CPLUS-VHHE

4K2K HDMI to HDMI Enhancer

Operation Manual

DISCLAIMERS

The information in this manual has been carefully checked and

is believed to be accurate. Cypress Technology assumes no

responsibility for any infringements of patents or other rights of third

parties which may result from its use.

Cypress Technology assumes no responsibility for any inaccuracies

that may be contained in this document. Cypress also makes no

commitment to update or to keep current the information contained

in this document.

Cypress Technology reserves the right to make improvements to this

document and/or product at any time and without notice.

No part of this document may be reproduced, transmitted,

transcribed, stored in a retrieval system, or any of its part translated

into any language or computer le, in any form or by any means—

electronic, mechanical, magnetic, optical, chemical, manual, or

otherwise—without express written permission and consent from

Cypress Technology.

TRADEMARK ACKNOWLEDGMENTS

All products or service names mentioned in this document may be

trademarks of the companies with which they are associated.

SAFETY PRECAUTIONS

Please read all instructions before attempting to unpack, install or

operate this equipment and before connecting the power supply.

Please keep the following in mind as you unpack and install this

equipment:

• Always follow basic safety precautions to reduce the risk of re,

electrical shock and injury to persons.

• To prevent re or shock hazard, do not expose the unit to rain,

moisture or install this product near water.

• Never spill liquid of any kind on or into this product.

• Never push an object of any kind into this product through any

openings or empty slots in the unit, as you may damage parts

inside the unit.

• Do not attach the power supply cabling to building surfaces.

• Use only the supplied power supply unit (PSU). Do not use the PSU

if it is damaged.

• Do not allow anything to rest on the power cabling or allow any

weight to be placed upon it or any person walk on it.

• To protect the unit from overheating, do not block any vents or

openings in the unit housing that provide ventilation and allow for

sufcient space for air to circulate around the unit.

REVISION HISTORY

VERSION NO. DATE (DD/MM/YY) SUMMARY OF CHANGE

RDV1 17/08/15 Preliminary release

CONTENTS

1. Introduction............................................ 1

2. Applications........................................... 1

3. Package Contents ................................ 1

4. System Requirements............................ 1

5. Features.................................................. 2

6. Operation Controls and Functions....... 3

6.1 Front and Rear Panels .....................3

6.2 Top Panel ..........................................4

6.3 Side Panel .........................................5

7. Connection Diagram ............................ 6

8. Specications ........................................ 7

9. Acronyms ............................................... 8

1. INTRODUCTION

The 4K2K HDMI to HDMI Enhancer is a handy device for your HDMI

signal extension. With bandwidth, HDCP analyzing, EDID and YUV420

selections this device allows you with fast and clear viewing on the

HDMI signal status. Further, this device allows user to upload EDID for

selection which create alternative EDID selection for specic usage.

Moreover, with hot keys and LEDs design which allow fast switching on

various selection and quick viewing on the status.

2. APPLICATIONS

• HDMI signal extension

• Source and display signal status display

• EDID selection

• HDCP verication

• 4K2K YUV444 down sampling to 4K2K YUV420

3. PACKAGE CONTENTS

• 1×4K2K HDMI to HDMI Enhancer

• 1×5 V/2.6 A Power Adaptor

• 1×Operation Manual

4. SYSTEM REQUIREMENTS

Input HDMI source a signals with output HDMI display and connection

cables.

5. FEATURES

• HDMI with 4K2K 6G supported, HDCP 2.2/1.4 and DVI compliant

• Supports video source and output display signal analysis up to 6G

4K2K

• Supports HDMI 2.0

• Supports HDCP v1.4 & v2.2 a

• Supports EDID selection from internal, external and user’s EDID to be

insert

• Supports application control via USB

• Supports LEDs display with fast viewing on current selection status

• Supports USB rmware update

• Supports 6G bandwidth down sampling to 3G

6. OPERATION CONTROLS AND FUNCTIONS

6.1 Front and Rear Panels

HDMI IN

HDMI OUT

SERVICE

1 2 3 4

Front Rear

1HDMI IN: Connect with HDMI source equipment such as Blue-ray/

PS4 player with HDMI cable.

2DC 5V: Plug the 5V DC power supply into the unit and connect the

adaptor to an AC outlet.

3SERVICE: This slot is for rmware update use and customer EDID le

upload.

4HDMI OUT: Connect with display/amplier for both video and

audio output with HDMI cable.

6.2 Top Panel

PWR

YUV

420

USB

LINK

SYNC

HDCP

EDID

1.4

2.2

INT

EXT

USER

1PWR LED: This LED will illuminate when the device is connected with

power supply from the AC outlet.

2SYNC LEDs: These LEDs will illuminate according to both HDMI input

and output signal’s current bandwidth.

3HDCP LEDs: These LEDs will illuminate according to both HDMI input

and output’s HDCP encrypted signal.

4EDID LEDs: These LEDs will illuminate according to the selected EDID

setting.

5YUV420 LED: This LED will illuminate according to YUV420’s selection.

6USB LINK LED: This LED will illuminate when the connected USB

device is valid for PC control.

6.3 Side Panel

YUV420 EDID

ACTIVE SRC

1 2 3

1YUV420: Press this button to allows HDMI input 6G signal to be

subsampling to YUV420 from YUV444.

2EDID: Press this button to select EDID of INTernal/EXTernal or USER

where internal EDID is 1080p at 2CH, external EDID is depending on

the connected HDMI output display and USER is for upload EDID.

3ACTIVE SRC: Press this button to force the connected HDMI output

display to output image always.

Note: Output display must support CEC in order to perform this

function.
