS SECTION

BB &

3215 W. North Ave. • Melrose Park, IL 60160 • (800) 865-2112 or (708) 865-8870 • Fax: (708) 865-2941 • www.peerlessmounts.com

ISSUED: 10-31-07 SHEET #: 202-9242-2 03-20-08

Características:

• Para pantallas planas LCD de 23"a 46"*

• El soporte universal sostiene pantallas con configuraciones de montaje de hasta 17.5"W x 12.94" H

• Sostiene el televisor a sólo 2.5"de la pared para proporcionar una instalación discreta

• El diseño totalmente abierto de la placa de pared permite acceso completo a la pared y proporciona una amplia

variedad de opciones para el manejo de cables

• Los soportes universales de montaje para pantallas se enganchan a la placa de pared para proporcionar una

instalación rápida, fácil y segura

• Inclinación ajustable hacia delante de hasta 15° y hacia atrás de hasta -5°

• Inclinación de un solo toque para permitir el ajuste sin esfuerzo

• El soporte inclinable universal preapretado permite ajustar el ángulo de inclinación con un solo movimiento sencillo

• La palanca de fijación fácil fija la posición de la pantalla con seguridad sin la necesidad de usar herramientas

• La función opcional IncreLok™ ofrece ángulos de inclinación predeterminados en incrementos de -5°, 0°, 5°, 10° y

15°

• Incluye paquetes de sujetadores Sorted-For-You™ para instalaciones en montantes de madera, concreto y

bloques de hormigón de escorias

• Ajuste horizontal opcional de hasta 6"(dependiendo del modelo de la pantalla) para la colocación perfecta de la

pantalla

*Nota: Puede que esta montura no funcione con muchas de las

pantallas de plasma de 42" ó más. Utilice el verificador de

monturas (Mount Finder) para confirmar la compatibilidad.

Máxima capacidad de carga UL: 150 lb (68 kg)

Modelos: PT640 Este producto está inscripto en la

Lista UL. Debe ser instalado por

un instalador profesional

cualificado.

Instalación y montaje:

Soporte universal de pared Paramount™ con capacidad

de inclinación para pantallas LCD y pantallas planas de

plasma de 23" a 46"*

Visite el sitio Web de Peerless en www.peerlessmounts.com Para el Servicio al cliente llame al 1-800-729-0307 ó 708-865-8870

10 of 24

Español

ISSUED: 10-31-07 SHEET #: 202-9242-2 03-20-08

• No comience a instalar su producto de Peerless hasta haber leído y entendido las instrucciones y las advertencias

contenidas en la Hoja de Instalación. Si tiene alguna pregunta acerca de cualquiera de las instrucciones o las

advertencias, por favor, llame a Servicio al Cliente de Peerless al 1-800-865-2112.

• Este producto sólo debe ser instalado por una persona que tenga una aptitud mecánica, que tenga experiencia en

construcción básica de edificios y que entienda estas instrucciones en su totalidad.

• Asegúrese de que la superficie de apoyo sostendrá, con seguridad, la carga combinada del equipo y todos los

fijadores y componentes.

• Nunca sobrepase la capacidad máxima de soportar carga aceptada por Underwriters Laboratories. (Vea la página 9).

• Si va a instalar el producto en una pared con montantes de madera, asegúrese de que los tornillos de montaje estén

anclados en el centro de los montantes. Se recomienda utilizar un localizador de montantes de “borde a borde”.

• Siempre cuente con la ayuda de un asistente o utilice un equipo mecánico de izar para levantar y colocar el equipo

con más seguridad.

• Apriete los tornillos con firmeza, pero no en exceso. Apretarlos en exceso puede dañar los artículos y puede

disminuir significativamente su fuerza de fijación.

• Este producto fue diseñado con la intención de que se instale en las superficies de apoyo marcadas abajo con los

accesorios de instalación incluidos en este producto como se especifica en la hoja de instalación. Para instalar este

producto en otra superficie de apoyo, llame a Servicio al Cliente de Peerless al 1-800-865-2112.

• Este producto fue diseñado para ser instalado en paredes con la siguiente construcción solamente:

CONSTRUCCIÓN DE LA PARED ACCESORIOS ADICIONALES NECESARIOS

Montante de madera Ninguno

Viga de madera Ninguno

Concreto macizo Ninguno

Bloque de hormigón de escorias Ninguno

Montante de metal No lo instale excepto con el juego de accesorios de Peerless para

montantes de metal.

Llame a Servicio al Cliente para pedir el juego de accesorios de

Peerless para montantes de metal.

Ladrillo Comuníquese con Servicio al Cliente.

