MakerBot Replicator Manuel utilisateur

USER MANUAL

1 WELCOME 04

Safety and Compliance 05

About the MakerBot Replicator 07

2GETTING STARTED 10

Accessory Checklist 11

Unpacking the MakerBot Replicator 12

Setting up the MakerBot Replicator 14

3STARTUP 18

The MakerBot Replicator Control Panel 19

First Steps 20

4MAKERBOT DESKTOP 24

Downloading and Installing MakerBot Desktop 25

Printing from MakerBot Desktop 26

5THE CONTROL PANEL 34

Home Screen 35

Print 36

Filament 40

Preheat 41

Utilities 41

Settings 43

Info 44

VERSION 1

TABLE OF CONTENTS

Welcome.

Let’s get started.

VERSION 1

6TROUBLESHOOTING 45

Printing Problems 46

Connectivity Problems 48

Update Firmware 50

7REFERENCE 51

Speciﬁcations 52

Glossary 53

How to use MakerBot Support 56

Contact 57

8TERMS 58

TABLE OF CONTENTS

WELCOME.

Let’s Get started.

Welcome to the User Manual for the MakerBot®

Replicator®Desktop 3D Printer (Fih Generation

Model). The ﬁh generation MakerBot Replicator

is super easy to use, but it’s also packed with

brand-new features, so even if you’ve used a

MakerBot Desktop 3D Printer before, be sure to

read this manual all the way through.

Welcome, let’s get started5

SAFETY AND COMPLIANCE

RADIO AND TELEVISION INTERFERENCE

This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant

to Part 15 of the Federal Communications Commission (FCC) rules. These limits are designed to

provide reasonable protection against harmful interference in a residential installation. This equipment

generates, uses and can radiate radio frequency energy and, if not installed and used in accordance

with the instructions, may cause harmful interference to radio communications. However, there is no

guarantee that interference will not occur in a particular installation. If this equipment does cause harmful

interference to radio or television reception, which can be determined by turning the equipment o and on,

the user is encouraged to try to correct the interference by one or more of the following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and the receiver.

• Connect the equipment to an outlet on a circuit dierent from that to which the receiver is connected.

• Consult the dealer or an experienced radio/TV technician for help.

You may also ﬁnd helpful the following booklet, prepared by the FCC: “How to Identify and Resolve

Radio-TV Interference Problems.” This booklet is available from the U.S. Government Printing Oce,

Washington, D.C. 20402.

Changes and modiﬁcations not expressly approved by the manufacturer or registrant of this equipment

can void your authority to operate this equipment under FCC rules.

MANUFACTURER

MakerBot Industries, LLC

One MetroTech Center, 21st Floor

Brooklyn, NY 11201

347.334.6800

Now, before we get going, let’s review some important safety information.

Welcome, let’s get started6

SAFETY AND COMPLIANCE

Safety alert symbols precede each safety message in this manual. These symbols indicate

potential safety hazards that could harm you or others or cause product or property damage.

Warning: The MakerBot Replicator generates high temperatures. Always allow the

MakerBot Replicator to cool down before you reach inside.

Warning: The MakerBot Replicator includes moving parts that can cause injury.

Never reach inside the MakerBot Replicator while it is in operation.

Warning: There is a risk of shock. This product is not user serviceable.

Warning: Do not leave the MakerBot Replicator unattended during operation.

Caution: Do not print using materials that have not been approved by MakerBot for

use with the MakerBot Replicator. Refer to the Speciﬁcations section on page 52 for

more information.

Caution: The socket outlet must be located near the equipment and must be

easily accessible.

Caution: In case of emergency disconnect the MakerBot Replicator from the

wall socket.

Caution: The MakerBot Replicator melts plastic during printing. Plastic odors are

emitted during this operation. Make sure to set up the MakerBot Replicator in a well-

ventilated area.

Welcome, let’s get started7

ABOUT THE MAKERBOT REPLICATOR

The MakerBot Replicator makes solid, three-dimensional objects out of melted MakerBot

PLA Filament. First, use MakerBot Desktop to translate 3D design ﬁles into instructions for the

MakerBot Replicator. Then transfer those instructions to the MakerBot Replicator via USB drive,

USB cable, or your local network. The MakerBot Replicator will melt MakerBot PLA Filament

and squeeze it out onto the build plate in thin lines to build your object layer by layer. This

method of 3D printing is called fused deposition modeling.

HOW IT WORKS

Welcome, let’s get started8

ABOUT THE MAKERBOT REPLICATOR

MAKERBOT REPLICATOR DIAGRAMS

6. Filament Drawer

7. Filament Spindle

Welcome, let’s get started9

ABOUT THE MAKERBOT REPLICATOR

1614 15

1413121110

GettinG started

When you set up your MakerBot®Replicator®

Desktop 3D Printer, remember that it was built

and packaged very carefully at the MakerBot

factory. We hope you’ll take your time and be

just as careful unpacking it and getting it set up.
