UNITY/I

User Manual

UT3K, UT4K, UT5K, and UT8K

Single-Phase Uninterruptible Power Systems

MLS-0350B-OL

IMPORTANT SAFETY INSTRUCTIONS

SAVE THESE INSTRUCTIONS

This manual contains important instructions for your UNITY/I UPS.

The installation and use of this product must comply with all national, federal, state, municipal or local codes that apply.If you

need help, please have your UPS model and serial number and call Best Power’s Worldwide Service at 1-800-356-5737 (U.S.A.

or Canada) or 1-608-565-2100. Outside of the U.S.A. and Canada, you can also call the nearest Best Power office for more

information.

Best Power

P.O. Box 280

Necedah, Wisconsin 54646 U.S.A.

Telephone: 1-608-565-7200

Toll-free: 1-800-356-5794 (U.S.A. and Canada)

FAX: 1-608-565-2221

International Fax: 1-608-565-7675

Worldwide Service, Best Power

P.O. Box 11

Necedah, Wisconsin 54646 U.S.A.

Telephone: 1-608-565-2100

Toll-free: 1-800-356-5737 (U.S.A. and Canada)

FAX: 1-608-565-7642

Best Power Technology Mexico, S.A. de C.V.

Golfo de Riga, 34

Colonia Tacuba

Mexico D.F. 11410

MEXICO

Telephone: (52)(5) 399-0369

FAX: (52)(5) 399-1320

Best Power Technology Pte. Ltd.

PICO Creative Centre, Level 5

20 Kallang Avenue

SINGAPORE 339411

Telephone: 65-2938122

FAX: 65-2968766

Sola Australia Ltd.

13 Healey Road

Dandenong Victoria 3175

AUSTRALIA

Telephone: 61-3-9706-5022

FAX: 61-3-9794-9150

Best Power Technology Limited

BEST House

Wykeham Industrial Estate

Moorside Road

Winchester

Hampshire

SO23 7RX

ENGLAND

Telephone: (44) 1962-844414

Toll-Free: 0800-378444

FAX: (44) 1962-841846

Best Power Technology GmbH

Am Weichselgarten 23

D-91058 Erlangen

GERMANY

Telephone: +49/9131/77700

Gebührenfrei: 0130/84/7712 (in Germany)

Fax: +49/9131/777050

Borri Elettronica Industriale Srl

Via dei Lavoratori, 124

20092 CINISELLO BALSAMO (Mi)

Milan, ITALY

Telephone: (39) 2-6600661-2

FAX: (39) 2-6122481

Best Power Technology AG

Limmatstrasse 12

8957 Spreitenbach

SWITZERLAND

Telephone: 056/418-30-30

FAX: 056/418-30-33

IF THE UPS IS SOUNDING AN ALARMand you need to know what the alarm means and how to respond, turn to Section

204. To silence the audible alarm, press the [CANCEL] key.Silencingthe audible alarm does not correct the condition that caused

the alarm.

CAUTION!

All uninterruptible power systems (UPS) units contain dangerous voltages.

The unit can provide power from its batteries. To avoid possible personal injury or equipment dam-

age, assume that hazardous voltage is present at the unit’s output any time AC input power or DC

battery voltage is applied. To make certain there is no output voltage, turn the unit off, unplug the

unit, and disconnect all DC sources.

For units with line cords, the power supply cord is intended to serve as the disconnect device. The

socket-outlet shall be near the equipment and shall be easily accessible.

Before maintenance or repair, all connections must be removed. Before maintenance, repair, or

shipment, the unit must be completely switched off and unplugged or disconnected.

VORSICHT!

Vorsicht: Alle USV-Einheiten beinhalten gefährliche Spannungen.

Wenn der “Ein/Aus”-Schalter der USV eingeschaltet ist, kann an den Steckdosen der USV

gefährliche Spannung anliegen. Die Batterie der USV liefert selbst dann Strom, wenn die USV nicht

ans Netz angeschlossen ist.

Bei Modellen mit Netzstecker wird zum Abschalten des Geräts der Stecker aus der Steckdose gezo-

gen; bei anderen Modellen muß der Wechselstrom-Trennschalter benutzt werden. Die Steckdose muß

sich in der Nähe des Gerätes befinden und bequem erreichbar sein.

Achtung: Vor einer Wartung oder Instandsetzung müssen alle Anschlußleitungen entfernt werden.

