MEMS FIBER OPTIC SWITCH MODULE 40-855

pickering

Issue 4.2 May 2017

User Manual

MEMS Fiber Optic Switch Module

(Model No. 40-855)

pickeringtest.com pickering

Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

Page (II)

MEMS FIBER OPTIC SWITCH MODULE 40-855

pickering

Page (II) REED RELAY MODULE 40-110/115/120/125

pickering

No part of this publication may be reproduced, transmitted, transcribed, translated or stored in any form, or by

any means without the written permission of Pickering Interfaces.

Technical details contained within this publication are subject to change without notice.

ISO 9001

Reg No. FM38792

Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

Page (III)

MEMS FIBER OPTIC SWITCH MODULE 40-855

pickering

Page (III)

REED RELAY MODULE 40-110/115/120/125

pickering

TECHNICAL SUPPORT

For Technical Support please contact Pickering Interfaces either by phone, the website or via e-mail.

WARRANTY

All products manufactured by Pickering Interfaces are warranted against defective materials and workmanship for a period of

three years, excluding programmable power supplies, from the date of delivery to the original purchaser. Any product found to be

defective within this period will, at the discretion of Pickering Interfaces be repaired or replaced.

Products serviced and repaired outside of the warranty period are warranted for ninety days.

Extended warranty and service are available. Please contact Pickering Interfaces by phone, the website or via e-mail.

ENVIRONMENTAL POLICY

Pickering Interfaces operates under an environmental management system similar to ISO 14001.

Pickering Interfaces strives to full all relevant environmental laws and regulations and reduce wastes and releases to the

environment. Pickering Interfaces aims to design and operate products in a way that protects the environment and the health and

safety of its employees, customers and the public. Pickering Interfaces endeavours to develop and manufacture products that can

be produced, distributed, used and recycled, or disposed of, in a safe and environmentally friendly manner.

Worldwide Technical Support and Product Information

pickeringtest.com

Germany

Tel: +49 89 125 953 160

E-mail: [email protected]

Sweden

Tel: +46 340-69 06 69

E-mail: [email protected]

USA

Tel: (West) +1 541 471 0700

Tel: (East) +1 781 897 1710

E-mail: [email protected]

Czech Republic

Tel: +420 558 987 613

E-mail: [email protected]

France

Tel +33 9 72 58 77 00

E-mail [email protected]

Pickering Interfaces Headquarters

Stephenson Road Clacton-on-Sea CO15 4NL United Kingdom

Tel: +44 (0)1255-687900

E-Mail: [email protected]

China

Tel: +86 4008 799 765

E-mail: [email protected]

Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

Page (IV)

MEMS FIBER OPTIC SWITCH MODULE 40-855

pickering

Page (IV) REED RELAY MODULE 40-110/115/120/125

pickering

MEANING / DESCRIPTION SYMBOL

PROTECTIVE EARTH (GROUND)

To identify any terminal which is intended for connection to an external conductor for

protection against electric shock in case of a fault, or the terminal of a protective earth

(ground) electrode.

DANGEROUS VOLTAGE

To indicate hazards arising from dangerous voltages.

WARNING / CAUTION

An appropriate safety instruction should be followed or caution to a potential hazard

exists.

Refer to the relevant instructions detailed within the product manual.

HEAVY

If this product is heavy and reference should be made to the safety instructions for

provisions of lifting and moving.

LASER PRODUCT

This product is capable of switching laser optical signals.

STATIC SENSITIVE

To indicate that static sensitive devices are present and handling precautions should

be followed.

SAFETY SYMBOLS

PRODUCT SAFETY

The following safety symbols may be used on the product and throughout the product documentation.

Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

Page (V)

MEMS FIBER OPTIC SWITCH MODULE 40-855

pickering

Technical Support and Warranty................................................III

Product Safety .............................................................................IV

Contents (this page)....................................................................V

Warnings and Cautions ..............................................................VII

Section 1

Technical Specication...............................................................1.1

Section 2

Technical Description .................................................................2.1

Functional Description..........................................................2.1

Section 3

Installation....................................................................................3.1

Pre Operation Checks...........................................................3.1

Hardware Installation ............................................................3.2

Software Installation .............................................................3.2

Testing Operation ..................................................................3.3

Section 4

Programming Guide....................................................................4.1

Programming Options For Pickering PXI Cards.................4.1

Module Architecture 40-855.................................................4.3

Programming The Module 40-855.......................................4.4

Section 5

Connector Information................................................................5.1

Section 6

Trouble Shooting .........................................................................6.1

Section 7

Maintenance Information............................................................7.1

Relay Lookup Tables.............................................................7.1

Component Layout................................................................7.2

CONTENTS

Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

Page (VI)

MEMS FIBER OPTIC SWITCH MODULE 40-855

pickering

THIS PAGE INTENTIONALLY BLANK

Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

Page (VII)

MEMS FIBER OPTIC SWITCH MODULE 40-855

pickering

Page (VII)

REED RELAY MODULE 40-110/115/120/125

pickering

WARNINGS AND CAUTIONS

WARNING - HAZARDOUS ENVIRONMENTS SYMBOL

This product is not specically designed for use in hazardous environments, for example in explosive

atmospheres. If the product is to be used in hazardous environments we recommend that the user

ensures suitable protective measures are taken.

