CYP CH-1107EX Manuel utilisateur
CH-1107EX
HDMI/CAT6 to Single CAT6 Extender
Operation Manual
Operation Manual
DISCLAIMERS
The information in this manual has been carefully checked and
is believed to be accurate. Cypress Technology assumes no
responsibility for any infringements of patents or other rights of third
parties which may result from its use.
Cypress Technology assumes no responsibility for any inaccuracies
that may be contained in this document. Cypress also makes no
commitment to update or to keep current the information contained
in this document.
Cypress Technology reserves the right to make improvements to this
document and/or product at any time and without notice.
COPYRIGHT NOTICE
No part of this document may be reproduced, transmitted,
transcribed, stored in a retrieval system, or any of its part translated
into any language or computer le, in any form or by any means—
electronic, mechanical, magnetic, optical, chemical, manual, or
otherwise—without express written permission and consent from
Cypress Technology.
© Copyright 2011 by Cypress Technology.
All Rights Reserved.
Version 1.1 August 2011
TRADEMARK ACKNOWLEDGMENTS
All products or service names mentioned in this document may be
trademarks of the companies with which they are associated.
SAFETY PRECAUTIONS
Please read all instructions before attempting to unpack, install or
operate this equipment and before connecting the power supply.
Please keep the following in mind as you unpack and install this
equipment:
• Always follow basic safety precautions to reduce the risk of re,
electrical shock and injury to persons.
• To prevent re or shock hazard, do not expose the unit to rain,
moisture or install this product near water.
• Never spill liquid of any kind on or into this product.
• Never push an object of any kind into this product through any
openings or empty slots in the unit, as you may damage parts
inside the unit.
• Do not attach the power supply cabling to building surfaces.
• Use only the supplied power supply unit (PSU). Do not use the PSU
if it is damaged.
• Do not allow anything to rest on the power cabling or allow any
weight to be placed upon it or any person walk on it.
• To protect the unit from overheating, do not block any vents or
openings in the unit housing that provide ventilation and allow for
sufcient space for air to circulate around the unit.
REVISION HISTORY
VERSION NO. DATE DD/MM/YY SUMMARY OF CHANGE
VS1 25/10/11 First Release
VR2 16/04/12 CAT6 Type Error
VS2 24/02/14 Updated Diagrams/Text
CONTENTS
1. Introduction..............................................1
2. Applications.............................................1
3. Package Contents .................................. 1
4. System Requirements.............................. 1
5. Features....................................................2
6. Operation Controls and Functions......... 3
6.1 Front Panel ..........................................3
6.2 Rear Panel...........................................3
7. Connection Diagram .............................. 4
8. Specications .......................................... 5
8.1 Technical Specications ...................5
8.2 Compatible Products ........................6
9. Acronyms .................................................6
1
1. INTRODUCTION
The HDMI/CAT6 to Single CAT6 Extender is an advanced solution
for HDMI and CAT6 signal distribution. It can be used to extend
the distance between a compatible transmitter and receiver or
used directly with an HDMI source. The CAT6 output can be easily
connected to a compatible Single CAT6 to HDMI Receiver to allow
a stable connection between an HDMI source and any compatible
HDMI display. Alternatively, it can be cascaded to extend the signal
to several hundred meters.
2. APPLICATIONS
• Smart AV installation for HDMI signal extension
• Switch between a local HDMI or remote CAT6 source
• Household entertainment media sharing
3. PACKAGE CONTENTS
• HDMI/CAT6 to Single CAT6 Extender
• 5
V/1
A DC Power Supply Adaptor
• Operation Manual
4. SYSTEM REQUIREMENTS
HDMI source device such as a DVD/Blu-ray player or a compatible
HDMI to CAT6 transmitter and an HDMI display with HDMI connection
cables and industry standard CAT6 cable and a compatible CAT6 to
HDMI receiver.
2
5. FEATURES
• HDCP 1.1 and DVI 1.0 compliant
• HDMI with Deep Color video up to 12-bit, 1080p@24/60 Hz
• Supports LPCM 7.1CH, Dolby TrueHD, Dolby Digital Plus and DTS-HD
Master Audio transmission (32 to 192 kHz Fs sampling rate)
• Supports a wide range of PC and HDTV resolutions from VGA to
WUXGA and 480i to 1080p
• Supports HDMI cable distances of up to 15 meters at 1080p/8-bit
and 12-bit resolutions
• Supports CAT6 cable distances of up to 45 meters at 1080p/8-bit
resolution and 10 meters at 1080p/12-bit resolution
• Fully HDCP compliant
• EDID 8/12-bit setting switch
Note:
1. This system was tested with CAT6/23AWG/Solid cable, results may
vary with cables of another specifcation.
