HP MCS G2 Guide d'installation

HP Modular Cooling System G2

Installation Overview

Optimum environment and site

preparation

CAUTION: Contaminated water might cause decreased

cooling capacity or disruption in service. The water

flowing into the MCS unit must meet the guidelines stated

in the HP Modular Cooling System G2 Site Preparation

Guide. The MCS warranty does not cover damage caused

by contaminated water.

IMPORTANT: Before you begin the installation process,

read the HP Modular Cooling System G2 Site Preparation

Guide.

Environmental requirements must be met to provide optimum

performance with minimum maintenance for your unit.

The HP Modular Cooling System G2 Site Preparation Guide

provides information about planning your unit configuration

efficiently and organizing your site location before delivery of your

MCS unit.

To locate the latest version of the HP Modular Cooling System G2

Site Preparation Guide:

1. Go to the HP website

(http://www.hp.com/go/rackandpower).

2. Select Rack and Rack Options.

3. Select Modular Cooling System.

4. Select Support and Documents.

5. Select Manuals.

6. Select and download the HP Modular Cooling System G2 Site

Preparation Guide.

Safety information

The HP Modular Cooling System G2 is tested to the maximum

pressure (PS) of 8 bar (116 PSI) without fluid trapped inside by

closed, external valves.

If valves are installed on the external pipe work that could potentially

trap fluid inside the MCS unit, special precautions must be taken. In

order to prevent severe plumbing failure due to extreme pressure,

use an expansion tank with a preinstalled safety valve in the

plumbing circuit connected to the unit.

MCS G2 kit contents

•HP MCS G2 unit installed on an HP 10000 G2 Series Rack (1)

•Automatic Door Release kit (1)

•Rear plate cover (1)

•Condensation pump to facility hose (blue) (1)

•Condensation pan to facility hose (clear)* (1)

•Power cord, 4.5 m (14.8 ft), L6-20 to C19 (2)

•Power cord, 4.5 m (14.8 ft), IEC-309 to C19 (2)

•CAT5e cable, 7.62 m (25 ft) (1)

•Serial cable* (1)

•Access panel (1)

•Bracket (2)

•M6 trilobe flathead screw (2)

•M6 flathead screw (2)

*This item might ship preinstalled on the MCS unit rather than in the

standard kit contents package.

Required tools

The following tools are required for installation:

•Flat blade screwdriver

•#2 Phillips screwdriver

•Adjustable wrench

•T-25 Torx driver

•T-30 Torx driver

•Bubble level

•Cap wrench (included with your HP Hook-Up Kit)

•Hose wrench (included with your HP Hook-Up Kit)

Installing the MCS unit

WARNING: The MCS unit and rack are shipped together

on a heavy duty shock pallet weighing approximately

1633 kg (3600 lb). HP recommends hiring professional

movers to move the heavy duty shock pallet, remove the

MCS unit and rack from the pallet, and move the MCS

unit and rack to the final location.

CAUTION: Contaminated water might cause decreased

cooling capacity or disruption in service. The water

flowing into the MCS unit must meet the guidelines stated

in the HP Modular Cooling System G2 Site Preparation

Guide. The MCS warranty does not cover damage caused

by contaminated water.

IMPORTANT: Before you begin the installation process,

read the HP Modular Cooling System G2 Site Preparation

Guide.

1. Install the HP Hook-Up Kit.

2. Read the unpacking instructions on the MCS packaging

material.

3. Remove the MCS unit and rack from the pallet with four or

more people.

4. Roll the MCS unit and rack to the final location.

NOTE: You only need to remove the caster plate (steps 4

through 6) if you are routing your hoses through the hole

in the raised floor.

5. Loosen the jam nut, and then raise the unit by lowering the two

rear leveling feet on both the MCS unit and the rack until you

can remove the rear caster plate.

6. Remove the rear caster plate.

7. Lower the unit by raising the two rear leveling feet on both the

MCS unit and the rack so that the MCS unit can move freely on

the remaining casters.

8. Adjust the leveling feet to level the MCS unit and rack, using a

bubble level.

IMPORTANT: Check both ball valves on the water hoses to

confirm that they are in the closed position before

attaching the hoses to the MCS unit. Water that leaks into

the unit can cause significant damage.

9. Route the water hoses from the HP Hook-Up Kit through the

floor cut-out.

10. Install each main hose to the MCS unit using the hose wrench.

11. Cap the unused side of each T-fitting on the MCS unit using the

cap wrench.

12. Route the two drain hoses to the drain collection system catch

basin.

a. Install and route the blue drain hose into either the

condensation return line or the gravity drain collection

system catch basin.

b. Route the preinstalled clear drain hose into the gravity

drain collection system catch basin.

c. Position the gravity drain collection system below the

condensation collection pan, allowing gravity to draw the

water out of the condensation collection pan and into the

gravity drain collection system basin.

13. Turn on the water by opening the four ball valves.

a. Open the ball valves at the facility water line connections.

b. Open the ball valves at the main hose connections.

