SMART Table 230i Manuel d'installation

SMARTTable™ 230i

interactive learning center

Hardware user’s guide

Product registration

If you register your SMART product, we’ll notify you of new features and software upgrades.

Keep the following information available in case you need to contact SMARTSupport.

Serial number:

Date of purchase:

Trademark notice

SMARTTable, SMARTBoard, SMARTExchange, SMARTPodium, DViT, SMARTNotebook, SMARTDocumentCamera, SMARTSync, smarttech, the SMART logo

and all SMART taglines are trademarks or registered trademarks of SMARTTechnologiesULC in the U.S. and/or other countries. Windows and Windows Vista are either

registered trademarks or trademarks of Microsoft Corporation in the U.S. and/or other countries. Mac and Macintosh are registered trademarks of Apple Inc., registered in

the U.S. and other countries. All other third-party product and company names may be trademarks of their respective owners.

into any language in any form by any means without the prior written consent of SMARTTechnologiesULC. Information in this manual is subject to change without notice

and does not represent a commitment on the part of SMART.

One or more of the following patents: US6326954 and US7151533. Other patents pending.

10/2011

Important information

W W A R N I N G

lFailure to follow the installation instructions shipped with your SMARTTable™ interactive

learning center could result in personal injury and product damage.

lEnsure that any cables extending across the floor to your SMART product are properly

bundled and marked to prevent a trip hazard.

lMake sure an electrical socket is near your SMART product and remains easily accessible

during use.

lLock the casters before allowing children to use your table.

lDo not climb (or allow children to climb) on your table. Climbing on your table could result in

personal injury and product damage.

lTo reduce the risk of fire or electric shock, do not expose your SMART product to rain or

moisture.

lUse caution when servicing your table’s internal parts even after you disconnect the power.

The uninterruptible power supply (UPS) continues to provide dangerous voltages to the

computer and projector after you disconnect the AC power source.

lDo not stare (or allow children to stare) directly into the projector’s beam of light.

lDo not attempt to service the projector other than by performing routine lamp replacement.

Only an authorized service provider should provide service. Aside from the lamp module,

there are no users-serviceable parts inside the unit.

lDo not remove any screws other than those specified in the lamp replacement instructions.

lDo not touch or replace the projector lamp (which will be very hot) for at least an hour after

shutdown. Touching the lamp can cause severe burns.

lDo not puncture, crush, heat or disassemble the remote control battery, expose it to fire or

any liquid, short its terminals, or abuse the battery in any other way because this may cause

the battery to explode or ignite, and could cause a fire or personal injury.

lIf the remote control battery leaks, ensure that you do not get battery fluid in your eye. If you

do, immediately rinse the affected eye with water and seek medical attention.

lDo not install the remote control battery backwards or reverse its polarity. Do not install

battery types other than the one specified in the documentation. Both of these actions can

cause damage to the remote control and can cause a fire or personal injury.

C C A U T I ON

lDisconnect the power cable only after you turn off the table as documented in this guide and

the indicator lights and fans turn off. Disconnecting the power cable at any other time can

shorten the life of the projector lamp.

lDo not place cords, boxes or other items on the surface of your table. Doing so can scratch

the surface.

lIf your SMART product becomes wet, dry it completely before turning it on.

lSMART Technologies recommends that you use the remote control to complete only the

procedures documented in this guide. Using the remote control for other purposes may

change the projector’s settings, which were specifically configured for the table.

I I M P O R T A N T

lDo not operate your table’s projector in environments that are higher than 10,000' (3,000 m)

above sea level.

lYour SMARTTable is sensitive to infrared radiation and can interpret bright light as touches.

It could be necessary to turn off or remove any pot lights or other incandescent lighting in the

room and move your table away from bright windows, or close any open blinds or curtains

before using your SMARTTable.

lYour table’s surface does not respond to touch until the computer completes its startup

process. Wait 30 to 60 seconds after you turn on your table before you touch the surface.

lBefore you clean your table, turn it off so that you do not inadvertently start applications when

you wipe the surface.

lDo not place keyboards, mouse devices or other objects on the touch surface. The camera

may interpret these objects as touches if they are placed on the touch surface.

lThis product contains lithium button cell batteries in the computer and in the remote

control (perchlorate material—special handling may apply).

