Keysight Technologies UXA N9040B Manuel utilisateur

N9069C

Noise Figure

Measurement

Guide

Keysight X-Series

Signal Analyzers

This manual provides documentation for the following models:

N9040B UXA

N9030B PXA

N9020B MXA

N9010B EXA

N9000B CXA

N8973B NFA

N8974B NFA

N8975B NFA

N8976B NFA

Notices

2015-2016

No part of this manual may be

reproduced in any form or by any

means (including electronic storage

and retrieval or translation into a

foreign language) without prior

agreement and written consent from

Keysight Technologies, Inc. as

governed by United States and

international copyright laws.

Trademark Acknowledgments

Manual Part Number

N9069-90001

Edition

Edition 1, March 2016

Supersedes: February 2016

Published by:

Keysight Technologies

1400 Fountaingrove Parkway

Santa Rosa, CA 95403

Warranty

THE MATERIAL CONTAINED IN THIS

DOCUMENT IS PROVIDED “AS IS,”

AND IS SUBJECT TO BEING

CHANGED, WITHOUT NOTICE, IN

FUTURE EDITIONS. FURTHER, TO

THE MAXIMUM EXTENT PERMITTED

BY APPLICABLE LAW, KEYSIGHT

DISCLAIMS ALL WARRANTIES,

EITHER EXPRESS OR IMPLIED WITH

REGARD TO THIS MANUAL AND

ANY INFORMATION CONTAINED

HEREIN, INCLUDING BUT NOT

LIMITED TO THE IMPLIED

WARRANTIES OF

MERCHANTABILITY AND FITNESS

FOR A PARTICULAR PURPOSE.

KEYSIGHT SHALL NOT BE LIABLE

FOR ERRORS OR FOR INCIDENTAL

OR CONSEQUENTIAL DAMAGES IN

CONNECTION WITH THE

FURNISHING, USE, OR

PERFORMANCE OF THIS

DOCUMENT OR ANY INFORMATION

CONTAINED HEREIN. SHOULD

KEYSIGHT AND THE USER HAVE A

SEPARATE WRITTEN AGREEMENT

WITH WARRANTY TERMS

COVERING THE MATERIAL IN THIS

DOCUMENT THAT CONFLICT WITH

THESE TERMS, THE WARRANTY

TERMS IN THE SEPARATE

AGREEMENT WILL CONTROL.

Technology Licenses

The hardware and/or software

described in this document are

furnished under a license and may be

used or copied only in accordance

with the terms of such license.

U.S. Government Rights

The Software is “commercial

computer software,” as defined

by Federal Acquisition Regulation

(“FAR”) 2.101. Pursuant to FAR

12.212 and 27.405-3 and

Department of Defense FAR

Supplement (“DFARS”) 227.7202,

the U.S. government acquires

commercial computer software

under the same terms by which

the software is customarily

provided to the public.

Accordingly, Keysight provides

the Software to U.S. government

customers under its standard

commercial license, which is

embodied in its End User License

Agreement (EULA), a copy of

which can be found at

http://www.keysight.com/find/sweula

The license set forth in the EULA

represents the exclusive authority

by which the U.S. government

may use, modify, distribute, or

disclose the Software. The EULA

and the license set forth therein,

does not require or permit,

among other things, that

Keysight: (1) Furnish technical

information related to

commercial computer software

or commercial computer

software documentation that is

not customarily provided to the

public; or (2) Relinquish to, or

otherwise provide, the

government rights in excess of

these rights customarily provided

to the public to use, modify,

reproduce, release, perform,

display, or disclose commercial

computer software or

commercial computer software

documentation. No additional

government requirements

beyond those set forth in the

EULA shall apply, except to the

extent that those terms, rights, or

licenses are explicitly required

from all providers of commercial

computer software pursuant to

the FAR and the DFARS and are

set forth specifically in writing

elsewhere in the EULA. Keysight

shall be under no obligation to

update, revise or otherwise

modify the Software. With

respect to any technical data as

defined by FAR 2.101, pursuant

to FAR 12.211 and 27.404.2 and

DFARS 227.7102, the U.S.

government acquires no greater

than Limited Rights as defined in

FAR 27.401 or DFAR 227.7103-5

(c), as applicable in any technical

data.

Safety Notices

A CAUTION notice denotes a hazard. It

calls attention to an operating

procedure, practice, or the like that,

if not correctly performed or adhered

to, could result in damage to the

product or loss of important data. Do

not proceed beyond a CAUTION

notice until the indicated conditions

are fully understood and met.

A WARNING notice denotes a hazard.

It calls attention to an operating

procedure, practice, or the like that,

if not correctly performed or adhered

to, could result in personal injury or

death. Do not proceed beyond a

WARNING notice until the indicated

conditions are fully understood and

met.

Where to Find the Latest Information

Documentation is updated periodically. For the latest information about these products, including instrument software

upgrades, application information, and product information, browse to one of the following URLs, according to the name

of your product:

http://www.keysight.com/find/N9040B

http://www.keysight.com/find/N9030B

http://www.keysight.com/find/N9020B

http://www.keysight.com/find/N9010B

http://www.keysight.com/find/N9000B

http://www.keysight.com/find/N8973B

To receive the latest updates by email, subscribe to Keysight Email Updates at the following URL:

http://www.keysight.com/find/MyKeysight

Information on preventing instrument damage can be found at:

www.keysight.com/find/PreventingInstrumentRepair

Is your product software up-to-date?

