Keysight Technologies E5052B Manuel du propriétaire

Product Declassification and Security Product Name: 10 MHZ TO 7 GHZ SIGNAL SOURCE ANALYZER

Model Number(s): E5052B

Page 1 of 10

E5052B Security Features

Rev. 2.4

Dec 2016

Product Declassification and Security Product Name: 10 MHZ TO 7 GHZ SIGNAL SOURCE ANALYZER

Model Number(s): E5052B

Page 2 of 10

Contacting Keysight Sales and Service Offices

Assistance with test and measurements needs and information on finding a local Keysight

office is available on the internet at, http://www.Keysight.com/find/assist. If you do not

have access to the internet, please contact your field engineer.

Note: In any correspondence or telephone conversation, refer to the signal source

analyzer by its model number and full serial number. With this information, the Keysight

representative can determine whether your unit is still within its warranty period.

Product Declassification and Security

Model Number(s): E5052B

Product Name: 10 MHZ TO 7 GHZ SIGNAL SOURCE ANALYZER

This document describes instrument security features and the steps to declassify an

instrument through memory sanitization or removal. For additional information please go

to www.keysight.com/find/ad and click on the security instrument tab.

Table of Contents

Terms and Definitions.……………………………………………......3

Instrument Memory………………………………………………...…4

Memory Clearing, Sanitization and/or Removal…………………...…6

User and Remote Interface Security ………...……………….…….…9

Procedure for Declassifying a Faulty Instrument……………..….…...10

Product Declassification and Security Product Name: 10 MHZ TO 7 GHZ SIGNAL SOURCE ANALYZER

Model Number(s): E5052B

Page 3 of 10

Terms and Definitions

Definitions:

Clearing –Clearing is the process of eradicating the data on media before reusing the media so that the

data can no longer be retrieved using the standard interfaces on the instrument. Clearing is typically used

when the instrument is to remain in an environment with an acceptable level of protection.

Sanitization –Sanitization is the process of removing or eradicating stored data so that the data cannot

be recovered using any known technology. Instrument sanitization is typically required when an instrument

is moved from a secure to a non-secure environment such as when it is returned to the factory for

calibration. (The instrument is declassified) Keysight memory sanitization procedures are designed for

customers who need to meet the requirements specified by the US Defense Security Service (DSS). These

requirements are outlined in the “Clearing and Sanitization Matrix” issued by the Cognizant Security Agency

(CSA) and referenced in National Industrial Security Program Operating Manual (NISPOM) DoD 5220.22M

ISL 01L-1 section 8-301.

Security Erase –Refers to either the clearing or sanitization features of Keysight instruments.

Instrument declassification –A term that refers to procedures that must be undertaken before an

instrument can be removed from a secure environment such as is the case when the instrument is returned

for calibration. Declassification procedures will include memory sanitization and or memory removal.

Keysight declassification procedures are designed to meet the requirements specified by the DSS NISPOM

security document (DoD 5220.22M chapter 8)

Product Declassification and Security Product Name: 10 MHZ TO 7 GHZ SIGNAL SOURCE ANALYZER

Model Number(s): E5052B

Page 4 of 10

Instrument Memory

This section contains information on the types of memory available in your instrument. It explains the size of

memory, how it is used, its location, volatility, and the sanitization procedure.

Summary of instrument memory - base instrument

Memory Type

and Size

Writable During

Normal Operation?

Data Retained When

Powered Off?

Purpose/Contents

Data Input

Method

Location in

Instrument and

Remarks

Sanitization

Procedure

Main Memory

(DDR SDRAM

DIMM)

1 GB/ 2 GB/ 4

Yes

Windows Operating

system memory

Operating

system

(not user)

Digital Mother Board

Cycle power

Media Storage

(Hard Disk

Drive)

40 GB/ 320 GB

Yes

Windows Operating

system boot device,

factory correction

data, and users file

including saved

traces data,

settings, or images.

User-saved

data

Removable Hard Disk

Drive (HDD)

Remove

Media Storage

(Solid State

Drive)

80 GB

Yes

Windows Operating

system boot device,

factory correction

data, and users file

including saved

traces data,

settings, or images.