WARNING - DANGER OF ELECTRIC SHOCK SYMBOL

This module may contain hazardous voltages. Before removing the module from the rack remove all

supplies and disconnect user I/O signals.

Unused slots in the PXI/LXI chassis are populated with blanking plates to prevent access to user

I/O signals that may be present. Blanking panels are available to order from Pickering in a variety

of slot widths. If the product is not used in this manner for example by using an extender card then

additional care must be taken to avoid contact with exposed signals.

CAUTION - HANDLING OF ELECTROSTATIC-SENSITIVE DEVICES SYMBOL

Certain semiconductor devices used in this equipment are liable to damage due to static voltage.

Observe the following precautions when handling these devices in their unterminated state, or

sub-assemblies containing these devices:

1. Persons removing sub-assemblies from equipment using these devices must be earthed by a

wrist strap and a resistor at the point provided on the equipment.

2. Soldering irons used during the repair operations must be low voltage types with earthed tips and

isolated from the mains voltage by a double insulated transformer.

3. Outer clothing worn must be unable to generate static charges.

4. Printed Circuit Boards (PCBs) tted with these devices must be stored and transported in

anti-static bags.

CAUTION - PRODUCT DOCUMENTATION SYMBOL

Suitably qualied & trained users should ensure that the accompanying documentation is fully read

and understood before attempting to install or operate the product.

WARNING - RISK OF INJURY SYMBOL

This product may be specically designed to switch optical signals. Under no circumstances look

into the end of an optical output or an optical cable attached to an optical output. LASER RADIATION

CAN SERIOUSLY DAMAGE YOUR EYESIGHT.

Read and understand the safety information of the laser source connected to the optical switch.

Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

Page (VIII)

MEMS FIBER OPTIC SWITCH MODULE 40-855

pickering

Page (VIII) REED RELAY MODULE 40-110/115/120/125

pickering

SAFETY INSTRUCTIONS

All cleaning and servicing requires the equipment to be isolated and disconnected from the power source and user

I/O signals (refer to the Maintenance Section).

• Appropriate manual handling procedures should be followed as dictated by the weight of the individual module or

the combined weight of the modules & chassis.

• Should a fault occur with the module or chassis, immediately isolate and disconnect the incoming power to the

chassis and the user I/O signals.

• Ensure the equipment is installed, operated and maintained by trained and authorised personnel.

• Modules are not accessed to EN 60825, users should observe the safety instructions and laser

class for the 3rd party laser source.

• The module may be capable of switching optical signals from a laser device; do not stare directly

at the user I/O ports.

• For suitably equipped products in the event of an emergency press the red “emergency stop” button situated on

the front of the unit.

Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

Page 1.1

MEMS FIBER OPTIC SWITCH MODULE 40-855

pickering SECTION 1 - TECHNICAL SPECIFICATION

SECTION 1 - TECHNICAL SPECIFICATION

pickeringtest.com

40-855

MEMS Fiber Optic Switch

●Single, Dual, Triple or Quad 2 to 1 Fiber Optic

Multiplexer

●High Density 1, 2 or 3 Slot Width Modules

●FC/APC, FC/PC or SC/PC Connectors

●Small Form Factor Connectors LC

or MU (mini SC)

●1240 to 1640nm Single Mode

●700 to 1700nm Multi-Mode

●Return Loss >55dB

●Long Operating Life >109Operations with High

Repeatability ± 0.01dB and Good Temperature

Stability

●Crosstalk -60dB Typical

●1ms Typical Switching Time

●VISA, IVI & Kernel Drivers Supplied for

Windows

●Supported by PXI or LXI Chassis

●3 Year Warranty

Pickering PXI Fiber Optic MEMS Switching modules are

available in many high density formats with a choice of

5 different connector styles to suit most applications:

FC/APC (for optimal performance), FC/PC and SC/PC

for general applications and LC and MU for high density

applications.

The ﬁber optic multiplexers connect the optical channel

by redirecting the optical signal into a selected output

ﬁber. This is achieved using Micro-Mechanical Mirrors

driven by a highly precise mechanism and activated via

an electrical control signal.

