OPTI-UPS VS375C Manuel utilisateur

Line Interactive

UPS Series

On Line UPS

Series

AVR Series

Networking

Series

Inverter Series

Surge Series

Green Power

Series

Standby UPS

Series

Value Series

The VSC Series are perfect for your personal and small office computers. They protect systems against blackouts,

sags, and surges. The smallest and lightest in its class, this high frequency and high efficiency UPS provides

complete protection for a workstation and its peripherals.

* 3 UPS outlets + 3 surge protected outlets

* Integrated protection for telephone / modem / LAN card

* Cold start capability

* 1050 Joules surge energy rating

VS375C / VS400C / VS575C / VS600C / VS1000C

VS375C / VS400C / VS575C / VS600C

VS400C

VS600C

Features

* RS232 communication port

* Easy battery replacement

* 4 hours recharge time

* Smart power management software

* Auto restart & self-diagnostics

Backup Time (Typical)

VS375C 1PC+1LCD 8 mins

VS400C 1PC+1LCD 9 mins

VS575C 1PC+1LCD 11 mins

VS600C 1PC+1LCD 12 mins

A) ON / OFF, TEST / SILENCE

B) AC Mode

C) Battery Mode

D) Battery Fault

ON/OFF

TEST/SILENCE

AC Mode

Battery Mode

Battery Fault

Front Panel

Rear Panel

Specifications

VS375C

VS575C

100V

110V

120V

RJ45/11

AC Input

RS232

Bypass

UPS Outlet

220V

230V

240V

RJ45/11

AC Input

RS232

Bypass

UPS Outlet

Standby

Simulated Sine Wave

100 / 110 / 120Vac or 220 / 230 / 240Vac

50Hz / 60Hz Auto Sensing

Rated Voltage +/- 20%

Fuse

100 / 110 / 120Vac or 220 / 230 / 240Vac

Rated Voltage +/- 5% (on battery)

4 ms (typical)

3 Battery backup + 3 Surge (US)

3 Battery backup + 3 Surge (IEC)

RJ11 / RJ45

1050 Joules

Full time EMI/RFI filtering

< 4 Hours

RS232

0°~40°C / 32°~104°F

-20°~60°C / -4°~140°F

< 40dBA

7.9 x 3 x 6.9 / 9.6 x 5 x 9.8

200 x 77 x 175 / 248 x 127 x 250

BSMI ; CE

UL / cUL ; C-Tick , A-Tick ; GOST-R

Model Name

Topology

On-battery Output Waveform

INPUT

Maximum Capacity

Nominal Input Voltage **

Nominal Input Frequency

Input Voltage Range

Input Short Protection

OUTPUT

Nominal Output Voltage

Output Voltage Regulation

Transfer Time

Number of Outlets

PROTECTION

Data Line Surge Protection

Surge Energy Rating

Normal Mode Noise Suppression

BATTERY

User Replaceable Battery

Recharge Time to 90%

COMMUNICATIONS INTERFACE

Communication Port*

ENVIRONMENTAL

Operation Temperature

Storage Temperature

Audible Noise

PHYSICAL

Dimensions (Physical / Packing)

(L x W x H)

Weight (Net / Gross)

CONFORMANCE

5.1/ 6.4

2.3 / 2.9

5.3 / 6.6

2.4 / 3.0

(in)

(mm)

575VA / 345W

12V / 3AH x 1 12V / 3.8AH x 1

375VA / 225W

(lbs)

(kg)

Approvals

Win

windows

95/98

ME/NT

IBM

IBM OS/2

IBM AIX

SUN Solaris

HP-UX

SGI Irix

Novell Netware

Linux

FreeBSD

Specifications are subject to change without notice.

You can purchase RS232 to USB cable.

** See VS1000C on page 6

windows

2000 / XP

2003 / Vista

VS375C / VS400C VS575C / VS600C

Simulated

Sine Wave

For personal computers and SOHO
