OPTI-UPS RS650B Manuel utilisateur

28.

RS650B

Features

Front Panel

Specifications

* RS650B

* LCD status display

* USB communication port

* Automatic voltage regulator

* Short circuit protection

Line Interactive

UPS Series

On Line UPS

Series

AVR Series

Networking

Series

Inverter Series

Surge Series

Green Power

Series

Standby UPS

Series

Remarkable Series

RS650B

Rear Panel

* Over charge & over discharge protection

* Smart audible & LCD icon alarms

* Surge, spike and lightning protection

* User replaceable battery

RS650B

On/Off

Outlet

USB Port

RJ-11/45

Surge Breaker

www.opti-ups.com

Model Name RS650B

Topology

On-battery Output Waveform

INPUT

Maximum Capacity (VA/W)

Nominal Input Voltage

Nominal Input Frequency

Input Voltage Range

Input Short Protection

OUTPUT

Nominal Output Voltage

Output Voltage Regulation

Transfer Time

Protected Outlets

PROTECTION

Automatic Voltage Regulator (AVR)

Data Line Surge Protection

Output Short Circuit Protection

Normal Mode Noise Suppression

BATTERY

User Replaceable Battery

Typical Recharge Time to 90%

ADVANCE WARNING DIAGNOSTICS

LCD Status Display

Audible Alarms

COMMUNICATIOS INTERFACE

Communication Port

Control Software

Cold-start Capability

PHYSICAL

Dimensions (Physical / Packing) (mm)

(L×W×H) (inch)

Weight (Net / Gross) (lb)

(kg)

CONFORMANCE

Regulatory Approvals

Line-Interactive

Simulated Sine Wave

650VA / 390W

110/120Vac

50Hz / 60Hz Auto Sensing

Rated Voltage +/- 25%

Circuit Breaker

110/120Vac

120Vac +/- 10%, Step Wave

4 ms(Typical)

4 Battery Backup Outlets

Yes

RJ11 / RJ45

Output Auto cut off, Buzzer Beeping

Full time EMI Filtering

Maintenance-free Sealed Lead-Acid Battery, Leakproof

8 Hours

Normal, Fault, Battery, Charge, Overload, Load, Battery Capacity

AC Unusual/Battery Low Voltage/Overload/Short Circuit/PCB Failed, beeps for 60 Seconds

USB Port

UPSlion2000

Yes

330 x 85 x 150 / 357 x 132 x 250

13.0 x 3.4 x 5.9 / 14.1 x 5.2 x 9.9

15.0 / 15.4

6.8 / 7.0

UL/cUL listed, UL497A, UL1778

Remarkable Series

RS650B

Remarkable Series

RS650B
