CYP CH-1601TXRX Manuel utilisateur
DRAFT
CH-1601TXRX
HDMI/Audio over CAT5e/6/7 Extender with 48V PoE
Operation Manual
Operation Manual
DRAFT
DISCLAIMERS
The information in this manual has been carefully checked and
is believed to be accurate. Cypress Technology assumes no
responsibility for any infringements of patents or other rights of third
parties which may result from its use.
Cypress Technology assumes no responsibility for any inaccuracies
that may be contained in this document. Cypress also makes no
commitment to update or to keep current the information contained
in this document.
Cypress Technology reserves the right to make improvements to this
document and/or product at any time and without notice.
COPYRIGHT NOTICE
No part of this document may be reproduced, transmitted,
transcribed, stored in a retrieval system, or any of its part translated
into any language or computer le, in any form or by any means
- electronic, mechanical, magnetic, optical, chemical, manual,
or otherwise - without express written permission and consent from
Cypress Technology.
© Copyright 2014 by Cypress Technology.
All Rights Reserved.
Version 1.0 November 2014
TRADEMARK ACKNOWLEDGMENTS
All products or service names mentioned in this document may be
trademarks of the companies with which they are associated.
DRAFT
SAFETY PRECAUTIONS
Please read all instructions before attempting to unpack or install or
operate this equipment, and before connecting the power supply.
Please keep the following in mind as you unpack and install this
equipment:
• Always follow basic safety precautions to reduce the risk of re,
electrical shock and injury to persons.
• To prevent re or shock hazard, do not expose the unit to rain,
moisture or install this product near water.
• Never spill liquid of any kind on or into this product.
• Never push an object of any kind into this product through
module openings or empty slots, as you may damage parts.
• Do not attach the power supply cabling to building surfaces.
• Do not allow anything to rest on the power cabling or allow it to
be abused by persons walking on it.
• To protect the equipment from overheating, do not block the slots
and openings in the module housing that provide ventilation.
REVISION HISTORY
VERSION NO. DATE DD/MM/YY SUMMARY OF CHANGE
RDV1 20/10/14 Preliminary Release
DRAFT
CONTENTS
1. Introduction............................................ 1
2. Applications........................................... 1
3. Package Contents ................................ 1
4. System Requirements............................ 1
5. Features.................................................. 2
6. Operation Controls and Functions....... 3
6.1 Transmitter’s Front Panel..................3
6.2 Transmitter’s Rear Panel ..................4
6.3 Receiver’s Front Panel.....................5
6.4 Receiver’s Rear Panel .....................6
6.5 IR Cable Pin Assignment..................7
6.6 D-Sub 9-Pin Assignment...................7
7. Connection Diagram ............................ 8
8. Specications ........................................ 9
9. Acronyms ............................................. 10
DRAFT
1
1. INTRODUCTION
This HDMI and Audio over Single CAT5e/6/7 Transmitter and Receiver
set can send uncompressed audio/video along with controls, IP and
USB data over a single run of CAT5e/6/7 cable up to 100m. It has the
added benet of control through the built-in RS-232 and IR ports and
a bidirectional LAN serving connection. There is a bidirectional digital
audio capability that gives users the convenience of an additional
audio connection. This system also allows the connection of any
USB host, enabling a USB connection to up to 2 USB ports, giving the
Receiver the ability to act like a USB hub. The 48V PoE design can
power the Receiver (PD) from the Transmitter (PSE), eliminating the
need for a separate power supply for the Receiver.
2. APPLICATIONS
• 48V PoE from Transmitter (PSE) to Receiver (PD)
• Household entertainment extending and control
• Lecture room display and control
• Showroom display and control
• Meeting room presentation and control
• Classroom display and control
3. PACKAGE CONTENTS
• 1 x HDMI/Audio over CAT5e/6/7 Transmitter
• 1 x CAT5e/6/7 to HDMI/Audio Receiver
• 1 x IR Blaster
• 1 x IR Extender
• 1 x 48 DC Power adaptor
• Operational Manual
4. SYSTEM REQUIREMENTS
Input source equipment such as DVD/Blu-ray player, host PC/Laptop
and HDMI equipped output display (TV or monitor) with amplier or
active speakers.