Vor einer Wartung, Instandsetzung oder Transport muß die USV komplett abgeschaltet und

abgesteckt werden.

Table of Contents

Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1

001 Storing the UNITY/I UPS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1

002 If You Have a Question . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1

100 Starting the UNITY/I UPS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2

101 Startup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3

102 Setting the Time and Date . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5

200 Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7

201 Front Panel Lights . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7

202 Front Panel Keys and Display . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8

203 Inside the Front Door . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9

204 Alarms: What They Mean and What to Do About Them . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10

205 If You Have an Extended Power Outage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13

206 Shutting Down the UNITY/I . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13

300 Parameters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14

301 Displaying Parameters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14

302 Changing Parameter Values . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .15

303 Parameter Table . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .16

400 Maintenance and Service . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .20

401 Regular Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .20

402 Worldwide Service . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .20

403 Accessing the Alarm and System Logs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .21

500 Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .23

600 Options . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .27

Appendix A: Remote Emergency Power Of (EPO) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .29

Appendix B: Attaching the Stabilizer Bracket . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .30

Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .31

4/97

This manual is for units with ROM versions 1.06-1.08.

Introduction

The UNITY/I™ UPS is easy to start and operate. Once you start the UPS, it provides continuous, computer-

grade power to your equipment. The UPS keeps you informed of its status with its front panel lights, four-digit

display, and audible signals (beeper). Using the display and front panel keys, you can display UPS information

and program some features.

This manual tells you how to start and operate the UNITY/I UPS. Begin with Section 100, “Starting the

UNITY/I UPS,” which will help you determine whether you need to do any installation before you start the

UPS.

001 Storing the UNITY/I UPS

If you are not going to use the UPS right away, store it between -20° and +40° Celsius (-4° to +104° F). If you

remove the batteries and store them separately, you can store the UPS at -20° to +60° Celsius (-4° to +140° F).

Batteries have a longer shelf life if you store them below 25° Celsius (77° F).Recharge stored batteries every

90 to 120 days.

002 If You Have a Question

Best Power is committed to outstanding customer service. Worldwide Service is happy to help you with your

problems or questions. A service technician is available 24 hours a day, 365 days a year. Just call Worldwide

Service or the nearest Best Power office, or send a fax to the Worldwide Service fax number. Please have your

unit’s serial number available when you call; this number is inside the front door of the UPS.

If you prefer to contact Best Power via computer, you can use Bulletin Board Service, CompuServe, or Best

Power’s World Wide Web site to get more product information.

Best Power’s toll-free Fax-on-Demand service is also available 24 hours a day to give you access to technical

notes and product information.

Worldwide Service: 1-800-356-5737 (U.S., Canada) or 1-608-565-2100

Worldwide Service FAX: 1-608-565-7642 or 1-608-565-2509

Bulletin Board Service 1-608-565-7424

CompuServe: Go BEST at any ! prompt.

World Wide Web Site: http:/www.bestpower.com

Fax on Demand: 1-800-487-6813 (U.S. and Canada)

* The drawings in Figure 1 show a UT3K, UT4K or UT5K. The UT8K is similar in appearance.

100 Starting the UNITY/I UPS

If your UNITY/I UPS does not have an input line cord and plug, it is a hardwired unit and must be installed by a

qualified electrician (see the

UNITY

/I Installation Manual). After a qualified electrician has installed the UPS,

or if the UPS has an input plug, follow the instructions in this section to start the unit.

Make sure that the UPS is near the equipment it will protect. Leave at least 4 inches (100 mm) space on top of

and behind the UPS for ventilation. Do not put the UPS near a source of heat.

Make sure that the temperature is 0° to 40° Celsius (32° to 104° Fahrenheit) and the relative humidity is 0 to

95% without condensation. The air must be free of dust, chemicals that corrode or other contaminants. Air must

be free to move around the unit. The batteries’ service life is longer if the operating ambient temperature

stays below 25° C (77° F).

Front View* Back View*

Output

Receptacles

(optional)

Front Panel Lights,

Display, and Keys

Front Door

(Keyswitch and

Serial Number

Inside)

Serial Number

Main Output

Circuit Breaker

(some models)

Communication

Port

Line Cord

DC Port

Grounding

Terminal

Stabilizer

Bracket

Figure 1

101 Startup

1If you have a UT3K, UT4K or UT5K:Attach the stabilizer

bracket to the back of the UPS (see Appendix B).

