SIIG NN-E20022-S1 Manuel utilisateur
DP FireWire PCIe
Installation Guide
04-0540C
Introduction
The DP FireWire PCIe easily adds FireWire
connectivity to your PCIe equipped desktop.
Features and Benefits
• Provides3FireWireports(6-pin)formultiple
device connections
• Compliant with PCI Express base
specification 1.0a
• Compliant with 1394a-2000 and 1394-1995
standards
• Supports data transfer rates of 100, 200,
400Mbps
• Spare enhanced low profile bracket is
included to work in low profile chassis
• Works with DV camcorders, hard disk,
removable drives, scanners, digital cameras
and other FireWire audio/video devices
2
System Requirements
• PCI Express-enabled PC or Mac®
desktop
with an available PCI Express slot
• Windows® 8 (32-/64-bit) / 7 (32-/64-bit) /
Vista (32-/64-bit) / XP (32-/64-bit) / Server
2003 & 2008 (32-/64-bit) / Server 2008 R2
/ 2000
• Mac OS X v10.4 or later
Package Contents
•DP FireWire PCIe
• Spare enhanced low profile bracket
• "Y" split power cable
• Installation guide
3
Figure 1
FireWire ports
Power
connector
Internal FireWire
port
Layout
Hardware Installation
Note:Forlowprofilesystems,replacethecurrently
mounted full height bracket with the included
low profile bracket.
General instructions for installing the card are
provided below. Since the design of computer
cases and motherboards vary, refer to your
computer’s reference manual for further
information, if needed.
4
Static Electricity Discharge may permanently
damage your system. Discharge any static
electricity build up in your body by touching
your computer case for a few seconds. Avoid
any contact with internal parts and handle cards
only by their external edges.
1. Turn OFF the power to your computer.
Unplug the power cord and remove your
computer cover.
2. Remove the slot bracket from an available
PCIe slot.
3. Carefully align the card to the selected PCIe
slot push the board down firmly, but gently,
until it is well seated.
4. Connect the system power source to the DP
FireWire PCIe Power connector (use the
included "Y" split power cable, if needed).
5. Replace the slot bracket holding screw to
secure the card.
6. Replace the computer cover and reconnect
the power cord.
5
Driver Installation
Please make sure the board is installed before
proceeding with driver installation.
Windows
Windows 8 / 7 / Vista / XP / Server 2003 & 2008
/ Server 2008 R2 / 2000 will automatically detect
and install the correct driver for the DP FireWire
PCIe. No driver installation is needed.
To Verify Windows Installation
1. Right click Computer or My Computer,
then click Manage.
For Windows 8 / 7 / XP / 2003: Right click
Computer or My Computer, click Manage,
click Device Manager.
For Windows Vista: Right click Computer,
click Manage, click Continue, click Device
Manager.
For Windows Server 2008 / Server 2008 R2:
Right click Computer, click Manage, double
click Diagnostics, click Device Manager.
6
2. Double click 1394 Bus Controller or IEEE
1394 Bus host controllers, a VIA 1394
OHCI Compliant Host Controller should
be displayed.
Mac OS X
Mac OS will automatically detect and install the
correct driver for the DP FireWire PCIe. No
additional driver installation is needed.
To Verify Mac OS Installation
1. Open System Profiler.
2. Under Hardware, click PCI Cards, an IEEE
1394 Open HCI card should be displayed.
7
Technical Support and Warranty
QUESTIONS? SIIG’s Online Support has answers! Simply visit our web site at
www.siig.com and click Support. Our online support database is updated daily with
new drivers and solutions. Answers to your questions could be just a few clicks away.
You can also submit questions online and a technical support analyst will promptly
respond.
SIIG offers a 5-year manufacturer warranty with this product. This warranty covers the
original purchaser and guarantees the product to be free of any defects in materials or
workmanship for five (5) years from the date of purchase of the product.
SIIG will, at our discretion, repair or replace (with an identical product or product
having similar features and functionality) the product if defective in materials or
workmanship. This warranty gives you specific legal rights, and you may also have other
rights which vary from state to state. Please see our web site for more warranty details.
If you encounter any problems with this product, please follow the procedures below.
A) If it is within the store's return policy period, please return the product to the store
where you purchased from.
B) If your purchase has passed the store's return policy period, please follow the steps
below to have the product repaired or replaced.
Step 1: Submit your RMA request.
Go to www.siig.com, click Support, then REQUEST A PRODUCT REPLACEMENT
to submit a request to SIIG RMA or fax a request to 510-657-5962. Your RMA request
will be processed, if the product is determined to be defective, an RMA number will
be issued.
Step 2: After obtaining an RMA number, ship the product.
• Properly pack the product for shipping. All accessories that came with the
original package must be included.
• Clearly write your RMA number on the top of the returned package. SIIG will
refuse to accept any shipping package, and will not be responsible for a product
returned without an RMA number posted on the outside of the shipping
carton.
• You are responsible for the cost of shipping to SIIG. Ship the product to the
following address:
SIIG, Inc.
6078 Stewart Avenue
Fremont, CA 94538-3152, USA
RMA #:
• SIIG will ship the repaired or replaced product via Ground in the U.S. and
International Economy outside of the U.S. at no cost to the customer.
PRODUCT NAME
DP FireWiire PCIe
FCC RULES: TESTED TO COMPLY WITH FCC PART 15, CLASS B
OPERATING ENVIRONMENT: FOR HOME OR OFFICE USE
FCC COMPLIANCE STATEMENT:
This device complies with part 15 of the FCC Rules. Operation is subject to
the following two conditions: (1) This device may not cause harmful
interference, and (2) this device must accept any interference received,
including interference that may cause undesired operation.
THE PARTY RESPONSIBLE FOR PRODUCT COMPLIANCE
SIIG, Inc.
6078 Stewart Avenue
Fremont, CA 94538-3152, USA
Phone: 510-657-8688
About SIIG, Inc.
Founded in 1985, SIIG, Inc. is a leading manufacturer of IT connectivity
solutions (including Serial ATA and Ultra ATA Controllers, FireWire, USB,
and legacy I/O adapters) that bridge the connection between Desktop/
Notebooksystemsand external peripherals. SIIG continuesto grow by adding
A/V and Digital Signage connectivity solutions to our extensive portfolio.
SIIGproducts offer comprehensive usermanuals, many user-friendlyfeatures,
and are backed by an extensive manufacturer warranty. High quality control
standards are evident by the overall ease of installation and compatibility of
our products, as well as one of the lowest defective return rates in the industry.
SIIG products can be found in computer retail stores, mail order catalogs,
throughmajordistributors, system integrators, andVARsin the Americas and
the UK, and through e-commerce sites.
DPFireWire PCIeis a trademark of SIIG,Inc. SIIG andthe SIIG logo are registeredtrademarks
of SIIG, Inc. Microsoft and Windows are registered trademarks of Microsoft Corporation. All
othernames usedin this publicationare for identificationonly andmay be trademarksof their
respective owners.
January, 2014 Copyright © 2014 by SIIG, Inc. All rights reserved.