User-saved

data

Removable Solid

State Drive (SSD)

Remove

Memory for

PCI and DSP

(Static RAM)

2.5MB

Yes

Data Processing for

measurement

Measureme

nt (not

user)

PCI DSP Card

Cycle power

Non-volatile

memory

(Flash

EEPROM) 1MB

Yes

Firmware for

instrument

operation

Non-User

Modifiable

PCI DSP Card

N/A

Non-volatile

memory

(Flash

EEPROM)

256Mbit

Yes

Firmware for

instrument

operation

Non-User

Modifiable

DSP Board

N/A

Memory for

Data Buffer

(Static RAM)

36Mbit

Yes

Data Processing for

measurement

Measureme

nt (not

user)

DSP Board

Cycle power

Product Declassification and Security Product Name: 10 MHZ TO 7 GHZ SIGNAL SOURCE ANALYZER

Model Number(s): E5052B

Page 5 of 10

Memory for

Data Buffer

(Static RAM)

512MB

Yes

Data Processing for

measurement

Measureme

nt (not

user)

DSP Board

Cycle power

DSP Work

Memory

(Static RAM)

18Mbit

Yes

Data Processing for

measurement

Measureme

nt (not

user)

DSP Board

Cycle power

Product Declassification and Security Product Name: 10 MHZ TO 7 GHZ SIGNAL SOURCE ANALYZER

Model Number(s): E5052B

Page 6 of 10

Memory Clearing, Sanitization and/or Removal Procedures

This section explains how to clear, sanitize, and remove memory from you instrument for all memory that

can be written to during normal operation and for which the clearing and sanitization procedure is more

than trivial such as rebooting your instrument.

Description and

purpose

Main Memory (DDR SDRAM) for Windows Operating system memory

Size

1. For MY471xxxxx/ SG471xxxxx –1 GB RAM.

2. For MY472xxxxx/ SG472xxxxx; MY473xxxxx/ SG473xxxxx –2 GB

RAM.

3. For MY474xxxxx/ SG474xxxxx –4 GB RAM.

Memory clearing

Power rebooting. This is a volatile memory.

Memory sanitization

Power rebooting. This is a volatile memory.

Memory removal

This memory cannot be removed without damaging the instrument

Write protecting

N/A

Memory validation

N/A

Remarks

Confirmation or setting the BIOS Options: BIOS is the PC's built-in program describing the standard procedure of basic

inputs and outputs for the system hardware. BIOS involves the system BIOS, start-up program and BIOS setup utility.

The E5052B starts up first with the BIOS when the power is turned on. See the trouble shooting section in the service

manual for the procedure to confirm or set the BIOS options, known as the BIOS setup utility.

Name: E5052B Signal Source Analyzer Service Guide

Location: http://www.keysight.com/find/ssa > Product Library > Manuals.

Description and

purpose

Media Storage (Removable Hard Disk Drive) for Windows Operating system

boot device, factory correction data, and users file including saved traces

data, settings, or images.

Size

1. For MY471xxxxx/ SG471xxxxx - 40 GB HDD.

2. For MY472xxxxx/ SG472xxxxx; MY473xxxxx/ SG473xxxxx –320 GB

HDD.

3. For MY474xxxxx/ SG474xxxxx –80 GB SSD.

Memory clearing

N/A

Memory sanitization

N/A

Memory removal

Hard disk is set as a removable type.

Write protecting

N/A

Memory validation

N/A

Remarks:

Hard Disk Removal: Because it is virtually impossible to completely and selectively erase all user data on a hard drive

without also destroying the operating system, the best method for maintaining security when the E5052B must be

removed from a secure area is to replace the hard drive with a "non-secure" hard drive, i.e. a drive that has never had

any sensitive data placed on it.

E5052B standard set is delivered with a removable hard disk unit.

Product Declassification and Security Product Name: 10 MHZ TO 7 GHZ SIGNAL SOURCE ANALYZER

Model Number(s): E5052B

Page 7 of 10

E5052BU-018/ 028/ 058 is the additional hard disk drive/ solid state drive to prepare the second unit for E5052B

removable hard disk user.

For E5052B with SN: MY471xxxxx, SG471xxxxx; MY472xxxxx, SG472xxxxx; MY473xxxxx, SG473xxxxx;

E5052BU-018/ 028 is discontinued. The E5052B unit needs to be upgraded with E5052BU-040 Digital hardware module

upgrade kit by Keysight service center. The upgrade kit contains one removable SSD by default. If additional spare disk

is required, procure E5052BU-058 Solid state drive kit.

For E5052B with SN: MY474xxxxx, SG474xxxxx;

A spare disk is available as E5052BU-058.

