Issue 2.1 August 2023

40-553A User Manual

PXI 10 A Solid State Matrix Module

Page (II) 10A SOLID STATE MATRIX MODULE 40-553A

pickering

Page (II) REED RELAY MODULE 40-110/115/120/125

pickering

No part of this publication may be reproduced, transmitted, transcribed, translated or stored in any form, or by

any means without the written permission of Pickering Interfaces.

Technical details contained within this publication are subject to change without notice.

ISO 9001

Reg No. FM38792

Page (III)

10A SOLID STATE MATRIX MODULE 40-553A

pickering

Page (III)

REED RELAY MODULE 40-110/115/120/125

pickering

TECHNICAL SUPPORT

For Technical Support please contact Pickering Interfaces either by phone, the website or via e-mail.

WARRANTY

All products manufactured by Pickering Interfaces are warranted against defective materials and workmanship for a period of

three years, excluding programmable power supplies, from the date of delivery to the original purchaser. Any product found to be

defective within this period will, at the discretion of Pickering Interfaces be repaired or replaced.

Products serviced and repaired outside of the warranty period are warranted for ninety days.

Extended warranty and service are available. Please contact Pickering Interfaces by phone, the website or via e-mail.

ENVIRONMENTAL POLICY

Pickering Interfaces operates under an environmental management system similar to ISO 14001.

Pickering Interfaces strives to full all relevant environmental laws and regulations and reduce wastes and releases to the

environment. Pickering Interfaces aims to design and operate products in a way that protects the environment and the health and

safety of its employees, customers and the public. Pickering Interfaces endeavours to develop and manufacture products that can

be produced, distributed, used and recycled, or disposed of, in a safe and environmentally friendly manner.

Worldwide Technical Support and Product Information

pickeringtest.com

Germany

Tel: +49 89 125 953 160

E-mail: [email protected]

Sweden

Tel: +46 340-69 06 69

E-mail: [email protected]

USA

Tel: (West) +1 541 471 0700

Tel: (East) +1 781 897 1710

E-mail: [email protected]

Czech Republic

Tel: +420 558 987 613

E-mail: [email protected]

France

Tel +33 9 72 58 77 00

E-mail [email protected]

Pickering Interfaces Headquarters

Stephenson Road Clacton-on-Sea CO15 4NL United Kingdom

Tel: +44 (0)1255-687900

E-Mail: [email protected]

China

Tel: +86 4008 799 765

E-mail: [email protected]

Page (IV) 10A SOLID STATE MATRIX MODULE 40-553A

pickering

Page (IV) REED RELAY MODULE 40-110/115/120/125

pickering

MEANING / DESCRIPTION SYMBOL

PROTECTIVE EARTH (GROUND)

To identify any terminal which is intended for connection to an external conductor for

protection against electric shock in case of a fault, or the terminal of a protective earth

(ground) electrode.

DANGEROUS VOLTAGE

To indicate hazards arising from dangerous voltages.

WARNING / CAUTION

An appropriate safety instruction should be followed or caution to a potential hazard

exists.

Refer to the relevant instructions detailed within the product manual.

HEAVY

If this product is heavy reference should be made to the safety instructions for

provisions of lifting and moving.

STATIC SENSITIVE

To indicate that static sensitive devices are present and handling precautions should

be followed.

SAFETY SYMBOLS

PRODUCT SAFETY

The following safety symbols may be used on the product and throughout the product documentation.

Page (V)

10A SOLID STATE MATRIX MODULE 40-553A

pickering

Technical Support and Warranty................................................III

Product Safety .............................................................................IV

Contents (this page)....................................................................V

Warnings and Cautions ..............................................................VII

Section 1

Technical Specication...............................................................1.1

Section 2

Technical Description .................................................................2.1

Functional Description..........................................................2.1

Hardware Interlock ................................................................2.2

Section 3

Installation....................................................................................3.1

Pre Operation Checks...........................................................3.1

Hardware Installation ............................................................3.2

Software Installation .............................................................3.2

Testing Operation ..................................................................3.3

