SMARTBoard™ 685ix

InteractiveWhiteboardSystem

Configuration and User’s Guide

Product Registration

If you register your SMART product, we’ll notify you of new features and software

upgrades.

Keep the following information available in case you need to contact SMART

Technical Support.

Interactive Whiteboard Serial Number:_____________________________________

Projector Serial Number: _______________________________________________

Date of Purchase: ___________________________________________________

FCC Warning

This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the

FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is

operated in a commercial environment. This equipment generates, uses and can radiate radio frequency energy and, if not

installed and used in accordance with the manufacturer’s instructions, may cause harmful interference to radio

communications. Operation of this equipment in a residential area is likely to cause harmful interference in which case the

user will be required to correct the interference at his own expense.

Trademark Notice

The SMART logo, SMART Board, SMART Notebook, SMART Meeting Pro, Actalyst, SMART GoWire, SMART Bridgit,

SMART Podium, SMART Hub and smarttech are trademarks or registered trademarks of SMART Technologies ULC in the

U.S. and/or other countries. Windows, Microsoft, Excel, PowerPoint and Internet Explorer are either registered trademarks

or trademarks of Microsoft Corporation in the U.S. and/or other countries. Apple, Macintosh, Mac, iMac and PowerBook are

trademarks of Apple Inc., registered in the U.S. and other countries. HDMI is a trademark or registered trademark of HDMI

Licensing LLC. VESA is a registered trademark of The Video Electronics Standards Association. All other third-party

product and company names may be trademarks of their respective owners.

transcribed, stored in a retrieval system or translated into any language in any form by any means without the prior written

consent of SMART Technologies ULC. Information in this manual is subject to change without notice and does not

represent a commitment on the part of SMART.

Patent No. US5448263; US6141000; US6320597; US6326954; US6337681; US6540366; US6741267; US6747636;

US7151533; US7289113; US7499033; US7626577; US7687736; US7757001;CA2058219; and CA2252302. Other patents

pending.

05/2011

Introduction

Important Information

Read This Section First

NOTE

If you own a SMART product other than a SMART Board™ 685ix interactive

whiteboard system, refer to the installation guide that came with your product for

relevant warnings and maintenance instructions.

In this document, “SMART Board 685ix interactive whiteboard system” refers to the

SMART Board 685 interactive whiteboard and its UX60 projector, accessories and

optional equipment. Before you install and use the SMART Board 685ix interactive

whiteboard system, read and understand the safety warnings and precautions in this

user’s guide, SMART Board 600 and SBD600 Series Interactive Whiteboard

Installation and User's Guide (document 1414) and Important Information for SMART

Board 685ix Interactive Whiteboard Users (document 137499). These safety warnings

and precautions describe the safe and correct operation of the interactive whiteboard

system and its accessories, helping you prevent injuries and equipment damage. You

must always ensure that the interactive whiteboard system is being used correctly.

The UX60 projector included with your system is designed to work with certain

SMART Board interactive whiteboard models only. Contact your authorized SMART

reseller for more information.

ii | INTRODUCTION – IMPORTANT INFORMATION

Safety Warnings, Cautions and Important

Information

WARNINGS – GENERAL

• Do not climb (or allow children to climb) on any

part of your wall-mounted SMART Board

interactive whiteboard system.

• Climbing on the interactive whiteboard or

projector boom could result in personal injury or

product damage. Do not climb on, hang from or

suspend objects from the UX60 projector.

• To reduce the risk of fire or electric shock, do not

expose any component of your SMART Board

interactive whiteboard system to rain or moisture.

• Failure to follow the installation instructions shipped with your SMART product

could result in personal injury and damage to the product.

• Make sure that an electrical socket is near your SMART product and remains

easily accessible during use.

• When mounting the projector on a framed or hollow wall, you must attach both

the mounting bracket and safety tether to a stud to safely support the

projector’s weight. If you use only drywall anchors, the drywall can fail,

resulting in product damage and possible personal injury.

• Ensure that any cables extending across the floor to your SMART product are

properly bundled and marked to prevent a trip hazard.

WARNINGS – PROJECTOR

• Do not stare (or allow children to stare) directly into the beam of light created

by the projector. Instruct children not to look in the direction of, or stare at, this

beam of light. Encourage users to keep their back to the projector when

working at the interactive whiteboard. Before they turn to face the audience,

users should step sideways, out of the projector’s beam.

• Do not attempt to service the projector other than performing routine lamp

replacement. Other than the lamp module, there are no user-serviceable

parts inside the unit. Do not open or disassemble the projector as this may

cause electric shock.

• This projector detects its remaining lamp life. Replace the lamp when a lamp

life warning message appears. If you continue to use the projector after the

replacement message appears, the lamp can shatter or burst, scattering

glass throughout the projector.

iii | INTRODUCTION – IMPORTANT INFORMATION

• If the lamp has shattered or burst:

– Call an authorized SMART reseller for instructions. Do not attempt to

replace the lamp.