2Open the UPS’ front door by pulling the top of the door

toward you (see Figure 1 to find the door). Make sure that

the keyswitch inside the front door is turned to “Off” (see

Figure 2).

3If your UNITY/I has an input line cord and plug:Plug in

the UPS. If the plug does not match the wall outlet, have a

qualified electrician install the proper wiring and outlet.

If your UNITY/I is hardwired (does not have an input line

cord and plug),an electrician should have installed the UPS.

An external bypass/AC disconnect switch should be mounted

on the wall nearby (see Figure 3). Turn the UPS AC LINE

DISCONNECT SWITCH to “ON” and the UPS BYPASS

SWITCH to “OFF.”

4If you have an external battery pack(s)(see Figure 4), refer to the

installation instructions that came with your battery pack(s). Then continue

with the steps below:

a. After completing the battery pack installation, hold down the Precharge

switch on the front of the battery cabinet for five seconds (see Figure 5).

b. Insert the key into the main DC switch on the front of the battery

cabinet. Turn it clockwise, then pull the switch out toward you. The

ON-LINE light will light on the battery pack cabinet.

5Turn the keyswitch inside the front door of the UPS to “Auto” (see Figure

6). The yellow BATTERY light will turn on briefly, then the green LINE

light will turn on.

Figure 2

Figure 3

Figure 4

Figure 5

Precharge Switch

Keyswitch

UNITY/I Battery Pack

Figure 6

The four-digit display will show the estimated runtime

in minutes and seconds (see Figure 7). For now, the

estimated runtime is high because there is no equipment

drawing power from the UPS. If the red ALARM light

is on,see Section 204 before you go on.

Note:Do not continue until the green LINE light is on. The UPS is set at the factory to automatically select

its output frequency; to do this, the UPS mustrun on AC line. If the UPS does not run on ACline the

first time you start it, you must either set parameters 14 and 15 or wait until the green LINE light

comes on before you switch on the connected equipment. To set the parameters, see Section 302.

6Once you switch on the unit and the LINE light comes on, the UPS will begin to charge the batteries. If this

is the first time you have started the UPS, let the UPS run on line for at least 24 hours to charge the

batteries. You may use the UPS right away; however, its battery runtime will be reduced until it fully

charges the batteries.

7If your UNITY/I has receptacles on the back,switch off the equipment you want to connect to the UPS.

Then, plug the equipment into the receptacles on the back of the UPS and switch on the equipment. If the

red ALARM light comes on, see Section 204.

If your UNITY/I does not have receptacles on the back,the electrician who installed the UNITY/I should

have connected your equipment to it. Turn the UPS BYPASS SWITCH (see Figure 3) to “UPS.” Then,

switch on the equipment connected to the UPS. If the red ALARM light comes on, see Section 204.

The UNITY/I UPS is now providing continuous, computer-grade power to your equipment and is ready to

provide battery backup power when needed.

Note:You may occasionally hear short “clicking” sounds inside the unit; these clicks are a normal part of

unit operation.

8If you plan to use CheckUPS software, connect the interface cable from the UPS to the computer system,

with the “UPS” end connected to the UNITY/I.

Using CheckUPS with Windows 95:Shut down your computer and insert the CheckUPS CD. Restart the

computer. Follow the instructions in the CheckUPS package.

Using CheckUPS withoutWindows 95:Start the computer and follow the instructions in the CheckUPS

package.

9Fill out the warranty registration card in this manual and return it to Best Power. Please return the registra-

tion card within ten days of installation.

Figure 7

102 Setting the Time and Date

The UPS stores the time, date, and year in parametersthat you can program (see Section 300 for more about

parameters). These parameters must be programmed correctly so that the UPS can store accurate information in

its alarm and system logs. Whenever the UPS has been shut down, you should reset the time and date after you

restart the UPS. To set the time, date, and year parameters, follow the steps below.

Note:When the unit is in parameter mode, the functions of the front panel keys change. The label inside the

front door of the unit explains what the keys do when the UPS is in parameter mode. The label also

shows a “Programming Template” with different key names for parameter mode.

1.To enter the parameter mode, hold down the [CANCEL] and [RUNTIME] keys together. Release the keys when

the display changes to P-00(for parameter 0).

2.Enter the user password (377) by following these steps:

a. Press [CANCEL]. The display should show 0(the value of parameter 0).

b. Use the [%LOAD] key to change the display to 377. If you accidentally scroll past 377, use the [VOUT]

key to go back.

