SIIG CyberParallel ExpressCard Manuel utilisateur

CyberParallel ExpressCard

Quick Installation Guide

04-0468A

Introducing the CyberParallel ExpressCard

TheCyberParallelExpressCardhigh-speedparalleladapter

provides one parallel port to your ExpressCard equipped

system.

Features and Benefits

•Full support for Windows-based software

•SupportsSPP,PS2,EPPandECPparallelportmodes

•Compliant with IEEE 1284-1994 parallel port

standard

•Compliant with PCI Express Specification, Rev. 1.0a

•SupportsSPP,PS2,EPPandECPparallelportmodes

•Fast ECP/EPP parallel port optimizes performance

fromparallelportdevicessuchasprinters,removable

drives, scanners, CD-R/RWs, and more

System Requirements

•Notebook or Desktop system with an available

ExpressCard slot

•Windows®2000/XP (32-/64-bit)/Server 2003

(32-/64-bit)/Vista (32-/64-bit)

PackageContents

•CyberParallelExpressCard

• ExpressCard 1P Cable

• Driver CD and Quick Installation Guide

ExpressCard 1P

Cable connector

Layout

Figure 1. Layout

ExpressCard 1P Cable

Figure 2. Cable Layout

Parallel port (DB25)

ExpressCard 1P

connector

Hardware Installation

General instructions for installing the ExpressCard are

provided. Since the design of systems may vary, refer to

your system’s reference manual for further information,

if needed.

1. Connect the ExpressCard 1P Cable to the cable

connector on the ExpressCard.

2. Insert the CyberParallel ExpressCard into the

ExpressCard slot of your system with the label

facing up. Make sure it is inserted all the way in for

a solid connection.

Note:Whenconnecting/disconnectingdevices,hold

the CyberParallel ExpressCard so it does not move

from side to side, otherwise it may eject from the

slot or lose connection.

Figure 3: Connecting the cable

Driver Installation

This section provides information on how to install the

CyberParallel ExpressCard drivers.

Windows 2000

1. At the Found New Hardware Wizard, click Next.

2. Select Search for a suitable driver for my device

(recommended), and click Next.

3. Check Specify a location, uncheck the other boxes,

then click Next.

4. Insert the driver CD, type in D:\2000, then click OK.

(Change D: to match your CD-ROM drive letter)

5. Click Next and Finish.

6. Repeat steps 1-5 one or two times.

7. RestartWindowstocompletethe driver installation.

32-bit Windows XP/Server 2003

1. At the Found New Hardware Wizard, insert the

driver CD.

For XP w/SP1 or earlier/ Server 2003: go to step #2.

For XP w/SP2 or later/Server 2003 wSP1 or later:select

No, not this time, click Next.

2. Select Install the software automatically

(Recommended,then click Next.

3. Click Finish.

4. Repeat steps 1-3.

5. RestartWindowstocompletethe driver installation.

64-bit Windows XP/Server 2003

1. At the Found New Hardware Wizard, insert the

driver CD. Select No, not this time, click Next.

2. Select Install the software automatically

(Recommended,then click Next.

3. Click Continue Anyway, then click Finish.

4. Repeat steps 1-3 to complete the driver installation.

Verify Windows 2000/XP/2003 Installation

1. Right click My Computer, click Manage, then click

Device Manager.

2. Click on the +(plus sign) in front of Ports (COM &

LPT), SIIG CyberPro Parallel port.... should be

displayed one time.

Windows Vista™

1. At the Found New Hardware window, insert the

driver CD, click Locate and install driver software

(recommended), then click Continue.

2. Click Next, then click Close.

3. Repeat step #2 to complete the driver installation.

Note: If your internet connection is enabled the

driver installation may not match the steps above

because Windows Vista operating system will use

Windows Update to install the driver for the

CyberParallel ExpressCard. In this case, verify Vista

installation as described below.

Verify Windows Vista Installation

1. Right click My Computer, click Manage, click

Continue, then click Device Manager.

2. Click on the +(plus sign) in front of Ports (COM &

LPT), SIIG CyberPro Parallel Port.... should be

displayed one time.

Changing Parallel Port

Some parallel port devices need a specific LPT in order

to function properly. If your device works, do not make

any changes.

