4 by 4 HDMI with Audio Matrix Fast Switch

Operation Manual

DISCLAIMERS

The information in this manual has been carefully checked and

is believed to be accurate. Cypress Technology assumes no

responsibility for any infringements of patents or other rights of third

parties which may result from its use.

Cypress Technology assumes no responsibility for any inaccuracies

that may be contained in this document. Cypress also makes no

commitment to update or to keep current the information contained

in this document.

Cypress Technology reserves the right to make improvements to this

document and/or product at any time and without notice.

No part of this document may be reproduced, transmitted,

transcribed, stored in a retrieval system, or any of its part translated

into any language or computer le, in any form or by any means—

electronic, mechanical, magnetic, optical, chemical, manual, or

otherwise—without express written permission and consent from

Cypress Technology.

Version 1.0 May 2014

TRADEMARK ACKNOWLEDGMENTS

All products or service names mentioned in this document may be

trademarks of the companies with which they are associated.

SAFETY PRECAUTIONS

Please read all instructions before attempting to unpack, install or

operate this equipment and before connecting the power supply.

Please keep the following in mind as you unpack and install this

equipment:

• Always follow basic safety precautions to reduce the risk of re,

electrical shock and injury to persons.

• To prevent re or shock hazard, do not expose the unit to rain,

moisture or install this product near water.

• Never spill liquid of any kind on or into this product.

• Never push an object of any kind into this product through any

openings or empty slots in the unit, as you may damage parts

inside the unit.

• Do not attach the power supply cabling to building surfaces.

• Use only the supplied power supply unit (PSU). Do not use the PSU

if it is damaged.

• Do not allow anything to rest on the power cabling or allow any

weight to be placed upon it or any person walk on it.

• To protect the unit from overheating, do not block any vents or

openings in the unit housing that provide ventilation and allow for

sufcient space for air to circulate around the unit.

REVISION HISTORY

VERSION NO. DATE DD/MM/YY SUMMARY OF CHANGE

VR0 21/12/15 Preliminary Release

CONTENTS

1. Introduction............................................ 1

2. Applications........................................... 1

3. Package Contents ................................ 1

4. System Requirements............................ 1

5. Features.................................................. 2

6. Operation Controls and Functions....... 3

6.1 Front Panel ........................................3

6.2 Rear Panel.........................................4

6.3 OSD Menu.........................................5

6.4 Remote Control..............................11

6.5 IR Cable Pin Assignment................12

6.6 RS-232 Protocols .............................12

6.7 RS-232 & Telnet Commands..........13

6.8 Telnet Control .................................17

6.9 WebGUI Control .............................19

7. Connection Diagram .......................... 23

8. Specications ...................................... 24

9. Acronyms ............................................. 26

1. INTRODUCTION

The 4 by 4 HDMI matrix with audio which allows HDMI and audio

signal to be routed to and displayed on connected HDMI displays

and or audio output equipments simultaneously. Additional audio

selection and extension allows users to utilise both video and audio

more efciency. With fast switching technology the device can

greatly eliminate the time required by swapping or turning ON/OFF

the connected displays. It supports 4Kx2K, 3D, 36-bit Deep Color, Hi-

Def lossless audio and other features dened by HDMI specications.

The management of source/sink scenarios can be operated easily

through on-panel buttons, IR remote control, RS-232 or Ethernet

protocol.

2. APPLICATIONS

• Home Theater/Entertainment

• Lecture Room/Hall Presentation

• Show Room/Demo Room

• Public Commercial Display

• Information Board

3. PACKAGE CONTENTS

• 4 by 4 HDMI 4Kx2K Matrix with Audio

• Remote Control with Battery

• Left & Right Rack Ears

• 12V/3A DC Power Adaptor

• IR Receiver Cable

• Operation Manual

4. SYSTEM REQUIREMENTS

Input source equipments such as Blu-ray/DVD/PS3 player or Set-

Top-Box and output HDMI TV/Display and or audio amplier with

connection cables.

5. FEATURES

• HDMI with 3D & 4Kx2K supported, HDCP and DVI compliant

• Supports four HDMI inputs and four HDMI outputs

• Supports external audio inputs and outputs for HDMI outputs

selection and additional audio extension up to 300M/984ft with

sampling rate at 48kHz

• Supports HDMI and Optical audio format for both HDMI and Optical

outputs selection

• Support individual output MUTE function on both video and audio

• Displays any of four High-Denition sources on four HDTV displays

simultaneously with fast switch

• 3DTV Pass-Through

• Supports HDTV resolutions up to 4Kx2K (3840x2160@24/25/30 & 50/60

Y420 4096x2160@24 & 50/60Hz Y420)

• Supports data rate up to 300Mbps or 9Gbps and Deep Color up to

1080p 36-bit

• Supports individual EDID or common EDID

• Supports LPCM 2CH with sampling up to 192kHz

• Input port HDCP support Standard and Apple mode. The Apple

mode selection to guarantees the use of Apple devices

6. OPERATION CONTROLS AND FUNCTIONS

6.1 Front Panel

POWER

IN 1IN 2IN 3IN 4AUDIOHDMI

OUT AOUT B OUT C OUT DVIDEO

ENTER

PRESET

ALLLOCK

DIGITALMUTE

TAKE

CANCEL

4X4 HDMI WITH AUDIO MATRIX FAST SWITCH

1 2 3 5 12 14 15 18

4 6

8 9

11 13 1614 17

1POWER: Press this button to turn ON the device and the LED will

illuminated.

