OPTI-UPS Power Series Manuel utilisateur
User Guide
Power Series
Models PS1000B, PS1500B, PS2200B, PS3000B
PS1000B-RM, PS1500B-RM, PS2200B-RM,
PS3000B-RM
1
CopyrightOPTI International Corporation, 1997. All rights reserved. OPTI-UPS
and OPTI-SAFE Xtreme are trademarks of OPTI-UPS Corporation
For your records
The serial number of your UPS is on the rear panel. You should note the
serial number in the space provided below. Retain this booklet as a
permanent record of your purchase to aid in identification in the event of
theft or loss.
Model No:
Serial No.:
Purchase Date:
LIMITED WARRANTY
What the warranty covers:
We warrant this product to be free from defects in material and workmanship
during the warranty period. If a product proves to be defective in material or
workmanship during the warranty period, we will at our sole option repair or
replace the product with a like product.
How long the warranty is effective:
For accurate warranty period and conditions, please contact local branch offices or
your dealers.
Who the warranty protects:
This warranty is valid only for the first consumer purchaser.
What the warranty does not cover:
1. Any product on which the serial number has been defaced, modified or
removed.
2. Damage, deterioration or malfunction resulting from:
a) Accident, misuse, neglect, fire, water, or other acts of nature,
unauthorized product modification, or failure to follow instructions
supplied with the product.
b) Repair or attempted repair by anyone not authorized.
c) The fault is result of accidental damage or damage in transit or
transportation, including but not limited to liquid spillage.
d) Removal or installation of the product.
e) Causes external to the product.
f) Use of supplies or parts not meeting our specifications.
g) Normal wear and tear.
h) Any other cause which does not relate to a product defect.
3. Removal, installation and set-up service charges.
Limitation of implied warranties:
THERE ARE NO WARRANTIES, EXPRESS OR IMPLIED, WHICH EXTEND
BEYOND THE DESCRIPTION CONTAINED HEREIN INCLUDING THE IMPLIED
WARRANTY OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR
PURPOSE.
Exclusion of damages:
OUR LIABILITY IS LIMITED TO THE COST OF REPAIR OR REPLACEMENT OF
THE PRODUCT. WE SHALL NOT BE LIABLE FOR:
1. DAMAGE TO OTHER PROPERTY CAUSED BY ANY DEFECTS IN THE
PRODUCT*, DAMAGES BASED UPON INCONVENIENCE, LOSS OF
USE OF THE PRODUCT, LOSS OF TIME, LOSS OF PROFITS, LOSS OF
BUSINESS OPPORTUNITY, LOSS OF GOODWILL, LOSS OF DATA,
LOSS OF SOFTWARE, COSTS OF SUBSTITUTE EQUIPMENT,
INTERFERENCE WITH BUSINESS RELATIONSHIPS, CLAIMS BY
THIRD PARTIES, OR OTHER COMMERCIAL LOSS, EVEN IF ADVISED
OF THE POSSIBILITY OF SUCH DAMAGES.
2. ANY OTHER DAMAGES, WHETHER INCIDENTAL, CONSEQUENTIAL
OR OTHERWISE.
3. ANY CLAIM AGAINST THE CUSTOMER BY ANY OTHER PARTY.
Effect of state law:
This warranty gives you specific legal rights, and you may also have other rights
which vary from state to state. Some states do not allow limitations on implied
warranties and/or do not allow the exclusion of incidental or consequential damages,
so the above limitations and exclusions may not apply to you.
Limitations of Warranty (for Australian States and Territories)
The Trade Practices Act 1974 and corresponding State and Territory Fair Trading
Acts or legalization of another Government (“the relevant acts”) in certain
circumstances imply mandatory conditions and warranties which cannot be excluded.
This warranty is in addition to and not in replacement for such conditions and
warranties. To the extent permitted by the Relevant Acts, in relation to your product
and any other materials provided with the product (“the Goods”) the liability of Opti
Australia under the Relevant Acts is limited, at the option of Opti Australia to:
•Replacement of the Goods; or
•Repair of the Goods; or
•Payment of the cost of replacing the Goods; or
•Payment of the cost of having the Goods repaired.
Opti Australia reserves the right to request proof of purchase upon any warranty
claim.
Life Support:
We do not recommend the use of our UPS products for life support equipment or
direct care where failure of a UPS product could cause failure of, or diminished
effectiveness of the life support equipment or patient care.
EFFECTIVE October 1, 1997
IMPORTANT SAFETY INSTRUCTIONS
SAVE THESE INSTRUCTIONS !
THIS MANUAL CONTAINS IMPORTANT SAFETY INSTRUCTIONS.
