Boya BY-BM6060 Manuel utilisateur
BY-BM6060
User Manual • Uživatelský manuál •
Užívateľský manuál • Használati utasítás •
Benutzerhandbuch
Dear customer,
Thank you for purchasing our product. Please read the following instructions carefully
before first use and keep this user manual for future reference. Pay particular attention
to the safety instructions. If you have any questions or comments about the device,
please contact the customer line.
✉www.alza.co.uk/kontakt
✆+44 (0)203 514 4411
Importer Alza.cz a.s., Jankovcova 1522/53, Holešovice, 170 00 Praha 7, www.alza.cz
Introduction
Thanks for purchasing BOYA!
The BY-BM6060 focuses on super-cardioid characteristics and resistance to low-noise
circuitry noise, it’s well-suited to a variety of applications from independent films, TV
programs to documentaries.
Initiate switchable high-pass filter control to roll of the low-frequency noise at 150Hz
such as rumbles and traffic.
Its 3-pin XLR output follows 24-48V phantom power supply. When your devices are not
phantom powered, the BY-BM6060 can be powered by one AA battery.
In addition, the BY-BM6060 includes a fur windshield and foam windscreen for an
intelligible sound effect and secure protection.
Package Contents:
•BY-BM6060 Microphone
•Shock mount
•Foam windscreen
•Fur windshield
•Zipper bag
•User Manual
•Warranty card
Product Structure:
1. Microphone boom
2. Power indicator
3. High-pass filter switch
4. 3-pin XLR output
5. Shock mount
6. Foam windscreen
7. Fur windshield
Installing the battery
1. Unscrew the microphone by rotating the base clockwise and pull out the cover
properly to reveal the battery compartment.
2. Insert one AA battery into the compartment aligning as the right polarity
3. Close the compartment and rotate it anticlockwise to tighten it.
Features:
•Ideal for independent films, TV programs, documentaries and more
•Delivers clear and intelligible sound
•Alloy-aluminium construction
•Low-noise circuitry
•Switchable high pass filter control (150Hz)
•Powered by 24-48 V phantom power or 1.5 V AA battery
•Includes fur windshield, foam windscreen, carry pouch, shock mount adapter
Specifications:
Type:
Condenser
Polar Pattern
Super-Cardioid
Frequency Response:
60 Hz – 20000 Hz
Sensitivity:
-36±3dB(0dB=1V/Pa@1KHz)
Signal-to-Noise Ratio:
80 dB
Output Impedance:
200Ω
Power Requirements:
24-48 V phantom power or 1.5 V AA battery
Output:
3-pin XLR
High Pass Filter:
150 Hz
Weight:
129 g (4.6 oz)
FREQUENCY RESPONSE
Frequency:
Warranty Conditions
A new product purchased in the Alza.cz sales network is guaranteed for 2 years. If you
need repair or other services during the warranty period, contact the product seller
directly, you must provide the original proof of purchase with the date of purchase.
The following are considered to be a conflict with the warranty conditions, for
which the claimed claim may not be recognized:
•Using the product for any purpose other than that for which the product is intended
or failing to follow the instructions for maintenance, operation and service of the
product.
•Damage to the product by a natural disaster, the intervention of an unauthorized
person or mechanically through the fault of the buyer (e.g. during transport, cleaning
by inappropriate means, etc.).
•Natural wear and aging of consumables or components during use (such as
batteries, etc.).
•Exposure to adverse external influences, such as sunlight and other radiation or
electromagnetic fields, fluid intrusion, object intrusion, mains overvoltage,
electrostatic discharge voltage (including lightning), faulty supply or input voltage and
inappropriate polarity of this voltage, chemical processes such as used power
supplies, etc.
•If anyone has made modifications, modifications, alterations to the design or
adaptation to change or extend the functions of the product compared to the
purchased design or use of non-original components.
EU Declaration of Conformity
Identification data of the manufacturer's / importer's authorized representative:
Importer: Alza.cz a.s.
Registered office: Jankovcova 1522/53, Holešovice, 170 00 Prague 7
IČO: 27082440
Subject of the declaration:
Title: Microphone
Model / Type: BY-BM6060
The above product has been tested in accordance with the standard(s) used to
demonstrate compliance with the essential requirements laid down in the
Directive(s):
Directive No. (EU) 2014/30/EU
Directive No. 2011/65/EU as amended 2015/863/EU
Prague, 23.11.2020
WEEE
This product must not be disposed of as normal household waste in accordance with
the EU Directive on Waste Electrical and Electronic Equipment (WEEE - 2012/19 / EU).
Instead, it shall be returned to the place of purchase or handed over to a public
collection point for the recyclable waste. By ensuring this product is disposed of
correctly, you will help prevent potential negative consequences for the environment
and human health, which could otherwise be caused by inappropriate waste handling of
this product. Contact your local authority or the nearest collection point for further
details. Improper disposal of this type of waste may result in fines in accordance with
national regulations.
Vážený zákazníku,
Děkujeme vám za zakoupení našeho produktu. Před prvním použitím si prosím pečlivě
přečtěte následující pokyny a tento manuál si uschovejte pro budoucí použití. Věnujte
zvláštní pozornost bezpečnostním pokynům. Pokud máte jakékoliv dotazy nebo
připomínky k produktu, kontaktujte zákaznickou linku.
✉www.alza.cz/kontakt
✆+420 255 340 111
Dovozce: Alza.cz a.s., Jankovcova 1522/53, Holešovice, 170 00 Praha 7, www.alza.cz
