DMP Electronics 734B Guide d'installation

INSTALLATION AND PROGRAMMING GUIDE

734B Access

Control Module

About the 734B .......................................... 1

Power Supply......................................................... 1

Zone Terminals ...................................................... 1

Annunciators.......................................................... 1

Indicator LEDs ....................................................... 1

Form C Relay......................................................... 2

Programming Connection................................ 2

Keypad In and Out Connections ................... 2

PCB Features...............................................3

Install the 734B...........................................4

Wire the Magnetic Lock.................................... 5

Isolation Relay (optional) ................................. 7

Install the 333Suppressor ............................... 8

Wire the Zone Terminals................................... 9

Connect a Magstripe Reader.......................... 11

Set the 734B Address.......................................14

Program the 734B .................................... 17

Program BINs as User Codes.........................18

Program BINs Locally .......................................18

Program the Module in Standalone Mode 19

TABLE OF CONTENTS

Programming Reference ........................ 20

Program Start Display .....................................20

Serial Number .....................................................20

Initialization Option ..........................................20

Initialize Conﬁrm Option ................................20

Activate Zone 2Bypass...................................21

Zone 2 Bypass Time.........................................22

Relock on Zone 2Change.............................. 22

Activate Zone 3Request to Exit .................23

Zone 3REX Strike Time..................................24

Activate Onboard Speaker............................24

BIN Code Length ..............................................24

Enable Local Processing ................................24

BIN Code .............................................................24

No Communication with Panel ....................25

Remove Keypad.................................................26

Keypad Bus Wiring Speciﬁcations.........27

Product Speciﬁcations ............................28

Readers ..................................................... 29

Digital Monitoring Products, Inc. | 734B Installation and Programming Guide 1

Annunciators

An onboard programmable piezo provides

local annunciation at the 734B. You can

also connect a variety of switched ground

annunciators to the 734B for remote

annunciation.

Indicator LEDs

The 734B provides three indicator LEDs.

The red LED turns on for the same

duration as the door strike relay. The

yellow LED turns on for one second to

indicate receipt of a valid input. The green

LED indicates that data is being sent to

the panel.

The 734B Access Control Module allows you to use the powerful built‑in access control

capability of DMP Panels. The module is designed speciﬁcally to support BIN tables for

the banking industry. For example, use the 734B to control access to ATM vestibules with

magstripe readers.

Connect a 734B to a DMP panel’s Keypad Bus or AX‑Bus to use the powerful built‑in

access control capability of DMP panels or install the module as a standalone access

control device. The 734B includes the following features:

Power Supply

The 734B operates at 12/24VDC from

the power supply supporting a door’s

magnetic lock or door‑strike.

Warning: To avoid the risk of

equipment damage, do not exceed

750mA total output current for zones

connected to the module.

Zone Terminals

Zones 1, 2, and 3on the 734B can be

programmed for a variety of burglary or

access control applications.

ABOUT THE 734B

2 734B Installation and Programming Guide | Digital Monitoring Products, Inc.

Form C Relay

The 10Amp Form C relay draws up to

35mA of current. Refer to the NC/C/NO

(Dry Contact Relay) and the Isolation

Relay sections in this document for more

information.

Programming Connection

The 734B also provides a keypad

programming connection that allows

you to use a standard DMP LCD keypad

for initial setup. Programming can be

completed using a keypad connected to

the 734B or from XR150/XR550Series

panels.

Keypad In and Out

Connections

The keypad in (KYPD IN) connection

receives and transmits data to the panel

keypad bus or AX‑Bus.

The keypad out (KYPD OUT) connection

receives and transmits data out to other

keypads or modules. Install a dual

connector four‑position harness to allow

daisy chain connection to other devices,

up to the maximum number of devices

supported. XR150Series panels support

up to 8devices. XR550Series panels

support up to 16devices. When using the

AX‑Buses with XR550devices, you can

have 32doors, expandable to 96.

Caution: When the 734B is powered

from 24VDC, do not connect devices

to KYPD OUT header.

Digital Monitoring Products, Inc. | 734B Installation and Programming Guide 3

PCB FEATURES

RED

PROG

RED

KYPD OUT

DATA

XMT LED

WIEGAND

READ LED

RELAY

GRN

YEL

RED

+ –

Piezo

1234 5 6 7 810 11 12 13 14

LC ASRED WHT GRN BLK Z1 Z2 Z3 Z4+ Z4–RA GND GND

KYPD IN RED

Door Relay

Terminal

Inputs

Status

Indicator

Outputs Zones

To Panel

Keypad Bus

or AX‑Bus

To Other

Keypad Bus

or AX‑Bus

Piezo

Indicator

LEDs

Keypad

Programming

Header

Address DIP

Switches

Figure 1: PCB Features

4 734B Installation and Programming Guide | Digital Monitoring Products, Inc.

INSTALL THE 734B

Mount the 734B

The module comes in a high‑impact plastic housing that you can mount directly to a

wall, backboard, or other ﬂat surface.

For easy installation, the back and ends of the 734B housing have wire entrances. The

back also contains multiple mounting holes that allow you to mount the module on

a single‑gang switch box. DMP recommends mounting the 734B near the protected

door. See Figure 2for mounting hole locations on the housing base.

1. Remove the PCB from the

plastic housing by loosening

the clips on one side and gently

lifting it out of the housing base.

2. Insert the included screws in the

desired mounting hole locations

and tighten them to secure the

housing to the surface.

3. Reinstall the PCB in the housing

base.

Mounting Holes

Figure 2: Mounting Hole Locations

Digital Monitoring Products, Inc. | 734B Installation and Programming Guide 5

Wire the Magnetic Lock

The 734B provides a Form C (SPDT) relay for controlling locks and other

electronically‑controlled barriers. The three relay terminals marked NO C NC allow

you to connect the device wiring to the relay for module control.

Use an additional power supply to power magnetic locks and door strikes. See

Figure 3and Figure 4for typical magnetic lock and door strike wiring.

The Form C relay draws up to 35mA of current and contacts are rated for 10Amps

(resistive) at 12/24VDC. When connecting multiple locks to the Form C relay, the

total current for all locks cannot exceed 10Amps. If the total current for all locks

exceeds 10Amps, problems may arise and an isolation relay may be needed. See the

Isolation Relay section for information.

PROG

RED RED

KYPD IN

DATA

XMT LED

WIEGAND

READ LED

RELAY

NCCNO

GRNYELRED

Model 333

Suppressor

Normally Closed

–

Magnetic Door Lock

12/24 VDC

Power Supply

Figure 3: Typical Magnetic Lock Wiring

PROG

RED

DATA

XMT LED

WIEGAND

READ LED

RELAY

NCCNO

GRNYELRED

Model 333

Suppressor

Normally Open

–+

DC Door Strike

12/24 VDC

Power Supply

Figure 4: Typical Door Strike Wiring

6 734B Installation and Programming Guide | Digital Monitoring Products, Inc.

KYPD IN / KYPD OUT Connections

• KYPD IN (Keypad In): Receives and transmits data to the panel Keypad

bus/AX‑Bus.

• KYPD OUT (Keypad Out): Receives and transmits data out to other keypad(s) or

module(s). Install a dual‑connector harness to allow connection to other devices

up to the maximum number of devices supported.

When the 734B is powered from 24VDC, do not connect devices to KYPD OUT header.

Status LEDs

The 734B board contains three status LEDs.

• The Red LED turns on for the same duration as the door strike relay.

• The Yellow LED turns on for one second to indicate receipt of a valid input.

• The Green LED indicates data sent to the panel.
