HDMI/CAT6 to Single CAT6 Extender

Operation Manual

DISCLAIMERS

The information in this manual has been carefully checked and

is believed to be accurate. Cypress Technology assumes no

responsibility for any infringements of patents or other rights of third

parties which may result from its use.

Cypress Technology assumes no responsibility for any inaccuracies

that may be contained in this document. Cypress also makes no

commitment to update or to keep current the information contained

in this document.

Cypress Technology reserves the right to make improvements to this

document and/or product at any time and without notice.

No part of this document may be reproduced, transmitted,

transcribed, stored in a retrieval system, or any of its part translated

into any language or computer le, in any form or by any means—

electronic, mechanical, magnetic, optical, chemical, manual, or

otherwise—without express written permission and consent from

Cypress Technology.

Version 1.1 August 2011

TRADEMARK ACKNOWLEDGMENTS

All products or service names mentioned in this document may be

trademarks of the companies with which they are associated.

SAFETY PRECAUTIONS

Please read all instructions before attempting to unpack, install or

operate this equipment and before connecting the power supply.

Please keep the following in mind as you unpack and install this

equipment:

• Always follow basic safety precautions to reduce the risk of re,

electrical shock and injury to persons.

• To prevent re or shock hazard, do not expose the unit to rain,

moisture or install this product near water.

• Never spill liquid of any kind on or into this product.

• Never push an object of any kind into this product through any

openings or empty slots in the unit, as you may damage parts

inside the unit.

• Do not attach the power supply cabling to building surfaces.

• Use only the supplied power supply unit (PSU). Do not use the PSU

if it is damaged.

• Do not allow anything to rest on the power cabling or allow any

weight to be placed upon it or any person walk on it.

• To protect the unit from overheating, do not block any vents or

openings in the unit housing that provide ventilation and allow for

sufcient space for air to circulate around the unit.

REVISION HISTORY

VERSION NO. DATE DD/MM/YY SUMMARY OF CHANGE

VS1 25/10/11 First Release

VR2 16/04/12 CAT6 Type Error

CONTENTS

1. Introduction..............................................1

2. Applications.............................................1

3. Package Contents .................................. 1

4. System Requirements.............................. 1

5. Features.................................................... 1

6. Operation Controls and Functions......... 2

6.1 Front Panel ..........................................2

6.2 Rear Panel...........................................3

7. Connection Diagram .............................. 4

8. Specications .......................................... 5

9. Acronyms .................................................5

1. INTRODUCTION

The HDMI™/CAT6 to Single CAT6 Extender is an advanced solution for

HDMI and CAT6 signal distribution. The CAT6 output port can be easily

connected to CAT6 to HDMI receivers to allow a stable connection

between an HDMI source and any compatible HDMI display.

Alternatively, it can be cascaded to extend the signal to several

hundred meters.

2. APPLICATIONS

• Smart AV Installation for HDMI signal extension

• Household entertainment media sharing

3. PACKAGE CONTENTS

• HDMI/CAT6 to single CAT6 extender

• Operation Manual

• 5 V/1 A DC Power Supply Adaptor

4. SYSTEM REQUIREMENTS

Input HDMI/DVI source equipment or HDMI to single CAT6 transmitter

and output to single CAT6 to HDMI receiver.

5. FEATURES

• HDCP 1.1 and DVI 1.0 compliant.

• HDMI v1.3 with Deep Color video up to 12-bit, 1080p@24/60 Hz.

• Supports LPCM 7.1CH, Dolby TrueHD, Dolby Digital Plus and DTS-HD

Master Audio transmission (32–192 kHz Fs sample rate).

• Supports a wide range of PC and HDTV resolutions from VGA to

WUXGA and 480i to 1080p.

• Fully HDCP Compliant.

• EDID 8/12-bit setting switch.