Section 4

Programming Guide....................................................................4.1

Programming Options For Pickering PXI Modules ............4.1

Module Architecture..............................................................4.2

Programming The Module ....................................................4.3

Section 5

Connector Information................................................................5.1

Section 6

Trouble Shooting .........................................................................6.1

Section 7

Maintenance Information............................................................7.1

Switching System Test Tools ...............................................7.1

Relay Lookup Tables.............................................................7.1

Appendix A

Interlock Connector Wiring ........................................................A.1

CONTENTS

Page (VI) 10A SOLID STATE MATRIX MODULE 40-553A

pickering

THIS PAGE INTENTIONALLY BLANK

Page (VII)

10A SOLID STATE MATRIX MODULE 40-553A

pickering

Page (VII)

2 AMP 1-POLE UHD MATRIX MODULES 40-575 / 576 / 577 / 578 / 579

pickering

WARNINGS AND CAUTIONS

WARNING - HAZARDOUS ENVIRONMENTS SYMBOL

This product is not specically designed for use in hazardous environments, for example in explosive

atmospheres. If the product is to be used in hazardous environments we recommend that the user

ensures suitable protective measures are taken.

WARNING - DANGER OF ELECTRIC SHOCK SYMBOL

This module may contain hazardous voltages. Before removing the module from the rack remove all

supplies and disconnect user I/O signals.

Unused slots in the host chassis are populated with blanking plates to prevent access to user I/O

signals that may be present. Blanking panels are available to order from Pickering in a variety of

slot widths. If the product is not used in this manner for example by using an extender card then

additional care must be taken to avoid contact with exposed signals.

Not to be used in safety critical circuits, refer to the Pickering Interfaces’ terms & conditions of sale.

This module must not be used for the switching of Mains Circuits. For the switching of voltages up

to the module’s full specication, Secondary Circuit power supplies and the Device Under Test must

be fully isolated from the Mains Circuit and the safety earth.

The host chassis must be correctly installed and be connected to mains or factory safety ground,

please refer to your chassis installation manual.

Diagram Showing Separation Between The Mains Circuit and Secondary Circuit / DUT

For the purposes of this document, a Mains Circuit is an installation classied as Overvoltage

Category II up to 300V. Separation between the Secondary Circuit and Mains Circuit is achieved

by a transformer in which the primary windings are separated from the secondary windings by

reinforced insulation, double insulation, or a screen connected to the protective conductor terminal.

CAUTION - HANDLING OF ELECTROSTATIC-SENSITIVE DEVICES SYMBOL

Certain semiconductor devices used in this equipment are liable to damage due to static voltage.

Observe the following precautions when handling these devices in their unterminated state, or

sub-assemblies containing these devices:

1. Persons removing sub-assemblies from equipment using these devices must be earthed by a

wrist strap and a resistor at the point provided on the equipment.

2. Soldering irons used during the repair operations must be low voltage types with earthed tips and

isolated from the mains voltage by a double insulated transformer.

3. Outer clothing worn must be unable to generate static charges.

4. Printed Circuit Boards (PCBs) tted with these devices must be stored and transported in

anti-static bags.

PXI Switching

Module

Device

Under Test

Power

Supply

Power

Supply

Host Chassis

Secondary Circuit

Mains

Circuit

Mains

Circuit

Mains/Factory

Safety Ground

Page (VIII) 10A SOLID STATE MATRIX MODULE 40-553A

pickering

Page (VIII) 2 AMP 1-POLE UHD MATRIX MODULES 40-575 / 576 / 577 / 578 / 579

pickering

CAUTION - PRODUCT DOCUMENTATION SYMBOL

Suitably qualied & trained users should ensure that the accompanying documentation is fully read

and understood before attempting to install or operate the product.

SAFETY INSTRUCTIONS

All cleaning and servicing requires the equipment to be isolated and disconnected from the power source and user I/O

signals (refer to the Maintenance Section).

• Appropriate manual handling procedures should be followed as dictated by the weight of the individual module or

the combined weight of the modules & chassis.

