Switching Diodes

Publication date: October 2007 SKF00077AED

This product complies with the RoHS Directive (EU 2002/95/EC).

Note) *:t=1 s

MA3J142AG, MA3J142KG

Silicon epitaxial planar type

For switching circuits

■Features

•Allowing high-density mounting

•Short reverse recovery time trr

•Small terminal capacitance Ct

■Absolute Maximum Ratings Ta=25°C

Parameter Symbol Rating Unit

Reverse voltage VR80 V

Maximum peak reverse voltage VRM 80 V

Forward current IF100 mA

Peak forward current IFM 225 mA

Non-repetitive peak forward IFSM 500 mA

surge current

Junction temperature Tj150 °C

Storage temperature Tstg −55 to +150 °C

Parameter Symbol Conditions Min Typ Max Unit

Forward voltage VFIF=100 mA 1.2 V

Reverse voltage VRIR=100 µA80V

Reverse current IRVR=75 V 100 nA

Terminal capacitance CtVR= 0 V, f = 1 MHz 2 pF

Reverse recovery time *trr IF= 10 mA, VR= 6 V 3 ns

Irr = 0.1 IR , RL= 100 W

■Electrical Characteristics Ta=25°C ±3°C

Bias Application Unit (N-50BU)

90%

Pulse Generator

(PG-10N)

Rs= 50 Ω

Wave Form Analyzer

(SAS-8130)

Ri= 50 Ω

tp= 2 µs

tr= 0.35 ns

δ = 0.05

IF= 10 mA

VR= 6 V

RL= 100 Ω

10%

Input Pulse Output Pulse

Irr = 0.1 IR

trtp

trr

Note) 1. Measuring methods are based on JAPANESE INDUSTRIAL STANDARD JIS C 7031 measuring methods for diodes.

2. Absolute frequency of input and output is 100 MHz.

3. *: trr measurement circuit

■Package

•Code

SMini3-F2

•Pin Name

MA3J142AG MA3J142KG

1: Cathode 1: Anode

2: N.C. 2: N.C.

3: Anode 3: Cathode

■Marking Symbol

MA3J142AG: MB

MA3J142KG: MI

■Internal Connection

MA3J142AG, MA3J142KG

SKF00077AED

This product complies with the RoHS Directive (EU 2002/95/EC).

IFVFIRVRVFTa

IRTaCtVRIF(surge) tW

Characteristics charts of MA3J142AG

−2

0 0.2 0.4 0.6 0.8 1.0 1.2

−1

Forward voltage V

(V)

Forward current I

(mA)

= 150°C

100°C

25°C

−20°C

−1

0 20 40 60 80 100 120

Reverse voltage VR(V)

Reverse current IR(nA)

= 150°C

25°C

100°C

0.4

0.8

1.2

1.6

−40 0 40 80 120 160 200

Ambient temperature T

(°C)

Forward voltage V

(V)

= 100 mA

10 mA

3 mA

−1

−40 0 40 80 120 160 200

Ambient temperature T

(°C)

Reverse current I

(nA)

35 V

6 V

= 75 V

0.8

1.6

2.4

3.2

0 20 40 60 80 100 120

Reverse voltage VR(V)

Terminal capacitance Ct(pF)

f = 1 MHz

Ta= 25°C

−1

10110

−1

Pulse width t

(ms)

Forward surge current I

F(surge)

(A)

Non repetitive

F(surge)

= 25°C

MA3J142AG, MA3J142KG

SKF00077AED

This product complies with the RoHS Directive (EU 2002/95/EC).

Characteristics charts of MA3J142KG

−2

0 0.2 0.4 0.6 0.8 1.0 1.2

−1

Forward voltage V

(V)

Forward current I

(mA)

= 150°C

100°C

25°C

−20°C

0 20 40 60 80 100 120

Reverse voltage VR(V)

Reverse current IR(nA)

25°C

100°C

= 150°C

0.4

0.8

1.2

1.6

–40 0 40 80 120 160 200

Ambient temperature T

(°C)

Forward voltage V

(V)

= 100 mA

10 mA

3 mA

−40 0 40 80 120 160 200

Ambient temperature T

(°C)

Reverse current I

(nA)

= 75 V 35 V

6 V

1.2

1.0

0.8

0.6

0.4

0.2

0 20406080100120

Reverse voltage VR(V)

Terminal capacitance Ct(pF)

f = 1 MHz

Ta =25°C

10 −1

102

103

10110 −1

Pulse width tW(ms)

Forward surge current IF(surge) (A)

Non repetitive

IF(surge)

Ta= 25°C

IFVFIRVRVFTa

IRTaCtVRIF(surge) tW

MA3J142AG, MA3J142KG

SKF00077AED

This product complies with the RoHS Directive (EU 2002/95/EC).

SMini3-F2

Unit: mm

0.30

+0.05

−0.02

0.13

+0.05

−0.02

2.00

±0.20

(0.89)

0.90

±0.10

(0.65)(0.65)

1.30

±0.10

1.25

±0.10

2.10

±0.10

0.425

±0.050

(0.49)

0 to 0.10

(5°)

Request for your special attention and precautions in using the technical information and

semiconductors described in this book

(1)If any of the products or technical information described in this book is to be exported or provided to non-residents, the laws and

regulations of the exporting country, especially, those with regard to security export control, must be observed.

(2)The technical information described in this book is intended only to show the main characteristics and application circuit examples

of the products, and no license is granted under any intellectual property right or other right owned by our company or any other

company. Therefore, no responsibility is assumed by our company as to the infringement upon any such right owned by any other

company which may arise as a result of the use of technical information described in this book.

(3)The products described in this book are intended to be used for standard applications or general electronic equipment (such as office

equipment, communications equipment, measuring instruments and household appliances).

Consult our sales staff in advance for information on the following applications:

–Special applications (such as for airplanes, aerospace, automobiles, traffic control equipment, combustion equipment, life support

systems and safety devices) in which exceptional quality and reliability are required, or if the failure or malfunction of the prod-

ucts may directly jeopardize life or harm the human body.

–Any applications other than the standard applications intended.

(4)The products and product specifications described in this book are subject to change without notice for modification and/or im-

provement. At the final stage of your design, purchasing, or use of the products, therefore, ask for the most up-to-date Product

Standards in advance to make sure that the latest specifications satisfy your requirements.

(5)When designing your equipment, comply with the range of absolute maximum rating and the guaranteed operating conditions

(operating power supply voltage and operating environment etc.). Especially, please be careful not to exceed the range of absolute

maximum rating on the transient state, such as power-on, power-off and mode-switching. Otherwise, we will not be liable for any

defect which may arise later in your equipment.

 Even when the products are used within the guaranteed values, take into the consideration of incidence of break down and failure

mode, possible to occur to semiconductor products. Measures on the systems such as redundant design, arresting the spread of fire

or preventing glitch are recommended in order to prevent physical injury, fire, social damages, for example, by using the products.

(6)Comply with the instructions for use in order to prevent breakdown and characteristics change due to external factors (ESD, EOS,

thermal stress and mechanical stress) at the time of handling, mounting or at customer's process. When using products for which

damp-proof packing is required, satisfy the conditions, such as shelf life and the elapsed time since first opening the packages.

(7)This book may be not reprinted or reproduced whether wholly or partially, without the prior written permission of Matsushita

Electric Industrial Co., Ltd.
