Installation and Assembly:

LCD Screen Adjustable Wall/Cabinet Mount

Models: SAL730P, SAL730P-S, RTLAL-100, RTLAL-100S, D-LAL-100,

D-LAL-100S

Features:

• Fits 10" - 20" LCD screens

• Pivotsand articulatesin alldirections, evenaround cornersand cabinets

• Frees up space by folding flat against the wall

• Keeps electronic wires routed internally to reduce clutter

2 of 30 ISSUED: 06-10-05 SHEET #: 095-9223-4 08-30-05

Note: Read entire instruction sheet before you start installation and assembly.

Forcustomer care call(800) 729-0307 or(708) 865-8870.

Table of Contents

Parts List.............................................................................................................................................................................. 3

InstallationtoSideof Cabinet ........................................................................................................................................... 4, 5

Installation to Wood Stud Wall ............................................................................................................................................. 6

Installation to Solid Concrete and Cinder Block .................................................................................................................... 7

Tools Needed for Assembly

• studfinder ("edgeto edge"stud finder is recommended)

• phillipsscrewdriver

• drill with 1/4" and 5/32" drill bits

Accessories

• Metal StudAccessory Kit (ACC 908) (Not evaluated by UL)

• Do not begin to install your Peerless product until you have read and understood the instructions and warnings

contained in this Installation Sheet. If you have any questions regarding any of the instructions or warnings, call

Peerless customer service at 1-800-729-0307.

• This product should only be installed by someone of good mechanical aptitude, has experience with basic building

construction, and fully understands these instructions.

• Make sure that the supporting surface will safely support the combined load of the equipment and all attached

hardware and components.

• Never mount this product to a metal stud wall construction unless the stud can be verified to be constructed of 25

gauge steel minimum, the drywall is 1/2" thick minimum and you obtain and use the Peerless accessory kit for metal

studs.

• Neverexceed the MaximumULLoadCapacity.

• If mounting to wood wall stud wall construction, make sure that mounting screws are anchored into the center of the

studs. Use of an "edge to edge" stud finder is highly recommended.

• Always use an assistant or mechanical lifting equipment to safely lift and position equipment.

• Tighten screws firmly, but do not overtighten. Overtightening can damage the items, greatly reducing their holding

power. See suggested torque values where applicable within these instructions.

WARNING

3 of 30 ISSUED: 06-10-05 SHEET #: 095-9223-4 08-30-05

D-LAL-100 D-LAL-100S

RTLAL-100 RTLAL-100S

SAL730P SAL730P-S

Description Qty. Part # Part #

Awall arm assembly 1 095-0279 095-0279-S

Badapter plate 1 095-1101 095-4101

C1/4-20 x 1.5" flat head screw 2 520-1264 520-2164

D.25" ID x .75" OD x .125" H washer 2 540-2015 540-2015

E1/4-20 nylock nut 2 530-2002 530-2002

FM5 x .8 x 10 mm self-tapping phillips screw 4 520-9250 520-2005

G3/16" allen wrench 1 560-0071 560-0071

HAlligator® concrete anchor 2 590-0097 590-0097

I#14 x 2.5" flat head wood screw 2 520-1202 520-2165

JM4 x .7 x 12 mm phillips screw 4 504-9013 504-2013

K4 mm allen wrench 1 560-9646 560-9646

Lcord management clip 2 590-1264 590-2164

M.198" ID x .313" OD x .437" H retaining spacer 4 590-5005 590-5003

NM4 x .7 x 20 mm phillips screw 4 504-9020 504-2014

Parts List

4 of 30 ISSUED: 06-10-05 SHEET #: 095-9223-4 08-30-05

fig. 1.2

fig. 1.1

SCREEN

CABINET

DOOR

CABINET

DOOR WALL

WALL

“D1” 11-7/8"

(302 mm)

max. distance from

cabinet door is

Installation to Side of Cabinet

If you are mounting your screen to a wall, skip to page 6 for wood stud walls and page 7 for concrete walls.

Note: Screen is not attached to mount at this point. It is shown only as a reference for visualization purposes.

Place your screen on side wall of cabinet in a location that will allow enough clearance between the screen and the

back wall when the mount is folded up as shown in figure 1.1. Mark the center of screen on the cabinet. Mark a

vertical line 1-1/2” (38 mm) toward the wall which represents the center of wall plate. Dimension “D1” represents the

minimum distance between the wall plate and the screen for this clearance.