I M P O R T A N T I N F O R M A T I O N

Contents
Important information i
Chapter 1: Getting started 1
About your SMART Table 1
How your SMARTTable works 2
What’s included with your SMARTTable 3
Using your SMARTTable with other SMART products 5
Chapter 2: Using your SMARTTable 7
Turning your SMARTTable on or off 7
Using SMARTTable software 10
Using your SMARTDocumentCamera with your table 12
Chapter 3: Maintaining your SMARTTable 13
Cleaning your SMARTTable 13
Updating the software 13
Orienting the image 14
Replacing the projector lamp 16
Chapter 4: Using the remote control 17
Locating the remote control 18
Setting the projector for high altitudes 18
Replacing the remote control battery 19
Appendix A: Troubleshooting 21
Troubleshooting power and connection issues 21
Setting up your table for troubleshooting touch issues 22
Restarting SMARTTable Activities 23
Diagnosing basic problems with touch 24
Remodeling the background 26
Appendix B: Hardware environmental compliance 27
Waste Electrical and Electronic Equipment regulations (WEEE directive) 27
Restriction of Certain Hazardous Substances (RoHS directive) 27
Batteries 27
Packaging 28
Covered electronic devices 28
China’s Electronic Information Products regulations 28
U.S. Consumer Product Safety Improvement Act 28
iii

Chapter 1: Getting started

About your SMART Table 1

How your SMARTTable works 2

What’s included with your SMARTTable 3

The SMART Table USB drive 3

Power cable 3

Keys 4

Projector remote control 4

Installation instructions 4

Uninterruptible power supply (UPS) 4

UPS installation instructions 4

Warranty information 5

Using your SMARTTable with other SMART products 5

This guide is intended for teachers and application developers. It introduces you to SMARTTable

software and explains how to use, maintain and troubleshoot your table.

N N O T E

For information on setting up your SMARTTable interactive learning center or its accessories, see

the SMARTTable 230i textless installation instructions (smarttech.com/kb/141081) included with

your SMARTTable.

About your SMART Table

Your SMARTTable interactive learning center has a

touch-sensitive surface. By touching the surface, students can

create, select, move and resize digital objects. More than one

student can touch the surface at a time. This encourages

collaboration and cooperation as students learn and play together.

Using a Wi-Fi® network connection to a computer with

SMARTSync™ classroom management software, teachers can

Chapter 1

observe students’ tabletop activities from a distance, take control of the table, and capture and print

the tabletop image.

SMARTTable software includes interactive applications, learning activities and educational games.

You can also download any of the SMARTTable activity packs or applications available on the

SMARTExchange™ website (exchange.smarttech.com) and customize the activities using

SMARTTable Toolkit. Install and run the toolkit on your computer and then transfer your activity

packs using a USB drive or SMARTSync software.

You can use your table with other SMART products, including the SMARTDocumentCamera™ and

SMARTNotebook™ collaborative learning software, as part of an overall learning solution. For

example, you can introduce a new concept to students on a SMARTBoard™ interactive whiteboard,

and then ask the students to explore the idea in detail using the SMARTTable interactive learning

center.

How your SMARTTable works

Your table contains five main components:

lComputer

lProjector

lSpeakers

lCamera

lSurface

lUninterruptible power supply (UPS)

The computer runs the SMARTTable software, the projector projects the computer’s display onto the

surface, the speakers play the computer’s audio and the camera detects students’ touch on the

surface. Combined, these components allow students to interact with SMARTTable software.

The computer, projector, speakers, camera and UPS are inside the SMARTTable cabinet, and the

surface is on the SMARTTable top. The uninterruptible power supply (UPS) provides backup power

to the computer if power is unexpectedly disconnected from the SMARTTable, allowing the

computer to shut down safely.

Your SMARTTable uses technology based on DViT™ (DigitalVisionTouch) technology to detect

multiple students’ touches. Other SMART products use DViT technology, including select

SMARTBoard interactive whiteboards, SMARTBoard interactive displays and SMARTPodium™

interactive pen displays.

C H A P T E R 1

Getting started

What’s included with your SMARTTable

Your table includes the following items:

lSMART Table USB drive

lPower cable

lKeys

lProjector remote control

lInstallation instructions

lUninterruptible power supply (UPS)

lWarranty information

The SMART Table USB drive

The USB drive contains the SMARTTable Toolkit software as

well as links to user’s guides. Use the USB drive to do the

following:

lInstall the SMARTTable Toolkit on a Windows® or Mac

computer

lInstall new activity packs and applications on your SMARTTable

lUpdate any SMARTTable software

N N O T E S

lThe SMART Table USB drive can store up to 2 GB of files (preloaded software takes up

approximately half of the storage capacity).

lIf you lose your SMART Table USB drive, you can order a new one from your reseller, or you

can use another USB drive to transfer files to your table. The USB drive you use must be

formatted for use with Windows operating systems.

Power cable

The power cable provided with your SMARTTable is specific to

your region and should work with outlets in your school.

Connect the power cable to the SMARTTable following the

instructions in the SMARTTable 230i textless installation instructions (smarttech.com/kb/141081).

