AWS CHROME-1KG Manuel utilisateur

American Weigh Scales

CHROME-1KG (1000g x 0.1g)

CHROME-201 (200g x 0.01g)

User Manual

CHROME

CHROME Manual

Thank you for purchasing the American Weigh

CHROME digital pocket scale. Please read all operating

instructions carefully before use. Scales are precision

measuring devices and should always be handled with

proper care. To ensure years of reliable service, keep these

simple tips in mind:

• Do not exceed the scales maximum capacity.

Overloading your scale can permanently damage it!

• Avoid exposure to extreme heat or cold. Scales

perform best at normal room temperature. If

temperatures have changed dramatically, calibration

adjustment may be necessary.

• Allow your scale to warm up for 30-60 seconds before

performing calibration adjustment(if available).

• Store your scale in a clean, dry location. Dust, dirt,

and moisture can accumulate on the weighing

sensors and electronics causing inaccuracy or

malfunction.

• Avoid using your scale in close proximity to strong

radio wave emitting devices such as computers, cash

registers, and cordless phones.

• Alwaysweighonaatandlevelsurface,freefrom

vibrations and drafts. The corner of a room is usually

the most stable.

• Gently apply all items to be weighed. Do not drop

items onto the weighing platform.

• Avoid dropping your scale. The warranty does not

cover damage due to rough treatment or overload.

• Checkthebatteriesrstifyouarehavinganytrouble

with your scale. This simple step can remedy most

scale issues.

• Do not disassemble your scale. This product contains

no user serviceable parts.

I. Part List

1. Scale

2. Cover/Expansion Tray

3. AAA Batteries (x2)

II. Key Description

III. Battery Installation

1. Beforeusingthescaleforthersttime,check

the battery compartment and remove any plastic

insulation strips or packaging that may be in place to

prevent battery drainage during shipping/storage.

2. If you are replacing the batteries, make sure the

positive and negative contacts are properly aligned.

TARE UNIT PCS

Tare Key

Unit Key

ON/OFF Key

Pcs. Key

CHROME Manual

IV. Operation

1. Placethescaleonaat,levelsurfaceandpressthe

key to turn the scale on.

2. Once the start-up process completes and the scale

goes to zero you are ready to weigh.

3. Place the quantity to be weighed onto the weighing

platform.

4. Wait a couple seconds for the display to stabilize

before taking a weight reading.

V. Changing the Unit of Measure

1. Press the UNIT key to change the scales displayed

unit of measure.

2. If the scale is turned off then back on, it will default

to the last unit used.

• CHROME-1KG & CHROME-201 Units: g (gram)

oz (ounce) ozt (troy ounce) ct (carat) gn (grain)

dwt (pennyweight)

VI. Using the Tare Feature

You can use this scale’s tare feature to subtract the weight

of an empty container or vessel for net weight determination.

NOTE: The weight of the container will subtract from the

available capacity.

1. Place the empty container or vessel on the weighing

platform.

2. Press the TARE key once. The display will then

reset to zero. If the container is removed, it’s weight

will be displayed as a negative number.

3. Youmaynowllthecontainerwiththequantityto

be weighed. The display will show the net weight of

the contents.

4. To return to normal weight display (gross weight),

remove any items from the weighing platform and

press the TARE key again to re-zero the scale.

VII. Using the Counting Feature

1. Press the ON/OFF key to turn the scale on.

2. Place a sample quantity of the items being weighed

on the platform. This quantity should either be 25,

50, 75, or 100 pieces.

3. Once the weight is stable, press and hold the PCS

key to enter counting mode setup.

4. The current sample size will be displayed on the

LCD (ie. “P 25”).

5. Press the UNIT key to change it between 25, 50,

75, or 100 and press PCStoconrm.Thecountwill

be displayed on the LCD. You may now add more

items. As items are added or removed the count will

update automatically.

VIII. Calibration

Calibration and adjustment are performed at the factory.

However, the weighing range can shift slightly during

shipping. Also, due to changes in local acceleration of gravity

around the world, adjustment is recommended when moving

the scale from one location to another. To check calibration:

1. Place the required calibration weight on the scale

and note the displayed value.

2. If the displayed value is not within acceptable

tolerance (see chart on the next page), adjustment

is required.

CHROME Manual

Model Acceptable

Tolerance (±)

Calibration

Weight

Recommended

Accuracy Class

CHROME-201 0.03g 200g OIML M1

CHROME-1KG 0.2g 500g OIML M1

IX. Adjustment

1. While the scale is on, press and hold the UNIT key

until the display shows CAL, then release.

2. Press the UNIT key once more. The display will

ash“CAL”followedbytherequiredcalibration

weight (see chart above).

3. Place the required calibration weight on the center

of the platform.

4. Thedisplaywillash“PASS”andreturntonormal

weighing mode. Calibration is complete.

X. Troubleshooting

• Problem: Scale will not turn on

• Solution: Check the batteries

• Problem: Displayedweightuctuatesrandomly

• Solution: Make sure your workspace is stable and

free of any air currents or vibration

• Problem: Displayed weight is inaccurate

• Solution: Perform a calibration adjustment

XI. Error Codes

1. OUTZ - Zero range has shifted. Perform calibration

adjustment. If the problem persists, the load cell may

be permanently damaged due to overloading.

2. ERR2 - Maximum capacity exceeded. Remove the

extra weight to avoid damaging the load cell.

3. L - Batteries are low. Replace the batteries.

XII. Specications

CHROME-201 CHROME-1KG

Max. Capacity 200g 1000g

Readability 0.01g 0.1g

Power 2 x AAA Lithium

Dimensions 4.5 x 2.5 x 0.6 in.

Platform Dimensions 2.1 x 2.4 in.

Warranty 10 Year Limited Warranty

XIII. Capacity/Readability Charts

CHROME-201 CHROME-1KG

200g x 0.01g 1000.0g x 0.1g

1000ct x 0.05ct 5000.0ct x 0.5ct

7.055oz x 0.001oz 35.27oz x 0.01oz

126dwt x 0.01dwt 643.0dwt x 0.1dwt

3086.4gn x 0.2gn 15432gn x 2gn

6.430ozt x 0.001ozt 32.15ozt x 0.01ozt
