CYP EL-5600 Manuel utilisateur

EL-5600

Multi Format Presentation Switch (including SDI)

OPERATION MANUAL

DISCLAIMERS

The information in this manual has been carefully checked and is

believed to be accurate. CYP (UK) Ltd assumes no responsibility for any

infringements of patents or other rights of third parties which may result

from its use.

CYP (UK) Ltd assumes no responsibility for any inaccuracies that may be

contained in this document. CYP (UK) Ltd also makes no commitment to

update or to keep current the information contained in this document.

CYP (UK) Ltd reserves the right to make improvements to this document

and/or product at any time and without notice.

No part of this document may be reproduced, transmitted, transcribed,

stored in a retrieval system, or any of its part translated into any language

or computer le, in any form or by any means—electronic, mechanical,

magnetic, optical, chemical, manual, or otherwise—without express

written permission and consent from CYP (UK) Ltd.

Version 1.1 August 2011

TRADEMARK ACKNOWLEDGMENTS

All products or service names mentioned in this document may be

trademarks of the companies with which they are associated.

SAFETY PRECAUTIONS

Please read all instructions before attempting to unpack, install or operate

this equipment and before connecting the power supply.

Please keep the following in mind as you unpack and install this

equipment:

• Always follow basic safety precautions to reduce the risk of re,

electrical shock and injury to persons.

• To prevent re or shock hazard, do not expose the unit to rain,

moisture or install this product near water.

• Never spill liquid of any kind on or into this product.

• Never push an object of any kind into this product through any

openings or empty slots in the unit, as you may damage parts inside

the unit.

• Do not attach the power supply cabling to building surfaces.

• Use only the supplied power supply unit (PSU). Do not use the PSU if

it is damaged.

• Do not allow anything to rest on the power cabling or allow any

weight to be placed upon it or any person walk on it.

• To protect the unit from overheating, do not block any vents or

openings in the unit housing that provide ventilation and allow for

sucient space for air to circulate around the unit.

REVISION HISTORY

VERSION NO. DATE SUMMARY OF CHANGE

v1.00 29/07/2013 First release

v1.01 06/07/2013 Corrections

CONTENTS

1. Introduction...........................................6

2. Applications ...........................................6

3. Package Contents ..................................6

4. System Requirements ...........................6

5. Features..................................................7

6. Operation Controls and Functions .......8

6.1 Front Panel................................................... 8

6.2 Rear Panel..................................................... 9

6.3 Remote Control........................................10

6.4 RS-232 Protocols......................................11

6.5 RS-232 Commands..................................12

6.6 OSD MENU .................................................14

7. Connection and Installation .............. 16

8. Specications...................................... 17

8.1 Technical Specications ........................17

8.2 Supported Input/Output Resolution .......18

9. Acronyms............................................. 20

1. INTRODUCTION

The EL-5600 presentation switch is an advanced HDMI, PC, SDI,

Composite, S-Video and Component switcher/scaler. This device can

scale and switch input sources and display them via the HDMI and VGA/

HD outputs simultaneously with their associated audio signals at a wide

range of output resolutions (up to 1080p or WUXGA reduced blanking).

Audio can be de-embedded from HDMI and SDI input sources using the

built-in Digital to Analogue audio converter (DAC), whilst analogue audio

can also be converted to digital for ultimate exibility in audio signal

management. In addition, there is an SDI Loop Out for monitoring or

extending the SDI input signal. Control is via the IR remote, RS-232, or via

front panel buttons and includes an on-screen menu providing settings

and system information.

2. APPLICATIONS

Digital and analogue signal convergence

Convert analogue video/audio signals for use with digital displays

Integrate multiple sources and signal types to a single display in a

Meeting room or Conference hall environment

3. PACKAGE CONTENTS

EL-5600 Multi format switch

Remote Control (CR-117)

15-pin D-Sub to 3 RCA adaptor cable

Power Adaptor

Operation Manual

4. SYSTEM REQUIREMENTS

Source equipment such as Blu-ray players or SDI camera, VGA or HDMI

display and amplier/active speakers with connection cables.

