TOORX WLX70 Manuel utilisateur

Ed : 02/17

INSTRUCTION

Rev : 0000

PART LIST

NUMBER NAME COUNT

1 LEFT BASE FRAME 1

2 RIGHT BASE FRAME 1

3 BACK BEAM FRAME 1

4 LEFT UPRIGHT FRAME 1

5 RIGHT UPRIGHT FRAME 1

6 LEFT OBLIQUE FRAME 1

7 RIGHT OBLIQUE FRAME 1

8 FOOT PLATE 1

9 TOP CROSS FRAME 1

1 GUIDE BAR 2

11 WEIGHT ROD 4

12 WEIGHT CARRIAGE 4

13 LEFT SLIDING TUBE 1

14 RIGHT SLIDING TUBE 1

15 ROUND BAR 24

16 BRACERS 24

17 LEFT BARBELL SLIDING SEAT 1

18 RIGHT BARBELL SLIDING SEAT 1

19 WEIGHT CARRIAGE(LONG) 2

2 BARBELL BAR 1

21 BARBELL ROD SLEEVE 1

22 QUICK CLIP 2

23 LINEAR BEARING 6

24 INTERNAL CIRCLIP 6

25 SPRING 2

26 OBLIQUE SQUARE END CAP 4

27 SQUARE END PLUG 6

28 Φ25 ROUND END PLUG 4

29 Φ3 ROUND END PLUG 4

3 BALL PLUG 6

31 RUBBER CUSHION 4

32 EXPANSION SCREWS 4

33 M1 X75 HEX BOLT 4

34 M1 X7 HEX BOLT 12

35 M1 X2 HEX BOLT 12

36 M1 X16 HEX BOLT 32

37 M1 X1 SCREWS 6

38 M8X8 SCREWS 2

39 M1 ARC WASHER 8

4 M1 WASHER 72

41 Φ5 MM WASHER 4

42 Φ38MM WASHER 2

43 M10 LOCKNUT 12

PART DRAW

(1)LEFT BASE AME (2)RIGHT BASE FRAME (3)BACK BEAM FRAME (4)LEFT UPRIGHT FRAME

(5)RIGHT UPRIGHT AME (6)LEFT OBLIQUE FRAME (7)RIGHT OBLIQUE FRAME (8)FOOT PLATE

(9)TOP CROSS AME (1 )GUIDE BAR (11)WEIGHT ROD (12)WEIGHT CARRIAGE

(13)LEFT SLIDING TUBE (14)RIGHT SLIDING TUBE (15)ROUND BAR (16)BRACERS

(17)LEFT BELL

SLIDING SEAT

(18)RIGHT BARBELL

SLIDING SEAT

(2 )BARBELL BAR

(3 )BALL PLUG

(25)SPRING (26)OBLIQUE

SQUARE END CAP

(31)RUBBER

CUSHION

(22)QUICK CLIP

(27)SQUARE

END PLUG

(24)INTERNAL

CIRCLIP

(29)¦µ3 MM ROUND

END PLUG

(28)¦µ25MM ROUND

END PLUG

(21)BARBELL ROD

SLEEVE

(23)LINEAR

BEARING

(19)WEIGHT

CARRIAGE

(LONG)