The range of MEMS (Micro-Electro-Mechanical-Systems)

based optical switches is:

40-850 – Single or Dual 4 Channel Multiplexer

40-852 – Single 8 Channel Multiplexer

40-855 – Single, Dual, Triple or Quad 2 Channel

Multiplexer

Pickering will construct custom optical systems to

customers precise requirements. We have a large

range of electrical switching modules which can form a

complete PXI based telecom switching solution.

MEMS technology offers many advantages over

traditional Optical Prism Technology as used in module

types 40-810/815/820. MEMS offer similar optical

performance but with lower price, higher packing density,

faster operate time and much longer operating life.

Block Diagram of Dual 2 Channel Fiber Optic

Multiplexer

Key Features

• Very fast operate time <1ms

• Very long life >109operations

• Return loss greater than 55dB

• High repeatability over a broad range of

environmental conditions

• High density

Applications

• Optical signal routing

• Fiber network conﬁguration

• Fiber Optic Component Test

Common

Channel 1

Channel 2

Common

Channel 1

Channel 2

Channel 3

Channel 4

Common

Channel 3

Channel 4

Channel 5

Channel 6

Channel 7

Channel 8

Channel 1

Channel 2

Set State

Reset State

ISSUE 5.1 MAY 2017

40-855-012

2 Channel

Fiber Optic

Multiplexer

Common

Channel 1

Channel 2

Common

Channel 1

Channel 2

Channel 3

Channel 4

Common

Channel 3

Channel 4

Channel 5

Channel 6

Channel 7

Channel 8

Channel 1

Channel 2

Set State

Reset State

Common

Channel 1

Channel 2

Common

Channel 1

Channel 2

Channel 3

Channel 4

Common

Channel 3

Channel 4

Channel 5

Channel 6

Channel 7

Channel 8

Channel 1

Channel 2

Set State

Reset State

Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

Table des matières

Autres manuels Pickering Unité de contrôle

Pickering

Pickering 40-880 Manuel utilisateur

Pickering

Pickering 40-670A Manuel utilisateur

Pickering

Pickering 40-529A Manuel utilisateur

Pickering

Pickering 40-265 Manuel utilisateur

Pickering

Pickering 40-522 Manuel utilisateur

Pickering

Pickering 40-521 Manuel utilisateur

Pickering

Pickering 40-651 Manuel utilisateur

Pickering

Pickering 40-656A Manuel utilisateur

Pickering

Pickering 40-520 Manuel utilisateur

Pickering

Pickering 45-542 Manuel utilisateur

Pickering

Pickering 40-785C Manuel utilisateur

Pickering

Pickering PXI BRIC 40-562A Manuel utilisateur

Pickering

Pickering PXI BRIC 40-560A Manuel utilisateur

Pickering

Pickering PXI BRIC 40-569B Manuel utilisateur

Pickering

Pickering 40-650A Manuel utilisateur

Pickering

Pickering 40-584 Manuel utilisateur

Pickering

Pickering SYSTEM 10 Manuel utilisateur

Pickering

Pickering SYSTEM 10 Manuel utilisateur

Pickering

Pickering 40-292 Manuel utilisateur

Pickering

Pickering 40-884A Manuel utilisateur

Pickering

Pickering 4x-727A Manuel utilisateur

Pickering

Pickering 4 785C Series Manuel utilisateur

Pickering

Pickering 40-220A Manuel utilisateur

Pickering

Pickering PXI BRIC 40-569 Manuel utilisateur

Manuels Unité de contrôle populaires d'autres marques

Festo

Festo Compact Performance CP-FB6-E Manuel de la liste des pièces

Elo TouchSystems

Elo TouchSystems DMS-SA19P-EXTME Manuel utilisateur

JS Automation

JS Automation MPC3034A Manuel utilisateur

JAUDT

JAUDT SW GII 6406 Series Guide rapide

Spektrum

Spektrum Air Module System Manuel utilisateur

BOC Edwards

BOC Edwards Q Series Manuel utilisateur

KHADAS

KHADAS BT Magic Manuel utilisateur

Etherma

Etherma eNEXHO-IL Manuel utilisateur

PMFoundations

PMFoundations Attenuverter Manuel utilisateur

GEA

GEA VARIVENT Manuel utilisateur

Walther Systemtechnik

Walther Systemtechnik VMS-05 Manuel utilisateur

Altronix

Altronix LINQ8PD Instructions de montage

Eaton

Eaton Powerware Series Manuel utilisateur

WAGO

WAGO 750-407/040-000 Manuel utilisateur

Sony

Sony CCU-590 Manuel utilisateur

Graco

Graco 25D614 Manuel utilisateur

Task Force Tips

Task Force Tips YE-RF-900 Manuel de programmation

Shini

Shini SPV-U Series Manuel utilisateur