2. Cable distance tested with Sony Playstation 3 (120
GB model), 37″
Philips 8-bit LCD TV and 40″ Samsung 12-bit LCD TV.
3. The gures provided in this manual are for reference only; actual
performance may depend on the source and display used as well
as the cable specication.
3
6. OPERATION CONTROLS AND FUNCTIONS
6.1 Front Panel
EDID
INPUT
8 Bit 12 Bit
HDMI CAT6
CAT6 OUT
1 2 3
1HDMI/CAT6 INPUT Switch: Allows users to select either HDMI or CAT6
as the input source.
28/12-bit EDID Switch: Allows users to change the output display’s
EDID between 8-bit or 12-bit resolution.
3CAT6 OUT: Connect to the CAT6 input of a compatible Single CAT6
to HDMI Receiver unit (see Section 8.2) attached to an display.
6.2 Rear Panel
DC 5V
HDMI
INPUT
CAT6
1 2 3
1CAT6 IN: Connect to the CAT6 output of a compatible HDMI
to Single CAT6 Transmitter unit (see Section 8.2) attached to an
source device.
2HDMI IN: Connect to the HDMI or DVI output (with a DVI to HDMI
adaptor) of a source device such as a DVD/Blu-ray player or a Set-
top Box with an HDMI cable.
3DC 5V: Connect the 5V DC power supply to the unit and plug the
adaptor into an AC outlet.
4
7. CONNECTION DIAGRAM
DC 5V
HDMI OUTPUT
CAT6 IN
EDID
INPUT
8 Bit 12 Bit
HDMI CAT6
CAT6 OUT
DC 5V
HDMI
INPUT
CAT6
DC 5V
HDMI OUTPUT
CAT6 IN
EDID
INPUT
8 Bit 12 Bit
HDMI CAT6
CAT6 OUT
DC 5V
HDMI
INPUT
CAT6
DC 5V
HDMI OUTPUT
CAT6 IN
EDID
INPUT
8 Bit 12 Bit
HDMI CAT6
CAT6 OUT
DC 5V
HDMI
INPUT
CAT6
DC 5V
HDMI INPUT
CAT6 OUT
DC 5V
POWER
HDMI IN
SYNC-RED
3D-ORG CAT6 OUT
1
CAT6 OUT
8
CAT6 OUT
7
Option 1 Option 2
TX
RX
EX EX EX
RX RX
Option 3
DVD or Blu-ray Player DVD or Blu-ray Player DVD or Blu-ray Player
CAT6 Cable
(45m/8-bit)
CAT6 Cable
(45m/8-bit)
HDMI to CAT6 Splitter
CAT6 Cable
(45m/8-bit)
CAT6 Cable
(45m/8-bit)
CAT6 Cable
(45m/8-bit)
Display or TV Display or TVDisplay or TV
HDMI
Input
HDMI
Input
HDMI
Input
HDMI
Output
HDMI
Output
HDMI
Output
5
8. SPECIFICATIONS
8.1 Technical Specications
Video Bandwidth 2.25
MHz/6.75 Gbps
Input Ports 1×HDMI (Female connector), 1×RJ45
Output Port 1×RJ45
EDID Setting TV
HDMI Resolutions 480i~1080p@50/60, 1080p@24 &
VGA~WUXGA (RB)
HDMI Cable Distance 15m@1080p/8-bit or 12-bit
CAT6 Cable Distance 45m@1080p/8-bit or 10m@1080p/12-bit
ESD Protection Human body model:
±8 kV (air-gap discharge)
±4 kV (contact discharge)
Power Supply 5
V DC/1
A linear power adaptor
(US/EU standards,CE/FCC/UL certied)
or 5
V/1.2
A switching power adaptor (with
universal plug, CE/FCC/UL certied)
Dimensions 78.5
mm (W)×102
mm (D)×30
mm (H)
Weight 182
g
Chassis Material Aluminum
Silkscreen Color Silver
Power Consumption 4.1
W
Operating Temperature 0
˚C~40
˚C/32
˚F~104
˚F
Storage Temperature −20
˚C~60
˚C/−4
˚F~140
˚F
Relative Humidity 20~90
% RH (non-condensing)