E5052B Hardware, Software & Firmware Upgrades:

http://www.keysight.com/main/editorial.jspx?cc=MY&lc=eng&ckey=2082886&nid=-

35185.631410.00&id=2082886&cmpid=zzfinde5052b_upgrades

Removal Procedure:

http://ena.support.keysight.com/e5052b/manuals/webhelp/eng/product_information/maintenance/removing_mountin

g_removable_hard_disk.htm

Description and

purpose

Memory for PCI and DSP (Static RAM)

Size

2.5 MB

Memory clearing

Power rebooting. This is a volatile memory.

Memory sanitization

Power rebooting. This is a volatile memory.

Memory removal

This memory cannot be removed without damaging the instrument

Write protecting

N/A

Memory validation

N/A

Remarks

Description and

purpose

Non-volatile memory (Flash EEPROM) for Firmware for instrument

operation

Size

1 MB

Memory clearing

Adjustment program performed by Keysight factory personnel or by

calibration labs only.

Memory sanitization

Adjustment program performed by Keysight factory personnel or by

calibration labs only.

Memory removal

This memory cannot be removed without damaging the instrument

Write protecting

N/A

Memory validation

N/A

Remarks

The data is not stored by user under normal operation.

Product Declassification and Security Product Name: 10 MHZ TO 7 GHZ SIGNAL SOURCE ANALYZER

Model Number(s): E5052B

Page 8 of 10

Description and

purpose

Non-volatile memory (Flash EEPROM) for Firmware for instrument

operation

Size

256 Mbit

Memory clearing

N/A

Memory sanitization

N/A

Memory removal

This memory cannot be removed without damaging the instrument

Write protecting

N/A

Memory validation

N/A

Remarks

The data is not stored by user under normal operation.

Description and

purpose

Memory for Data Buffer while Data processing

Size

36 Mbit

Memory clearing

Power rebooting. This is a volatile memory.

Memory sanitization

Power rebooting. This is a volatile memory.

Memory removal

This memory cannot be removed without damaging the instrument

Write protecting

N/A

Memory validation

N/A

Remarks

Description and

purpose

Memory for Data Buffer while Data processing

Size

512 MB

Memory clearing

Power rebooting. This is a volatile memory.

Memory sanitization

Power rebooting. This is a volatile memory.

Memory removal

This memory cannot be removed without damaging the instrument

Write protecting

N/A

Memory validation

N/A

Remarks

Description and

purpose

DSP Work Memory

Size

18 Mbit

Memory clearing

Power rebooting. This is a volatile memory.

Memory sanitization

Power rebooting. This is a volatile memory.

Memory removal

This memory cannot be removed without damaging the instrument

Write protecting

N/A

Memory validation

N/A

Remarks

Product Declassification and Security Product Name: 10 MHZ TO 7 GHZ SIGNAL SOURCE ANALYZER

Model Number(s): E5052B

Page 9 of 10

User and Remote Interface Security Measures

Screen and Annotation Blanking

You can prevent frequency information from appearing on the E5052B screen and printouts.

To set security levels from the E5052B menu, go to Display, then Security Level.

When the security level is set to Frequency Blank or All Numeric Blank, the following information is blanked.

Display annotation

All marker readouts

All tables

All soft key menus

All printouts

Programming via GPIB or VBA

The frequency blank operation is supported on firmware revision A.02.00 or higher.

The latest firmware can be downloaded from:

http://www.keysight.com/find/ssa > Technical Support >Software Downloads & Utilities

USB Mass Storage Device Security

The following procedure shows how to disable a USB Mass Storage Device.

1. [Save/Recall] > Explorer….

2. Double-click “DisableUsbStorage.exe” from D”\Agilent\Service.

3. Click OK in the SUCCEEDED message window that appears. If any USB mass storage device is

connected to the E5052B under this condition, the Hardware Wizard will start, but the USB

mass storage device will not work.

The following procedure shows how to enable a USB Mass Storage Device.

1. [Save/Recall] > Explorer….

2. Double-click “EnableUsbStorage.exe” from D”\Agilent\Service.

3. Click OK in the SUCCEEDED message window that appears.

Note: If the program fails to run, it is possible that you have not logged in as a user in the Administrators

Group. When you want to execute any of the above programs, make sure to log in as a user in the

Administrators Group.

Note: For users who have E5052B with a serial prefix of MY421, these units do not contain the necessary

programs in their HDD at shipment. Visit the following URL to obtain the program.

http://www.keysight.com/find/ssa > Technical Support >Software Downloads & Utilities > Program/Utility

Product Declassification and Security Product Name: 10 MHZ TO 7 GHZ SIGNAL SOURCE ANALYZER

Model Number(s): E5052B

Page 10 of 10

Remote Access Interfaces

The user is responsible for providing security for the I/O ports for remote access by controlling

physical access to the I/O ports. The I/O ports must be controlled because they provide access to

all user settings, user states and the display image.

