Introduction

1 Introduction

Welcome to Kramer Electronics! Since 1981, Kramer Electronics has been

providing a world of unique, creative, and affordable solutions to the vast range

of problems that confront the video, audio, presentation, and broadcasting

professional on a daily basis. In recent years, we have redesigned and upgraded

most of our line, making the best even better! Our 1,000-plus different models

now appear in 11 groups

that are clearly defined by function.

Congratulations on purchasing your Kramer DigiTOOLS® TP-551N HDMI

Line Transmitter and Kramer DigiTOOLS® TP-552N HDMI Line Receiver

which are ideal for:

Home theater, presentation and multimedia applications

Rental and staging

The package includes the following:

TP-551N and/or TP-552N

Power adapter (5V DC Input)

This user manual

2 Getting Started

We recommend that you:

Unpack the equipment carefully and save the original box and

packaging materials for possible future shipment

Review the contents of this user manual

Use Kramer high performance high resolution cables

2.1 Quick Start

This quick start chart summarizes the basic setup and operation steps.

1 GROUP 1: Distribution Amplifiers; GROUP 2: Switchers and Matrix Switchers; GROUP 3: Control Systems; GROUP 4:

Format/Standards Converters; GROUP 5: Range Extenders and Repeaters; GROUP 6: Specialty AV Products; GROUP 7:

Scan Converters and Scalers; GROUP 8: Cables and Connectors; GROUP 9: Room Connectivity; GROUP 10: Accessories

and Rack Adapters; GROUP 11: Sierra Products

2 Download up-to-date Kramer user manuals from the Internet at this URL: http://www.kramerelectronics.com

3 The complete list of Kramer cables is on our Web site at http://www.kramerelectronics.com

KRAMER: SIMPLE CREATIVE TECHNOLOGY

Getting Started

Overview

3 Overview

The Kramer TP-551N and the TP-552N constitute a high quality HDMI line

transmitter / receiver system using two STP CAT 5E cables. The transmission

range between the HDMI source and the HDMI acceptor can be extended to

up to 60m (200ft) @ 1080i and 50m (166ft)@1080p.

This transmitter / receiver pair:

Supports up to 1.65Gbps bandwidth

Passes the EDID, HPD

and CEC

signals from the source to the

display device using the CAT 5E cables

The TP-551N HDMI Line Transmitter features:

An HDMI input and a pair of RJ-45 CAT 5 output connectors

Three status LEDs (INPUT, OUTPUT and POWER)

The TP-552N HDMI Line Receiver features:

An HDMI output and a pair of RJ-45 CAT 5 input connectors

Three status LEDs (INPUT, OUTPUT and POWER)

EQ. adjustment to enhance performance

3.1 Shielded Twisted Pair (STP) / Unshielded Twisted Pair (UTP)

The decision whether to use shielded twisted pair (STP) cable or unshielded

twisted pair (UTP) cable depends on the nature of the application.

It is recommended that in applications with high interference, shielded twisted

pair (STP) cable is used. However, the shield itself does create a capacitance

that degrades the frequency response of the machines. For shorter distances, of

50m or so, shielded twisted pair (STP) cable is preferred because it provides

protection from interference (degradation is not apparent).

For long range applications, unshielded twisted pair (UTP) cable is preferred.

However, the unshielded twisted pair (UTP) cable should be installed far away from

electric cables, motors and so on, which are prone to create electrical interference.

In general, it is recommended to use shielded twisted pair (STP) skew-free

Kramer cable BC-SXTP for transmitting VGA signals, and shielded twisted

pair (STP) non-skew-free Kramer BC-STP cable for digital signals.

1 High Performance Data

2 Consumer Electronics Control

KRAMER: SIMPLE CREATIVE TECHNOLOGY

Overview

3.2 About HDMI

High-Definition Multimedia Interface (HDMI) is an uncompressed all-digital

audio/video interface, widely supported in the entertainment and home cinema

industry. It delivers the highest high-definition image and sound quality.