Note:If you hold downthe [%LOAD] or the [VOUT] key, the display will scroll more quickly after a few

seconds.

c. Press [RUNTIME]. The display should show Ito show you have entered the user password.

d. Press [CANCEL]. The display should show P-00.

3.Set the year (parameter 91) by following these steps:

a. Use the [%LOAD] key to change the display to P-9I.

b. Press [CANCEL]. The display should show a year.

c. Use the [%LOAD] orthe [VOUT] key to change the display to the correct year.

d. Press [RUNTIME]. The display should show the correct year.

e. Press [CANCEL]. The display should show P-91.

4. Set the date (parameter 90) by following these steps:

a. Use the [VOUT] key to change the display to P-90.

b. Press [CANCEL]. The display should show a date formatted as mm.dd (month.day).

c. Use the [%LOAD] or [VOUT] key to change the display reading to the correct month and day. For example, if

the date were March 27, you should enter “0327.”

d. Press [RUNTIME]. The display should show the correct date (mm.dd).

e. Press [CANCEL]. The display should show P-90.

5. Set the time (parameter 89) by following these steps:

a. Use the [VOUT] key to change the display to P-89.

b. Press [CANCEL]. The display should show a time formatted as hh:mm (hour:minute).

c. Use the [%LOAD] or [VOUT] key to change the display reading to the correct time in 24-hour time. For times

from 1 p.m. to 11:59 p.m., add twelve to the hour. For example, 2:30 p.m. would be 14:30.

d. Press [RUNTIME]. The display should show the correct time (in 24-hour time).

e. Press [CANCEL]. The display should show P-89.

6. To escape the parameter mode, press [VLINE] twice.

Autres manuels pour Unity/I UT3K

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Best Power UPS

Best Power

Best Power Fortress LI520 Manuel utilisateur

Best Power

Best Power Fortress AS/400 Manuel utilisateur

Best Power

Best Power Sola 305 Manuel utilisateur

Best Power

Best Power Patriot Pro II 1000 VA Manuel utilisateur

Best Power

Best Power B610 Manuel utilisateur

Best Power

Best Power UNITY/I UT310 Manuel utilisateur

Best Power

Best Power Unity/I UT3K Manuel utilisateur

Best Power

Best Power 610 3.0kVA Manuel utilisateur

Best Power

Best Power B510-0600A Manuel utilisateur

Best Power

Best Power Fortress Manuel utilisateur

Best Power

Best Power 0650 SERIES Mode d’emploi

Best Power

Best Power Axxium Pro 9910 Manuel utilisateur

Best Power

Best Power Patriot 250 VA Manuel utilisateur

Best Power

Best Power Fortress 750 VA Manuel utilisateur

Best Power

Best Power UNITY/I UT310 Manuel utilisateur

Best Power

Best Power SOLA UPS 620 Rackmount Series Manuel utilisateur

Best Power

Best Power Fortress 750 VA Manuel utilisateur

Best Power

Best Power Fortress.TeleCom 750 VA Manuel utilisateur

Best Power

Best Power 610 Manuel utilisateur

Manuels UPS populaires d'autres marques

Pylontech

Pylontech Victron & Pylontech US5000 Manuel utilisateur

Tecnoware

Tecnoware EVO DSP PLUS MM 6.8 Manuel utilisateur

Mecer

Mecer ME-1000-WTU Manuel utilisateur

Mustek

Mustek PowerMust 530(B) Plus Manuel d'installation et d'exploitation

Emerson

Emerson Liebert NXL series Manuel utilisateur

MAKELSAN

MAKELSAN BOXER SERIES Manuel utilisateur

Block

Block PC-0524-400-0 Manuel utilisateur

CyberPower

CyberPower CP585LCD Manuel utilisateur

Eaton

Eaton 3S Instructions de montage

CyberPower

CyberPower Office Tower Series UPS 1000 Manuel utilisateur

CyberPower

CyberPower BM100 Manuel utilisateur

Mustek

Mustek PowerMust 400 Offline Manuel utilisateur

Xantrex

Xantrex Trace 512 UR-UPS Manuel utilisateur

Forza

Forza SL-1501UL Manuel utilisateur

LEGRAND

LEGRAND keor 310081 Manuel utilisateur

ABB

ABB Conceptpower DPA 500 Manuel utilisateur

ZincFive

ZincFive BC Series Manuel utilisateur

BPC

BPC 1.5K SMART Manuel utilisateur