Go to next page for installing the mount to the cabinet.

To swivel screen around the cabinet, read below.

If you would like the screen to swivel around the cabinet, place your wall arm in a location that will allow enough

clearance between the wall arm and the cabinet door as shown in figure 1.2.The dimension 11-7/8" (302 mm)

represents the maximum distance the center of the wall plate needs to be from the cabinet door. Mark a vertical line

on the cabinet where the wall arm assembly will be placed as shown in figure 1.2.

Notes:

• Beforeswiveling thewall armaround cabinet, ensure the cords have enough slack to allow fullarticulation ofwall

arm(A).

• Toallow swiveling around the cabinet and folding up the mount, the minimum distance from cabinet door must be

at least equal to dimension “D1”.

Go to next page for installing the mount to the cabinet.

Side View of Cabinet

(wall arm folded up against cabinet) Side View of Cabinet

(wall arm swiveled around cabinet)

• Make sure that the cabinet unit and cabinet side wall

will safely support the combined load of the

equipmentand all attached hardwareand

components.

• Beforeinstalling yourmount, emptycabinet and note

locationof shelves to avoiddrilling into theshelves.

CAUTIONWARNING

CS = center of screen

CP = center of wall plate

CS CP

1-1/2"

(38 mm)

WALL PLATE

5 of 30 ISSUED: 06-10-05 SHEET #: 095-9223-4 08-30-05

Remove cord covers from wall arm assembly (A) as shown in figure 1.3. Use wall plate as template to mark center of

holes along the vertical line drawn in step 1. Make sure wall plate is level, then drill two 9/32" (7 mm) holes through

cabinetwallwhere marked.

Installation to Side of Cabinet

WALL

VERTICALLINE

WALL PLATE

Fasten wall arm assembly (A) to side of cabinet using two 1/4-20 flat head screws (C), washers (D), and 1/4-20

nylock nuts (E) as shown in figures 1.4 and 1.5.

Skip to step 2 on page 8.

CABINETSIDE WALL

A C DE

Cfig. 1.5

CABINET

SIDE

WALL

Side View of Cabinet

Cutaway View of Cabinet Side Wall

Isometric View of

Cabinet Side Wall

1-2

1-1

fig. 1.3

fig. 1.4

CORDCOVERS

6 of 30 ISSUED: 06-10-05 SHEET #: 095-9223-4 08-30-05

Installation to Wood Stud Wall

Remove cord covers from wall arm assembly (A) as shown in figure 1.6. Using a stud finder, locate and mark the

edges of the wood stud used in mounting this product. Use of an edge to edge stud finder is highly recommended.

Use a level to draw a vertical line down the center of the stud. Use wall plate as template to mark center of holes

along the vertical line. Drill two 5/32" (4 mm) dia. holes 2.5" (65 mm) deep.Attach wall arm assembly (A) to wall

using two #14 x 2.5" flat head wood screws (I) as shown in figure 1.7.

Skip to step 2 on page 8.

• Makesurethatthewallwillsafelysupportthecombinedloadoftheequipmentandallattachedhardwareandcomponents.

WARNING

• Tightenscrews sothat wallplate is firmly attached, but do not overtighten. Overtightening can damagethe screws,

greatlyreducingtheirholdingpower.

• Never tighten in excess of 80 in. • lb (9 N.M.).

• Make sure that mounting screws are anchored into the center of the studs. The use of an "edge to edge" stud finder is

highlyrecommended.

WARNING

WOOD

STUD

WALL

fig. 1.6

fig. 1.7

CORDCOVERS

7 of 30 ISSUED: 06-10-05 SHEET #: 095-9223-4 08-30-05

Installation to Solid Concrete and Cinder Block

• When installing Peerless wall mounts on cinder block, verify that you have a minimum of 1-3/8" of actual concrete

thickness in the hole to be used for the concrete anchors. Do not drill into mortar joints! Be sure to mount in a solid

part of the block, generally 1" minimum from the side of the block. Cinder block must meetASTM C-90 specifications.

It is suggested that a standard electric drill on slow setting is used to drill the hole instead of a hammer drill to avoid

breakingout the backof the hole when enteringa void orcavity.

• Concrete must be 2000 psi density minimum. Lighter density concrete may not hold concrete anchor.