The I/O ports include RS-232, GPIB and LAN.

The LAN port provides the following services, which can be selectively disabled:

http

ftp

sockets

telnet

There is also a ‘ping’ service, which presently cannot be selectively disabled. The concern here

might be that it is possible to discover IP addresses of connected instruments in order to query their

setups over the net or break into the code.

Procedure for Declassifying a Faulty Instrument

As shipped from the factory, all the E5052Bs have the following instrument-specific calibration files stored

on the hard disk drive. When replacing a hard disk drive, in order to achieve specified performance, these

files must be copied to the new hard drive. These files are located in the directory, D:\syscal.

Perform the procedure described on the E5052B User’s Guide to declassifying an E5052B if it needs to be

removed from a secure area and be returned to a secure area.

The procedure can be found on Information on Maintenance on the E5052B User’s Guide.

The latest manual can be also downloaded from:

http://www.keysight.com/find/ssa > Technical Support > Manuals & Guides

Table des matières

Autres manuels Keysight Technologies Instrument de mesure

Keysight Technologies

Keysight Technologies 16861A Manuel utilisateur

Keysight Technologies

Keysight Technologies B2901A Manuel utilisateur

Keysight Technologies

Keysight Technologies B1500A Guide d'installation

Keysight Technologies

Keysight Technologies 86120D Manuel utilisateur

Keysight Technologies

Keysight Technologies N9030B Manuel d'installation et d'exploitation

Keysight Technologies

Keysight Technologies N4960A Manuel utilisateur

Keysight Technologies

Keysight Technologies B2900B Series Manuel utilisateur

Keysight Technologies

Keysight Technologies UXA N9040B Manuel utilisateur

Keysight Technologies

Keysight Technologies 16034G Manuel utilisateur

Keysight Technologies

Keysight Technologies N9041B Manuel d'installation et d'exploitation

Keysight Technologies

Keysight Technologies Agilent Technologies PXI Express M9202A Guide de l'utilisateur

Keysight Technologies

Keysight Technologies B2900A Series Manuel utilisateur

Keysight Technologies

Keysight Technologies PNA Series Manuel utilisateur

Keysight Technologies

Keysight Technologies B2900A Series Manuel utilisateur

Keysight Technologies

Keysight Technologies InfiniiMax III Series Manuel utilisateur

Keysight Technologies

Keysight Technologies N4373E Manuel utilisateur

Keysight Technologies

Keysight Technologies N9010B Manuel d'installation et d'exploitation

Keysight Technologies

Keysight Technologies X Series Guide de démarrage rapide

Keysight Technologies

Keysight Technologies CX3300 Series Manuel utilisateur

Keysight Technologies

Keysight Technologies E4990A Manuel utilisateur

Keysight Technologies

Keysight Technologies M937 A Series Manuel utilisateur

Keysight Technologies

Keysight Technologies M9391A PXIe Guide de l'utilisateur

Keysight Technologies

Keysight Technologies N5221B Manuel utilisateur

Keysight Technologies

Keysight Technologies E4980A Manuel utilisateur

Manuels Instrument de mesure populaires d'autres marques

Suaoki

Suaoki D40 Manuel utilisateur

Elster

Elster BK-G1.6 Manuel utilisateur

Endress+Hauser

Endress+Hauser Deltabar FMD71 Manuel

Duratool

Duratool D03128 Manuel utilisateur

Vega

Vega VEGAPULS 65 Manuel utilisateur

Tonghui

Tonghui TH2618B Manuel utilisateur

Tenmars

Tenmars TM-801 Manuel utilisateur

MSR

MSR 145 Manuel utilisateur

TPS

TPS WP-82 Manuel utilisateur

ELMETRON

ELMETRON CP-511 Manuel utilisateur

PCB Piezotronics

PCB Piezotronics 003C30 Manuel utilisateur

Tenma

Tenma 72-10465 Manuel utilisateur

Endress+Hauser

Endress+Hauser Proline Promag 50 Caractéristiques techniques

Siemens

Siemens SITRANS F Coriolis FCT030 Manuel de la liste des pièces

KLINGER

KLINGER CMF V Series Manuel utilisateur

EXFO

EXFO FTB-2 Manuel d'exploitation et d'entretien

Keysight

Keysight M8290A Manuel utilisateur

ADTEK

ADTEK MW-5 Manuel utilisateur