– Do not touch the glass fragments because they can cause injury.

– Leave and then ventilate the area where the lamp shattered or burst.

– Wash your hands thoroughly if you have come into contact with 

lamp debris.

– Thoroughly clean the area around the projector, and discard any edible

items placed in that area because they could be contaminated.

• When returning the projector to the wall-mounting bracket, replace all of the

screws you removed when you removed the projector. Failure to do so can

result in the projector falling from the boom resulting in product damage and

personal injury.

CAUTIONS

• Avoid turning off the projector during the lamp ignition phase because this can

lead to premature lamp failure. Before turning off the projector, keep the lamp

on for a minimum of 15 minutes after turning it on to preserve the lamp life.

• When you switch the projector off, ensure that the cooling cycle is complete

before disconnecting the power. Allow 90 seconds for the projector to

complete the cooling cycle.

• Never operate this unit immediately after moving it from a cold location to a

warm location. When the unit is exposed to such a change in temperature,

moisture can condense on the lens and crucial internal parts. Allow the

system to reach room temperature before operation to prevent possible

damage to the unit.

• In a high altitude location where the altitude is over 6000' (1829 m), the air is

thinner and cooling efficiency is reduced, so use the projector with the fan

mode set to High.

• Do not block the projector’s ventilation slots and openings.

• Do not place in hot locations, such as near heating equipment. Doing so could

cause a malfunction and shorten the life of the projector.

• Do not set up or use the interactive whiteboard system in an area with

excessive levels of dust, dirt, humidity or smoke.

• Do not scrub the surface of the mirror with the supplied cleaning cloth. Use

the cloth with a light touch. Do not put cleaning solvents on the mirror or

cleaning cloth.

iv | INTRODUCTION – IMPORTANT INFORMATION

• Cycling power to the projector repeatedly can lock or damage the interactive

whiteboard system. After you turn off the system, wait at least 15 minutes for

cooling before turning on the system.

• You must connect the USB cable that came with your SMART Board

interactive whiteboard to a computer that has a USB compliant interface and

that bears the USB logo. In addition, the USB source computer must be

compliant with CSA/UL/EN 60950 and bear the CE mark and CSA and/or UL

mark(s) for CAS/UL 60950. This is for operating safety and to prevent

damage to the SMART Board interactive whiteboard.

• Do not add extra weight or apply pressure to the UX60 projector boom, the

wall-mounted interactive whiteboard or its pen tray. SMART Technologies

designed the brackets to support only the weight of the components during

normal use.

• If the interactive whiteboard system requires replacement parts, make sure

that the service technician uses replacement parts specified by SMART

Technologies, or parts with the same characteristics as the original.

IMPORTANT

• Turn off the SMART product before cleaning it.

• Using the UX60 projector system near a TV or radio can cause interference to

the images or sound. If this happens, move the TV or radio away from the

projector.

• Do not place the interactive whiteboard system near any appliance that

generates a strong magnetic field.

• Do not place the interactive whiteboard system in direct sunlight.

• The screws that secure the interactive whiteboard to the wall are located

directly behind the pen tray. The pen tray must be removed before you can

remove the interactive whiteboard. When you secure the pen tray, you also

secure the interactive whiteboard.

• The SMART Board 685ix interactive whiteboard system does not include

speakers. Consult your authorized SMART reseller to determine your audio

output options.

• Disconnect the product from its power source when it is not used for a long

period.

v | INTRODUCTION – IMPORTANT INFORMATION

Transporting the SMART Board 685ix Interactive

Whiteboard System

If you need to ship any part of your SMART Board 685ix interactive whiteboard

system, repack it with the original packaging. If the original packaging is no longer

available, you can purchase replacement packaging from your authorized SMART

reseller.

If you prefer to use your own packaging materials, make sure that you adequately

protect the unit. Ship the interactive whiteboard in an upright position to deter shippers

from placing heavy objects on it.

vi | INTRODUCTION – IMPORTANT INFORMATION

Contents

Important Information ..............................................................................................i

Read This Section First ....................................................................................i

Safety Warnings, Cautions and Important Information ....................................ii

1About Your SMART Board 685ix Interactive Whiteboard System ........................ 1

SMART Board 685ix Interactive Whiteboard System Features...................... 2

Standard Accessories..................................................................................... 6

Optional Accessories ...................................................................................... 8

2Before Installing Your SMART Board 685ix Interactive Whiteboard System ...... 11

Environmental Requirements ....................................................................... 12

3Using Your UX60 Projector ................................................................................. 15

Components of the UX60 Projector .............................................................. 16

Remote Control............................................................................................. 18

Extended Control Panel (ECP) ..................................................................... 21

4Integrating Other Devices with Your Interactive Whiteboard System ................. 25

Connecting Computers and Peripheral Devices to Your UX60 Projector..... 26

Temporarily Connecting Devices to Your Interactive Whiteboard System ... 32

Video Format Compatibility........................................................................... 34