In particular, HDMI

Provides a simple

interface between any audio/video source, such as a

set-top box, DVD player, or A/V receiver and video monitor, such as a

digital flat LCD / plasma television (DTV), over a single lengthy

cable

Supports standard, enhanced, high-definition video, and multi-channel

digital audio

on a single cable

Transmits all ATSC HDTV standards and supports 8-channel digital audio,

with bandwidth to spare to accommodate future enhancements and

requirements

Benefits consumers by providing superior, uncompressed digital video

quality via a single cable

, and user-friendly connector

Is backward-compatible with DVI (Digital Visual Interface)

Supports two-way communication between the video source (such as a

DVD player) and the digital television, enabling new functionality such as

automatic configuration and one-button play

HDMI has the capacity to support:

Existing high-definition video formats (720p, 1080i, and 1080p/60), as

well as standard definition formats such as NTSC or PAL

1 Ensuring an all-digital rendering of video without the losses associated with analog interfaces and their unnecessary digital-

to-analog conversions

2 HDMI, the HDMI logo and High-Definition Multimedia Interface are trademarks or registered trademarks of HDMI

licensing LLC

3 With video and multi-channel audio combined into a single cable, the cost, complexity, and confusion of multiple cables

currently used in A/V systems is reduced

4 HDMI technology has been designed to use standard copper cable construction at up to 15m

5 HDMI supports multiple audio formats, from standard stereo to multi-channel surround-sound. HDMI has the capacity to

support Dolby 5.1 audio and high-resolution audio formats

6 HDMI provides the quality and functionality of a digital interface while also supporting uncompressed video formats in a

simple, cost-effective manner

Overview

3.3 Recommendations for Achieving the Best Performance

To achieve the best performance:

Connect only good quality connection STP CAT 5 24 AWG cables,

thus avoiding interference, deterioration in signal quality due to poor

matching, and elevated noise-levels (often associated with low

quality cables)

Avoid interference from neighboring electrical appliances and position

your TP-551N/TP-552N away from moisture, excessive sunlight and

dust

Caution – No operator-serviceable parts inside unit.

Warning – Use only the Kramer Electronics input power

wall adapter that is provided with this unit

Warning – Disconnect power and unplug unit from wall

before installing or removing device or servicing unit.

1 For example, part number 2535-052002

KRAMER: SIMPLE CREATIVE TECHNOLOGY

Your HDMI Line Transmitter / Receiver

4 Your HDMI Line Transmitter / Receiver

This section describes the:

TP-551N HDMI Line Transmitter, see section 4.1

TP-552N HDMI Line Receiver, see section 4.2

4.1 Your TP-551N HDMI Line Transmitter

Figure 1 and Table 1 define the TP-551N:

Figure 1: TP-551N HDMI Line Transmitter

Table 1: TP-551N HDMI Line Transmitter Features

# Feature Function

1 5V DC +5V DC connector for powering the unit

2 B Connect to the CAT 5 IN B RJ-45 connector on the TP-552N

CAT 5 OUT RJ-45

Connector A Connect to the CAT 5 IN A RJ-45 connector on the TP-552N

4 HDMI IN Connector Connect to the HDMI source

5 INPUT LED Lights when an input is connected

6 OUTPUT LED Lights when an output is detected

7 POWER LED Lights when receiving power

Your HDMI Line Transmitter / Receiver

4.2 Your TP-552N HDMI Line Receiver

Figure 2 and Table 2 define the TP-552N:

Figure 2: TP-552N HDMI Line Receiver

Table 2: TP-552N HDMI Line Receiver Features

# Feature Function

1 5V DC +5V DC connector for powering the unit

2 HDMI OUT Connector Connect to the HDMI acceptor

3 B Connect to the CAT 5 OUT B RJ-45 connector on the TP-551N

CAT 5 IN RJ-45

Connector A Connect to the CAT 5 OUT A RJ-45 connector on the TP-551N

5 INPUT LED Lights when an input is detected

6 OUTPUT LED Lights when an output is connected

7 EQ. SETUP Dipswitches Adjust the cable compensation equalization level (see section 5.1)

8 POWER LED Lights when receiving power

KRAMER: SIMPLE CREATIVE TECHNOLOGY

Connecting the TP-551N and TP-552N

5 Connecting the TP-551N and TP-552N

You can use the TP-551N HDMI Line Transmitter with the TP-552N HDMI

Line Receiver to configure an HDMI transmitter/receiver system.

To connect the TP-551N to the TP-552N, as illustrated in the example in

Figure 3, do the following:

1. Connect the CAT 5 OUT A and B RJ-45 connectors on the TP-551N to the

CAT 5 IN A and B RJ-45 connectors on the TP-552N, respectively, via two

STP CAT 5E cables (see section 5.2).

