Kramer TP-210 Manuel utilisateur

Kramer Electronics, Ltd.

USER MANUAL







Model:

TP-210

XGA Line Transmitter / DA

Contents

Introduction 1

Getting Started 1

2.1

Quick Start 2

Overview 3

3.1

Power Connect Feature 3

3.2

Shielded Twisted Pair (STP) / Unshielded Twisted Pair (UTP) 4

3.3

Recommendations for Achieving the Best Performance 4

Your TP-210 XGA Line Transmitter / DA 4

Installing the TP-210 on a Rack 7

Connecting the TP-210 8

6.1

Wiring the CAT 5 LINE IN / LINE OUT RJ-45 Connectors 10

Technical Specifications 11

Figures

Figure 1: TP-210 XGA Line Transmitter / DA 5

Figure 2: TP-210 Underside View 6

Figure 3: Connecting the TP-210 XGA Line Transmitter / DA 9

Figure 4: CAT 5 PINOUT 10

Tables

Table 1: Front Panel TP-210 XGA Line Transmitter / DA Features 6

Table 2: TP-210 XGA Line Transmitter / DA Underside Features 6

Table 3: CAT 5 PINOUT 10

Table 4: Technical Specifications of the TP-210 11

Introduction

1 Introduction

Welcome to Kramer Electronics (since 1981): a world of unique, creative and

affordable solutions to the infinite range of problems that confront the video,

audio and presentation professional on a daily basis. In recent years, we have

redesigned and upgraded most of our line, making the best even better! Our

500-plus different models now appear in 8 Groups

, which are clearly defined

by function.

Congratulations on purchasing your Kramer TP-210 XGA Line Transmitter

/DA. This product is ideal for utilizing existing CAT5 cabling that results in an

efficient, fast and uncluttered environment for:

Presentation and multimedia applications

Long range graphics distribution for schools, hospitals, security, and

stores

The package includes the following items:

TP-210 XGA Line Transmitter / DA

Power cord

This user manual

2 Getting Started

We recommend that you:

Unpack the equipment carefully and save the original box and

packaging materials for possible future shipment

Review the contents of this user manual

Use Kramer high performance high resolution cables

1 GROUP 1: Distribution Amplifiers; GROUP 2: Video and Audio Switchers, Matrix Switchers and Controllers; GROUP 3:

Video, Audio, VGA/XGA Processors; GROUP 4: Interfaces and Sync Processors; GROUP 5: Twisted Pair Interfaces;

GROUP 6: Accessories and Rack Adapters; GROUP 7: Scan Converters and Scalers; and GROUP 8: Cables and Connectors

2 Download up-to-date Kramer user manuals from our Web site at http://www.kramerelectronics.com

3 The complete list of Kramer cables is on our Web site at http://www.kramerelectronics.com

KRAMER: SIMPLE CREATIVE TECHNOLOGY

Getting Started

2.1 Quick Start

This quick start chart summarizes the basic setup and operation steps.

Computer

Graphics

Source

Display

CAT5cable

TP-120

TP-210

Local

Display

Overview

3 Overview

The TP-210 XGA Line Transmitter / DA is a 1:2 XGA and 1:10 CAT5

transmitter distribution amplifier that receives an XGA signal

and transmits it

over 10 CAT5 cables to appropriate receivers to create a multimode

XGA/CAT5 distribution system.

The TP-210 XGA Line Transmitter:

Features a resolution up to UXGA

Has two XGA outputs for local monitoring

Has 10 CAT5 outputs for simultaneous signal transmission to 10

locations, each with a transmission range of more than 300 ft. (more

than 100 meters

)

Includes H and V SYNC switches for changing the polarity of the

signal

3.1 Power Connect Feature

The Power Connect feature lets you power a transmitter / receiver system by

connecting just one power adapter— to either the transmitter or the receiver.

The other unit is fed via the cable connecting between the transmitter/receiver.

The Power Connect feature applies as long as the cable can carry power. The

distance does not exceed 50 meters on standard CAT5 cable, for longer

distances, heavy gauge cable should be used

For a CAT5 cable exceeding a distance of 50 meters, separate power supplies

should be connected to the transmitter and to the receiver simultaneously.

Each output on the TP-210 can supply up to 500mA/12V, but no more than

2.5A in total (for all the outputs). Before using this feature, be sure that the

TP-210 is capable of providing the current requirements of the CAT5 receivers.

