OPERATION MANUAL

EL-42PIP

4 x 2 HDMI Switch with Integrated Multi-View

(Picture In Picture) Technology

DISCLAIMERS

The information in this manual has been carefully checked and is

believed to be accurate. CYP (UK) Ltd assumes no responsibility for any

infringements of patents or other rights of third parties which may result

from its use.

CYP (UK) Ltd assumes no responsibility for any inaccuracies that may be

contained in this document. CYP (UK) Ltd also makes no commitment to

update or to keep current the information contained in this document.

CYP (UK) Ltd reserves the right to make improvements to this document

and/or product at any time and without notice.

No part of this document may be reproduced, transmitted, transcribed,

stored in a retrieval system, or any of its part translated into any language

or computer file, in any form or by any means—electronic, mechanical,

magnetic, optical, chemical, manual, or otherwise—without express

written permission and consent from CYP (UK) Ltd.

Version 1.1 August 2011

TRADEMARK ACKNOWLEDGMENTS

All products or service names mentioned in this document may be

trademarks of the companies with which they are associated.

SAFETY PRECAUTIONS

Please read all instructions before attempting to unpack, install or operate

this equipment and before connecting the power supply.

Please keep the following in mind as you unpack and install this

equipment:

• Always follow basic safety precautions to reduce the risk of fire,

electrical shock and injury to persons.

• To prevent fire or shock hazard, do not expose the unit to rain,

moisture or install this product near water.

• Never spill liquid of any kind on or into this product.

• Never push an object of any kind into this product through any

openings or empty slots in the unit, as you may damage parts inside

the unit.

• Do not attach the power supply cabling to building surfaces.

• Use only the supplied power supply unit (PSU). Do not use the PSU if

it is damaged.

• Do not allow anything to rest on the power cabling or allow any

weight to be placed upon it or any person walk on it.

• To protect the unit from overheating, do not block any vents or

openings in the unit housing that provide ventilation and allow for

sufficient space for air to circulate around the unit.

REVISION HISTORY

VERSION NO. DATE SUMMARY OF CHANGE

v1.00 10/03/2018 First release

v2.00 17/10/2018 Added section 8.2.2 and updated

Section 6.6, 6.7.3 (Matrix Mode)

CONTENTS

1. Introduction...........................................6

2. Applications ...........................................6

3. Package Contents ..................................6

4. System Requirements ...........................7

5. Features..................................................7

6. Operation Controls and Functions.......8

6.1 Front Panel................................................... 8

6.2 Rear Panel..................................................... 9

6.3 Remote Control........................................10

6.4 RS-232 Control..........................................11

6.5 Telnet Control............................................12

6.6 RS-232 and Telnet Commands............13

6.7 WebGUI Control .......................................25

7. Connection Diagram .......................... 42

8. Specifications...................................... 43

8.1 Technical Specifications ........................43

8.2 Video Specifications................................44

9. Acronyms............................................. 46

1. INTRODUCTION

This 4 by 2 Multiviewer is a high performance HDMI switch with

integrated scaling and multi-windowing technology. It is an ideal solution

for monitoring or displaying multiple sources simultaneously for use in

control rooms, conference rooms or classrooms. Video resolutions up to

4K@60Hz and LPCM audio up to 7.1 channels at 192kHz are supported on

both input and output and this unit is fully compatible with the HDCP 1.x

and 2.2 standards.

Any of 4 different HDMI sources may be displayed individually, full

screen, or they can be displayed using a variety of multi-window modes

including quad view and PiP with the output being sent to 2 mirrored

HDMI outputs (4K@50/60Hz output supports quad view and full screen

only). Management of input/window routing, position and sizing can be

controlled easily by use of the front panel controls as well as by WebGUI,

RS-232, Telnet, and IR remote control options.

2. APPLICATIONS

Entertainment Room & Home Theatre

Show Room & Demo Room

Lecture Room & Hall Presentation

Public Commercial Display

3. PACKAGE CONTENTS

1×4 by 2 HDMI Multiviewer

1×12V/3A DC Power Adapter

2×5-pin Terminal Block

1×Remote Control (CR-180)

1×Rackmount Ears (Set of 2)

1×Operation Manual

4. SYSTEM REQUIREMENTS

HDMI source equipment such as media players, video game consoles

or set-top boxes.

HDMI receiving equipment such as HDTVs, monitors or audio

ampliers.

