American Weigh Scales, Inc.
AMW
-
Card120
AMW
-
Card250
User Manual
Card Scale
Digital Pocket Scale
American Weigh Card Scale
Thank you for purchasing the American Weigh
CARD series digital scale. Please read all operating
instructions carefully before use. This electronic scale
is a precision instrument. With normal care and proper
treatment, it will provide years of reliable service.
Never load the scale with more than the maximum
capacity. Overloading will permanently damage it!
Avoid any exposure to extreme heat or cold. Your
scale works better when operated at normal room
temperature. Always allow the scale to acclimatize to
normal room temperature for at least one hour before
use.
Give your scale suf cient warm up time. Usually
30-60 seconds before calibration to give the internal
components a chance to stabilize.
Keep your scale in a clean environment. Dust, dirt,
moisture, vibration, air currents and a close distance to
other electronic equipment can all cause an adverse
effect on the reliability and accuracy of your scale.
Handle with care. Gently apply all items to be weighed
onto tray top. Although this scale is designed to be
quite durable, try to avoid rough treatment as this may
permanently damage the internal sensor.
Avoid shaking, dropping or otherwise shocking the
scale. This is a precision instrument and must be
handled with extreme care.
Only operate the scale on a stable, vibration free
surface.
I. OPERATION
Place Scale on a horizontal at surface.
1. Press [ON/OFF] key.
2. Wait until "0.0” is displayed.
3. Put the object(s) on the weighing platform.
4. Using the [MODE] key, you can switch between the
weighing units.
II. TARE WEIGHING
1. Turn on scale as described above.
2. Place the "tare item" on the platform.
3. Press [TARE] and wait until "0.0" is displayed.
4. Add the "net-weight-item".
III. CALIBRATION
Calibration is NOT required before rst use. Only
calibrate if scale is not weighing properly.
**Make sure you use the correct calibration weight for
your scale or the calibration will not be accurate**
Card-120: 100g calibration weight
Card-250: 200g calibration weight
1. Turn OFF the scale.
2. Press [ON/OFF] shortly. Then immediately press
and hold [MODE] until “CAL” is displayed. Release
the [MODE] key.
3. Press [MODE] again. Now the display reads “CAL”
and the required calibration weight will ash 3 times.
4. Place place the required weight on the center of the
platform. Wait 3-4 seconds. The LCD display reads
“PASS”, then “100.0”.
5. Remove the weight and press [ON/OFF] to turn off
the scale. Finished! Repeat if needed.
Please check the availability of weights at the store
you bought your scale from.
IV. TROUBLESHOOTING
The primary reasons for inaccuracy or malfunction
are low batteries, incorrect calibration, overload or
operating on an unstable surface. Please keep this in
mind and maintain and operate your scale properly.
This scale is a precise instrument and must be
handled with the utmost care and caution.
[Display]
Elimination of errors
Nothing, Battery-Symbol, [lo] or [88888]
Change the batteries.
[OUE2]
Recalibrate the scale as shown above.
[EEEEE]
You are overloading the scale. Remove the
excessive load immediately!
[LLLLL]
The delicate weighing load cells have
been damaged by misusing the scale
(i.e. it was shocked, dropped or
overloaded). You can try recalibrating the
scale. If the load cell has not been
damaged too much it will work
again after recalibration.
[UNST]
Use the scale in a more stable position
Model
AMW-Card-120
AMW-Card-250
Capacity
120g
4.23oz
77.16dwt
3.85ozt
250g
8.82oz
8.54ozt
160.75dwt
Resolution
0.1g / 0.01oz / 0.01ozt / 0.1dwt
Display
4 - Digit Backlit LCD
Calibration Weight
(not Included)
100g
200g
Platform Dimensions
(inches)
2.5 x 3
Scale Dimensions
(inches)
5 x 3 x 0.75
Power
2 x CR2032 Batteries (included)
Gross Weight
0.28 lb
Speci cations