14. Plug the network cable into the RJ-45 connector on the power

inlet box.

15. Plug the other end of the network cable to your network

connection.

IMPORTANT: Do not connect the power cords into a

power supply.

16. Plug the primary power cord into the power connector on the

left.

WARNING: To reduce the risk of electric shock or

damage to the equipment:

•Do not disable the power cord grounding plug. The

grounding plug is an important safety feature.

•Plug the power cord into a grounded (earthed)

electrical outlet that is easily accessible at all times.

•Unplug the power cord from the power supply to

disconnect power to the equipment.

•Do not route the power cord where it can be walked

on or pinched by items placed against it. Pay

particular attention to the plug, electrical outlet, and

the point where the cord extends from the storage

system.

17. If you are using a secondary power cord, plug it into the

power connector on the right.

18. Guide the other ends of the power cords through the MCS unit,

and then plug them into an appropriate power source.

19. (Optional) Secure the two brackets to the MCS frame using two

M6 trilobe flathead screws.

20. (Optional) Align the access panel with the two brackets.

21. (Optional) Secure the access panel to the brackets on the MCS

frame using two M6 flathead screws.

Installation is complete.

Powering up and configuring

the unit

WARNING: To reduce the risk of electric shock or

damage to the equipment:

•Do not disable the power cord grounding plug. The

grounding plug is an important safety feature.

•Plug the power cord into a grounded (earthed)

electrical outlet that is easily accessible at all times.

•Unplug the power cord from the power supply to

disconnect power to the equipment.

•Do not route the power cord where it can be walked

on or pinched by items placed against it. Pay

particular attention to the plug, electrical outlet, and

the point where the cord extends from the storage

system.

1. Plug the power cords into an appropriate power source.

2. Connect the network cable to your network infrastructure.

NOTE: If you have a DHCP server, you can change the IP

address through the web interface instead of through the

serial port. For more information, refer to "Configuring the

IP address through the web interface (on page 8)."

3. Using the serial cable provided, connect a PC with a serial

port or an asynchronous terminal to the serial communication

port on the management module.

4. Access the management module through a terminal emulation

program, such as HyperTerminal or Minicom.

5. Confirm that you have set the following parameters to access a

terminal emulation program:

oBits per second: 9600

oData bits: 8

oParity: none

oStop bits: 1

oFlow control: none

6. Log in to the HP Modular Cooling System Configuration Utility.

a. In the login field, enter the user name. The default user

name is Admin.

b. In the password field, enter the password. The default

password is Admin. The Main Menu screen appears.

7. Enter the product ID and serial number. The product ID and 10-

digit serial number are located on a label inside the rear MCS

unit door.

a. From the Main Menu screen, enter 3 Factory Default.

The Default Product Identification screen appears.

b. To set the product ID, enter 2 Product ID MCS.

c. To set the serial number, enter 3 Serial Number MCS.

d. To return to the Main Menu screen, press Esc.

8. Access the HP Modular Cooling System Configuration Utility.

a. From the Main Menu screen, enter 1 Network

Configuration. The Menu Network Configuration

screen appears.

b. Enter 1 IP Configuration. The IP Configuration screen

appears.

c. To disable DHCP, enter 4 Enable/Disable DHCP.

d. Enter 1 IP Address, and then enter the new IP address.

e. Enter 2 IP Subnet mask, and then enter the IP subnet

mask.

f. Enter 3 IP Def. Router, and then enter the gateway.

9. Activate the values.

a. Return to the Main Menu Network Configuration screen.

b. Enter 4 Activate Actual Values.

c. To reboot, enter yat the prompt. You must reboot to

activate the IP settings, product ID, and serial number

values.

10. Access the Management module through the web interface.

a. Launch a supported browser. The browser window

appears.

b. In the Address field (Microsoft® Internet Explorer) or the

Location field (Firefox Mozilla), enter

http://ipaddress (where ipaddress is the IP

address of the management module). The login screen

appears.

11. Log in through the web interface.

a. Enter the user name in the User Name field. The default

user name is Admin.

b. Enter the password in the Password field. The default

password is Admin.

c. Click Sign In.

12. Verify that the water source is available and turned on by

viewing the Water Flow status in the Overview menu.

13. Click Setup>Accounts, and then change the default Web

Admin and Web User passwords.

14. Click Save Settings.

15. (Optional, but recommended) Click

Setup>Management>Remote Access, select SSL Enable.

16. (Optional) Enter an SSL key.

17. Click Save Settings.

18. To set up your trap receivers, click Setup>Management>Trap

Receivers.

19. Click Save Settings.

20. (Optional, but recommended) To set up your SNMP managers,

click Setup>Management>SNMP Managers.

21. Click Save Settings.

For more information on adjusting the management module settings

through the web interface, see the HP Modular Cooling System G2

Web Interface User Guide located on the Documentation CD

shipped with this product.

Configuring the IP address through

the web interface

1. View the IP address received from DHCP on the operator

display.