• Should a fault occur with the module or chassis, immediately isolate and disconnect the incoming power to the

chassis and the user I/O signals.

• Ensure the equipment is installed, operated and maintained by trained and authorised personnel.

• For suitably equipped products in the event of an emergency press the red “emergency stop” button situated on

the front of the unit.

Page 1.1

10A SOLID STATE MATRIX MODULE 40-553A

pickering SECTION 1 - TECHNICAL SPECIFICATION

SECTION 1 - TECHNICAL SPECIFICATION

10 A Solid State Matrix Module

with Optional Hardware Interlock

Supported by

eBIRST

eBIRST switching system test tools simplify switching system

fault-ﬁnding by quickly testing the system and graphically

identifying the faulty relay.

For more information go to: pickeringtest.com/ebirst

y6x2 Power Matrix

yAvailable With Optional Hardware Interlock

y10 A Rating at 200 V

yVery High Hot Switch Capacity

yVery High Inrush Current Rating

yFast Operating Speed

yLong Service Life

yDrivers Supplied for Windows and Linux, Plus

Support for Real-time Systems

ySupported by PXI or LXI Chassis

ySupported by

eBIRST

™

y3 Year Warranty

The 40-553A is a high current 6x2 matrix occupying two

PXI chassis slots. Matrix crosspoints are fully isolated solid

state relays which offer fast operation under hot switching

conditions and high inrush current with no operational life

degradation.

Signal paths can support 10 A of continuous current and

switch up to 200 V. The relays can sustain inrush currents in

excess of 50 A. AC or DC signals can be switched since they

are polarity insensitive.

The 40-553A is particularly well suited to automotive and

aerospace applications where switching of high capacity loads

is required. The module is supplied with a comprehensive

package of drivers, including support for selected RT

operating systems.

X2 X4X1 X3 X5 X6

Matrix

Crosspoint

40-553A Solid State 6x2 Matrix Schematic Diagram.

pickeringtest.com

40-553A

PXI 10 A Solid State Matrix Modules

Issue 2.0 July 2023

Page 1.2 10A SOLID STATE MATRIX MODULE 40-553A

pickering

SECTION 1 - TECHNICAL SPECIFICATION

PXI & CompactPCI Compliance

The module is compliant with the PXI Speciﬁcation 2.2. Local

Bus, Trigger Bus & Star Trigger are not implemented.

Uses a 33 MHz 32-bit backplane interface.

Safety & CE Compliance

All modules are fully CE compliant and meet applicable

EU directives:

Low-voltage safety EN61010-1:2010,

EMC Immunity EN61326-1:2013,

Emissions EN55011:2009+A1:2010.

Operating/Storage Conditions

Operating Temperature:

Humidity:

Altitude:

0 °C to +55 °C

Up to 90 % non-condensing

5000 m

Storage Temperature:

Humidity:

Altitude:

-20 °C to +75 °C

Up to 90 % non-condensing

15000 m

Switching Speciﬁcation

Switch Type: Solid State MOSFET

Max Switch Voltage:

Continuous Crosspoint Current:

±200 V* (DC or AC peak)†

10 A

Peak Current: 50 A for 200 µs

Max Y-Bus Current: 40 A

Path Resistance - On: 75 mΩ at 25 ˚C typical

Rise/Fall Time:

Operate Time:

Recommended Maximum Cycle

Rate (on, then off):

20 µs typical

70 µs on, 120 µs off

150 operations/sec

* For full voltage rating, signal sources to be switched

must be fully isolated from mains supply and safety earth.

† Differential voltage between channels must not exceed

rated voltage, additional caution should be used when

applying AC voltages as multiple asynchronous supplies

can create high differential voltages between channels.

Power Requirements

+3.3 V +5 V +12 V -12 V

100 mA 700 mA 0 0

Mechanical Characteristics

Double slot 3U PXI (CompactPCI card).

3D models for all versions in a variety of popular ﬁle formats

are available on request.

Connectors

PXI bus via 32-bit P1/J1 backplane connector.