5. FEATURES

HDMI inputs and outputs with 18Gbps (600MHz) 4K UHD support

DVI 1.0 compatible with the use of an HDMI-DVI adaptor

HDCP 1.x and 2.2 compliant

Supports HD resolutions up to 4K@60Hz (4:4:4, 8-bit)

4 HDMI inputs and 2 mirrored HDMI outputs

Seamless switching (no loss of sync to display) when switching

sources in both full screen and multi-window modes

Supports PiP (Picture-in-Picture), side by side, 3+1 quad view, and 2×2

quad view display options with independent audio source selection

Note: 4K@50/60Hz output supports 2×2 Quad View only and is limited to

1080p/4K sources.

Supports the ability to store a multi-window arrangement as a preset

that can be recalled later

Each window can have a border with a selectable colour

Uploadable and freely positioned graphic logo support

Note: The logo and border features are not available when the output is set

to 4K@50/60Hz.

Supports easy adjustment of window size, position and settings in the

PiP windowing mode via the WebGUI

Matrix mode supports input and output resolutions up to

1080p@60Hz with a single shared audio source (Outputs are mirrored

at higher resolutions)

Controllable via front panel buttons, WebGUI, Telnet, RS-232, and IR

remote

6. OPERATION CONTROLS AND FUNCTIONS

6.1 Front Panel

POWER

IN 1 IN 2 IN 3 IN 4

MATRIX

1234

MULTI VIEW

WINDOW SOURCE SELECT

W1 W2 W3 W4

1234

MENU LOCK

ENTER PRESET

EL-42PIP

1 2 53

4 6

7 8 10 11

1POWER: Press this button to power the unit on (green LED) or place it

into stand-by mode (red LED).

2IR WINDOW: Accepts IR signals from the included IR remote for

control of this unit only.

3MATRIX A/B IN1~IN4: These input selection buttons behave

differently depending on the current input and output resolutions in

use.

AAll inputs and outputs are below 4K: Press any of these buttons to

seamlessly switch to the selected input (IN1~IN4)for display on the

associated output (A or B).

BAny input or output is 4K: Press any of these buttons to seamlessly

switch to the selected input (IN1~IN4) for display on both outputs

simultaneously.

Note: Audio for both outputs will follow the most recently selected input

(from A or B) in both modes.

4MULTIVIEW: Press any of these buttons to switch immediately to the

corresponding Multiview output mode.

5WINDOW SOURCE SELECT: Press these buttons to sequentially

switch through the available inputs for each window in Multiview

output modes.

6MENU: Press to enter the LCD menu, or to back out from menu Items.

7ENTER: Press to confirm a selection within the LCD menu or to go

deeper into a menu item.

8+ & −: Press to move up and down or adjust selections within menus.

9LOCK: Press to lock all button functions on the front panel. Press the

button again to release the lock function. The LCD will display a“Lock”

message when the function is active.

10 PRESET: Press this button to switch between the“Preset Load”and

“Preset Save”modes. Pressing the button a 3rd time exits the Preset

menu.

APreset Save: When in“Preset Save”mode, pressing the“Enter” button

will save the currently displayed window layout.

BPreset Load: When in the “Preset Load” mode, pressing the “Enter”

button will load the previously saved window layout.

Note: The audio selection is not saved as a part of the preset, only the

window layout.

11 LCD WINDOW: Displays the unit’s menu, settings, and information.

6.2 Rear Panel

DC 12V

CONTROL SERVICE

GND

RTS

CTS

COM

L/R OUT

HDMI OUT

1234

HDMI IN

1 2 4

5 6 7

1HDMI IN 1~4: Connect to HDMI source equipment such as media

players, game consoles or set-top boxes. DVI source equipment may

be connected by using an HDMI to DVI adapter.

2HDMI OUT A~B: Connect to HDMI TVs, monitors or amplifiers for

digital video and audio output. DVI display equipment may be

connected by using HDMI to DVI adapter.

3L/R OUT: Connect to powered speakers or an amplifier using a 5-pin

adapter cable for balanced stereo analogue audio output.

Note: Only LPCM 2.0 sources are supported. Bitstream audio sources will

be muted automatically.

4COM: Connect directly to a PC, laptop or other serial control device

with a 3-pin adapter cable to send RS-232 commands to control the

unit.

5CONTROL: Connect directly, or through a network switch, to your PC/

laptop to control the unit via Telnet/WebGUI.

6SERVICE: This slot is reserved for firmware update use only.

7DC 12V: Plug the 12V DC power adapter into the unit and connect it

to an AC wall outlet for power.

6.3 Remote Control

1POWER: Power on the machine or enter to

standby mode.

