Creality HALOT-ONE Manuel utilisateur
3D Printer User Manual
V1.0
HALOT-ONE
Create Realities, Realize Dreams
HALOT-ONE
Thank you for choosing Creality. For your convenience, please read through this User Manual before you started and follow the instructions provided carefully.
Creality is always ready to provide you with high-quality services. If you encounter any issues or have any questions when using our products, please use the contact
information at the end of this manual. To further improve your user experience, you can find more about our devices via the following methods:
User manual: You can find instructions and videos in the USB drive provided with the printer.
You can also visit our official website (https://www.creality.com) to find information regarding software, hardware, contact information, device instructions, device
warranty information, and more.
Please visit our official website https://www.creality.com. Click on Homepage → Support→ Download. Download the required firmware and install it to use it with
your printer.
Firmware Upgrade:
Dear Users：
Instructions for Use
Do not use this printer by methods or operations that are not described in this manual, otherwise it may result in accidental injury or property damage.
Do not place this printer near flammable materials, explosive materials or high heat sources. Please place this printer in a ventilated, cool and low-dust environment.
Do not place this printer in a vibrating or any other unstable environment, as the printing quality will be compromised when the printer shakes.
Please use the filament recommended by the manufacturer, otherwise the printer may be damaged.
Please use the power cord provided with the printer and do not use the power cord of other products. The power plug must be plugged into a three-hole socket with a ground wire.
Do not open the printer cover while the printer is in operation, otherwise the printing process may be interrupted.
Do not wear cotton gloves while operating the printer, otherwise the moving parts may cause accidental injury including cuts and lacerations.
1
2
3
4
5
6
7
8
9
10
12
11
Please regularly clean the printer body with a dry cloth while the power is off, and wipe off dust, sticky printing materials, and foreign objects on the guide rails.
Children under the age of 10 must not use this printer without adult supervision in order to avoid accidental injury.
Warning: Do not plug or unplug the power cable while the printer is turned on.
Users should abide by the laws and regulations of the corresponding country and region where the equipment is located (place of use), abide by professional ethics, and pay
attention to safety obligations. The use of our products or equipment for any illegal purpose is strictly prohibited. Our company is not responsible for the relevant legal
responsibilities of any violators.
After the printing is complete, please wear gloves and wait for a while before removing the printing platform. Use tools to remove the model from the platform, and do not touch
the platform with your bare hands when cleaning it.
About the Printer
Device Specifications
List of Parts
Table of Contents
Installing the 3D Printer
Using the 3D Printer
Troubleshooting
First Printing
Circuit Wiring
Remote Controlled Printing
01-01
02-02
03-03
04-05
11-13
06-10
16-16
15-15
14-14
1. About the Printer
01
Torx Head Screw
Leveling Screw
Platform
Tray Fixing Screw
Tray
Air Filter Power Socket
Power Switch
Type-B USB Port
USB Port
Touch Screen
Limit Sensor
9
10
7
8
11
12
2.Equipment parameters
02
Model Name HALOT-ONE
USB Disk, Creality Cloud
1620*2560
0.05mm
1-4S/layer
100W
221*221*404mm
295*295*545mm
8.8KG
5 inch touch screen
Common rigid photosensivie resin, Standard resin, Hight hardness,High toughness, Dental model resin.
Integral light source (wavelength 405nm)
Win7/Win8/Win10 64bit, Mac system(32-bit is not supported)
127*80*160mm(length,width and height)
Slicing Software Operation System
Rated Power
Build Size
Touch Screen
Machine Size
Package size
Gross Weight
Machine Language
Print Method
Print speed
Compatible Resin
Rated Voltage
Light Source Type
XY Axis Resolution
XY Axis Accuracy
Basic Parameters
100-240V~, 50/60Hz
7.1KGNet Weight
中文(简/繁)/ English/ Español/ Deutsche/ Français/ Pусский/ Português/ Italiano/ Türk/Nederlands/Polskie/日本語/한국어
Layer Thickness 0.01-0.2mm
03
3. List of Parts
List of Tool Kit Items
USB Drive x 1
Printing Platform x 1 Tray x 1 Printer x 1
Paper Funnel x 4
Release Filmx 1
Paint Brush x 12#, 2.5#, 3# Screwdriver x 1
Metal Blade x 1
Note: The components above are for reference only. The actual product may vary.
Power Cord x 1
04
Remove the protective cotton above the printing screen
as shown in the picture：
4. Assemble the 3D Printer
1. Take out the machine 3.Remove the foam above the screen
2.Remove the resin vat
5. Installing the 3D Printer
05
Printer x 1
Upper Cover x 1
Note: Embed the upper cover in the mainframe to complete the installation.
06
6. Interface Information
Note: The current interface is for reference only, due to the continuous upgrading of functions, the actual to the official
website of the latest firmware Ul as the standard.
Setting