¿Otra superficie o no está seguro? Comuníquese con Servicio al Cliente.

ADVERTENCIA

Herramientas necesarias para el montaje

•localizador de montantes (se recomienda usar el de “borde a borde”)

•destornillador phillips

•taladro

•broca de 1/4" para pared de concreto y de bloques de hormigón de

escorias

•broca de 1/2" para pared con montantes de metal

•broca de 5/32" para pared con montantes de metal o madera

•nivel

Contenido

Lista de piezas ........................................................................................................................................................................................ 11

Instalación en una pared con montantes de madera dobles .............................................................................................................. 12

Instalación en una pared de concreto macizo o de bloques de hormigón de escorias .................................................................... 13

Instalación de los soportes adaptadores ............................................................................................................................................. 14

Instalación de la pantalla plana en la placa de pared .......................................................................................................................... 16

Para atención al cliente, llame al (800) 865-2112 ó (708) 865-8870.

Nota: Lea la hoja de instrucciones completa antes de comenzar la instalación y el ensamblaje.

Accesorios

•Repisa ParamountTM - PCS200 para

componentes de A/V

•Juego de accesorios de piezas para la

fijación en montantes de metal - ACC415

(El montante de metal no ha sido evaluado

por UL)

Autres manuels pour PARAMOUNT PT640 and assembly

Table des matières

Langues :

Autres manuels PEERLESS Support et étagère

PEERLESS

PEERLESS SOLID POINT PLCM 1 Mode d’emploi

PEERLESS

PEERLESS SA761P Mode d’emploi

PEERLESS

PEERLESS Smartmount D-FPF-220 Mode d’emploi

PEERLESS

PEERLESS Vision-Point LCV 100 Mode d’emploi

PEERLESS

PEERLESS SP730P Mode d’emploi

PEERLESS

PEERLESS CMJ 470W Mode d’emploi

PEERLESS

PEERLESS DS495 Mode d’emploi

PEERLESS

PEERLESS Paramount PA760 Mode d’emploi

PEERLESS

PEERLESS IWB600-WB Mode d’emploi

PEERLESS

PEERLESS PWMT300 Manuel utilisateur

PEERLESS

PEERLESS A100IWBMOUNT Mode d’emploi

PEERLESS

PEERLESS SmartMount ST 630P Mode d’emploi

PEERLESS

PEERLESS SlimLine MOWV241/BK Manuel utilisateur

PEERLESS

PEERLESS WSP700 Mode d’emploi

PEERLESS

PEERLESS LWB375 Mode d’emploi

PEERLESS

PEERLESS PARAMOUNT PP740 Manuel utilisateur

PEERLESS

PEERLESS SP850-UNLP-GB Mode d’emploi

PEERLESS

PEERLESS DS 35 Mode d’emploi

PEERLESS

PEERLESS SF630-AB Mode d’emploi

PEERLESS

PEERLESS Paramount PP730 and assembly Mode d’emploi

PEERLESS

PEERLESS DST360 Mode d’emploi

PEERLESS

PEERLESS VPM 25-J Mode d’emploi

PEERLESS

PEERLESS Paramount PS200 Mode d’emploi

PEERLESS

PEERLESS Smartmount SA752PU Mode d’emploi

Manuels Support et étagère populaires d'autres marques

Salamander

Salamander Acadia AC/W/L400/WH Manuel utilisateur

Fohhn

Fohhn VAT-09 Guide de l'utilisateur

ricoo

ricoo FS0522 Manuel utilisateur

AMSOIL

AMSOIL BMK-22 Guide rapide

Kargo Master

Kargo Master 48220 Manuel utilisateur

Milestone AV Technologies

Milestone AV Technologies SIMPLICITY SLF2 Manuel utilisateur

ricoo

ricoo S1222 Manuel utilisateur

Ready-Set-Mount

Ready-Set-Mount RSMCM602 Manuel utilisateur

VidaBox

VidaBox VB MNT FFS2 Manuel utilisateur

Welch Allyn

Welch Allyn 48960 Manuel utilisateur

Arkon

Arkon CM035-ST-2 Manuel utilisateur

PROEL

PROEL PLWIN60C Manuel utilisateur

Agilent Technologies

Agilent Technologies E2609B Manuel utilisateur

Mustang

Mustang MV-ARM4 Manuel utilisateur

Mounting Solutions

Mounting Solutions WRM-320 Manuel utilisateur

Pyle

Pyle PMKSPAD1 Manuel utilisateur

ShelterIt

ShelterIt 21208 Manuel utilisateur

SPL

SPL RackPack?4 1040 Manuel utilisateur