Signals via 2 front panel 8-pin male power D-Type connectors,

for pin outs please refer to the operating manual.

Interlock via 4-pin female 00 series connector*

(40-553A versions with hardware interlock option)

*Mating half supplied when hardware interlock option

ordered, to be wired by end user.

Hardware Interlock

The 40-553A modules are available with an optional hardware

interlock. The interlock, when activated, will return all relays

to their default unpowered state (assuming the relays are

fully functional) and also provide error notiﬁcation via the

software interface. The interlock feature can be daisy-chained

between additional hardware interlock enabled modules for

example to allow one signal to disable multiple cards. For

further details please refer to the Hardware Interlock section

within the user manual.

100 Ω

+3.3 V

GND

External

Wire Link

Front Panel

Connector

Interlock

Daisy-chain

Interlock

Detection

Circiuitry

Processor Relay Driver(s)

SPI Serial

Comms

Output Enable

SPI Serial

Comms

Output Enable

Drive

Outputs

Relays

Interlock Signal Routing Diagram for 40-553A

Versions With Hardware Interlock Option

Interlock Connector

40-553A

pickeringtest.com Page 2

Speciﬁcations

Table des matières

Autres manuels Pickering Unité de contrôle

Pickering

Pickering 40-559 Manuel utilisateur

Pickering

Pickering 40-170 Manuel utilisateur

Pickering

Pickering 41-670 Manuel utilisateur

Pickering

Pickering 40-574 Manuel utilisateur

Pickering

Pickering 40-519B Manuel utilisateur

Pickering

Pickering PXI 40-710 Manuel utilisateur

Pickering

Pickering 40-582 Manuel utilisateur

Pickering

Pickering 41-761 Manuel utilisateur

Pickering

Pickering 40-292 Manuel utilisateur

Pickering

Pickering BRIC Series Manuel utilisateur

Pickering

Pickering SYSTEM 10 Manuel utilisateur

Pickering

Pickering PXI 40-795-001 Manuel utilisateur

Pickering

Pickering 40-573 Manuel utilisateur

Pickering

Pickering PXI BRIC 40-569 Manuel utilisateur

Pickering

Pickering 40-520 Manuel utilisateur

Pickering

Pickering 4x-585A Manuel utilisateur

Pickering

Pickering 40-884A Manuel utilisateur

Pickering

Pickering 40-582A Manuel utilisateur

Pickering

Pickering 40-561A Manuel utilisateur

Pickering

Pickering 40-670A Manuel utilisateur

Pickering

Pickering 40-262 Manuel utilisateur

Pickering

Pickering 40-880 Manuel utilisateur

Pickering

Pickering PXI BRIC 40-562A Manuel utilisateur

Pickering

Pickering 41-760 Manuel utilisateur

Manuels Unité de contrôle populaires d'autres marques

Festo

Festo Compact Performance CP-FB6-E Manuel de la liste des pièces

Elo TouchSystems

Elo TouchSystems DMS-SA19P-EXTME Manuel utilisateur

JS Automation

JS Automation MPC3034A Manuel utilisateur

JAUDT

JAUDT SW GII 6406 Series Guide rapide

Spektrum

Spektrum Air Module System Manuel utilisateur

BOC Edwards

BOC Edwards Q Series Manuel utilisateur

KHADAS

KHADAS BT Magic Manuel utilisateur

Etherma

Etherma eNEXHO-IL Manuel utilisateur

PMFoundations

PMFoundations Attenuverter Manuel utilisateur

GEA

GEA VARIVENT Manuel utilisateur

Walther Systemtechnik

Walther Systemtechnik VMS-05 Manuel utilisateur

Altronix

Altronix LINQ8PD Instructions de montage

Eaton

Eaton Powerware Series Manuel utilisateur

WAGO

WAGO 750-407/040-000 Manuel utilisateur

Sony

Sony CCU-590 Manuel utilisateur

Graco

Graco 25D614 Manuel utilisateur

Task Force Tips

Task Force Tips YE-RF-900 Manuel de programmation

Shini

Shini SPV-U Series Manuel utilisateur