2. Access the Management module through the web interface.

a. Launch a supported browser. The browser window

appears.

b. In the Address field (Microsoft® Internet Explorer) or the

Location field (Firefox Mozilla), enter

http://ipaddress (where ipaddress is the IP

address of the management module). The login screen

appears.

3. Log in through the web interface.

a. Enter the user name in the User Name field. The default

user name is Admin.

b. Enter the password in the Password field. The default

password is Admin.

c. Click Sign In.

4. Click Setup>Network.

a. Select the radio button to disable DHCP (enabled is the

default setting).

b. Click Save Settings.

c. Change the IP address in the IP Address field of the

management module.

d. Change the network mask of the management module.

e. Change the default gateway of the management module.

f. Click Save Settings.

g. Log in to the new IP address.

5. Verify that the water source is available and turned on by

viewing the Water Flow status in the Overview menu.

6. Click Setup>Accounts, and then change the default Web

Admin and Web User passwords.

7. Click Save Settings.

8. (Optional, but recommended) Click

Setup>Management>Remote Access, select SSL Enable.

9. (Optional) Enter an SSL key.

10. Click Save Settings.

11. To set up your trap receivers, click Setup>Management>Trap

Receivers.

12. Click Save Settings.

13. (Optional, but recommended) To set up your SNMP managers,

click Setup>Management>SNMP Managers.

14. Click Save Settings.

For more information on adjusting the management module settings

through the web interface, see the HP Modular Cooling System G2

Web Interface User Guide located on the Documentation CD

included with this product.

Automatic Door Release Kit

To view the HP Automatic Door Release hardware installation

instructions, see the documentation that shipped with that kit.

To enable the automatic door release functionality:

1. Click Setup>Advanced.

2. Select the Enable button at the bottom of the screen.

Legal notices

The information contained herein is subject to change without notice. The only warranties for HP products and services are set forth in the express

warranty statements accompanying such products and services. Nothing herein should be construed as constituting an additional warranty.

HP shall not be liable for technical or editorial errors or omissions contained herein.

Microsoft and Windows are U.S. registered trademarks of Microsoft Corporation.

Part Number 463068-001

December 2007

Table des matières

Autres manuels HP Matériel informatique

HP HP 27113A Manuel

HP UNDP-1H Manuel utilisateur

HP StorageWorks FC1142SR Manuel utilisateur

HP Xw6600 - Workstation - 2 GB RAM Manuel utilisateur

HP Integrity rx1600 Manuel utilisateur

HP D7171A - NetServer - LPr Manuel d'installation et d'exploitation

HP 64751 Manuel utilisateur

HP WL110 - Wireless PC Card Manuel utilisateur

HP Xw8400 - Workstation - 4 GB RAM Manuel utilisateur

HP 98640A Manuel d'installation et d'exploitation

HP A1250 Series Instructions de montage

HP NC364T Manuel utilisateur

HP Xw4600 - Workstation - 2 GB RAM Manuel utilisateur

HP A3550A - High Availability Disk Arrays Model 20 Storage... Manuel utilisateur

HP HP-UX 10.20 Manuel utilisateur

HP Smart Array P400 Instructions d'utilisation

HP Integrity rx8620 Manuel utilisateur

HP 64782 Manuel utilisateur

HP Xw4600 - Workstation - 2 GB RAM Manuel utilisateur

HP Nc6400 - Compaq Business Notebook Manuel utilisateur

HP 381513-B21 - Smart Array P800 Controller... Manuel utilisateur

HP A58 0AF Series Instructions de montage

HP 98625A Manuel utilisateur

Manuels Matériel informatique populaires d'autres marques

EMC2

EMC2 VNX Series Manuel du propriétaire

Panasonic

Panasonic DV0PM20105 Manuel utilisateur

Mitsubishi Electric

Mitsubishi Electric Q81BD-J61BT11 Manuel utilisateur

Gigabyte

Gigabyte B660M DS3H AX DDR4 Manuel utilisateur

Raidon

Raidon iT2300 Manuel utilisateur

National Instruments

National Instruments PXI-8186 Manuel utilisateur

Hauppauge

Hauppauge WinTV-HVR-2250 Manuel utilisateur

Kontron

Kontron CP6002 Manuel utilisateur

Manhattan

Manhattan 702843 Manuel utilisateur

Aphex

Aphex 230 Manuel utilisateur

AMD

AMD Phenom II Manuel d'exploitation

Intel

Intel NUC 12 Pro Manuel utilisateur

dbx

dbx Zone Pro 1260 Manuel utilisateur

Galaxy

Galaxy GHDX2-2430S-24F4D Manuel utilisateur

Intel

Intel AXXRMFBU4 Manuel utilisateur

Kontron

Kontron DIMM-PC/MD Manuel utilisateur

ST X-NUCLEO-SAFEA1B Mode d'emploi

STEINWAY LYNGDORF

STEINWAY LYNGDORF SP-1 Manuel utilisateur
