Operation Manual
Operation Manual
CLUX-SDI2OF & CLUX-OF2SDI
SDI over Optical Fiber Extender
DISCLAIMERS
The information in this manual has been carefully checked and
is believed to be accurate. Cypress Technology assumes no
responsibility for any infringements of patents or other rights of third
parties which may result from its use.
Cypress Technology assumes no responsibility for any inaccuracies
that may be contained in this document. Cypress also makes no
commitment to update or to keep current the information contained
in this document.
Cypress Technology reserves the right to make improvements to this
document and/or product at any time and without notice.
COPYRIGHT NOTICE
No part of this document may be reproduced, transmitted,
transcribed, stored in a retrieval system, or any of its part translated
into any language or computer le, in any form or by any means—
electronic, mechanical, magnetic, optical, chemical, manual, or
otherwise—without express written permission and consent from
Cypress Technology.
© Copyright 2011 by Cypress Technology.
All Rights Reserved.
Version 1.0 September 2011
TRADEMARK ACKNOWLEDGMENTS
All products or service names mentioned in this document may be
trademarks of the companies with which they are associated.
SAFETY PRECAUTIONS
Please read all instructions before attempting to unpack, install or
operate this equipment and before connecting the power supply.
Please keep the following in mind as you unpack and install this
equipment:
• Always follow basic safety precautions to reduce the risk of re,
electrical shock and injury to persons.
• To prevent re or shock hazard, do not expose the unit to rain,
moisture or install this product near water.
• Never spill liquid of any kind on or into this product.
• Never push an object of any kind into this product through any
openings or empty slots in the unit, as you may damage parts
inside the unit.
• Do not attach the power supply cabling to building surfaces.
• Use only the supplied power supply unit (PSU). Do not use the PSU
if it is damaged.
• Do not allow anything to rest on the power cabling or allow any
weight to be placed upon it or any person walk on it.
• To protect the unit from overheating, do not block any vents or
openings in the unit housing that provide ventilation and allow for
sufcient space for air to circulate around the unit.
REVISION HISTORY
VERSION NO. DATE SUMMARY OF CHANGE
VR0 15/01/2012 Preliminary release
CONTENTS
1. Introduction..............................................1
2. Applications.............................................1
3. Package Contents ..................................1
4. System Requirements..............................1
5. Features....................................................1
6. Operation Controls and Functions.........2
6.1 Transmitter...........................................2
6.2 Receiver..............................................3
7. Specications ..........................................4
8. Connection and Installation...................5
9. Acronyms.................................................6
1
1. INTRODUCTION
The SDI to Optical Fiber Extender is a pair of tool to extend your SDI
signals over Optical Fiber for long distance transmission up to 10km.
Signals from 50MB/s to 3Gb/s without loss or compression with thinner,
lighter cables for easy installations.
2. APPLICATIONS
• Broadcast signal extension
• Surveillance
• Studio
• Television station
3. PACKAGE CONTENTS
•SDI over Optical Fiber Tranmsitter
•SDI over Optical Fiber Receiver
•5V / 2.6A DC Power Adaptor x2
•Operation Manual
4. SYSTEM REQUIREMENTS
Input SDI source equipment such as broadcast video recorder or
camera and output to SDI monitor/display with SDI connection cable
and optical ber in between the two extenders.
5. FEATURES
• SMPTE 287-2006 compliant
• Robust error free transmission of signals from 50Mb/s to 3Gb/s over
at least 10km single-mode ber but it will depend on the ber
module used
• Supports video pathological patterns for SD-SDI, HD-SDI and 3G-SDI
• Supports SD/HD/3G timings: 480i, 576i, 720p, 1080i 50/59.94/60,
1080p 23.98/24/25/29.97/50/59.94/60, 1080PsF 23.98/24/25/29.97/30
• Bypass integrated SDI audio up to max. 16 channels of 48kHz audio
• Auto video mode detection (3G/HD/SD)
• Faster data transmission
• Lower power consumption
2
6. OPERATION CONTROLS AND FUNCTIONS
6.1 Transmitter
1 2 3 4
1DC 5V:
This slot is to plug with the 5V DC power supply adaptor and
connect it to an AC wall outlet.
23G / HD / SD LED:
These LEDs will illuminate according to the input SDI signal of 3G/
HD/SD format. The device will detect the signal automatically.
3SDI IN:
This slot is to connect with input SDI source equipment such as SNG
video recorder or SDI video camera.
4OPTICAL OUT:
This slot is to connect with optical ber up to 10km for SDI signal
sending to the receiver.
3
6.2 Receiver
4
1 2 3
1SDI OUT:
This slot is to connect with SDI monitor or display for SDI video and
audio output display.
23G / HD / SD LED:
These LEDs will illuminate according to the output SDI signal of 3G/
HD/SD format. The device will detect the signal automatically.
3DC 5V:
This slot is to plug with the 5V DC power supply adaptor and
connect it to an AC wall outlet.
4OPTICAL IN:
This slot is to connect with optical ber up to 10km from the
transmitter side of SDI box for signal receiving.
4
7. SPECIFICATIONS
Transmitter
Input Ports 1 x SDI
Output Ports 1 x Single-Mode Fiber Optical with LC
connector
Receiver
Input Ports 1 x Single-Mode Fiber Optical with LC
connector
Output Ports 1 x SDI
SDI I/O Cable Distance 3G up to 100M (BELDEN 1694A)
HD up to 200M (BELDEN 1694A)
SD up to 300M (BELDEN 1694A)
Optical Fiber Cable Distance Up to 10 km
Dimensions (mm) 78.5(W) x 143(D) x 30(H)
Power Supply 5V/2.6A DC (US/EU standards, CE/
FCC/UL certied)
Weight(g) 200
Chassis Material Aluminum
Silkscreen Color Silver
Operating Temperature 0ºC~ 40ºC/ 32ºF~ 104ºF
Storage Temperature -20ºC~ 60ºC/ -4ºF~ 140ºF
Relative Humidity 20 ~ 90% RH (non-condensing)
Power Consumption(W) 3/each
5
8. CONNECTION AND INSTALLATION
SNG Camcorder SDI camera
or
SDI Monitor
SDI Cable 300M
SDI Cable 300M
Optical Cable 10km
6
9. ACRONYMS
ACRONYM COMPLETE TERM
3G Bandwidth 2.97Gbps ≈ 3G
LED Light-Emitting Diode
SDI Serial Digital Interface
SNG Satellite News Gathering