KEEP THIS MANUAL HANDY FOR REFERENCE.
•CAUTION: A BATTERY CAN PRESENT A RISK OF ELECTRICAL SHOCK,
BURNS FROM HIGH SHORT-CIRCUIT CURRENT, FIRE OR EXPLOSION
FROM VENTED GASES. OBSERVE PROPER PRECAUTIONS.
•WHEN REPLACING BATTERIES, USE THE SAME NUMBER AND THE
FOLLOWING TYPE BATTERIES: SEALED LEAD-ACID MAINTENANCE FREE
(PS1000B: 1234W x2) (PS1500B: 1234W x3) (PS2200B: 7.2AH/12V x8)
(PS3000B: 1234W x8) (PS1000B-RM: 7.2AH/12V x3) (PS1500B-RM: 1234W x3)
(PS2200B-RM: 1221W x8) (PS3000B-RM: 1221W x8)
•PROPER DISPOSAL OF BATTERIES IS REQUIRED. REFER TO YOUR LOCAL
CODES FOR DISPOSAL REQUIREMENTS.
CAUTION: !
THE UPS CONTAINS VOLTAGES WHICH ARE POTENTIALLY
HAZARDOUS. ALL REPAIRS SHOULD BE PERFORMED BY
QUALIFIED SERVICE PERSONNEL.
THE UPS HAS ITS OWN INTERNAL ENERGY SOURCE (BATTERY).
THE OUTPUT RECEPTACLES MAY BE ALIVE EVEN WHEN THE UPS
IS NOT CONNECTED TO AN AC SUPPLY.
Safe and continuous operation of the UPS depends partially on the care taken by
users. Please observe the following precautions.
•Do not disassemble the UPS.
•Do not attempt to power the UPS from any receptacle except a 2-pole
3-wire grounded receptacle.
•Do not place the UPS near water or in environments of excessive humidity.
•Do not allow liquid or any foreign objects to get inside the UPS.
•Do not block air vents on the side of the UPS.
•Do not plug appliances, such as hair dryers, into the UPS receptacles.
•Do not place the UPS under direct sunshine or close to heat-emitting
sources.
•This UPS is intended for installation in a temperature controlled, indoor area
free of conductive contaminants.
•The socket-outlet shall be installed near the UPS and easily accessible.
•With the installation of the UPS it should be prevented, that the sum of the
leakage current of the UPS and the connected consumer exceeds 3.5mA.
•The battery supply should be disconnected in the plus and minus pole at the
quick connectors of the battery when maintenance or service work inside the
UPS is necessary.
•Do not dispose of batteries in a fire, the battery may explode.
•Do not open or mutilate the battery or batteries, released electrolyte is
harmful to the skin and eyes.
•A battery can present a risk of electric shock and high short circuit current.
The following precaution should be observed when working on batteries
* Remove watches, rings or other metal objects.
* Use tools with insulated handles.
FEDERAL COMMUNICATIONS COMMISSION (FCC)
WARNING:
This equipment has been tested and found to comply with the limits for a
Class B digital device, pursuant to Part 15 of the FCC rules. These limits
are designed to provide reasonable protection against harmful interference
in a residential installation.
This equipment generates, uses and can radiate radio frequency energy
and if not installed and used in accordance with the instructions, may cause
harmful interference to radio communications. However there is no
guarantee that interference will not occur in a particular installation. If this
equipment does cause harmful interference to radio or television reception,
which can be determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of the following
measures:
•Reorient or relocate the receiving antenna.
•Increase the separation between the equipment and the receiver.
•Connect the equipment into an outlet on a circuit different from that to
which the receiver is connected.
•Consult the dealer or an experienced radio/TV technician for help.
CANADIAN DEPARTMENT OF COMMUNICATIONS (DOC)
This equipment does not exceed Class B limits for radio noise emissions
from digital apparatus set out in the Radio Interference Regulation of the
Canadian Department of Communications. Operation in a residential area
may cause Unacceptable interference to radio and TV reception requiring
the owner or operator to take whatever steps are necessary to correct the
interference.