Periodically, Keysight releases software updates to fix known defects and incorporate product enhancements. To search

for software updates for your product, go to the Keysight Technical Support website at:

http://www.keysight.com/find/techsupport

Contents

Table of Contents

1 Introduction to Noise Figure

How does the Noise Figure Measurement Work? 10

Noise Source 10

Y-factor Measurement 10

Process 11

What does the Keysight N9069C Noise Figure Measurement Application

Do? 12

2 Making Noise Figure Measurements

Making Basic Measurements 14

Basic Amplifier Measurement 14

Calibrating the Analyzer 15

Making the Measurement 19

Making Frequency Converter Measurements 20

Making Frequency Converting DUT Measurements 20

Initial Setup Procedure 23

Calibration of the Measurement Setup 25

Making the Corrected Noise Figure and Gain Measurement 27

Making Multi-stage Converter Measurements 28

Measurements with a System Downconverter 28

Measurement Modes with a DSB System Downconverter 30

Measurement Modes with an SSB System Downconverter 31

Calculating Measurement Uncertainty 34

Using the U7227-Series USB Preamplifiers in Noise Figure Measurements 37

Initial Connection to the Signal Analyzer 38

Guide for Using U7227-Series USB Preamplifier and the Internal Preamplifier

inside X-Series Signal Analyzer 41

Amplitude Concerns in the Noise Figure Test System 41

Rough Guide for the Noise Figure Test System Configuration 42

Contents

3 Measurement Related Tasks and Concepts

Setting the Measurement System 50

Accounting for Frequency Conversion 50

Sidebands and Images 50

Signal Leakage 51

LO Leakage 51

LO Harmonics 51

Single Sideband Measurements 52

Double Sideband Measurements 54

Choosing and Setting Up the Local Oscillator 56

Selecting a Local Oscillator for Extended Frequency measurements with the

X-Series 56

Selecting a Local Oscillator 57

Calibrating the Analyzer 58

Corrected Measurements 58

When to Perform Calibration 59

Interpolated Results 59

Calibration Indicator 59

Interpolated Calibration 59

User Cal vs. Internal Cal 59

Setting the Signal Analyzer to Make a Measurement 61

DUT Setup Form 61

Entering Excess Noise Ratio (ENR) Data 64

Selecting a Common ENR Table 65

Entering ENR Table Data for Noise Sources 65

Saving an ENR Table 68

Entering ENR Data from Internal Storage 69

Using a Spot ENR Value 69

Setting the Tcold Value 69

Setting the Measurement Frequencies 70

Using Swept Frequency Mode 70

Using List Frequency Mode 71

Contents

Using Fixed Frequency Mode 73

Setting the Bandwidth and Averaging 73

Effect of Bandwidth and Averaging on Speed, Jitter, and Measurement

Accuracy 73

Selecting the Resolution Bandwidth (RBW) Value 73

Setting Averaging 74

Selecting the Input Attenuation Range 75

Setting the Input Attenuation used for Measurement 76

Setting up External LO Control 77

Adding External LO to List 77

Setting up DUT LO or System Downconverter LO 77

Using Loss Compensation 78

Examples where Loss Compensation is applied 78

Configuring Fixed Loss Compensation 79

Creating a Loss Compensation Table 80

Setting Temperature of Loss 81

Viewing Measurement Results 82

Displaying the Measurement Results 82

Selecting the Layout 82

Selecting Result Types to Display 83

Setting the Scaling 84

Calculating the Noise Power into Different Stages of the Noise Figure Measurement

System 85

Calculating the Noise Figure for Noise Power Calculation 86

Further Information 87

Contents

Keysight X-Series Signal Analyzers

N9069C Noise Figure

Measurement Guide

1 Introduction to Noise Figure

Modern receiving systems must often process very weak signals, but the noise

added by the system components tends to obscure those very weak signals.

Sensitivity, bit error ratio (BER) and noise figure are system parameters that

characterize the ability to process low-level signals. Of these parameters, noise

figure is unique in that it is suitable not only for characterizing the entire

system, but also the system components such as the preamplifier, mixer, and

IF amplifier that make up the system. By controlling the noise figure and gain of

the system components, you can directly control the noise figure of the overall

system. Once the noise figure is known, system sensitivity can be estimated

from the system bandwidth. Noise figure is often the key parameter that

differentiates one system from another, one amplifier from another, and one

transistor from another.

The noise figure of a network is defined to be the ratio of the signal-to-noise

power ratio at the input to the signal-to-noise power ratio at the output.

Noise figure is independent of the modulation format and of the fidelity of

modulators and demodulators. Noise figure is a more general concept than

noise-quieting used to indicate the sensitivity of FM receivers or BER used in

digital communication.

Noise figure should be thought of as separate from gain. Once noise is added

to the signal, subsequent gain amplifies the signal and noise together and

does not change the signal-to-noise ratio.

