Primus Maximus V1.0-EN

Dual Primus Maximus

Direct Drive Turntable

Owner’s Manual

Primus Maximus V1.0-EN

Introduction

This Owner’s Manual will help you, to install and use the Primus Maximus correctly and safe.

All persons, who install, operate, clean and/or dispose this turntable, should read this manual

carefully before using the turntable.

Please keep this manual stored for later reference or other users.

Please pay special attention to all safety relevant chapters.

These are clearly marked with this sign:

Primus Maximus V1.0-EN

Table of Content

Section Page

Safety 4

Unpacking 5

Delivery Content 6

Turntable Overview 7

Setup 8-9

Placement of the Turntable 8

Connection of Phono Cable 8

Installation of Platter and Mat 9

Installation of Counterweight 9

Installation of Hinges and Dust Cover 9

Connection of Power Supply 9

Adjustment 10-12

Balancing the Tonearm 10

Tracking Force and Antiskating Setting 11

Tonearm Height Adjustment 11

Azimuth Adjustment 11

Speed Adjustment 12

Operating the Turntable 12

Cleaning and Maintenance 13

Technical Data, Conformity to Directives and Standards 14

Disposal Instructions 14

Primus Maximus V1.0-EN

Safety

Please read this safety information carefully and do only act according these instructions.

- The turntable and parts of this turntable, like the platter, are very heavy. Please check, if you

can lift the heavy weight of this unit by yourself. Otherwise ask for assistance of another

person.

- Do only use the correct power supply unit.

- Do only connect the power supply to the correct mains voltage, which is stated on the power

supply unit.

- Take care, that all supply cables do not have any damage, to avoid fire hazards and electric

shock.

- Do not expose the turntable or power supply to moisture or water.

- Remove the mains plug from the socket if you do not intend to use the unit for a longer

period.

- If there is a malfunction or smoke coming from the unit, disconnect mains immediately.

- The packing material is no toy. Never allow children to play with this material. There is a high

risk to suffocate, when playing with plastic bags.

Primus Maximus V1.0-EN

Unpacking

The turntable is delivered in a special designed box, to ensure a safe transport of the turntable.

Inside, there are some layers of damping foam, to cover all the part safely. The following pictures

show the unpacking step by step.

…

We strongly recommend storing the packing box, including the inside packing material for future

transport of the turntable.

After all parts are removed from the packing box, please check the delivery content carefully.

Primus Maximus V1.0-EN

Delivery Content

A Turntable, including tonearm and pickup cartridge

B Dust cover

C Platter

D Platter mat

E Hinge (2x)

F Counterweight

G Power supply

H Mains cable

I Phono cable

J Singe puck

K 3x Allen key: 2,5mm, 2mm, 1.3mm

L Mini Screwdriver

Primus Maximus V1.0-EN

Turntable Overview

View on top side of the turntable

View on back side of the turntable

Primus Maximus V1.0-EN

Setup

Placement of the Turntable

Select a location, where you would like to place your turntable. Take care that the construction

below the turntable is solid enough to carry the heavy weight of the turntable. Do not place the

turntable close to loudspeakers, to avoid acoustic coupling. There should be also no direct sun to the

turntable. This can cause damage or bleaching of the wooden surface.

For correct horizontal placement, the turntable is equipped with 4 adjustable feet. You can check

placement with a spirit level. The feet have a micro thread. It can be leveled by turning the foot.

Connection of Phono Cable

The phono cable (item I in the delivery content) must be connected to the tonearm. Below the

tonearm, there is a big hole in the bottom plate of the turntable. Through this hole, you can see the 5

pin connector of the tonearm, refer picture below:

Lift up the turntable, to insert the 5-pin connector of the phono cable into the tonearm connector.

Place the turntable back at your table or rack.

The other end of the phono cable has standard RCA plugs for the left and right stereo channel and an

additional grounding wire. The RCA plugs must be connected to your Amplifier at the “Phono” input.

The grounding wire must be connected to the ground clamp at the phono section of your amplifier.

The turntable is equipped with a low output MC-Cartridge. Please ensure that your phono section

supports low output MC-Cartridges.

Primus Maximus V1.0-EN

Installation of Platter and Mat

Now you can place the platter (item C in the delivery content) carefully to the motor sub platter. It is

centered by the motor axle. The platter sits with its own weight on the motor platter and does not

need any fixture. Be careful, when you handle the heavy platter and do not drop it.

The platter mat (item D in the delivery content) can now be placed on top of the platter.

Installation of Counterweight

The counterweight (item F in the delivery content) must be installed at the backside rod of the

tonearm. By turning it, the position of the weight moves back and forth. Please refer picture below:

Installation of Hinges and Dust Cover

There are 2 hinge sockets at the rear side of the turntable (refer schematic of the top view in the

overview section). Here you can insert the 2 hinges (item E in the delivery content). Now you can

place the dust cover. It has 2 fixture slots at the rear side, which fit to the hinges.

Connection of Power Supply

Important: Please do only use the correct power supply unit (item G in the delivery content)!

The power supply has its own housing and can be placed separately. The DC jack of the power supply

must be connected to the DC input at the backside of the turntable. Refer to the schematic of the

back view in the overview section.

Now you can connect the mains cable (item H in the delivery content) to the power supply. The

mains connector of the cable can now be inserted to a mains socket in your room.

Primus Maximus V1.0-EN

Adjustment

Balancing the Tonearm

During this procedure it is very important that the stylus of the cartridge does not hit any

part. Otherwise it can be easily damaged or broken!

Please follow this procedure for balancing the tonearm step by step:

Step 1:

Set tracking force scale to “0”.

Step 2:

Set antiskating scale to “0”.

Step 3:

Move lift lever to “lift down” position.

Step 4:

Move the tonearm carefully from the tonearm rest to a

position between tonearm rest and platter.

Attention:

To avoid any damage of the pickup stylus, use one

hand, to hold the headshell in position.

Step 5:

The counterweight can be rotated on its axle.

Depending on the turning direction, it moves forward

or backward (refer upper and middle schematic on the

left). So you can find the position, where the tonearm

is freely levitating in the horizontal position (like in the

lower schematic on the left).

Attention:

Whenever you turn at the counterweight, use one

hand, to hold the headshell in position. So, you avoid

uncontrolled movement. Then release the headshell

carefully, to check the balancing.

Once the tonearm is correctly balanced, move it back to tonearm rest.