1 The terminology XGA is used throughout this manual, where this implies any RGBHV signal on an HD15 connector

having a resolution from VGA up to XGA

2 If the receiver is connected at a distance of over 50 meters, you need to connect a separate power supply for that receiver

3 CAT5 cable is still suitable for the video/audio transmission, but not for feeding the power at these distances

KRAMER: SIMPLE CREATIVE TECHNOLOGY

Your TP-210 XGA Line Transmitter / DA

3.2 Shielded Twisted Pair (STP) / Unshielded Twisted Pair (UTP)

The decision whether to use shielded twisted pair (STP) cable or unshielded

twisted pair (UTP) cable depends on the nature of the application.

It is recommended that in applications with high interference, shielded twisted

pair (STP) cable will give better results. However, the shield itself does create a

capacitance that degrades the frequency response of the machines. For shorter

distances, of 50m or so, shielded twisted pair (STP) cable is preferred because

it provides protection from interference (degradation is non-apparent).

For a long-range application, unshielded twisted pair (UTP) cable is preferred.

However, the unshielded twisted pair (UTP) cable should be installed far away

from electric cables, motors etc., which are prone to create electrical

interference.

3.3 Recommendations for Achieving the Best Performance

To achieve the best performance:

Connect only good quality connection cables, thus avoiding

interference, deterioration in signal quality due to poor matching,

and elevated noise- levels (often associated with low quality cables)

Avoid interference from neighboring electrical appliances and

position your Kramer TP-210 away from moisture, excessive

sunlight and dust

4 Your TP-210 XGA Line Transmitter / DA

Figure 1 and Table 1 define the TP-210:

Your TP-210 XGA Line Transmitter / DA

Figure 1: TP-210 XGA Line Transmitter / DA

KRAMER: SIMPLE CREATIVE TECHNOLOGY

Your TP-210 XGA Line Transmitter / DA

Table 1: Front Panel TP-210 XGA Line Transmitter / DA Features

# Feature Function

1 POWER Switch Illuminated switch for turning the unit ON or OFF

2 XGA INPUT HD15 Connector

Connects to the video source

3 XGA OUT 2 HD15 Connector

Connects to the video acceptor 2

4 XGA OUT 1 HD15 Connector

Connects to the video acceptor 1

5 OUT CAT5 Connectors Connect to the LINE IN connectors on Line Receivers

(from 1 to 10)

6 Power Connector with FUSE AC connector enabling power supply to the unit

The TP-210 underside is illustrated in Figure 2 and defined in Table 2:

Figure 2: TP-210 Underside View

Table 2: TP-210 XGA Line Transmitter / DA Underside Features

# Feature Function

1 VS Switch Slide the switch down

(to NORM.) to retain the polarity; slide the

switch up (to NEG.) to change the VS polarity to negative polarity

2 HS

Switch Slide the switch down

(to NORM.) to retain the polarity; slide the

switch up (to NEG.) to change the HS polarity to negative polarity

1 Using a cable with CAT5 connectors at both ends

2 By default, both switches are set to NORM

Installing the TP-210 on a Rack

5 Installing the TP-210 on a Rack

This section describes what to do before installing on a rack and how to rack

mount.

Before installing on a rack, be sure that the environment is

within the recommended range:

Operating temperature range +5 to +45 Deg. Centigrade

5 to 65% RHL, non-condensing

-20 to +70 Deg. Centigrade

5 to 95% RHL, non-condensing

Operating humidity range

Storage temperature range

Storage humidity range

When installing on a 19" rack, avoid hazards by taking

care that:

It is located within the recommended environmental

conditions, as the operating ambient temperature of a

closed or multi unit rack assembly may exceed the

room ambient temperature.

Attach both ear brackets to the

machine. To do so, remove the

screws from each side of the machine

(3 on each side), and replace those

screws through the ear brackets.

Place the ears of the machine

against the rack rails, and insert the

proper screws (not provided) through

each of the four holes in the rack

ears.

Note that:

Detachable rack ears can be removed

for desktop use

Always mount the machine in the rack

before you attach any cables or

connect the machine to the power

If you are using a Kramer rack adapter

kit (for a machine that is not 19"), see

the Rack Adapters user manual for

installation instructions (you can

download it at:

http://www.kramerelectronics.com)



In some models, the front panel

may feature built-in rack ears

Once rack mounted, enough air will still flow around the

machine.

The machine is placed straight in the correct horizontal

position.