DRAFT
2
5. FEATURES
• Supports HDBaseT 2.0 specication supporting over a single CAT6/7
cable up to 100m/328ft and CAT5e cable up to 90m/295ft
• Fully compliant with HDMI 1.4, and compatible with HDMI 2.0 (4K2K
60Hz with 4:2:0)
• Receiver features 2 USB 2.0 ports
• HDMI (with 3D & 4Kx2K support), HDCP and DVI compliant
• HDBaseT 5Play™ convergence: High-Denition (HD) Video and
Audio, 100BaseT Ethernet, PoE and Control (Bidirectional IR/RS-232
pass-through)
• Supports pass-through of audio formats: LPCM2/5.1/7.1CH, Dolby
Digital 2~5.1Ch, Dolby Digital Plus, Dolby TrueHD and DTS-HD Master
Audio
• Supports 10/100 Ethernet network connection
• Bidirectional LAN and external digital audio capability
• Supports RS-232 baud rate from 110~115200bps
DRAFT
3
6. OPERATION CONTROLS AND FUNCTIONS
6.1 Transmitter’s Front Panel
RS 232 IN IR IN 2 IR OUT 1LAN CAT5e/6/7 OUT DC 48V
POWER
654321
1RS-232 IN
Connect to a PC or Laptop with D-Sub 9- pin female cable for the
transmission of RS-232 commands.
2IR IN 2
Connect to the supplied IR Extender cable for IR signal reception.
Ensure that remote being used is within the direct line-of-sight of
the IR Extender.
3IR OUT 1
Connect to the supplied IR Blaster Cable for IR signal transmission.
Place the IR Blaster in direct line-of-sight of the equipment to be
controlled.
4LAN
Connect to an internet or network connection.
5CAT5e/6/7 OUT
Connect to the Receiver unit with a single CAT5e/6/7 cable for
transmission of all data signals. The yellow LED will illuminate to
represent the link from Receiver is steady, when it blink irregularly it
represent the link error or when not illuminate it means no link with
Receiver. The green LED will illuminate to represent the HDMI signal
contents HDCP signal.
6DC 48V & POWER LED
Plug the 48V DC power supply into the unit and connect the
adaptor to an AC outlet and the LED will illuminate.
DRAFT
4
6.2 Transmitter’s Rear Panel
HDMI IN COAX AUDIO IN
OUT 1IN
2R
L
USB
54321
1HDMI IN
Connect to HDMI source equipment such as a DVD or Blu-ray
player.
2USB
Connect from PC or Laptop for data transmit to or control from the
Receiver’s USB slots.
3COAX OUT 1
Connect to speaker with coaxial input for audio signal output from
Receiver’s COAX IN 1.
4COAX IN 2
Connect to audio source equipment such as DVD or Blu-ray player
for audio signal sending to Receiver’s COAX OUT2.
5AUDIO IN L/R
Connect with audio source equipment such as PC or CD player for
audio signal sending to Receiver’s AUDIO OUT L/R.
DRAFT
5
6.3 Receiver’s Front Panel
RS 232 OUT IR IN 1 IR OUT 2LAN CAT5e/6/7 IN
POWER
654321
1RS-232 OUT
Connect to the device that is to be controlled (via D-Sub 9-pin
male cable) by RS-232 commands.
2IR IN1
Connect to the supplied IR Extender cable for IR signal reception.
Ensure that remote being used is within the direct line-of-sight of
the IR Extender.
3IR OUT 2
Connect to the supplied IR Blaster cable for IR signal transmission.
Place the IR Blaster in direct line-of-sight of the equipment to be
controlled.
4LAN
Connect to a PC or Laptop to the internet or network connection.
5CAT5e/6/7 IN
Connect to the Transmitter unit with a single CAT5e/6/7 cable for
transmission of all data signals. The yellow LED will illuminate to
represent the link from Receiver is steady, when it blink irregularly it
represent the link error or when not illuminate it means no link with
Receiver. The green LED will illuminate to represent the HDMI signal
contents HDCP signal.
6POWER LED
This LED will illuminate when the device is connected with power
supply.
DRAFT
6
6.4 Receiver’s Rear Panel
HDMI OUT COAX AUDIO OUT
OUT 2IN
1R
L
POWER
LINK 1
LINK 2
USB
876542 31
1HDMI OUT
Connect to a HDMI equipped TV/monitor for display of the HDMI
input source signal.
2USB
Connect to USB peripheral devices such as printer, keyboard, ash
driver or …etc. for data receiving or sending back to Transmitter.
3POWER LED
This LED will illuminate when device is connected with USB power
supply.
4LINK 2
This LED will illuminated when the lower USB slot is connected with
signal activated.
5LINK 1
This LED will illuminated when the upper USB slot is connected with
signal activated.
6COAX OUT 2
Connect to speaker with coaxial input for audio signal output from
Transmitter’s COAX IN 2.
7COAX IN 1
Connect to audio source equipment such as DVD or Blu-ray player
for audio signal sending to Transmitter’s COAX OUT1
8AUDIO L/R OUT
Connect to speaker with RCA input for audio signal output.
