Gefen EXT-HD-EDIDPN Manuel utilisateur
Audio
Embedder
3GSDI
Release A1
User Manual
EXT-HD-EDIDPN
HDMI
Detective Plus
HDMI Detective Plus
Important Safety Instructions
ii
GENERAL SAFETY INFORMATION
1. Read these instructions.
2. Keep these instructions.
3. Heed all warnings.
4. Follow all instructions.
5. Do not use this product near water.
6. Clean only with a dry cloth.
7. Do not block any ventilation openings. Install in accordance with the manufacturer’s
instructions.
8. Do not install or place this product near any heat sources such as radiators, heat
registers, stoves, or other apparatus (including ampliers) that produce heat.
9. Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized
plug has two blades with one wider than the other. A grounding type plug has two
blades and a third grounding prong. The wide blade or the third prong are provided for
your safety. If the provided plug does not t into your outlet, consult an electrician for
replacement of the obsolete outlet.
10. Protect the power cord from being walked on or pinched particularly at plugs,
convenience receptacles, and the point where they exit from the apparatus.
11. Only use attachments/accessories specied by the manufacturer.
12. To reduce the risk of electric shock and/or damage to this product, never handle or
touch this unit or power cord if your hands are wet or damp. Do not expose this
product to rain or moisture.
13. Unplug this apparatus during lightning storms or when unused for long periods of time.
14. Refer all servicing to qualied service personnel. Servicing is required when the
apparatus has been damaged in any way, such as power-supply cord or plug is
damaged, liquid has been spilled or objects have fallen into the apparatus,
the apparatus has been exposed to rain or moisture, does not operate normally,
or has been dropped.
15. Batteries that may be included with this product and/or accessories should never be
exposed to open ame or excessive heat. Always dispose of used batteries
according to the instructions.
HDMI Detective Plus
Warranty Information
Gefen warrants the equipment it manufactures to be free from defects in material and
workmanship.
If equipment fails because of such defects and Gefen is notied within two (2) years from
the date of shipment, Gefen will, at its option, repair or replace the equipment, provided
that the equipment has not been subjected to mechanical, electrical, or other abuse or
modications. Equipment that fails under conditions other than those covered will be
repaired at the current price of parts and labor in effect at the time of repair. Such repairs
are warranted for ninety (90) days from the day of reshipment to the Buyer.
This warranty is in lieu of all other warranties expressed or implied, including without
limitation, any implied warranty or merchantability or tness for any particular purpose, all of
which are expressly disclaimed.
1. Proof of sale may be required in order to claim warranty.
2. Customers outside the US are responsible for shipping charges to and from Gefen.
3. Copper cables are limited to a 30 day warranty and cables must be in their original
condition.
The information in this manual has been carefully checked and is believed to be accurate.
However, Gefen assumes no responsibility for any inaccuracies that may be contained
in this manual. In no event will Gefen be liable for direct, indirect, special, incidental, or
consequential damages resulting from any defect or omission in this manual, even if
advised of the possibility of such damages. The technical information contained herein
regarding the features and specications is subject to change without notice.
For the latest warranty coverage information, refer to the Warranty and Return Policy under
the Support section of the Gefen Web site at www.gefen.com.
PRODUCT REGISTRATION
Please register your product online by visiting the Register Product page under the
Support section of the Gefen Web site.
iii
iv
HDMI Detective Plus
Gefen, LLC
c/o Customer Service
20600 Nordhoff St.
Chatsworth, CA 91311
Telephone: (818) 772-9100
(800) 545-6900
Fax: (818) 772-9120
Visit us on the Web: www.gefen.com
Technical Support Hours: 8:00 AM to 5:00 PM Monday - Friday, Pacic Time
HDMI Detective Plus is a trademark of Gefen, LLC.
Important Notice
Gefen, LLC reserves the right to make changes in the hardware, packaging, and any
accompanying documentation without prior written notice.
© 2013 Gefen, LLC. All Rights Reserved.
All trademarks are the property of their respective owners.
Contacting Gefen Technical Support
iv
v
• When connecting a HDMI cable between the source and the HDMI Detective Plus,
the cable should not exceed 30 feet (10 meters) in length.
• The HDMI cable between the HDMI Detective Plus and the display (or other sink
device) should not exceed 50 feet (15 meters) in length.
• The HDMI Detective Plus comes pre-programmed with 6 default EDID proles as well
as 6 user-programmable EDID banks. If these default EDID proles are erased or
overwritten with other EDID data, the original default EDID proles cannot be restored.
v
3GSDI Audio Embedder
Operating Notes
HDMI Detective Plus
vi
Features
• Supports resolutions up to 1080p Full HD, and 1920 x 1200 (WUXGA)
• HDMI Features Supported:
►HDCP
►12-bit Deep Color
► LPCM 7.1 audio, Dolby® TrueHD, Dolby Digital® Plus,
and DTS-HD Master Audio™
►3DTV pass-through
► Lip-Sync pass-through
► CEC pass-through
• USB port for advanced programming of features such as EDID management
• Congurable using Gefen EDID Tool+ software, downloadable from Gefen website
• DDC re-clocking
• Records the EDID from a display
• 6 pre-programmed EDID proles
• 6 user-programmable EDID banks
• Selectable HDCP pass-through
• Field upgradable rmware via USB port
• Compact and portable
Packing List
The HDMI Detective Plus ships with the items listed below. If any of these items are not
present in your box when you rst open it, immediately contact your dealer or Gefen.
• 1 x HDMI Detective Plus
• 1 x 1ft. Locking HDMI Cable
• 1 x 6ft. Mini USB to USB Cable
• 1 x 5V DC power supply
• 1 x Quick-Start Guide
HDMI Detective Plus
Features and Packing List
3GSDI Audio EmbedderHDMI Detective Plus
Table of Contents
viii
01 Getting Started
Panel Layout ......................................................................................................... 2
Back .............................................................................................................. 2
Top ................................................................................................................ 2
Front.............................................................................................................. 2
Left ................................................................................................................ 2
Installation ............................................................................................................. 4
Connecting the HDMI Detective Plus............................................................ 4
Sample Wiring Diagram ................................................................................ 4
02 Operating the HDMI Detective Plus
EDID Programming ............................................................................................... 8
Programming an External EDID.................................................................... 8
Passing HDCP Content................................................................................. 9
Recording an EDID to a EDID Bank ........................................................... 10
Loading an EDID from a EDID Bank........................................................... 11
Saving the Local EDID to a File .................................................................. 12
Uploading an EDID le to the Local Input ................................................... 13
Uploading an EDID le to a EDID Bank ...................................................... 14
03 Advanced Operation
Using the Virtual COM Port................................................................................. 18
Installing the Driver ..................................................................................... 19
Commands.......................................................................................................... 21
04 Appendix
Installing the Gefen EDID Tool+ .......................................................................... 36
Firmware Upgrade Procedure............................................................................. 40
Using the #fw_upgrade command .............................................................. 40
Specications ...................................................................................................... 41