• Make sure that the wall will safely support the combined load of the equipment and all attached hardware and

components.

WARNING

Removecord covers from wall armassembly (A) as

shown in figure 1.6. Level and use wall plate as

template to mark center of holes. Drill two 1/4" (6

mm) dia. hole to a minimum depth of 2" (51 mm).

Insert anchors (H) in holes flush with wall as shown in

fig1.8. Placewall arm(A) over anchor and secure

with wood screw (I) as shown in figures 1.9 and 1.11.

Make sure wall arm is level, and tighten all fasteners.

Seefigure 1.10.

• Concrete anchors are notintendedforattachmentto

concretewall covered witha layer ofplaster,drywall,

orother finishing material asshown below. If mounting

toconcrete wall coveredwith plaster/drywall is

unavoidable,plaster/drywall (up to5/8" thick) mustbe

counterboredas shown below. Besureconcrete

anchorsdo not pullaway from concretewhen tighten-

ing screws. If plaster/drywall is thicker than

5/8", custom fasteners must be supplied by installer.

WARNING

concrete

wall

Drill holes

and insert

anchors.

Place wall

plate over

anchor and

secure with

screw.

Tighten all

fasteners.

WALLPLATE

fig. 1.8

fig. 1.9

fig. 1.10

CUTAWAYVIEW

CORRECT

concrete

plaster/

drywall

INCORRECT

concrete

plaster/

drywall

• Tighten screws so that wall plate is firmly attached,

butdonotovertighten. Overtightening can damage the

screws,greatlyreducing their holdingpower.

• Never tighten in excess of 80 in. • lb (9 N.M.).

WARNING

AIH

fig. 1.11

8 of 30 ISSUED: 06-10-05 SHEET #: 095-9223-4 08-30-05

FORVESA®75MOUNTINGPATTERN:

Chooseholepatternasshownbelow.Attachadapter

plate (B) to back of screen using four M4 x 12 mm

screws(J)as shown below.

*Note: If hole pattern is in a pocket, attach adapter

plate (B) to back of screen using four M4 x 20 mm

screws(N)and four retaining spacers(M)asindi-

catedbelow.

• If screws don't get three complete turns in the screen inserts or if screws bottom out and bracket is still not tightly

secured, damage may occur to screen or product may fail.

WARNING

FORVESA100MOUNTINGPATTERN:

Chooseholepatternasshownbelow.Attachadapter

plate (B) to back of screen using four M4 x 12 mm

screws(J)as shown below.

*For screens with a hole

pattern in a pocket,

spacers (M) go between

adapter plate (B) and

screen.

Note: To add security, orderACC 918 for security screws. Refer toACC 918 instruction sheet for installing security screws.

9 of 30 ISSUED: 06-10-05 SHEET #: 095-9223-4 08-30-05

Route cords through center of cord management clip (L). Next, attach cord management clip to wall arm ball joint

using M5 screw (F) as shown. Tighten all four screws (F).

Note:Acord management clip (L) was added for additional cords. If you want to use this added clip, remove the

opposite bottom screw and repeat this step on opposite side of wall arm ball joint.

Note: If the ball joint feels loose

or too easy to adjust, slightly

tighten cap socket screw until

ball joint feels firmly in place.

Insert two M5 x 10 mm screws

(F)into toptwo holesof adapter

plate(B)leavingabout1/4"of

exposed thread. With slots

facingupward,hookscrews

onto wall arm ball joint as

showninfigure3.1.

InsertoneM5screw(F) through

bottom hole of wall arm ball joint

intoadapterplate(B)asshown

infigure3.2.

fig. 3.1 fig. 3.2

1/4"

WALL ARM

BALLJOINT F

WALL ARM

BALLJOINT

CAPSOCKET

SCREW

Ball join design at screen for

easyside-to-sidemovement

and ±35° of tilt.

10 of 30 ISSUED: 06-10-05 SHEET #: 095-9223-4 08-30-05

Note: Makesure cords haveenough slack to allow fullmovement of thearm.

Route cords inside arm slots of wall arm assembly as shown in figure 5.1. Optional: Run power cord through one

sideof mount andsignal cable(s) throughother side toavoid interference withthe signal.

Lock cords into place by sliding cord covers onto mount as shown in figure 5.2. Screen may have to be moved for

better access for sliding on the cord covers.