2INFO: Display the current status/

information of the unit.

3A1~A4 & B1~B4: (Matrix Selection)

AWhen all inputs and outputs are

below 4K: Press any of these buttons to

seamlessly switch to the selected input

(1~4) for display on the associated output

(A or B).

BWhen any input or output is 4K: Press

any of these buttons to seamlessly switch

to the selected input (1~4) for display on

both outputs simultaneously.

Note: Audio for both outputs will follow the most recently selected input

(from A or B) in both modes.

4MV1~MV4: (Multiview Selection) Press these buttons to switch

immediately to the corresponding Multiview output mode.

MV1: Switch to 2×2 quad view mode.

MV2: Switch to the 3+1 quad view mode.

MV3: Switch to the side-by-side view mode

MV4: Switch to PiP view mode.

5MATRIX/MULTIVIEW: Press to toggle between the Matrix and

Multiview modes.

6LOCK: Press to lock all button functions on the front panel. Press the

button again to release the lock function.

7ARROWS (///) & OK: Press the arrow buttons to navigate

the LCD menu. Press the“OK”button to confirm a selection or to go

deeper into a menu item.

8MENU: Press to enter the LCD menu.

9EXIT: Press to exit out of the current LCD menu item.

10 W1~W4: (Window Source Selection) Press these buttons to

sequentially switch through the available inputs for each window (1~4)

in Multiview output modes.

INFO POWER

A1 B1

A2 B2

A3 B3

A4 B4

MV1

MV2

MV3

MV4

LOCK MATRIX/

MULTIVIEW

EXIT MENU

SAVE

PRESET

SOURCE

MUTE

DOWN

AUDIO

CR-180

Table des matières

Autres manuels CYP Changer

CYP

CYP CPLUS-V4H1HP Manuel utilisateur

CYP

CYP EL-5500-HBT Manuel utilisateur

CYP

CYP CPRO-3D42S Manuel utilisateur

CYP

CYP CMSI-8D8DSA Manuel utilisateur

CYP

CYP CVSD-41ARN Manuel d'installation

CYP

CYP CLUX-41AP Manuel utilisateur

CYP

CYP PU-8H8HBT Manuel utilisateur

CYP

CYP CP-290 Manuel utilisateur

CYP

CYP CPLUS-31PS Manuel utilisateur

CYP

CYP EL-41S-4K22 Manuel utilisateur

CYP

CYP CSC-5300 Manuel utilisateur

CYP

CYP EL-41PIP Manuel utilisateur

CYP

CYP EL-5400 Manuel utilisateur

CYP

CYP CSDI-44 Manuel utilisateur

CYP

CYP CMLUX-4H4CAT Manuel utilisateur

CYP

CYP CLUX-41W Manuel utilisateur

CYP

CYP CPLUS-V4H1H Manuel utilisateur

CYP

CYP CFSW-51MHL Manuel utilisateur

CYP

CYP CM-345TP Manuel utilisateur

CYP

CYP DT-21 Manuel utilisateur

CYP

CYP EL-5400D Manuel utilisateur

CYP

CYP EL-5300 Manuel utilisateur

CYP

CYP EL-41WX Manuel utilisateur

CYP

CYP OR-HD62CD-4K22 Manuel utilisateur

Manuels Changer populaires d'autres marques

URC

URC Total Control MFS-8 Manuel utilisateur

Azbil

Azbil HPQ-D11 Manuel utilisateur

Sony

Sony DFS-900M Manuel utilisateur

SICK

SICK i17S Manuel utilisateur

F&F

F&F SZR-277 Manuel utilisateur

Shure

Shure UAMS/BK Manuel utilisateur

Dräger

Dräger X-zone Switch Off Manuel utilisateur

Asco

Asco Joucomatic 349 Series Manuel utilisateur

BT Mini Hub Manuel utilisateur

D-Link

D-Link DES-1226G Manuel utilisateur

Johnson Controls

Johnson Controls FS80-C Manuel utilisateur

Alcatel-Lucent

Alcatel-Lucent 7450 ESS-12 Manuel utilisateur

MicroNet

MicroNet SP1200A Manuel utilisateur

Ruijie

Ruijie RG-PF2920 Series Manuel d'installation et d'exploitation

Altinex

Altinex DA1914SX Manuel utilisateur

MiLAN

MiLAN MIL-SM2401M Manuel utilisateur

RJM

RJM MASTERMIND PBC/6X Manuel utilisateur

Atlas

Atlas MMK-KVM8 Manuel utilisateur