(35)M1 X2 HEX BOLT(32)EXPANSION EWS (33)M1 X75 HEX BOLT (34)M1 X7 HEX BOLT

(4 )M1 HER (43)M1 LOCKNUT

(39)M1 ARC WASHER

(42)¦µ38MM WASHER(41)¦µ5 MM WASHER

(36)M1 X16 HEX OLT (37)M1 X1 SCREWS (38)M8X8 SCREWS

EXPLODED DRAW

2 21

41 37

36 4

STEP 1

A. ATTACH LEFT BASE FRAME ( 1) AND RIGHT BASE FRAME ( 2) TO BACK BEAM FRAME

(3) USING 4PCS M1 X7 HEX BOLT (34) , 4PCS M1 ARC WASHER (39) AND 4PCS M1

WASHER (4 ) . THEN USE 4PCS M1 X16 HEX BOLT (36) , 4PCS M1 ARC WASHER

(39) AND 4PCS M1 WASHER (4 ) FROM THE TOP SIDE TO FIX AS SHOW

B. ATTACH FOOT PLATE (8) TO LEFT BASE FRAME ( 1) AND RIGHT BASE FRAME ( 2)

USE 4PCS M1 X7 HEX BOLT (34) , 8PCS M1 WASHER (4 ) AND 4PCS M1 LOCKNUT

（43）AS SHOW

34 4

43 4

34 4

4 36

STEP 2

A. ASSEBMLE LEFT UPRIGHT FRAME (4) AND RIGHT UPRIGHT FRAME (5) TO THE

BRACKET OF LEFT BASE FRAME ( 1) AND RIGHT BASE FRAME ( 2) USE 4PCS M1 X75

HEX BOLT (33) , 8PCS M1 WASHER (4 ) AND 4PCS M1 LOCKNUT （43）

B. ATTACH TOP CROSS FRAME (9) TO LEFT UPRIGHT FRAME (4) AND RIGHT UPRIGHT

FRAME (5) USING 4PCS M1 X7 HEX BOLT (34) , 8PCS M1 WASHER (4 ) AND 4PCS

M1 LOCKNUT （43）

C. ASSEMBLE ROUND BAR (15) INTO LEFT UPRIGHT FRAME (4) AND RIGHT UPRIGHT

FRAME (5) USING 12PCS BRACER (16) , 12PCS M1 WASHER (4 ) AND 12PCS

M1 X16 HEX BOLT （36）AS SHOW

4 4

43 4

4 4

34 4

16 4 36

STEP3

A. ATTACH LEFT OBLIQUE FRAME (6) TO LEFT UPRIGHT FRAME (4) AND LEFT BASE

FRAME ( 1) USING 4PCS M1 X2 HEX BOLT (35) , 4PCS M1 WASHER (4 ) .

ASSEMBLE RIGHT OBLIQUE FRAME (7) AT THE SAME WAY

B. ASSEMBLE 2PCS WEIGHT ROD (11) TO LEFT OBLIQUE FRAME (6) USING 2PCS

M1 X2 HEX BOLT (35) , 2PCS M1 WASHER (4 ) . ATTACH WEIGHT CARRIAGE (12)

TO WEIGHT ROD (11) USING 2PCS M1 X1 SCREW TO FIX AS SHOW

ASSEMBLE RIGHT SIDE SAME AS LEFT SIDE

4 35

STEP4

A. ASSEMBLE GUIDE BAR (1 ) THROUGH THE HOLE FROM THE TOP SIDE OF RIGHT

UPRIGHT FRAME (5), THEN SLIDE RIGHT BARBELL SLIDING SEAT (18) ONTO GUIDE

BAR (1 ), NEXT RUBBER CUSHION (31) , Φ5 MM WASHER (41) , SPRING (25) ,AGAIN

Φ5 MM WASHER (41) , RUBBER CUSHION (31), FINALLY RIGHT SLIDING TUBE （14）,

AFTER HAVE ALL THESE PARTS ON AS SHOW , INSERT THE END OF GUIDE BAR (1 )

INTO THE HOLE AT THE BOTTOM OF RIGHT UPRIGHT FRAME (5) . USING 1PCS

M1 X16 HEX BOLT (36) AND 1PCS M1 WASHER (4 ) TO TIGHT THE GUIDE BAR (1 )

FROM THE BOTTOM , AND THEN USING 1PCS M1 X16 HEX BOLT (36) , 1PCS M1

WASHER (4 ) AND 1PCS Φ38MM WASHER (42)TO TIGHT THE GUIDE BAR (1 ) FROM

THE TOP SIDE AS SHOW

B. ASSEMBLE GUIDE BAR (1 ) AT THE LEFT SIDE AS THE SAME WAY

STEP5

A. HAVE PARTS OF SLIDE LEFT BARBELL SLIDING SEAT (17), SLIDE RIGHT BARBELL

SLIDING SEAT (18) AND BARBELL ROD SLEEVE (21) IN LINE , AND THEN SLIDE

BARBELL BAR （2 ） THROUGH ALL THESE 3 PARTS , USING 2PCS M8X8 SCREW(38)

TO FIX THEM AS SHOW

B. SLIDE WEIGHT CARRIAGE (LONG)(19) ONTO BARBELL BAR （2 ）USING 2PCS

M1 X1 SCREW (37) TO FIX , THEN ATTACH QUICK CLIP (22) ON AS SHOW

38 22