Connecting a SMART Hub to Your Extended Control Panel........................ 37

Installing SMART Software........................................................................... 39

5Maintaining and Troubleshooting Your SMART Board 685ix Interactive Whiteboard

System ................................................................................................................ 41

After Installing Your SMART Board 685ix Interactive Whiteboard System... 42

Securing the Pen Tray and Interactive Whiteboard ...................................... 48

Maintaining Your SMART Board 685ix Interactive Whiteboard System ....... 50

viii | CONTENTS

Troubleshooting Your SMART Board 685ix Interactive Whiteboard System 53

Troubleshooting Image Issues...................................................................... 57

Other Common Issues.................................................................................. 60

Occasional Maintenance Instructions ........................................................... 64

6Remotely Managing Your SMART Board 685ix Interactive Whiteboard System 71

Connecting Your Serial Interface to the UX60 Projector .............................. 73

RS-232 Programming Commands................................................................ 75

Simple Network Management Protocol (SNMP)........................................... 87

Web Page Management ............................................................................... 87

7UX60 Projector Menu Commands ...................................................................... 95

Source Image Adjustment ............................................................................ 96

Audio Settings Adjustment............................................................................ 99

Default Settings Adjustment ......................................................................... 99

Network Settings Adjustments.................................................................... 101

Language Preference Setting ..................................................................... 103

Information Panel........................................................................................ 103

ADisabling USB Communications ....................................................................... 105

Disabling the ECP’s USB Port .................................................................... 105

BHardware Environmental Compliance............................................................... 107

Waste Electrical and Electronic Equipment Regulations (WEEE Directive)107

Restriction of Certain Hazardous Substances (RoHS Directive) ................ 107

Batteries...................................................................................................... 107

Packaging ................................................................................................... 108

China’s Electronic Information Products Regulations................................. 108

U.S. Consumer Product Safety Improvement Act ...................................... 108

CCustomer Support ............................................................................................. 109

Online Information and Support.................................................................. 109

Training....................................................................................................... 109

Autres manuels pour Board 685ix

Table des matières

Autres manuels SMART Tableau blanc interactif

SMART

SMART Podium 500 Series Manuel utilisateur

SMART

SMART Board 800 Series Manuel utilisateur

SMART

SMART Board 8055ie-SMP Manuel utilisateur

SMART

SMART KAPP iQ PRO 65 Manuel utilisateur

SMART

SMART SBID 8000 series Manuel utilisateur

SMART

SMART kapp 84 Manuel utilisateur

SMART

SMART SMART Board V280 Manuel utilisateur

SMART

SMART Board 6065 Manuel d'utilisation

SMART

SMART SBX885 Manuel utilisateur

SMART

SMART SMART Board 885-SMP Manuel utilisateur

SMART

SMART 880i5-SMP Manuel utilisateur

SMART

SMART Sympodium ID250 TM Manuel utilisateur

SMART

SMART Podium ID350 Manuel utilisateur

SMART

SMART 2000i-DVS Manuel utilisateur

SMART

SMART Board E70 Manuel d'utilisation

SMART

SMART 600i Manuel utilisateur

SMART

SMART Smart Board 6055i Manuel utilisateur

SMART

SMART KAPP IQ Manuel utilisateur

SMART

SMART M680 Manuel utilisateur

SMART

SMART Board 885ix2-NCP Manuel utilisateur

SMART

SMART Room System SRS-LYNC-XS Manuel de service

SMART

SMART Board 600i4 Manuel utilisateur

SMART

SMART M600i6 Manuel utilisateur

SMART

SMART SMART Board Manuel utilisateur

Manuels Tableau blanc interactif populaires d'autres marques

HitachiSoft

HitachiSoft StarBoard FX-TRIO-88W Manuel utilisateur

Buhl

Buhl LyteBoard Manuel utilisateur

SMART Board

SMART Board 680 Manuel utilisateur

Legamaster

Legamaster e-SCREEN ETX Manuel utilisateur

SMART Board

SMART Board SBM685ix2 Manuel utilisateur

Seneca

Seneca eno Manuel utilisateur

BenQ

BenQ RP840G Manuel utilisateur

Olivetti

Olivetti OLIBOARD Manuel utilisateur

Turning Technologies

Turning Technologies MOBIVIEW Manuel utilisateur

Panasonic

Panasonic UB-5335 Manuel utilisateur

Dukane

Dukane ITP84 Manuel utilisateur

Bretford

Bretford EDUIMS Guide de configuration

Panasonic

Panasonic Panaboard UB-5315 Manuel utilisateur

Plus

Plus M-11S Manuel utilisateur

TRIUMPH BOARD

TRIUMPH BOARD ULTRA SLIM Manuel utilisateur

Returnstar Interactive Tech

Returnstar Interactive Tech IQBoard DVT V7.0 Manuel utilisateur

AVer

AVer CP series Manuel utilisateur

Genee

Genee 56" Manuel utilisateur
