CYP CSSW-91WF Manuel utilisateur
CSSW-91WF
9 x 1 HDMI/Smart Player Switcher
Operation Manual
Operation Manual
DRAFT MANUAL
DISCLAIMERS
The information in this manual has been carefully checked and
is believed to be accurate. Cypress Technology assumes no
responsibility for any infringements of patents or other rights of third
parties which may result from its use.
Cypress Technology assumes no responsibility for any inaccuracies
that may be contained in this document. Cypress also makes no
commitment to update or to keep current the information contained
in this document.
Cypress Technology reserves the right to make improvements to this
document and/or product at any time and without notice.
COPYRIGHT NOTICE
No part of this document may be reproduced, transmitted,
transcribed, stored in a retrieval system, or any of its part translated
into any language or computer le, in any form or by any means—
electronic, mechanical, magnetic, optical, chemical, manual, or
otherwise—without express written permission and consent from
Cypress Technology.
© Copyright 2012 by Cypress Technology.
All Rights Reserved.
Version VR1.0 January 2012
TRADEMARK ACKNOWLEDGMENTS
All products or service names mentioned in this document may be
trademarks of the companies with which they are associated.
SAFETY PRECAUTIONS
Please read all instructions before attempting to unpack, install or
operate this equipment and before connecting the power supply.
Please keep the following in mind as you unpack and install this
equipment:
• Always follow basic safety precautions to reduce the risk of re,
electrical shock and injury to persons.
• To prevent re or shock hazard, do not expose the unit to rain,
moisture or install this product near water.
• Never spill liquid of any kind on or into this product.
• Never push an object of any kind into this product through any
openings or empty slots in the unit, as you may damage parts
inside the unit.
• Do not attach the power supply cabling to building surfaces.
• Use only the supplied power supply unit (PSU). Do not use the PSU
if it is damaged.
• Do not allow anything to rest on the power cabling or allow any
weight to be placed upon it or any person walk on it.
• To protect the unit from overheating, do not block any vents or
openings in the unit housing that provide ventilation and allow for
sufcient space for air to circulate around the unit.
REVISION HISTORY
VERSION NO. DATE DD/MM/YY SUMMARY OF CHANGE
RDV1 29/06/12 Preliminary Release
CONTENTS
1. Introduction............................................................1
2. Applications...........................................................1
3. Package Contents ................................................1
4. System Requirements............................................1
5. Features..................................................................2
6. Operation Controls and Functions.......................4
6.1 Front Panel ....................................................... 4
6.2 Rear Panel........................................................ 5
6.3 Remote Control............................................... 6
6.4 USB Dongle (Optional Accessory)................. 6
6.5 RS-232 Commands.......................................... 7
7. Software Installation and un-installation .............7
7.2 Uninstall the Computer Software ................ 10
8. Conguring your application to use the Receiver ....11
8.1 Smart Phone Easy Connection.................... 12
8.2 Access Point Application ............................. 13
9. Connection and Installation.............................. 14
10. Specications ................................................... 15
11. Acronyms .......................................................... 16
1
1. INTRODUCTION
The 9 x 1 HDMI/Smart Player Switcher, allows 8 different HDMI sources
to be selected for one HDMI output display and the 9th selection is
with USB inputs for user to connect with USB Wi-Fi dongle to become
a smart player through “PC to TV” pc software. Other USB ports are
for mouse and keyboard allows aside control at the display end.
The HDMI/Smart Player Switcher is designed as a DLNA DMR(Digital
Media Renderer) which means users can easy send video/audio and
pictures from a computer wirelessly to TV. Also, it can act as a Wi-Fi
Access Point for users to access a wired internet connection with their
PC/NB or smart phones. The HDMI/Smart Player Switcher is a simple
yet incredibly useful device for your HDMI switch and sharing content
through network stream.
2. APPLICATIONS
• HDMI switch up to 8 sources
• Wireless PC/NB to TV
• Wireless Smart Phone to TV
• Wire PC/NB to TV
• Wi-Fi Access Point(with USB Dongle)
3. PACKAGE CONTENTS
• HDMI/Smart Player Switcher
• USB Dongle (Optional)
• CD Driver
• Power adaptor
• Remote Control CR-112
• Operation Manual
4. SYSTEM REQUIREMENTS
Input HDMI source equipments such as Blu-ray / DVD player and
output HDMI monitor with connection cables.
