CYP CH-1539TXPLPD Manuel utilisateur

Operation Manual

4K UHD+HDMI/DisplayPort/VGA/USB Type-C to

HDBaseT Switcher

CH-1539TXPLPD

DISCLAIMERS

The information in this manual has been carefully checked and is believed

to be accurate. Cypress Technology assumes no responsibility for any

infringements of patents or other rights of third parties which may result from

its use.

Cypress Technology assumes no responsibility for any inaccuracies that

may be contained in this document. Cypress also makes no commitment to

update or to keep current the information contained in this document.

Cypress Technology reserves the right to make improvements to this

document and/or product at any time and without notice.

No part of this document may be reproduced, transmitted, transcribed,

stored in a retrieval system, or any of its part translated into any language

or computer le, in any form or by any means—electronic, mechanical,

magnetic, optical, chemical, manual, or otherwise—without express written

permission and consent from Cypress Technology.

TRADEMARK ACKNOWLEDGMENTS

All products or service names mentioned in this document are trademarks of

the companies with which they are associated.

SAFETY PRECAUTIONS

Please read all instructions before attempting to unpack, install or operate

this equipment and before connecting the power supply. Please keep the

following in mind as you unpack and install this equipment:

• Always follow basic safety precautions to reduce the risk of re,

electrical shock and injury to persons.

• To prevent re or shock hazard, do not expose the unit to rain, moisture

or install this product near water.

• Never spill liquid of any kind on or into this product.

• Never push an object of any kind into this product through any openings

or empty slots in the unit, as you may damage parts inside the unit.

• Do not attach the power supply cabling to building surfaces.

• Use only the supplied power supply unit (PSU). Do not use the PSU if it

is damaged.

• Do not allow anything to rest on the power cabling or allow any weight to

be placed upon it or any person walk on it.

• To protect the unit from overheating, do not block any vents or openings

in the unit housing that provide ventilation and allow for su󰀩cient space

for air to circulate around the unit.

• Please completely disconnect the power when the unit is not in use to

avoid wasting electricity.

VERSION HISTORY

REV. DATE SUMMARY OF CHANGE

RDV1 2019/04/19 Preliminary release

CONTENTS

1. Introduction......................................................1

2. Applications.....................................................1

3. Package Contents ...........................................2

4. System Requirements.....................................2

5. Features............................................................3

6. Operation Controls and Functions................4

6.1 Front Panel..................................................4

6.2 Rear Panel...................................................4

6.3 IR Cable Pinouts..........................................6

6.4 RS-232 Pinout and Defaults........................6

6.5 WebGUI Control..........................................7

6.5.1 Switch Tab..........................................9

6.5.2 Automation Tab................................. 11

6.5.3 EDID Tab..........................................12

6.5.4 Network Tab .....................................15

6.5.5 System Tab.......................................16

6.6 Telnet Control ............................................17

6.7 RS-232 and Telnet Commands .................18

7. Connection Diagram .....................................27

8. Specications ................................................28

8.1 Technical Specications ............................28

8.2 Video Specications ..................................29

8.3 Audio Specications ..................................31

8.3.1 Digital Audio .....................................31

8.3.2 Analog Audio ....................................31

8.4 Cable Specications..................................32

8.5 HDBaseT Features....................................33

9. Acronyms.......................................................34

1. INTRODUCTION

This 4x1 Multi-Format to HDBaseT Switch is a 4K@60Hz (4:4:4) switcher

featuring HDMI, DisplayPort, USB Type-C, and VGA with stereo inputs

which are automatically converted to the standard HDBaseT format for

use with a compatible receiver. The HDMI, DisplayPort and USB-C inputs

support resolutions up to 4K@60Hz (4:4:4, 8-bit) and the VGA input

supports resolutions up to WUXGA (RB). With the use of the 3.5mm audio

input, stereo audio can be embedded with the VGA source as well. Despite

HDBaseT’s 10.2Gbps bandwidth limitation, high bandwidth 4K UHD HDMI

video sources, up to and including 4K@60Hz (4:4:4, 8-bit), can be supported

and will be automatically converted to 1080p when necessary.

Signal management features such as automatic switching based on input

signal and hot plug detection enable convenient hands-free operation.

Additional functionality such as EDID management, HDCP management and

basic signal event automation (which can send customized CEC commands

to the display automatically) is also available. The USB Type-C input can

provide power (up to 60W) to any connected device and the HDBaseT

output provides PoH (Power over HDBaseT) to power compatible receivers,

providing greater exibility in installations. Control is provided via a front

panel button, WebGUI, Telnet, and RS-232.