2IR Window: This IR Receiver receives the remote control signal from

the package include remote control only.

3IN 1~4: Press these IN buttons to select an input from the input

sources. Under audio selection press it continually to select audio

format. For example: HDMI OUT A need to output HDMI IN 2's

video with S/PDIF 2 audio format. Setting steps should be press

VIDEO→OUT A→IN 2→ TAKE→VIDEO, AUDIO→OUT A→IN 2(press

twice:S2)→TAKE→AUDIO.

4OUT A/D: Press these buttons along with an IN buttons to select an

input source for an output display. i.e. OUT A→ IN1→TAKE or OUT B

& OUT C→ IN4→TAKE.

5AUDIO: Press this button to select audio matrix setting only for

outputs.

6VIDEO: Press this button to select video matrix setting only for

outputs.

7HDMI: Press this button under AUDIO to select HDMI audio.

8DIGITAL: Press this button to select an input source audio.

9MUTE: Press this button to mute video image or audio output

sound. To unmute, press it again.

10 TAKE: Press this button to conrm the selection. If this button is not

pressed, all selection will be avoid.

11 CANCEL: Press this button to cancel the selection.

12 ENTER: Press to conrm the selection.

13 MENU: Press to enter into the menu.

14 +/-: Press these buttons to move up/down under menu selection.

15 PRESET: Press “PRESET”, the OLED menu will show Preset then select

IN 1~4. Preset 5~8 selection, press IN 1/2/3/4 twice. Press “TAKE” to

conrm the selection or press “CANCEL” to exit the selection.

16 All: Press this button to select all outputs with an input selection.

17 LOCK: Press this button to lock all button functions on the panel.

Press 3 seconds to relieve the lock function.

18 LCM: Displaying Input and Outputs selection and menu selection.

6.2 Rear Panel

HDMI IN

1234

HDMI OUT OPTICAL IN

ABCD

OPTICAL OUT

AUDIO-CATCONTROL

3C 4D

SERVICE

RS232IR IN DC 12V

1 2 3 4 5 6 7 8 9 10

1HDMI IN: Connect from source equipments such as Blu-ray/DVD/

PS3 players, Set-Top-Box or any HDMI equipped source device for

input signal sending.

2HDMI OUT: Connect to HDMI TV/display or HD Amplier for output

image and or audio display.

3OPTICAL IN: Connect from source equipment such as DVD, Blu-ray,

PS3 or etc. with audio signal.

4OPTICAL OUT: Connect to active speaker or audio amplier for

audio distribution.

5AUDIO-CAT 3C/4D: Connect this port 3C to the AUDIO-CAT output

of the Transmitter unit and 4D to the AUDIO-CAT input of the

Receiver unit using CAT5e/6/7 cable.

With 192kHz sampling rate over a single CAT5e/6/7 cable up to

100m/328ft, 96kHz sampling rate up to 150m/492ft and 48kHz

sampling rate up to 300m/984ft.

6SERVICE: This slot is reserved for rmware update use only.

7CONTROL: Connect from PC/Laptop with active internet service

for WebGUI control with RJ-45 terminated cable.

8RS232: Connect from PC/Laptop for RS-232 command sending to

control the device.

9IR IN: Connect the IR Receiver included in the package for IR

signal receive from the included remote control.

10 DC 12V: Connect the adaptor with power cord included in the

package and connect to AC wall outlet for power supply.

6.3 OSD Menu

Main Menu Sub Menu Description Default

EDID Mode All All Input port is using same

EDID.

In menu “EDID All”, can

select suitable EDID.

All

Appoint Each Input port can select

individual EDID.

In menu “EDID IN1~4” select

suitable EDID.

Exit

EDID All Sink A Copy Output A display EDID 8/2D/

PCM/1080p

Sink B Copy Output B display EDID

Sink C Copy Output C display EDID

Sink D Copy Output D display EDID

8/2D/

PCM/720p

Standard EDID,

Content: deep color/2D3D/

audio/native resolution

8/2D/

PCM/1080p

Standard EDID,

Content: deep color/2D3D/

audio/native resolution

8/2D/

PCM/4K2K

Standard EDID,

Content: deep color/2D3D/

audio/native resolution