In order to run the Smart Player smoothly, please refer to the following
hardare recommendation.
Desktop/Workstation PC:
• CPU: Intel Core 2 Duo 2.0G or better
2
• Chipset: Intel 965 series chipset or better
• Memory: DDR2-800, 2GB or better
• Graphic Card: NVIDIA GeForce 8400GS/ATI Radeon X300 or better
• Network: 802.11 g/n Wi-Fi and/or 100/1000 Mbps Ethernet
Notebook/Laptop PC:
• CPU: Intel Core 2 Duo 2.0G or better
• Chipset: Intel 965 series chipset or better
• Memory: DDR2-800, 2GB or better
• Graphic: Chipset integrated (Intel X3100 Graphic) or better or
NVIDIA GeForce Go 8200M/ATI Radeon Mobility X300 standalone
graphic chip or better
• Network: 802.11 g/n Wi-Fi and/or 100/1000 Mbps Ethernet
Supported OS:
• Windows 7, x86 and x64
• Windows Vista (Swervice Pack 1 or later), x86 and x64
• Windows XP (Service Pack 3 or later)
5. FEATURES
• HDMI, HDCP and DVI compliant
• Eight HDMI sources to connect up to an HDMI displays
• Supports CEC bypass
• Supports LPCM 7.1CH, Dolby TrueHD, Dolby Digital Plus and DTS-HD
Master Audio transmission (32-192kHz Fs sample rate)
• Supports HDMI input up to 15 meters with 8bits resolution or 10
meters with 12bits resolution and output up to 15 meters with
8/12bits
• Deep color video up to 12bit, support wide range of PC and HDTV
resolutions from VGA to WUXGA (1920x1200 Reduce Blanking) and
480i to 1080p
NOTE
A. Cable tested with CAT5e/23AWG using cables of another type
may result in a different operating distance.
B. Figuresprovidedinthismanualarereferenceguresactualonly,
guresmaydependonsourceanddisplayusewithcable
specication.
3
• Supports PC to TV and Smart Phone to TV
• Can be a Wi-Fi AP (Access Point)
• Wi-Fi Smart Player is a device that designed as a DLNA DMR (Digital
Media Render) device
• Display various picture, audio and video contents through network
streaming
• USB port for mouse/keyboard
4
6. OPERATION CONTROLS AND FUNCTIONS
6.1 Front Panel
1 2 3 4 5
HDMI IN
8STANDBY
CSSW-91WF 9X1 HDMI/SMART PLAYER SWITCHER
USB
SMART
PLAYER
8 97654321
HDMI
1HDMI input buttons and LEDs
Press the number buttons to select input source from 1~9, LED will
illuminate accordingly with the selection.
2IR window
This IR window accept only the IR signal of the remote control
included in the package.
3HDMI INPUT 1
Connect to the source equipment such as Blu-ray/DVD player for
signal sending on to HDMI output display.
4USB Port
This slot is to connect with Wi-Fi module
5POWER button & STANDBY LED
Press this button to switch ON or set the device to standby mode.
5
6.2 Rear Panel
1 2 3 4 5 6
ETHERNETUSB
14
3
6
5
8
7
HDMI IN
DC 5V
HDMI OUT
RS232
1USB Ports
These slots are to connect with USB devices such as keyboard and
mouse for aside control at the display side.
2ETHERNET
Connect this port to an active Ethernet connection for a wire
connection of Smart Player function.
3HDMI INPUT 2~8
Connect to the source equipment such as Blu-ray/DVD player for
signal sending on to HDMI output display.
4HDMI OUTPUT
Connect to HDMI TV/monitor for input signal display.
5RS-232
Connect from PC/NB for control the device through the RS-232
command with D-Sub 9pin cable.
6DC 5V
Plug the 5V DC power supply into the unit and connect the
adaptor to AC wall outlet.