2. APPLICATIONS

• Household entertainment sharing and control

• Lecture room display and control

• Showroom display and control

• Meeting room presentation and control

• Classroom display and control

3. PACKAGE CONTENTS

• 1×HDMI/DisplayPort/VGA/USB Type-C to HDBaseT Switcher

• 1×24V/3.75A DC Power Adapter

• 1×Power Cord

• 1×3.5mm to IR Blaster Cable

• 1×3-pin Terminal Block

• 1×Operation Manual

4. SYSTEM REQUIREMENTS

• Source equipment such as media players, video game consoles, PCs, or

set-top boxes.

• A compatible HDBaseT receiver with PoH (PD) support is recommended.

• The use of Premium High Speed HDMI cables, and industry standard

Cat.6, Cat.6a or Cat.7, is highly recommended.

5. FEATURES

• HDMI 2.0, DisplayPort 1.4, and DVI 1.0 compliant

• HDCP 1.x and 2.2 compliant

• Switchable HDMI, DisplayPort, VGA with analog audio, and USB Type-C

inputs

• 1 HDBaseT output

• Digital inputs support up to 4K UHD (18Gbps, 4K@60Hz 4:4:4, 8-bit)

• VGA input supports resolutions up to WUXGA (RB)

• Analog stereo audio is automatically embedded with the video from the

VGA input

• HDBaseT output supports resolutions up to 4K@60Hz (4:2:0, 8-bit) or

4K@30Hz (4:4:4, 8-bit). 4K@50/60Hz (4:4:4, 8-bit) or 4K@any (10/12-bit)

sources will be automatically converted to 1080p.

• Supported HDBaseT feature set: HD Video & Audio, PoH, and Control

Extension (Bi-directional IR/RS-232)

• HDBaseT output transmits video, audio and data over a single Cat.5e/6/7

cable and can reach distances up to 40m/131ft at 4K when using Cat.6a/7

• Supports pass-through of many audio formats including 8 channel LPCM,

Bitstream, and HD Bitstream

• Supports standard PoH from the unit to connected HDBaseT Receivers

(compatible Receivers only)

• Supports manual input selection or automatic input selection with hot plug

detection and “Last Memory” feature

• Basic signal event automation using CEC commands

• Comprehensive EDID management

• USB Type-C port provides up to 60W to power or charge the connected

device

• Controllable via a front panel button, WebGUI, Telnet, and RS-232

6. OPERATION CONTROLS AND FUNCTIONS

6.1 Front Panel

SERV.

CONTROL

SELECT

VGA USB-C HDMI DP

POWER

1 2 3 4

1SERV. Port: This port is reserved for rmware update use only.

2CONTROL Port: Connect directly, or through a network switch, to your

PC/laptop to control the unit via Telnet/WebGUI.

3POWER LED: This LED will illuminate to indicate the unit is on and

receiving power.

4SELECT Button & VGA/USB-C/HDMI/DP LEDs: Press the Select

button to sequentially switch through the available inputs. The currently

selected input’s LED will illuminate green. The LEDs will illuminate red to

indicate inputs that have live sources but are not currently selected.

6.2 Rear Panel

VGA AUDIO USB-C HDMI DP

IN IR

CAT5e/6/7 OUT

EXTENDER BLASTER

RS-232 DC 24V

TX RX G

BYPASS

CONSOLE

1 2 3 4 5 6 7 8 9

1VGA IN Port: Connect to VGA source equipment such as a PC or laptop.

AUDIO IN Port: Connect to the stereo analog output of the device

connected to the VGA input port.

2USB-C IN Port: Connect to USB Type-C video source equipment such

as a PC or laptop.

Note: Not all devices with USB Type-C ports can support video output.

Please verify that the device supports video output from the USB Type-C

port before connecting it.

3HDMI IN Port: Connect to HDMI source equipment such as a media

player, game console, or set-top box.

4DP IN Port: Connect to DisplayPort source equipment such as a PC or

laptop.

5CAT.5e/6/7 OUT Port: Connect to a compatible HDBaseT Receiver with

a single Cat.5e/6/7 cable for transmission of all data signals. PoH will

also be supplied to a connected compatible PD Receiver.

6IR EXTENDER Port: Connect to an IR Extender to receive IR control

signals and extend them to devices connected to the other end of the

HDBaseT connection. Ensure that the remote being used is within direct

line-of-sight of the IR Extender.

7IR BLASTER Port: Connect to the provided IR Blaster to transmit IR

signals from the other end of the HDBaseT connection to devices within

direct line-of-sight of the IR Blaster.

8RS-232 CONSOLE Port: Connect directly to a PC, laptop, or other serial

control device with a 3-pin adapter cable to send RS-232 commands to

control the unit.

RS-232 BYPASS Port: Connect to a PC, laptop, or other serial control

device with a 3-pin adapter cable for the extension of RS-232 signals to

the Receiver.

9DC 24V Port: Plug the 24V DC power adapter into this port and connect

it to an AC wall outlet for power.