Togetfull range ofmotion and enoughtension to hold

the screen in any position, simply tighten or loosen

cap socket screw a few turns using 4 mm allen

wrench(K)asshownabove.

CAPSOCKETSCREW

• Do not remove screw or loosen screw until it is no

longer engaged with the mount. Doing so may cause

the screen to fall.

CORD

WARNING

If more or less tension is desired in the arm pivot

points,do the following:

• To increase tension, turn socket screw clockwise

with3/16" allen wrench(G).

• Toreducetension,turnsocketscrewcounter-

clockwise with allen wrench (G). Do not turn more

than half a turn.

fig. 5.1

fig. 5.2

PeerlessisaregisteredtrademarkofPeerlessIndustries,Inc.

Allotherbrandandproductnamesaretrademarksorregisteredtrademarksoftheirrespectiveowners.

SOCKETSCREWS

Autres manuels pour SAL730P

Ce manuel convient aux modèles suivants

Table des matières

Langues :

Autres manuels PEERLESS Support et étagère

PEERLESS

PEERLESS Perfect Mount PMF2X2 Manuel utilisateur

PEERLESS

PEERLESS HCACC503 Manuel utilisateur

PEERLESS

PEERLESS SOLID-POINT PLCM1CP Mode d’emploi

PEERLESS

PEERLESS SmartMount SF650 Mode d’emploi

PEERLESS

PEERLESS SA761PU Mode d’emploi

PEERLESS

PEERLESS PED 410 Mode d’emploi

PEERLESS

PEERLESS WSP 490 Mode d’emploi

PEERLESS

PEERLESS Solid-Point PS 1 Mode d’emploi

PEERLESS

PEERLESS Paramount PRT2X2 Manuel utilisateur

PEERLESS

PEERLESS SF 24D Mode d’emploi

PEERLESS

PEERLESS Smartmount SWS310/BK Mode d’emploi

PEERLESS

PEERLESS Mobile Videowall Trolley PDVWM 2x2 46 55 L Mode d’emploi

PEERLESS

PEERLESS ACC 314 Mode d’emploi

PEERLESS

PEERLESS WSP820 Mode d’emploi

PEERLESS

PEERLESS PWMT300 Manuel utilisateur

PEERLESS

PEERLESS PARAMOUNT PA740 Manuel utilisateur

PEERLESS

PEERLESS A100IWBMOUNT Mode d’emploi

PEERLESS

PEERLESS LDM233K Mode d’emploi

PEERLESS

PEERLESS Paramount PA760 Mode d’emploi

PEERLESS

PEERLESS Paramount PF660 Mode d’emploi

PEERLESS

PEERLESS RTLA-100 Mode d’emploi

PEERLESS

PEERLESS SAL730P Mode d’emploi

PEERLESS

PEERLESS PLC Mode d’emploi

PEERLESS

PEERLESS PARAMOUNT PA730 Mode d’emploi

Manuels Support et étagère populaires d'autres marques

Salamander

Salamander Acadia AC/W/L400/WH Manuel utilisateur

Fohhn

Fohhn VAT-09 Guide de l'utilisateur

ricoo

ricoo FS0522 Manuel utilisateur

AMSOIL

AMSOIL BMK-22 Guide rapide

Kargo Master

Kargo Master 48220 Manuel utilisateur

Milestone AV Technologies

Milestone AV Technologies SIMPLICITY SLF2 Manuel utilisateur

ricoo

ricoo S1222 Manuel utilisateur

Ready-Set-Mount

Ready-Set-Mount RSMCM602 Manuel utilisateur

VidaBox

VidaBox VB MNT FFS2 Manuel utilisateur

Welch Allyn

Welch Allyn 48960 Manuel utilisateur

Arkon

Arkon CM035-ST-2 Manuel utilisateur

PROEL

PROEL PLWIN60C Manuel utilisateur

Agilent Technologies

Agilent Technologies E2609B Manuel utilisateur

Mustang

Mustang MV-ARM4 Manuel utilisateur

Mounting Solutions

Mounting Solutions WRM-320 Manuel utilisateur

Pyle

Pyle PMKSPAD1 Manuel utilisateur

ShelterIt

ShelterIt 21208 Manuel utilisateur

SPL

SPL RackPack?4 1040 Manuel utilisateur
