Gefen SL Switcher Manuel utilisateur
SL Switcher
USER MANUAL
www.gefen.com
Technical Support:
Telephone (818) 884-6294
(800) 545-6900
Fax (818) 884-3108
Technical Support Hours:
9:00 AM to 5:00 PM Monday thru Friday.
Write To:
Gefen Inc.
C/O Customer Service
6265 Variel Ave.
Woodland Hills, CA91367-9897
Notice
Gefen Inc. reserves the right to make changes in the hardware, packaging and any
accompanying documentation without prior written notice.
SL Switcher is a trademark of Gefen Inc.
© 2006 Gefen Inc., All Rights Reserved
ASKING FOR ASSISTANCE
TABLE OF CONTENTS
Introduction
Features
Panel Descriptions
Connecting and Operating the SL Switcher
RMT2-IR Installation
IR Extender Installation
Specifications
Warranty
1
2
3
4
5
6
7
8
Congratulations on your purchase of the ex•tend•it SL Switcher. Your complete satisfac-
tion is very important to us.
Gefen’s line of KVM (Keyboard Video & Mouse), DVI, ADC, USB, switches, extenders,
converters and hubs is designed to make computer use more comfortable, more pro-
ductive and less expensive. KVM switches allow access to multiple computers from a
single keyboard, while the extenders give the user control over a computer up to 330
feet away from the work area. The ex•tend•it line offers solutions for noise, space and
security concerns, data center control, information distribution, conference room presen-
tation, and school and corporate training environments.
Our Commitment
Gefen will always offer the finest quality product at the best possible price. Included in
that price is a lifetime of free support from a team of outstanding engineers.
Now you can switch easily and reliably between any combination of two DVI & USB 2.0
equipped computers (PC or Mac) - using only one keyboard, display and mouse. The
DVI cross platform switcher saves space - there’s no need to work on a desk crowded
with double displays, keyboards and mouse devices. It saves time - there’s no need to
move from one monitor to another to access different computers.And, it saves money
- there’s no need to purchase additional displays, mouse devices, keyboards etc.
INTRODUCTION
1
FEATURES
Features
• Saves money on hardware costs
• Saves space on your desktop
• Save time and increase your productivity
• Maintains highest 1920 x 1200 x 60Hz resolution video
• No loss of quality
• Use either PC or Mac with USB keyboard/mouse
• Switches easily between any two DVI computers
• Switch between two DVI, USB 2.0 and Audio Sources
• Rackmountable
Includes:
The SL Switcher
One 5v Power Supply
One RMT2-IR Remote
Two 6ft DVI cables
Two 6ft USB cables
Two Audio cables
One User's Manual
2
PANEL DESCRIPTIONS
3
Power Indicator
Selector
Indicates which
input is selected
Audio In 1 Audio In 2 Audio Out
Contact Closure Interface
- Connects to optional wired
RMT-2 remote control
5VDC Input DVI In 1 DVI In 2
DVI Out USB
Output
USB In 1
USB In 2
IR Eye Equalization
Knobs
Connecting and Operating the SL Switcher
How to Connect the SL Switcher to your devices
1- Connect the supplied cables from your first computer into the DVI In 1, USB In 1,
and Audio In 1 connection in the back of the SL Switcher.
2- Connect the supplied cables from your second computer into the DVI In 2, USB In 2,
and Audio In 2 connection in the back of the SL Switcher.
3- Connect the monitor to the DVI Out connection.
4- Connect your USB devices (e.g. keyboard, mouse) into the USB Out.
5- Connect your speakers to the Audio Out.
6- Plug the 5VDC power supply into the SL Switcher.
How to Operate the SL Switcher
1- Use the front panel push button to switch between sources.
2- Use the RMT-2IR wireless remote control to remotely switch between sources.
3- Use the optional RMT-2 wired remote control to remotely toggle between sources.
Operation Notes
When turning on or rebooting your computers, the SL Switcher must be selected
to the computer that is booting until the computer completes the boot cycle. This
step can be eliminated using the Gefen DVI Detective.
If you loose your picture when switch from source 1 to source 2 or viasaversa
you will require a DVI Detective.
The equalization knobs can be used to balance out signal noise resulting from
long cables for better picture quality.
4
RMT2-IR INSTALLATION
1. Remove battery cover from the back of the RMT2-IR remote.
2. Verify that dip switches 1 & 2 are in the down (OFF) position.
3. Insert the battery, hold the battery so that you can see the positive side facing up. The
side that is not marked must be facing down.
4. Test the RMT2-IR remote by pressing ONLY one button at a time. The indicator light
on the remote will flash once each time you press a button. WARNING: Do not press
multiple buttons simultaneously and do NOT press buttons rapidly. These actions will
cause the remote to reset and steps 1-4 will have to be repeated.
Note: The RMT2-IR ships with two batteries. One battery is required for operation, the
second battery is complimentary.
5
IR Extender Installation
How to Connect the IR Extender
1Open the unit and move the jumper labeled INFRARED (pictured* as "Step 1"
below) from Local to Remote
2In the bank of switches labeled SERVICE SWITCH (pictured* as "Step 2" below), flip
Service Switch #1 (top most switch) to the ON position
3 Reassemble the unit.
4Plug the IR extender into the Remote port on the front of the Switcher Unit
6
*Note: Picture depicts upper right corner
of the unit with the power light facing up.
SPECIFICATIONS
7
Video Amplifier Bandwidth ..................................................................................1.65 GHz
Input Video Signal.......................................................................................... 1.2 volts p-p
Input DDC Signal .................................................................................... 5 volts p-p (TTL)
Single Link Range ............................................................................. 1920 x 1200 x 60hz
DVI Input/Output Connector Type ............................................................................. DVI-I
USB 2.0 Input Connection ................................................................................... Type “B”
USB 2.0 Output Connection ................................................................................ Type “A”
Power Consumption ................................................................................ 15 Watts (max.)
Power Supply ......................................................................................................... 5 VDC
Dimensions ................................................................................. 4.625”D x 8”W x 1.75”H
Rackmountable ........................................................................................... 1 Rack Space
Shipping Weight ....................................................................................................... 5 Lbs
