4x1 HDMI 2.0 UHD Switcher with HDCP 2.2
Operation Manual
Operation Manual
DISCLAIMERS
The information in this manual has been carefully checked and
is believed to be accurate. Cypress Technology assumes no
responsibility for any infringements of patents or other rights of third
parties which may result from its use.
Cypress Technology assumes no responsibility for any inaccuracies
that may be contained in this document. Cypress also makes no
commitment to update or to keep current the information contained
in this document.
Cypress Technology reserves the right to make improvements to this
document and/or product at any time and without notice.
COPYRIGHT NOTICE
No part of this document may be reproduced, transmitted,
transcribed, stored in a retrieval system, or any of its part translated
into any language or computer le, in any form or by any means—
electronic, mechanical, magnetic, optical, chemical, manual, or
otherwise—without express written permission and consent from
Cypress Technology.
© Copyright 2016 by Cypress Technology.
TRADEMARK ACKNOWLEDGMENTS
All products or service names mentioned in this document may be
trademarks of the companies with which they are associated.
SAFETY PRECAUTIONS
Please read all instructions before attempting to unpack, install or
operate this equipment and before connecting the power supply.
Please keep the following in mind as you unpack and install this
equipment:
• Always follow basic safety precautions to reduce the risk of re,
electrical shock and injury to persons.
• To prevent re or shock hazard, do not expose the unit to rain,
moisture or install this product near water.
• Never spill liquid of any kind on or into this product.
• Never push an object of any kind into this product through any
openings or empty slots in the unit, as you may damage parts
inside the unit.
• Do not attach the power supply cabling to building surfaces.
• Use only the supplied power supply unit (PSU). Do not use the PSU
if it is damaged.
• Do not allow anything to rest on the power cabling or allow any
weight to be placed upon it or any person walk on it.
• To protect the unit from overheating, do not block any vents or
openings in the unit housing that provide ventilation and allow for
sufcient space for air to circulate around the unit.
REVISION HISTORY
VERSION NO. DATE (DD/MM/YY) SUMMARY OF CHANGE
RDV1 03/10/16 Preliminary Release
CONTENTS
1. Introduction..........................................................................1
2. Applications.........................................................................1
3. Package Contents ..............................................................1
4. System Requirements..........................................................2
5. Features................................................................................2
6. Operation Controls and Functions.....................................3
6.1 Transmitter Front Panel ..................................................3
6.2 Transmitter Rear Panel...................................................4
6.3 Remote Control..............................................................5
6.4 IR Pin Denitions..............................................................5
6.5 RS-232 Protocols .............................................................6
6.6 RS-232 Commands.........................................................7
6.7 Factory Default settings.................................................8
7. Connection Diagram ..........................................................9
8. Specications ....................................................................10
9. Timing .................................................................................11
1
1. INTRODUCTION
This 4 by 1 4K UHD HDMI Switcher is a brand new high performance
design for the next generation of audio/video equipment. It allows
a single HDMI output to switch between 4 HDMI sources. This unit
provides a high level of audio and video performance with support
for resolutions up to 4K@60Hz and high denition digital audio formats
such as LPCM 7.1 (with sampling rates up to 192kHz), Bitstream pass-
through. The included auto switching functionality allows for the
possibility of hands-free, user friendly, operation. Control is provided
via front panel buttons, IR remote, RS-232.
2. APPLICATIONS
• Demo Room Displays
• Hotel Lobby Information Displays
• Showrooms and Demo Rooms
• Public Commercial Displays
• Home Theaters
3. PACKAGE CONTENTS
• 4 by 1 HDMI Switcher
• 5V/2.6A DC Power Adaptor
• Rack ear set
• Operation Manual
• IR Extender (optional)
• IR Remote control (battery included) (optional)
2
4. SYSTEM REQUIREMENTS
• HDMI source equipment such as media players, video game
consoles or set-top boxes.
• HDMI receiving equipment such as HDTVs, monitors or audio
ampliers.
• The use of “Premium High Speed HDMI” cables is highly
recommended.
5. FEATURES
• HDMI 2.0 and DVI 1.0 compliant
• HDCP 2.2 compliant
• 4 HDMI inputs and 1 HDMI output
• 3D signal support (with 3D source and compatible 3D TV)
Supports 4K UHD resolutions up to 4096x2160@60Hz (YUV 4:4:4, 8-bit)
Pass-through of high denition audio including LPCM up to 7.1, and
Bitstream
• CEC pass-through
• Support Internal/External EDID management
3
6. OPERATION CONTROLS AND FUNCTIONS
6.1 Transmitter Front Panel
POWER
IR IN
1234INPUT
321 4 5
1POWER LED: This LED will illuminate to indicate the unit is on and
receiving power.
2INPUT: Press this button to sequentially switch through the available
inputs. Long press input key until LED start to icking, then release
the input key will execute factory default.
31~4: The illuminated LED indicates which source is currently
selected.
4IR Window: Accepts IR signals from the included IR remote for
control of this unit only.
5IR IN: Connect to the provided IR Extender to extend the IR control
range of the unit. Ensure that the remote being used is within direct
line-of-sight of the IR Extender.
4
6.2 Transmitter Rear Panel
INPUT 4INPUT 3INPUT 2 INPUT 1
RS-232
SERVICE
DC 5V
OUTPUT
1 2 3 4 5
1OUTPUT: Connect to HDMI TVs, monitors or ampliers for digital
video and audio output.
2INPUT 1~4: Connect to HDMI source equipment such as media
players, game consoles or set-top boxes.
3RS-232: Connect directly to your PC/laptop to send RS-232
commands to control the unit.
4SERVICE: This slot is reserved for rmware update use only.
5DC 5V: Plug the 5V DC power adapter into the unit and connect it
to an AC wall outlet for power.
5
6.3 Remote Control
1POWER: No function
2INPUT 1~4: Press any of these buttons to
switch to the corresponding input.
6.4 IR Pin Denitions
3
1
2
3
2
1
IR Signal
Power
Grounding
IR Extender
CR-72
POWER
INPUT
34
12
1
2
6
6.5 RS-232 Protocols
MATRIX
►
◄
REMOTE CONTROLLER
PIN Denition PIN Denition
1 NC 1 NC
2Tx 2Rx
3Rx 3Tx
4 NC 4 NC
5 GND 5 GND
6 NC 6 NC
7 NC 7 NC
8 NC 8 NC
9 NC 9 NC
Baud Rate: 115200bps
Data bit: 8 bits
Parity: None
Flow Control: None
Stop Bit: 1
