Panasonic ESD Diodes MAZE062D Manuel utilisateur

ESD Diodes

Publication date: March 2004 SKE00010CED

Note) *:P

D= 200 mW achieved with a printed circuit board.

MAZE062D

Silicon planar type

For surge absorption circuit

■Features

•Low joint capacity zener diode

■Absolute Maximum Ratings Ta=25°C

Unit: mm

Parameter Symbol Rating Unit

Repetitive peak forward current IFRM 200 mA

Power dissipation *PD150 mW

Junction temperature Tj150 °C

Storage temperature Tstg −55 to +150 °C

Internal connection

Parameter Symbol Conditions Min Typ Max Unit

Forward voltage VFIF=10 mA 0.9 1.0 V

Zener voltage *VZIZ=5 mA 5.9 6.5 V

Zener rise operating resistance RZK IZ=0.5 mA 100 Ω

Zener operating resistance RZIZ=5 mA 30 Ω

Reverse current IRVR=5.5 V 3 µA

Terminal capacitance CtVR=0 V, f =1 MHz 8 pF

■Electrical Characteristics Ta= 25°C ±3°C

Note) 1. Measuring methods are based on JAPANESE INDUSTRIAL STANDARD JIS C 7031 measuring methods for diodes.

2. Absolute frequency of input and output is 5 MHz.

3. Electrostatic breakdown voltage: ±15 kV

Test method: IEC-801 (C = 150 pF, R = 330 Ω, Contact discharge: 10 times)

Test unit: ESS-200AX

4. *: The VZvalue is for the temperature of 25°C. In other cases, carry out the temperature compensation.

Guaranteed at 20 ms after power application.

0.3

2.0

±0.2

1.3

±0.1

(0.65)

(0.65) 0.9

±0.1

2.1

±0.1

1.25

±0.1

0 to 0.1

(0.15)

(0.425)

5˚

+0.1

–0

0.15

+0.1

–0.05

Marking Symbol: 6.2C

1: Cathode 1

2: Cathode 2

3: Anode

EIAJ: SC-79 SMini3-F1 Package

This product complies with the RoHS Directive (EU 2002/95/EC).

MAZE062D

SKE00010CED

0 2001601208040

100

150

200

250

Ambient temperature T

(°C)

Power dissipation P

(mW)

Print foil

t =0.035 mm

10 mm

0.8 mm

10 mm

−3

048

−2

−1

Zener voltage V

(V)

Zener current I

(mA)

=25°C

=−20°C

=150°C

=100°C

−2

0 0.4 0.8 1.2

−1

Forward voltage VF(V)

Forward current IF(mA)

=25°C

=−20°C

=150°C

=100°C

−5

0246

−4

−3

−2

−1

Reverse voltage V

(V)

Reverse current I

(nA)

=150°C

=25°C

=100°C

−1

−2

−1

10110

Zener operating resistance R

(Ω)

Zener current I

(mA)

= 25°C

−5

20 40

Temperature coefficient of zener voltage S

(mV / °C)

Zener current I

(mA)

24 6

Terminal capacitance C

(pF)

Reverse voltage V

(V)

PDTaIZVZIFVF

IRVRRZIZSZIZ

CtVR
