Boya BY-CM6 Manuel utilisateur
BY- CM6
USB
Microphone
USB麦克风
User Manual
用户手册
• BY-CM6 Microphone
• USB-A to USB-C Cable (1.2m)
• USB-C to USB-C Cable (1.2m)
The BOYA BY-CM6 is a USB desktop microphone, compatible with most
Android phones and Windows/Mac computers. With a cardioid pickup
pattern, the BY-CM6 is designed to capture sound in front of the
microphone and eectively reduce unwanted background noise. It is
ideal for home-studio recording, podcasting, vocal performance, and
more.
The BY-CM6 features built-in controls for gain, headphone volume and
muting, and the 3.5mm headphone jack enables real-time monitoring.
An adjustable desktop stand allows you to place the microphone at the
angle that’s right for you.
General Introduction
Cautions
Package Contents
Thanks for choosing BOYA!
• If you do not intend to use the microphone for a long period of time,
please remove the USB cable.
• Do not touch the microphone while recording, as this will cause noise to
be recorded.
• Do not let the microphone close to high-voltage equipment or to devices
that emit strong electromagnetic elds, otherwise, it may cause the noise
to be recorded.
• Do not use or leave the microphone in hot, humid places.
1
1
235
4
6
7
Product Structure
2
1. Power indicator
2. Gain control
Turn the knob to adjust gain for microphone input level.
3. Headphone volume/mute control
Turn the knob to adjust headphone volume.
Short press the knob to mute/unmute the microphone.
4. 3.5mm headphone output
5. USB-C audio output
6. Locking knob for angle adjustment
7. Desktop stand
Mode
Power on
Power o
Mute on
Indicator
Solid blue light
Light o
Solid red light
3
Installation Guide
4
1. Loosen the locking knob, adjust the microphone to the desired angle,
then tighten the knob.
How to Use
5
Note:
50% levels are recommended. Please turn up/down according to your
needs.
3. Connect the microphone to a computer with the supplied cable.
4. Connect your headphones to the 3.5mm headphone jack for real-time
monitoring.
2. Turn the gain control and the volume control knobs halfway to max
before recording.
6
1. Connect the microphone to your
computer using the supplied cable.
2. Go to “Setting”, choose “Sound”.
3. Select “Speaker BY-CM6” as the
output device.
4. Select “Microphone BY-CM6” as
the input device.
Sound
Choose your output device
Choose your input device
Device properties
Device properties
93
Volume
Test your microphone
Input
Some apps are using custom output settings. You can personalize
these in app volume and device preferences below.
Some apps are using custom input settings. You can personalize
these in app volume and device preferences below.
Speaker (BY-CM6)
Microphone (BY-CM6)
Troubleshoot
Troubleshoot
Setup for Windows 10
7
1. Connect the microphone to your computer using the supplied cable.
2. Go to “Control Panel”-->“Hardware and Sound”--> “Sound”.
3. Select “Speaker BY-CM6” as the default device in “Sound”, under the
“Playback” menu.
4. Select “Microphone BY-CM6” as the default device in “Sound”, under
the “Recording” menu.
Sound
Playback
Speaker
BY-CM6
Default Device
Recording Sounds Communications
Select a playback device below to modify its settings:
Congure Properties
OK Cancel Apply
Set Default
Sound
Playback
Microphone
BY-CM6
Default Device
Recording Sounds Communications
Select a playback device below to modify its settings:
Congure Properties
OK Cancel Apply
Set Default
Setup for Windows 7
8
- High-quality USB desktop microphone
- Ideal for home-studio recording, podcasting, vocal performance, etc
- Compatible with most Android phones, Windows/Mac computers
- Cardioid polar pattern
- Gain control, headphone volume control and mute function
- 3.5mm headphone jack for real-time monitoring
- Durable detachable microphone desktop stand
- Plug and play, easy to operate
1. Connect the microphone to your computer using the supplied cable.
2. Go to Apple Icon-->System Preferences-->Sound Icon.
3. Select “BY-CM6” under the “Input” tab.
4. Select “BY-CM6” under the “Output” tab.
Sound
Name
External Microphone Microphone port
Type
BY-CM6 USB
Select a device for sound input:
Settings for the selected device:
Input volume:
Output volume: Mute
Input level:
Sound Eects Output Input
Shuw volume in menu bar
Sound
Name
Headphones Headphone port
Type
BY-CM6 USB
Select a device for sound output:
Settings for the selected device:
The selected device has no output controls
Output volume: Mute
Sound Eects Output Input
Shuw volume in menu bar
Features
Setup for Mac
9