5. FEATURES

Supports HDMI, Composite Video, S-Video, PC (VGA)/HD (Component)

and SDI inputs

Supports HDMI and VGA/Component (with adaptor) outputs

Supports SDI loop-through output

Supports analogue stereo, optical and coaxial digital inputs and

optical digital output, analogue stereo output or embedding to HDMI

output

Supports conversion of multiple video formats and audio input to

HDMI or PC/HD and analogue stereo outputs

Supports EDID and HDCP

Supports 3D de-interlacing, noise reduction and 3D comb lter

Supports frame rate conversion

Supports RS-232, IR remote control, and front panel control

Supports SDI Standards of SMPTE 425M (Level A and Level B), SMPTE

424M, SMPTE 292M, SMPTE 259M-C

Supports SDI bit rates at 2.970 Gb/s, 2.970/1.001 Gb/s, 1.485 Gb/s,

1.485/1.001 Gb/s and 270 Mb/s

Supports SDI signal input and output distances of up to 300m for SD

signals, 200m for HD signals and 100m for 3G signals

Supports SDI Auto video mode detection (3G/SD/HD)

Video functions: Aspect Ratio Adjustment / Video Noise Reduction /

Underscan & Overscan Selection / De-Interlacing

Note: SDI cable operating distance tested with belden 1694A cable. Operating

distances may vary for cables of dierent specications.

6. OPERATION CONTROLS AND FUNCTIONS

6.1 Front Panel

TUPNIREWOP PMOCVSVCRI RETNEUNEMIDS2IMDH1IMDHCP

CSLUX-300I DIGITAL VIDEO SCALER

XGA

720P

1 2 4 63 5

1POWER & POWER LED: Press this button to switch the device on or

to set it to standby mode. Once the device is connected to an active

power supply the LED will illuminate and the device will switch on

automatically.

2IR Receiver window: Receives only the IR signal from the remote

control included in the package.

3INPUT button and LEDs: Press this button repeatedly to cycle

through the input sources sequentially. An LED on the front panel will

illuminate to indicate the selected input source.

4MENU: Press this button to enter the OSD menu.

5−/+: Press these buttons to navigate up and down in the OSD menu.

6ENTER: Press this button to conrm the selection in the OSD menu.

Press this button simultaneously with the '+' (plus) button to instantly

switch the output to XGA resolution or with the '−' (minus) button to

instantly switch the output to 720p resolution.

6.2 Rear Panel

DC 5V

2ECIVRES1ECIVRES

OPTICAL OPTICAL

RS232

L/R L/R

Cr/Pr Cb/Pb Y SV

R L

R LCV

HDMI HDMI 1 HDMI 2

PC/HD PC

SDI

LOOP OUTPUT SDI

OUTPUT INPUT

1 63

2 4 5 7

1OUTPUT:

L/R: Connect to an amplier or active speakers for audio output in

stereo format.

HDMI: Connect to an HDMI display or amplier for video and/or audio

output.

OPTICAL: Connect to an amplier or active speakers for audio output

in digital format.

PC/HD: Connect to a monitor/display for video output. For HD

(Component) output,use the supplied D-Sub 9pin to 3 RCA adaptor

cable for HD resolutions from 480p~1080p.

2SERVICE 1: Reserved for manufacturer use only.

3SDI LOOP OUTPUT: Connect to an SDI display for monitoring of the

SDI input signal or an SDI extender for extending the SDI signal to

further areas.

4RS-232: Connect to a PC/Laptop to use RS-232 commands to control

the device (See Section 6.5 for details on RS-232 commands).

5SERVICE 2: Reserved for manufacturer use only.

6INPUT:

SDI: Connect to an SDI camera or other SDI source for both video and

audio signal conversion.

HDMI 1: Connect to an HDMI source such as Blu-ray/DVD player for

both video and audio signal conversion.

HDMI 2: Connect to an HDMI source such as Blu-ray/DVD player for

both video and audio signal conversion.

L/R: Connect to source's L/R output with 3.5mm mini-jack for audio

signal conversion.

PC/HD: Connect to a PC/Laptop source for video signal input with a

D-Sub 15pin cable.

OPTICAL: Connect to a source's optical output for audio signal

conversion.

YCbCr/HDPbPr + L/R: Connect to source equipment such as a DVD

player for both video and audio signal conversion.

CV + L/R: Connect to a composite video source such as video/DVD

player for both video and audio signal conversion.

SV + L/R: Connect to an S-Video source such as a video/DVD player for

both video and audio signal conversion.

7DC 5V: Plug the 5V DC power supply into the unit and connect the

adaptor to an AC outlet.

6.3 Remote Control

1INPUT: Press this button repeatedly

to cycle through the input sources

sequentially. An LED on the front panel

will illuminate to indicate the selected

input source.

2POWER: Press this button to switch the

device on or to set it to standby mode.

3CV/SV/COMP/PC/HDMI1/HDMI2/SDI:

Direct source selection keys. Press one

of these keys to switch to the selected

source.

4EXIT: Press this button to exit the menu or

the current selection in the OSD menu.

5MENU: Press this button to enter the OSD

menu.

6RESET: Press this button to reset the

device back into the default settings.

CR-117

POWERINPUT

PC HDMI 1 HDMI 2

SDI

EXIT MENU

RESET AUTO

ADJUST

SVCV COMP