1. Right click My Computer, click Manage,

For 2000/XP/2003: then click Device Manager.

ForVista:click Continue,thenclickDevice Manager.

2. Click on the +(plus sign) in front of Ports (COM &

LPT), double click the SIIG CyberPro Parallel port

you want to change.

3. Click the Port Settings tab.

4. Click the down arrow next to the LPT Port Number

box, then select a parallel port that is not in use.

5. Click OK to save the changes.

Legacy Device Support

If your parallel port device is not detected or does not

work properly, follow the steps below to enable legacy

plug and play support.

1. Right click My Computer, click Manage,

For 2000/XP/2003: click Device Manager.

ForVista: clickContinue,then clickDevice Manager.

2. Click on the +(plus sign) in front of Ports (COM &

LPT), double click the SIIG CyberPro Parallel port

you want to change.

3. Click the Port Settings tab.

4. Check Enable legacy Plug and Play.

5. Click OK to save the changes.

Technical Support and Warranty

QUESTIONS? SIIG’sOnline Support hasanswers! Simplyvisitour

web site at www.siig.com and click Support. Our online support

database is updated daily with new drivers and solutions. Answers

toyourquestionscouldbejustafewclicksaway. Youcanalsosubmit

questions online and a technical support analysts will promptly

respond.

SIIGoffersalifetimemanufacturer warrantywiththis product. Please

see our web site for more warranty details. If you encounter any

problems with this product, please follow the procedures below.

A) If it is within the store's return policy period, please return the

product to the store where you purchased from.

B) Ifyourpurchasehaspassedthe store's return policy period, please

follow these steps to have the product repaired or replaced.

Step 1: Submit your RMA request.

Go to www.siig.com, click Support, then RMA to submit a

request to SIIG RMA. If the product is determined to be

defective, an RMA number will be issued. SIIG RMA department

can also be reached at (510) 413-5333.

Step 2: After obtaining an RMA number, ship the product.

•Properly pack the product for shipping. All software, cable(s)

and any other accessories that came with the original package

must be included.

•Clearly write your RMA number on the top of the returned

package. SIIG will refuse to accept any shipping package, and

will not be responsible for a product returned without an

RMA number posted on the outside of the shipping carton.

•You are responsible for the cost of shipping. Ship the product

to the following address:

SIIG, Inc.

6078 Stewart Avenue

Fremont, CA 94538-3152, USA

RMA #:

•SIIG will ship the repaired or replaced product via Ground

in the U.S. and International Economy outside of the U.S. at

no cost to the customer.

CyberParallelExpressCardisatrademarkofSIIG,Inc. SIIGandtheSIIGlogoareregisteredtrademarks

ofSIIG,Inc. Microsoft,WindowsandWindowsVistaareregisteredtrademarksofMicrosoftCorporation.

Other names used in this publication are for identification only and may be trademarks of their

respectivecompanies.

About SIIG, Inc.

Foundedin1985,SIIG,Inc.isaleadingcomputerupgrademanufacturer

of I/O connectivity products, including PCI & ISA serial and parallel

ports, USB, Serial ATA & UltraATA controllers, FireWire (1394a/b),

networking, sound cards, and other accessories. SIIG is the premier

one-stop source of upgrades.

SIIGproducts offercomprehensiveuser manuals, manyuser-friendly

features, and are backed by an extensive manufacturer warranty.

High-quality control standards are evident by the overall ease of

installation and compatibility of our products, as well as one of the

lowest defective return rates in the industry. SIIG products can be

found in computer retail stores, mail order catalogs, through major

distributors, system integrators, and VARs in the Americas and the

UK, and through e-commerce sites.

PRODUCT NAME

CyberParallelExpressCard

FCC RULES: TESTED TO COMPLY WITH FCC PART 15, CLASS

B OPERATING ENVIRONMENT: FOR HOME OR OFFICE USE

FCCCOMPLIANCESTATEMENT:

This device complies with part 15 of the FCC Rules. Operation is

subject to the following two conditions: (1) This device may not cause

harmful interference, and (2) this device must accept any interference

received, including interference that may cause undesired operation.

THE PARTY RESPONSIBLE FOR PRODUCT COMPLIANCE

SIIG, Inc.

6078 Stewart Avenue

Fremont, CA 94538-3152, USA
