Gefen HDMI-441 Manuel utilisateur

4x1 HDMI

Switcher

USER MANUAL

www.gefen.com

Technical Support:

Telephone (818) 772-9100

(800) 545-6900

Fax (818) 772-9120

Technical Support Hours:

8:00 AM to 5:00 PM Monday through Friday.

Write To:

Gefen Inc.

C/O Customer Service

20600 Nordhoff St.

Chatsworth, CA 91311

www.gefen.com

[email protected]

Notice

Gefen Inc. reserves the right to make changes in the hardware, packaging and any

accompanying documentation without prior written notice.

4x1 HDMI Switcher is a trademark of Gefen Inc.

HDMI is a trademark of hdmi.org

ASKING FOR ASSISTANCE

TABLE OF CONTENTS

Introduction

Features

Panel Descriptions

Connecting and Operating the 4x1 HDMI Switcher

RMT4-IR Installation

IR Code Conﬂicts

RS-232 Interface

Speciﬁcations

Warranty

Congratulations on your purchase of the ex•tend•it 4x1 HDMI Switcher. Your complete

satisfaction is very important to us.

Gefen’s line of HDTV switches, extenders, and splitters are designed to make yourA/V

equipment use more comfortable, more productive and less expensive.

The 4x1 HDMI Switcher allows access to four HDTV devices, using one HDTV display.

The ex•tend•it line offers solutions for Home Theater, A/V installation, data center, infor-

mation distribution, conference room presentation, school and corporate training envi-

ronments.

Our Commitment

Gefen will always offer the ﬁnest quality product at the best possible price. Included in

that price is a lifetime support from a team of outstanding engineers.

The ex•tend•it 4x1 HDMI Switcher allows four HDTV HDMI devices to be switched eas-

ily in to one HDTV HDMI compatible monitor or projector. Simply connect your HDTV

display to the Switcher’s display output. The 4x1 HDMI Switcher can also be placed at

the end of a long HDMI cable to regenerate the HDMI signal.

INTRODUCTION

FEATURES

Features

• Switches easily between any four HDMI sources

• Maintains 480p, 720p, 1080i, and 1080p resolutions

• Maintains highest HDMI single link video resolution

• Maintains highest HDMI digital audio signal

• Supports HDCP compliant devices

• HDMI or DVI to HDMI cables are used to connect the inputs and switcher output

• Inputs can be switched with the IR remote control or RS232 control.

• Installs in seconds

Includes:

(1) 4x1 HDMI Switcher

(4) 6’ HDMI cables (M-M)

(1) 5VDC Power Supply

(1) RMT4-IR

(1) Users Manual

PANEL DESCRIPTIONS

Connects to

5VDC power

supply

IR eye

Indicates which

input is selected

RS232

Controller Port

HDMI

In 1

IR Extender

Port HDMI

In 3 HDMI

In 4 HDMI

Out

Power LED

HDMI

In 2 EQ knobs

CONNECTING AND OPERATING THE 4x1 HDMI SWITCHER

How to Connect the 4x1 HDMI Switcher to your devices

1 Connect the supplied cables from the HDTV HDMI sources into the 4x1 HDMI Switcher

inputs.

2Connect the cables from your display (monitor or projector) into the HDMI out of the

4x1 HDMI Switcher.

3 Plug the 5VDC power supply into the 4x1 HDMI Switcher.

* Adjust the EQ knob to remove signal noise resulting from longer input cables

How to Control the 4x1 HDMI Switcher

Use the RMT4-IR remote control to toggle between sources.

RMT4-IR INSTALLATION

1. Remove battery cover from the back of the RMT4-IR remote.

2. Verify that dip switches 1 & 2 are in the down (OFF) position.

3. Insert the battery, hold the battery so that you can see the positive side facing up. The

side that is not marked must be facing down.

4. Test the RMT4-IR remote by pressing ONLY one button at a time. The indicator light

on the remote will ﬂash once each time you press a button. WARNING: Do not press

multiple buttons simultaneously and do NOT press buttons rapidly. These actions will

cause the remote to reset and steps 1-4 will have to be repeated.

Note: The RMT4-IR ships with two batteries. One battery is required for operation, the

second battery is complimentary.

The optional IR extender allows you to

relocate your HDMI Switcher and still have

IR control of the HDMI Switcher

IR EXTENDER INSTALLATION

How to Connect the IR Extender

1 Plug the IR extender into the Remote port on the front of the Switcher Unit

2Flip the Dip Switch 1 underneath the unit to the ON position

IR CODE CONFLICTS

How to Resolve IR Code Conﬂicts

There are matching pairs of dip switches underneath the Switcher unit and under the

remote battery cover. Switch 1 & 2 on the Remote and Switch 1 & 2 underneath the unit

are the matching switches. These switches need to be matched for the remote to

communicate with the switcher. There are 4 possible sets of IR codes and at least one of

these sets should be able to resolve any IR conﬂicts with other home theater devices.

Remote Channel 1:

Remote Channel 2:

Remote Channel 3:

Remote Channel 4:

Remote

Switcher

RS-232 Interface

Binary Table

ASCII Input Binary

1 1 0011 0001

2 2 0011 0010

3 3 0011 0011

4 4 0011 0100

Terminal Settings

Bits per second ...................................................................................................... 19200

Data bits ......................................................................................................................... 8

Parity ....................................................................................................................... None

Stop bits ..........................................................................................................................1

Flow Control ............................................................................................................ None