6. OPERATION CONTROLS AND FUNCTIONS

6.1 Front Panel

EDID

INPUT

8 Bit 12 Bit

HDMI CAT6

CAT6 OUT

1 2 3

1HDMI/CAT6 Input Switch

This switch allows users to select either HDMI or CAT6 as the input

source.

2EDID 8/12-bit switch

This switch allows users to change the output display’s EDID

between 8- or 12-bit resolution.

3CAT6 Out

This port is to connect to a single CAT6 to HDMI receiver device

attached to an output display.

6.2 Rear Panel

DC 5V

HDMI

INPUT

CAT6

1 2 3

CAT6 Input

This port connects a single CAT6 transmitter device attached to a

source device by HDMI.

HDMI Input

HDMI connector to connect a suitably equipped source device

such as DVD/Blu-ray player.

DC 5V

This socket is where you plug the 5 V DC PSU into the unit,

connect the PSU to an AC outlet.

NOTE

A.Unit tested with CAT6/23AWG/Solid cable, using cables of another

specication may result in a different operating distance.

B.Source equipment used in cable distance testing included: Sony

Playstation 3 (120 GB model), 37″ Philips 8-bit LCD TV and 40″

Samsung 12-bit LCD TV.

C.Figures provided in this manual are for reference only, actual

performance may vary according to which source and display are

used as well as the type of cable used.

7. CONNECTION DIAGRAM

DVD or Blu-ray Player HDMI to Single CAT6

Transmitter

CAT6 Cable

(45 M/8-bit)

CAT6 Cable

(45 M/8-bit)

Single CAT6

to HDMI

Transmitter

Single CAT6 to

HDMI Receiver

Display Monitor or TV

HDMI Cable

(15 M/8-bit)

Option 1 Option 2 Option 3

EDID

INPUT

8 Bit 12 Bit

HDMI CAT6

CAT6 OUT

EDID

INPUT

8 Bit 12 Bit

HDMI CAT6

CAT6 OUT

DC 5V

HDMI

INPUT

CAT6

TV/STD

10 Bit

CAT6 OUT

EDID

8 Bit 12 Bit

CAT6 OUT

DC 5V

POWER

HDMI IN

SYNC-RED

3D-ORG

PU-Q1H8CS

CAT6 OUT

DC 5V

HDMI

INPUT

CAT6

DC 5V

HDMI

INPUT

CAT6

DC 5V

HDMI

INPUT

CAT6

DC 5V

POWER

HDMI IN

SYNC-RED

3D-ORG

PU-Q1H8CS

CAT6 OUT

DC 5V

HDMI INPUT

CAT6 OUT

8. SPECIFICATIONS

Video Bandwidth 2.25 MHz/6.75Gbps

Input Ports 1 × HDMI female port , 1 × CAT6 input

Output Ports 1 × CAT6 output

EDID TV

HDMI Cable In 1080p 8-bit (15 m), 12-bit (15 m)

CAT6 Cable In/Out 1080p 8-bit (7~45 m), 12-bit (7~15 m)

HDMI Resolution 480i~1080p50/60, 1080p24, VGA~WUXGA

ESD Protection Human body model: ±8 kV (air-gap discharge)

±4 kV (contact discharge)

Power Supply 5 V DC/1 A linear power adaptor

(US/EU standards,CE/FCC/UL certied)

or 5 V/1.2 A switching power adaptor

(with universal plug, CE/FCC/UL certied)

Dimensions 78.5 mm (W) × 102 mm (D) × 30 mm (H)

Weight 182 g

Chassis Material Metal

Silkscreen Colour Silver

Power Consumption 4.1 W

Operating Temperature 0 ˚C~40˚C/32 ˚F~104 ˚F

Storage Temperature −20˚C~60 ˚C/−4 ˚F~140˚F

Relative Humidity 20~90% RH (non-condensing)

9. ACRONYMS

ACRONYM COMPLETE TERM

CAT6 Category 6 Cable

HDMI High Denition Multimedia Interface