C H A P T E R 1

Getting started

If you must extend the power cable across the floor, ensure it’s properly marked to prevent a trip

hazard. SMARTTechnologies recommends that you connect the power cable to a power bar rather

than directly to an outlet. If you lose the cable, or if it becomes damaged, contact your support

representative for a replacement.

Keys

The keys allow you to lock the cabinet to prevent unwanted access to the

computer and projector. Store the keys in a convenient, safe location.

Projector remote control

The projector remote control is stored on the inside of the cabinet. You don’t need the remote control

while using the table, but SMART recommends that you keep it inside the cabinet so you can easily

locate it when you need to turn the projector on or off or to adjust the projector’s settings while

servicing the table.

Installation instructions

Follow the SMARTTable 230i textless installation instructions (smarttech.com/kb/141081) to

unpack and set up your SMARTTable.

Uninterruptible power supply (UPS)

The UPS provides power to the computer when power fails or if the power cable is disconnected

during table operation. The UPS generates an audible alarm and signals the computer to shut down

safely to protect the computer’s operating system from damage.

I I M P O R T A N T

lThe UPS does not provide power to other table components. You must connect the

SMARTTable to a power outlet to resume normal operation.

lThe UPS is not installed in your SMARTTable when you receive it. You can use the table

without the UPS, but SMART highly recommends that you install the UPS to protect the

computer’s operating system when power is accidentally or suddenly removed.

UPS installation instructions

Use the installation instructions provided or see Installing the 110/120V Battery Backup in Your

SMARTTable ST230i (smarttech.com/kb/141058) or see Installing the 220/240V Battery Backup in

Your SMARTTable ST230i (smarttech.com/kb/141684) to install and connect the UPS, and to

connect the projector and computer cables.

C H A P T E R 1

Getting started

Autres manuels pour Table 230i

Table des matières

Autres manuels SMART Tableau blanc interactif

SMART

SMART 880i5-SMP Manuel utilisateur

SMART

SMART Room System Manuel d'utilisation

SMART

SMART SBID 8070i-G4 Manuel utilisateur

SMART

SMART kapp 84 Manuel utilisateur

SMART

SMART Board 685ix Manuel utilisateur

SMART

SMART Board 600i3 Manuel utilisateur

SMART

SMART 8070i-SMP Manuel utilisateur

SMART

SMART SMART Board 885-SMP Manuel utilisateur

SMART

SMART board 8000i-G4 series Manuel d'utilisation

SMART

SMART Inforce 67X1 Manuel utilisateur

SMART

SMART 600i Manuel utilisateur

SMART

SMART KAPP iQ PRO 65 Manuel utilisateur

SMART

SMART SMART Board Manuel utilisateur

SMART

SMART M600i6 Manuel utilisateur

SMART

SMART Podium ID350 Manuel utilisateur

SMART

SMART SBM600i6 Manuel utilisateur

SMART

SMART RTM-ATCA-F125 Guide de démarrage rapide

SMART

SMART KAPP-IQ65-V2 Manuel utilisateur

SMART

SMART KAPP42 Manuel utilisateur

SMART

SMART Smart Board 6055i Manuel utilisateur

SMART

SMART Room System SRS-LYNC-XS Manuel de service

SMART

SMART KAPP iQ PRO 55 Manuel de service

SMART

SMART Podium 500 Series Manuel utilisateur

SMART

SMART FS640 Manuel utilisateur

Manuels Tableau blanc interactif populaires d'autres marques

HitachiSoft

HitachiSoft StarBoard FX-TRIO-88W Manuel utilisateur

Buhl

Buhl LyteBoard Manuel utilisateur

SMART Board

SMART Board 680 Manuel utilisateur

Legamaster

Legamaster e-SCREEN ETX Manuel utilisateur

SMART Board

SMART Board SBM685ix2 Manuel utilisateur

Seneca

Seneca eno Manuel utilisateur

BenQ

BenQ RP840G Manuel utilisateur

Olivetti

Olivetti OLIBOARD Manuel utilisateur

Turning Technologies

Turning Technologies MOBIVIEW Manuel utilisateur

Panasonic

Panasonic UB-5335 Manuel utilisateur

Dukane

Dukane ITP84 Manuel utilisateur

Bretford

Bretford EDUIMS Guide de configuration

Panasonic

Panasonic Panaboard UB-5315 Manuel utilisateur

Plus

Plus M-11S Manuel utilisateur

TRIUMPH BOARD

TRIUMPH BOARD ULTRA SLIM Manuel utilisateur

Returnstar Interactive Tech

Returnstar Interactive Tech IQBoard DVT V7.0 Manuel utilisateur

AVer

AVer CP series Manuel utilisateur

Genee

Genee 56" Manuel utilisateur