2. On the TP-552N, connect the HDMI OUT connector to an HDMI acceptor

(for example, a plasma display).

3. Connect the 5V DC power adapter to the power socket and connect the

adapter to the mains electricity on both

the TP-551N and the TP-552N (not

shown in Figure 3).

4. On the TP-551N, connect an HDMI source (for example, a DVD player) to

the HDMI IN connector.

5. On the TP-552N, adjust the equalization level (see section 5.1).

5.1 Adjusting the EQ. Level via the EQ. Setup Dipswitches

To adjust the EQ. level, set the dipswitches according to the cable length

, as

defined in Table 3:

Table 3: Recommended Equalization Levels Dipswitch Setup

Distance [m] DIP 1 DIP 2 DIP 3 DIP 4

Up to 50 OFF OFF ON ON

Up to 40 ON ON ON ON

Up to 30 OFF ON ON ON

1 The TP-551N/TP-552N does not include the Kramer power connect feature

2 It is recommended to use a Kramer cable (regular HDMI cable - C-HDMI/HDMI; flat HDMI cable –

C-HDMI/HDMI/FLAT(1.3)). The complete list of Kramer cables is on our Web site at http://www.kramerelectronics.com

3 The optimum dipswitch settings are dependent on the cable type and length, as well as the video resolution and

environment. The table shows the settings for typical installations using Kramer cabling. Experimentation may be necessary

in a specific application, and any of 16 possible switch combinations may be applied

Autres manuels pour TP-551N

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Kramer Émetteur

Kramer

Kramer TP-205A Manuel utilisateur

Kramer

Kramer SID-X3N Manuel utilisateur

Kramer

Kramer TP-210 Manuel utilisateur

Kramer

Kramer VA-1USB-T Manuel utilisateur

Kramer

Kramer KW-14T Manuel utilisateur

Kramer

Kramer F-121UK Manuel utilisateur

Kramer

Kramer WP-121 Manuel utilisateur

Kramer

Kramer TP-114 Manuel utilisateur

Kramer

Kramer TP-121EDID Manuel utilisateur

Kramer

Kramer TP-594Txr Manuel utilisateur

Kramer

Kramer VP-428H2 Manuel utilisateur

Kramer

Kramer VP-200XLTHD Manuel utilisateur

Kramer

Kramer F-110 Manuel utilisateur

Kramer

Kramer SID-X1 Manuel utilisateur

Kramer

Kramer TP-580TD Manuel utilisateur

Kramer

Kramer TP-185 Manuel utilisateur

Kramer

Kramer TP-121EDID Manuel utilisateur

Kramer

Kramer Cobra TS2 Manuel utilisateur

Kramer

Kramer VP-300THD Manuel utilisateur

Kramer

Kramer 611T Manuel utilisateur

Kramer

Kramer TP-121EDID Manuel utilisateur

Kramer

Kramer TP-145 Manuel utilisateur

Kramer

Kramer PT-2UT/R-KIT Manuel utilisateur

Kramer

Kramer 610T Manuel utilisateur

Manuels Émetteur populaires d'autres marques

NIVELCO

NIVELCO EasyTREK SCA-300 Series Manuel du propriétaire

Honeywell

Honeywell 5816WMBR Manuel utilisateur

Kamstrup

Kamstrup READy MTU Mode d'emploi

Omega

Omega ZW Series Manuel utilisateur

ABB

ABB Field 264H Mode d’emploi

Alinco

Alinco DJ-V17T Manuel utilisateur

Dejero

Dejero EnGo 3x Manuel utilisateur

Rosemount

Rosemount 4600 Manuel utilisateur

Speaka Professional

Speaka Professional 2342740 Manuel utilisateur

trubomat

trubomat GAB 1000 Manuel utilisateur

Teledyne Analytical Instruments

Teledyne Analytical Instruments LXT-380 Manuel utilisateur

Rondish

Rondish UT-11 Manuel utilisateur

MG 10JRE Manuel utilisateur

Burkert

Burkert 8177 Manuel utilisateur

Firetide

Firetide HotPort 3203 Manuel

Tele Radio

Tele Radio T9-02 Manuel utilisateur

Rotronic

Rotronic HygroFlex HF3 Series Manuel utilisateur

Jamara

Jamara FCX6 Pro Tel Manuel utilisateur