PS1000B/ PS1500B/ PS2200B/ PS3000 1
TABLE OF CONTENTS
1. INTRODUCTION
1.1 Overview 2
1.2 Sinewave Output 2
1.3 Smart Buck and Boost Line Conditioning 2
1.4 User Replaceable Battery Design 3
1.5 Advanced Interface to Communicate with Computer 3
1.6 User Configurable Settings 3
1.7 Data-Line Surge Protection 3
2. UPS CONTROLS
2.1 External Views 4
Front Panel 4
Rear Panel 5
2.2 On Button 6
2.3 Off Button 6
2.4 Select Button 7
2.5 Load Percentage Bar Graph 7
2.6 Battery Capacity bar graph 7
2.7 Fault code 7
2.8 Status Indication 7
2.9 Communication Port 8
2.10 Start-Up On Battery 8
2.11 Data-Line Surge Suppression 8
3. INSTALLATION AND OPERATION
3.1 Unpacking and Inspection 9
3.2 Placement 9
3.3 Determining How Much Equipment You Can Connect to
Your UPS 9
3.4 Powering Up Your UPS 10
3.5 Connecting Your Equipment to the UPS 10
3.6 Operation and Functional Test 12
3.7 Storage Instructions 12
4. SPECIFICATIONS
4.1 Electrical Specifications 13
4.2 Mechanical Specifications 15
4.3 Environmental Specifications 15
5. TROUBLESHOOTING
5.1 Troubleshooting Chart 16
6. USER REPLACEABLE BATTERY
6.1 Warning 17
6.2 Battery Replacement Procedure 18
2 PS1000B / PS1500B/ PS2200B / PS3000B
1. INTRODUCTION
1.1 Overview
These models are advanced line-interactive true sinewave uninterruptible power
systems (UPS) designed to prevent spikes, surges, sags, transients and
blackouts from reaching your sensitive equipment. Your equipment may include
such items as computers and computerized instruments to telecommunication
systems. When AC power is present, the UPS filters and conditions the power
continuously. When AC power fails, the unit employs its internal maintenance-
free battery to supply back-up power without interruption.
1.2 Sinewave Output
The output voltage is a true sinewave, the same waveform that your equipment
gets from the wall outlet. This provides guaranteed compatibility with all types of
loads and even the most sensitive equipment.
1.3 Smart Buck and Boost Line Conditioning
The voltage from your AC power source can fluctuate above and below the
standard rating. This microprocessor controlled UPS provides line conditioning
via both buck (step-down voltage) and boost (step-up voltage) functions. For
example, if your normal voltage is 120V and the voltage fluctuates up to 132V,
the buck function in your UPS will step it down so that your equipment receives
approximately 120V. If the voltage fluctuates down to 108V, the boost function
will step it up so that your equipment receives approximately 120V. This
provides your equipment with excellent voltage regulation with less possibility
for the UPS to drain its internal battery.
Ce manuel convient aux modèles suivants
8
Table des matières
Autres manuels OPTI-UPS UPS
OPTI-UPS
OPTI-UPS VS375C Manuel utilisateur
OPTI-UPS
OPTI-UPS DS1000B Manuel utilisateur
OPTI-UPS
OPTI-UPS OD330 Manuel utilisateur
OPTI-UPS
OPTI-UPS CS500B Manuel utilisateur
OPTI-UPS
OPTI-UPS Inverter Series IS1100LT Manuel utilisateur
OPTI-UPS
OPTI-UPS Thunder Shield TS1250W Manuel utilisateur
OPTI-UPS
OPTI-UPS CS500B Manuel utilisateur
OPTI-UPS
OPTI-UPS VS375C Manuel utilisateur
OPTI-UPS
OPTI-UPS Power PS500C Manuel utilisateur
OPTI-UPS
OPTI-UPS PS650D Manuel utilisateur
OPTI-UPS
OPTI-UPS EL3000-AL Manuel utilisateur
OPTI-UPS
OPTI-UPS Fighter Series FS600 / FS600B Manuel utilisateur
OPTI-UPS
OPTI-UPS DS1000B Manuel utilisateur
OPTI-UPS
OPTI-UPS On Line UPS Series DS1000B-RM Manuel utilisateur
OPTI-UPS
OPTI-UPS Excalibur 5000AL Manuel utilisateur
OPTI-UPS
OPTI-UPS ES1000C-RM Manuel utilisateur
OPTI-UPS
OPTI-UPS DS-D33 Manuel utilisateur
OPTI-UPS
OPTI-UPS OD330 Manuel utilisateur
OPTI-UPS
OPTI-UPS DS10KB31 Manuel utilisateur
OPTI-UPS
OPTI-UPS Stabilizer Series SS10000 Manuel utilisateur
Manuels UPS populaires d'autres marques
Pylontech
Pylontech Victron & Pylontech US5000 Manuel utilisateur
Tecnoware
Tecnoware EVO DSP PLUS MM 6.8 Manuel utilisateur
Mecer
Mecer ME-1000-WTU Manuel utilisateur
Mustek
Mustek PowerMust 530(B) Plus Manuel d'installation et d'exploitation
Emerson
Emerson Liebert NXL series Manuel utilisateur
MAKELSAN
MAKELSAN BOXER SERIES Manuel utilisateur
