HP Nx9420 - Compaq Business Notebook Manuel

External Media Cards

Document Part Number: 419584-001

January 2007

This guide explains how to use external media cards.

External Media Cards ii

Contents

1 Digital Media Slot cards

Inserting a digital card . . . . . . . . . . . . . . . . . . . . . . . . . . . 1–2

Stopping or removing a digital card. . . . . . . . . . . . . . . . . 1–3

2PCCards

Configuring a PC Card. . . . . . . . . . . . . . . . . . . . . . . . . . . 2–1

Inserting a PC Card . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2–2

Stopping or removing a PC Card . . . . . . . . . . . . . . . . . . . 2–3

3 Smart cards

Inserting a smart card . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3–2

Removing a smart card. . . . . . . . . . . . . . . . . . . . . . . . . . . 3–3

External Media Cards 1–1

Digital Media Slot cards

Optional digital cards provide secure data storage and

convenient data sharing. These cards are often used with

digital-media-equipped cameras and PDAs as well as other

computers.

The Digital Media Slot supports the following digital card

formats:

■Secure Digital (SD) Memory Card

■MultiMediaCard

■Memory Stick

■Memory Stick Pro

■Memory Stick Duo

■SmartMedia Card

■xD-Picture Card

ÄCAUTION: To avoid damaging the digital card or the computer, do not

insert any type of adapter into the Digital Media Slot.

1–2 External Media Cards

Digital Media Slot cards

Inserting a digital card

ÄCAUTION: To prevent damage to the digital card connectors, use

minimal force to insert a digital card.

To insert a digital card:

1. Hold the digital card label-side up, with the connectors facing

the computer.

2. Gently slide the card into the Digital Media Slot until the

card is seated.

When you insert a digital card, you will hear a sound when

the device has been detected and a menu of available options

may be displayed.

Digital Media Slot cards

External Media Cards 1–3

Stopping or removing a digital card

ÄCAUTION: To prevent loss of data or an unresponsive system, stop the

digital card before removing it.

To stop or remove a digital card:

1. Close all files and applications that are associated with the

digital card.

✎To stop data transfer, click Cancel in the operating system

Copying window.

2. To stop the digital card:

a. Double-click the Safely Remove Hardware icon in the

notification area, at the far right of the taskbar.

✎To display the Safely Remove Hardware icon, click

Show Hidden Icons in the notification area.

b. Click the digital card listing.

c. Click Stop, and then click OK.

3. To remove the card, gently pull it out of the slot.

External Media Cards 2–1

PC Cards

A PC Card is a credit card-sized accessory designed to conform

to the standard specifications of the Personal Computer Memory

Card International Association (PCMCIA). The PC Card slot

supports

■32-bit (CardBus) and 16-bit PC Cards.

■Type I or Type II cards.

✎Zoomed video PC Cards are not supported.

Configuring a PC Card

ÄCAUTION: To prevent loss of support for other PC Cards, install only the

software required for the device. If you are instructed by the PC Card

manufacturer to install device drivers:

■Install only the device drivers for your operating system.

■Do not install any other software, such as card services, socket

services, or enablers, supplied by the PC Card manufacturer.

2–2 External Media Cards

PC Cards

Inserting a PC Card

ÄCAUTION: To prevent damage to the computer and external media

cards, do not insert an ExpressCard into a PC Card slot or a PC Card into

an ExpressCard slot.

ÄCAUTION: To prevent damage to the connectors:

■Use minimal force to insert a PC Card.

■Do not move or transport the computer when a PC Card is in use.

To insert a PC Card:

1. Hold the PC Card label-side up, with the connector facing

the computer.

2. Gently slide the card into the slot until the card is seated.

When you insert a PC Card, you will hear a sound when the

device has been detected and a menu of available options

may be displayed.

✎The first time you insert a PC Card, the “Installing device

driver software” message is displayed in the notification

area, at the far right corner of the taskbar.

PC Cards

External Media Cards 2–3

Stopping or removing a PC Card

ÄCAUTION: To prevent loss of information or an unresponsive system,

stop a PC Card before removing it.

✎An inserted PC Card uses power even when idle. To conserve

power, stop or remove a PC Card when it is not in use.

To stop or remove a PC Card:

1. Close all applications and complete all activities that are

associated with the PC Card.

✎To stop data transfer, click Cancel in the operating system

Copying window.

2. To stop the PC Card:

a. Double-click the Safely Remove Hardware icon in the

notification area, at the far right of the taskbar.

✎To display the Safely Remove Hardware icon, click

Show Hidden Icons in the notification area.

b. Click the PC Card listing.

c. Click Stop, and then click OK.

2–4 External Media Cards

PC Cards

3. To remove the PC Card:

a. Press the PC Card slot eject button 1.

This action extends the button into position for releasing

the PC Card.

b. Press the eject button again to release the PC Card.

c. Gently pull the card 2out of the slot.

External Media Cards 3–1

Smart cards

✎The term smart card, which refers to both smart cards and

Java™ Cards, will be used throughout this guide.

A smart card is a credit card–sized accessory that carries a

microchip containing memory and a microprocessor. Like

personal computers, smart cards have an operating system to

manage input and output, and they include security features

to protect against tampering. Industry-standard smart cards are

used with the smart card reader.

A personal identification number (PIN) is needed to gain access

to the contents of the microchip. For more information about

smart card security features, refer to Help and Support.
