Page 1.1

6-CHANNEL BATTERY SIMULATOR MODULE 41-752

pickering SECTION 1 - TECHNICAL SPECIFICATION

SECTION 1 - TECHNICAL SPECIFICATION

pickeringtest.com

41-752

6 Channel Battery Simulator Module

●6 Power Supplies In A Single PXI Slot

●Independent Sense Connections

●Ideal For Battery Stack Emulation

●750V Independent Isolation Barriers

●Up To 300mA Output Per Simulator

●Battery Charging Emulation To 100mA

●Uses Backplane Power Sources

●Hardware shutdown control

●VISA and Kernel Drivers Supplied For

Windows XP/Vista/7/8 Plus Soft Front Panel

●Use In Pickering 19-Slot PXI Chassis Or

18-Slot LXI Chassis

The 41-752 is a 6 channel battery simulator, each channel

being capable of supplying up to 7V and 300mA to the

load. Each channel is fully isolated from ground and from

each other allowing the channels to be connected in series

to simulate batteries arranged in a stacked architecture. The

750V isolation barrier permits the 41-752 to be used to

create a lower power version of a battery stack representative

of those used for vehicle propulsion.

Each battery simulator provides independent power and

sense connections, allowing the battery simulator to sense

a remote load and correct for wiring voltage losses. The

battery simulator is designed to respond to dynamic loads,

minimizing the need for local decoupling capacitors at the

load.

A signal line on the user connector allows the user to

shutdown all battery simulator channels with a single

connection. Mulitple module control lines may be linked

together to provide an easy way of inhibiting voltage

generation when using many series connected modules

that provide high output voltages and providing a means of

automatic shutdown when connectors are removed.

ISSUE 3.0 JUN 2013

Soft Front Panel for The 41-752 Battery Simulator

POWER AND CONTROL FROM PXI BACKPLANE

CHANNEL 1

Vout+ Sense+Vout- Sense-

Current

Sink

Voltage

Source

CHANNEL 2

V+ S+V- S-

CHANNEL 3

V+ S+V- S-

CHANNEL 4

V+ S+V- S-

CHANNEL 5

V+ S+V- S-

CHANNEL 6

V+ S+V- S-

37-WAY D-TYPE CONNECTOR

Functional Block

Diagram For The

41-752 6-Channel

Battery Simulator

The 41-752 can be used as a 6 channel fully isolated power

supply with independent sense lines on each channel

The user connector is a 37-way high voltage D Type which

is fully supported by the wide range of Pickering Interfaces

connector accessories.

Page 1.2 6-CHANNEL BATTERY SIMULATOR MODULE 41-752

pickering

SECTION 1 - TECHNICAL SPECIFICATION

pickeringtest.com

Power Requirements from PXI Power Supply

+3.3V +5V +12V -12V

0.8A 2.0A 0.6A 0.3A

At maximum load for all channels,

Recommended chassis are 60-103 and 60-103A or 40-923

and 40-923A for applications requiring many modules (up to

18 off) in a single chassis to avoid chassis limitations.

Speciﬁcation

Number of Channels: 6 independent isolated channels.

Output Voltage Range:

0 to 7V, settable with 14-bit

resolution (approximately 0.43mV).

Output Voltage Accuracy:

0.2%

20mV from 1V to 7V output

over ambient temperature range

+ 11

C to +31

Isolation Voltage: ±750V

Output Current: Up to 300mA per channel for

voltages from 2.5V to 7V

Linearly de-rate to 200mA into a

short circuit below 2.5V without

thermal shutdown.

Current Sink: Variable current sink permits

the output to be loaded so the

battery simulator can sink current

from a charger. Current sink can

be set from 0 to 100mA in 16

steps. Current sink setting reduces

the current available at the user

connector.

Output Connections: Vout+, Vout- and two sense inputs

for each simulator channel.

Sense inputs detect output voltage

at front panel connector if no

remote sense lines are connected.

Load Response Time: 250µs

Power Source: PXI backplane +12V, +5V, +3.3V

and -12V.

Protection: All simulators are short circuit

protected, reverse voltage

protected and include thermal

shutdown.

Output Connector: 37-way D-type, high voltage

PXI Characteristics

Backplane connection: 33MHz, 32-bit.

Mechanical: 3U, 1-slot.

Mating Connectors & Cabling

For connection accessories for the 41-752 please refer to the

90-007D 37-way D-Type Connector Accessories data sheet

where a complete list and documentation can be found for

accessories.

Product Order Codes

Battery Simulator, 6-Channel 41-752-001

Table des matières

Autres manuels Pickering Unité de contrôle

Pickering

Pickering 40-521 Manuel utilisateur

Pickering

Pickering 4 890 Series Manuel utilisateur

Pickering

Pickering 40-584 Manuel utilisateur

Pickering

Pickering 40-553A Manuel utilisateur

Pickering

Pickering PXI 40-855 Manuel utilisateur

Pickering

Pickering 40-727 Manuel utilisateur

Pickering

Pickering PXI 40-795-001 Manuel utilisateur

Pickering

Pickering 40-561A Manuel utilisateur

Pickering

Pickering PXI 40-145 Manuel utilisateur

Pickering

Pickering 40-575 Manuel utilisateur

Pickering

Pickering SYSTEM 10 Manuel utilisateur

Pickering

Pickering PXI 40-597 Manuel utilisateur

Pickering

Pickering 40-296 Manuel utilisateur

Pickering

Pickering Pxi 41-660 Manuel utilisateur

Pickering

Pickering PXi 41-720 Manuel utilisateur

Pickering

Pickering 41-180 Manuel utilisateur

Pickering

Pickering PXI 40-787 Manuel utilisateur

Pickering

Pickering 40-290-021 Manuel utilisateur

Pickering

Pickering 40-529A Manuel utilisateur

Pickering

Pickering PXI 40-535 Manuel utilisateur

Pickering

Pickering 40-587B Manuel utilisateur

Pickering

Pickering 40-191B Manuel utilisateur

Pickering

Pickering 40-565A Manuel utilisateur

Pickering

Pickering PXI BRIC 40-562A Manuel utilisateur

Manuels Unité de contrôle populaires d'autres marques

Festo

Festo Compact Performance CP-FB6-E Manuel de la liste des pièces

Elo TouchSystems

Elo TouchSystems DMS-SA19P-EXTME Manuel utilisateur

JS Automation

JS Automation MPC3034A Manuel utilisateur

JAUDT

JAUDT SW GII 6406 Series Guide rapide

Spektrum

Spektrum Air Module System Manuel utilisateur

BOC Edwards

BOC Edwards Q Series Manuel utilisateur

KHADAS

KHADAS BT Magic Manuel utilisateur

Etherma

Etherma eNEXHO-IL Manuel utilisateur

PMFoundations

PMFoundations Attenuverter Manuel utilisateur

GEA

GEA VARIVENT Manuel utilisateur

Walther Systemtechnik

Walther Systemtechnik VMS-05 Manuel utilisateur

Altronix

Altronix LINQ8PD Instructions de montage

Eaton

Eaton Powerware Series Manuel utilisateur

WAGO

WAGO 750-407/040-000 Manuel utilisateur

Sony

Sony CCU-590 Manuel utilisateur

Graco

Graco 25D614 Manuel utilisateur

Task Force Tips

Task Force Tips YE-RF-900 Manuel de programmation

Shini

Shini SPV-U Series Manuel utilisateur