You do not overload the circuit(s). When connecting

the machine to the supply circuit, overloading the

circuits might have a detrimental effect on overcurrent

protection and supply wiring. Refer to the appropriate

nameplate ratings for information. For example, for

fuse replacement, see the value printed on the product

label.

The machine is earthed (grounded) in a reliable way

and is connected only to an electricity socket with

grounding. Pay particular attention

and that you use only the power cord that is

supplied with the machine.

to situations where

electricity is supplied indirectly (when the power cord is

not plugged directly into the socket in the wall), for

example, when using an extension cable or a power

strip,



CAUTION!!

Before Installing on a Rack

How to Rack Mount

To rack-mount a machine:

KRAMER: SIMPLE CREATIVE TECHNOLOGY

Connecting the TP-210

6 Connecting the TP-210

To connect the TP-210, as Figure 3 illustrates, do the following:

1. Connect an XGA source (for example, a computer graphics source) to the

XGA INPUT connector.

2. Connect the XGA OUT 1 XGA connector to an XGA acceptor (for example,

Local Display 1).

3. Connect the XGA OUT 2 XGA connector to an XGA acceptor (for example,

Local Display 2).

4. Connect

the 10 LINE OUTPUT CAT5 connectors (from 1 to 10) to the

LINE IN CAT5 connectors of 10 XGA line receivers (for example, the

Kramer

TP-120).

5. Connect the power cord

(not shown in Figure 3).

1 You do not have to connect all the LINE OUTPUTS

2 Alternatively, you can use a different Kramer receiver, for example, the Kramer PT-120

3 We recommend that you use only the power cord that is supplied with this machine

Autres manuels pour TP-210

Table des matières

Autres manuels Kramer Émetteur

Kramer

Kramer VP-428H2 Manuel utilisateur

Kramer

Kramer WP-110 Manuel utilisateur

Kramer

Kramer 610T Manuel utilisateur

Kramer

Kramer SWT3-41-U-T Manuel utilisateur

Kramer

Kramer TP-210A Manuel utilisateur

Kramer

Kramer 671T Manuel utilisateur

Kramer

Kramer VP-300THD Manuel utilisateur

Kramer

Kramer TP-121EDID Manuel utilisateur

Kramer

Kramer VA-1USB-T Manuel utilisateur

Kramer

Kramer 622T Manuel utilisateur

Kramer

Kramer VP-428H2 Manuel utilisateur

Kramer

Kramer F-110 Manuel utilisateur

Kramer

Kramer 691 Manuel utilisateur

Kramer

Kramer SID-X3N Manuel utilisateur

Kramer

Kramer TP-112HD Manuel utilisateur

Kramer

Kramer TA Manuel utilisateur

Kramer

Kramer TP-583Txr Manuel utilisateur

Kramer

Kramer WP-580Txr Manuel utilisateur

Kramer

Kramer TP-112HD Manuel utilisateur

Kramer

Kramer SID-X3N Manuel d'installation et d'exploitation

Kramer

Kramer TP-551N Manuel utilisateur

Kramer

Kramer TP-581T Manuel utilisateur

Kramer

Kramer PT-2UT/R-KIT Manuel utilisateur

Kramer

Kramer TP-780T Manuel utilisateur

Manuels Émetteur populaires d'autres marques

NIVELCO

NIVELCO EasyTREK SCA-300 Series Manuel du propriétaire

Honeywell

Honeywell 5816WMBR Manuel utilisateur

Kamstrup

Kamstrup READy MTU Mode d'emploi

Omega

Omega ZW Series Manuel utilisateur

ABB

ABB Field 264H Mode d’emploi

Alinco

Alinco DJ-V17T Manuel utilisateur

Dejero

Dejero EnGo 3x Manuel utilisateur

Rosemount

Rosemount 4600 Manuel utilisateur

Speaka Professional

Speaka Professional 2342740 Manuel utilisateur

trubomat

trubomat GAB 1000 Manuel utilisateur

Teledyne Analytical Instruments

Teledyne Analytical Instruments LXT-380 Manuel utilisateur

Rondish

Rondish UT-11 Manuel utilisateur

MG 10JRE Manuel utilisateur

Burkert

Burkert 8177 Manuel utilisateur

Firetide

Firetide HotPort 3203 Manuel

Tele Radio

Tele Radio T9-02 Manuel utilisateur

Rotronic

Rotronic HygroFlex HF3 Series Manuel utilisateur

Jamara

Jamara FCX6 Pro Tel Manuel utilisateur