10 N9069C Noise Figure Measurement Guide

Introduction to Noise Figure

How does the Noise Figure Measurement Work?

The noise figure measurement is usually made on 2-port devices to see the

decrease of the signal-to-noise ratio as the signal goes through the DUT. The

N9069C Noise Figure Measurement Application uses the Y-factor method to

calculate the noise figure. This section briefly explains how a complete Y-factor

measurement is made. You can refer to Application Note 57-2: Noise Figure

Measurement Accuracy - The Y-Factor Method for more detailed information.

The test system can be seen as a two-stage system as shown in the following

figure. The DUT is stage 1 and the instrument connected to the DUT is stage 2.

The noise figure of the DUT can be calculated using the following equation.

Equation 1-1

This equation is the basis for the noise figure measurement. The noise figure

and gain of the DUT are measured in the process.

Figure 1-1 Noise Figure Measurement Using a Two-Stage System

Noise Source

The Y-factor method uses a noise source to provide stimulus to the DUT input.

The noise source has two known levels of noise with a pre-calibrated Excess

Noise Ratio (ENR). The noise from the noise source is broadband.

Equation 1-2

and are the noise temperatures of the noise source in its ON and OFF

states. is the reference temperature of 290 K.

Y-factor Measurement

The complete Y-factor measurement of the DUT noise figure and gain consists

of two steps, calibration and measurement, as shown in Figure 1-2. The

analyzer measures the noise power corresponding to the noise source On and

noise source Off in certain bandwidth at different frequencies. A total of four

measurements are taken in the process.

F1F12 F21–()G1

⁄[]–=

ENR Ts

ON Ts

OFF

–()T0

⁄=

OFF

Autres manuels pour UXA N9040B

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Keysight Technologies Instrument de mesure

Keysight Technologies

Keysight Technologies B2980A Series Manuel utilisateur

Keysight Technologies

Keysight Technologies N9344C Manuel utilisateur

Keysight Technologies

Keysight Technologies P5000A Series Manuel utilisateur

Keysight Technologies

Keysight Technologies N7373C Manuel

Keysight Technologies

Keysight Technologies N2797A Manuel utilisateur

Keysight Technologies

Keysight Technologies N9010A Series Manuel d'installation et d'exploitation

Keysight Technologies

Keysight Technologies UXA N9040B Manuel utilisateur

Keysight Technologies

Keysight Technologies U5309A Guide de l'utilisateur

Keysight Technologies

Keysight Technologies V3500A Manuel utilisateur

Keysight Technologies

Keysight Technologies 86120B Manuel utilisateur

Keysight Technologies

Keysight Technologies N8480 Series Manuel de service

Keysight Technologies

Keysight Technologies PXA N9030A Manuel d'installation et d'exploitation

Keysight Technologies

Keysight Technologies M9393A Mode d'emploi

Keysight Technologies

Keysight Technologies N778 C Series Mode d'emploi

Keysight Technologies

Keysight Technologies MXA Series Manuel d'installation et d'exploitation

Keysight Technologies

Keysight Technologies N5250C PNA Series Manuel utilisateur

Keysight Technologies

Keysight Technologies U2000 Series Manuel utilisateur

Keysight Technologies

Keysight Technologies N432A Manuel utilisateur

Keysight Technologies

Keysight Technologies E5400-Pro Series Manuel utilisateur

Keysight Technologies

Keysight Technologies N5511A-K26 Manuel utilisateur

Keysight Technologies

Keysight Technologies N9000B Manuel d'installation et d'exploitation

Keysight Technologies

Keysight Technologies PNA Series Manuel utilisateur

Keysight Technologies

Keysight Technologies X-Series Guide de démarrage rapide

Keysight Technologies

Keysight Technologies 16861A Manuel utilisateur

Manuels Instrument de mesure populaires d'autres marques

Suaoki

Suaoki D40 Manuel utilisateur

Elster

Elster BK-G1.6 Manuel utilisateur

Endress+Hauser

Endress+Hauser Deltabar FMD71 Manuel

Duratool

Duratool D03128 Manuel utilisateur

Vega

Vega VEGAPULS 65 Manuel utilisateur

Tonghui

Tonghui TH2618B Manuel utilisateur

Tenmars

Tenmars TM-801 Manuel utilisateur

MSR

MSR 145 Manuel utilisateur

TPS

TPS WP-82 Manuel utilisateur

ELMETRON

ELMETRON CP-511 Manuel utilisateur

PCB Piezotronics

PCB Piezotronics 003C30 Manuel utilisateur

Tenma

Tenma 72-10465 Manuel utilisateur

Endress+Hauser

Endress+Hauser Proline Promag 50 Caractéristiques techniques

Siemens

Siemens SITRANS F Coriolis FCT030 Manuel de la liste des pièces

KLINGER

KLINGER CMF V Series Manuel utilisateur

EXFO

EXFO FTB-2 Manuel d'exploitation et d'entretien

Keysight

Keysight M8290A Manuel utilisateur

ADTEK

ADTEK MW-5 Manuel utilisateur
