CRU Dataport DX115 kit installation

Introduction

This document describes how to install the CRU Dataport DX115® removable media kit in your

workstation. The DX115 kit enables you to install removable media in your workstation.

Kit contents

Ensure that the following components are included in your drive kit:

●Warranty

●DX115 unit (case and drive carrier)

●Installation document

●SATA or SAS cable

●Five M3 screws

●Five 6-32 screw

●Tape label

registered trademark of Hewlett-Packard Development Company, L.P. Microsoft and

Windows are U.S. registered trademarks of Microsoft Corporation. Printed in the U.S.

ENWW Introduction 1

Warnings and cautions

WARNING! Any surface or area of the equipment marked with this symbol indicates the presence

of a hot surface or hot component. If this surface is contacted, the potential for injury exists. To reduce

the risk of injury from a hot component, enable the surface to cool before touching.

WARNING! Any surface or area of the equipment marked with this symbol indicates the presence

of an electrical shock hazard. To reduce the risk of injury from electrical shock, do not open any enclosed

area marked with this symbol.

WARNING! To reduce the risk of electric shock or damage to your equipment:

— Do not disable the power cord grounding plug. The grounding plug is an important safety feature.

— Plug the power cord in a grounded (earthed) outlet that is easily accessible at all times.

— Disconnect power from the equipment by unplugging the power cord from the electrical outlet.

WARNING! To reduce the risk of serious injury, read the Safety & Comfort Guide. It describes proper

workstation setup, posture, health, and work habits for computer users, and provides important electrical

and mechanical safety information. This guide is located at http://www.hp.com/ergo and on the

documentation CD (if one is included with the product).

WARNING! If a product is shipped in packaging marked with this symbol, , the product must always

be lifted by two persons to avoid personal injury due to product weight.

CAUTION: Static electricity can damage the electronic components of the workstation. Before

beginning these procedures, be sure you discharge static electricity by briefly touching a grounded metal

object.

CAUTION: Observe the following cautions when removing or replacing a processor:

— Installing a processor incorrectly can damage the system board. Contact an HP authorized reseller

or service provider to install the processor. If you plan to install the processor yourself, read all of the

instructions carefully before you begin.

— Failure to follow the workstation preparation instructions can result in an improperly installed

processor, causing extensive workstation damage.

— Processor socket pins are delicate and bend easily. Use extreme care when placing the processor

in the socket.

2 CRU Dataport DX115 kit installation ENWW

CAUTION: To prevent damage to the workstation, observe the following Electrostatic Discharge

(ESD) precautions while performing the system parts removal and replacement procedures:

— Work on a static-free mat.

— Wear a static strap to ensure that any accumulated electrostatic charge is discharged from your body

to the ground.

— Create a common ground for the equipment you are working on by connecting the static-free mat,

static strap, and peripheral units to that piece of equipment.

NOTE: HP accessories are for use in HP Workstation products. They have been extensively tested

for reliability and are manufactured to high quality standards.

ENWW Warnings and cautions 3

Step 1—Preparing the workstation

To prepare the workstation:

1. Refer to your workstation documentation for instructions on disassembling and preparing the

workstation for installation. Follow the instructions for shutting down power and disconnecting all

power from the system.

2. Remove the access panel and front bezel of your workstation. If necessary, refer to the Service

and Technical Reference Guide for your HP Workstation at http://www.hp.com/support/

workstation_manuals.

Step 2—Installing the DX115 case into the optical drive bay

Refer to the steps for your workstation in the following sections.

CAUTION: Insert or remove the carrier (with a disk drive) only when the workstation is shut down.

Other procedures may result in system hangs, data loss or even drive damage. (The component

supplier’s user guide describes a procedure for inserting or removing the carrier (with drive) while the

workstation is booted and then powering the drive via the enclosure’s power switch. Microsoft Windows

XP and Vista do not support this action.)

HP xw6000 Workstation series

1. Remove and discard the counter-sunk screw at the side of the DX115 case as shown (for xw6000

series only). This hole will be used for the shipping screw.

2. Install the DX115 unit in the optical drive bay using the quick release system.

4 CRU Dataport DX115 kit installation ENWW

3. Install one 6-32 x 1/4 in. screw (silver) per DX115 unit for shipping support as shown.

CAUTION: Failure to install the shipping screw may result in damage to the removable hard drive

system.

HP xw4000 Workstation series

1. Install four, M3 x 5mm screws (black) in the lower four mounting holes.

2. Install the DX115 unit in the optical drive bay using the quick release system.

3. Install one, M3 x 5mm screw (black) per DX115 unit for shipping support as shown.

ENWW Step 2—Installing the DX115 case into the optical drive bay 5

HP xw8000 and xw9000 Workstation series

1. Install the DX115 unit in the optical drive bay using the quick release system

2. Install one M3 x 5mm screw (black) per DX115 unit for shipping support as shown.

CAUTION: Failure to install the shipping screw may result in damage to the removable hard drive

system.

Step 3—Installing a hard disk in the DX115 carrier

CAUTION: Insert or remove the carrier (with a disk drive) only when the workstation is shut down.

Other procedures may result in system hangs, data loss or even drive damage. (The component

supplier’s user guide describes a procedure for inserting or removing the carrier (with drive) while the

workstation is booted and then powering the drive via the enclosure’s power switch. Microsoft Windows

XP and Vista do not support this action.)

NOTE: It is not necessary to remove the DX115 case from the workstation for this step.

Install your hard drive in the DX115 carrier. For detailed instructions, refer to either:

●The CRU Dataport DX115® User’s Guide for SATA or SAS removable drive enclosures

●The CRU Dataport website at http://www.cru-dataport.com/htmldocs/products/dataexpress/

dx115.html

6 CRU Dataport DX115 kit installation ENWW

Step 4—Completing the workstation assembly

CAUTION: Insert or remove the carrier (with a disk drive) only when the workstation is shut down.

Other procedures may result in system hangs, data loss or even drive damage. (The component

supplier’s user guide describes a procedure for inserting or removing the carrier (with drive) while the

workstation is booted and then powering the drive via the enclosure’s power switch. Microsoft Windows

XP and Vista do not support this action.)

1. After the drive is installed in the carrier. Insert the drive carrier in the case. Press the handle in (1)

and use the key (2) to lock the carrier if shipping the unit (3).

2. Connect the power (1) and data (2) cables to the primary (upper) ports on the unit.

3. To prepare your installed hard drive for operation, refer to the appropriate hard drive

documentation.

4. If shipping the unit, use the key to lock the carrier and install the shipping screw as described in

the previous steps.

ENWW Step 4—Completing the workstation assembly 7

CAUTION: Failure to lock the drive during shipment may result in damage to your removable

hard drive system.

Failure to install the shipping screw may result in damage to the removable hard drive system.

5. Replace workstation bezel and access panel.

8 CRU Dataport DX115 kit installation ENWW
