AWS H-11 Manuel utilisateur

American Weigh Scales, Inc.

User Manual

H-Series

Hanging Scale

H-11 (11lb x 0.005lb)

H-22 (22lb x 0.01lb)

H-66 (66lb x 0.02lb)

H-110 (110lb x 0.05lb)

H-Series Manual

Thank you for purchasing the American Weigh H-

Series digital hanging scale. Please read all operating

instructions carefully before use. This electronic scale

is a precision instrument. With normal care and proper

treatment, it will provide years of reliable service.

Never load the scale with more than the maximum

capacity. Overloading will permanently damage it!

Avoid any exposure to extreme heat or cold. Your

scale works better when operated at normal room

temperature. Always allow the scale to acclimate to

normal room temperature for at least one hour before

use.

Keep your scale in a clean environment. Dust, dirt,

moisture, vibration, air currents and a close distance to

other electronic equipment can all cause an adverse

effect on the reliability and accuracy of your scale.

Handle with care. Gently apply all items to be weighed

onto the hook. Although this scale is designed to be

quite durable, try to avoid rough treatment as this may

permanently damage the internal sensor.

Avoid shaking, dropping or otherwise shocking the

scale. This is a precision instrument and must be

handled with extreme care.

I. OPERATION

Place Scale on a horizontal at surface.

1. Place the scale in a vertical position with no weight

on the hook.

2. Press the ON button. Wait until zero is displayed.

3. Hang the object(s) on the weighing hook.

4. Using the [SET] key, you can switch between the

weighing units. The scale will auto-off after 60 seconds

of no use.

II. TARE WEIGHING

1. Turn on scale as described above.

2. Place the "tare item" on the hook.

3. Press [TARE] and wait until zero is displayed.

4. Add the "net-weight-item".

III. ADVANCED CALIBRATION

Calibration is NOT required before rst use. Only

calibrate if scale is not weighing properly.

1. Turn off the scale.

2. Press and hold the TARE and ON/OFF keys at the

same time.

3. Release the ON/OFF key rst, then the TARE key.

4. You will see the offset number (~1000 - 1800)

5. Press TARE and CAL will ash followed by the rst

required calibration weight.

6. Hang the rst calibration weight from the hook and

press TARE.

7. The second reuired calibration weigh will be

displayed. Hang it on the hook and press TARE.

8. The third required calibration weight will be

displayed. Hang it on the hook and press TARE.

NOTE: To stop calibration, press ON/OFF at any time.

IV. TROUBLESHOOTING

The primary reasons for inaccuracy or malfunction

are low batteries, incorrect calibration, overload or

operating on an unstable surface. Please keep this in

mind and maintain and operate your scale properly.

This scale is a precise instrument and must be

handled with the utmost care and caution.

[Display] Elimination of errors

Nothing, Battery-Symbol, [lo] or [88888]

Change the batteries.

[OUt2] Recalibrate the scale as shown above.

[EEEEE] You are overloading the scale. Remove the

excessive load immediately!

[LLLLL] The delicate weighing load cells have

been damaged by misusing the scale

(i.e. it was shocked, dropped or

overloaded). You can try recalibrating the

scale. If the load cell has not been

damaged too much it will work

again after recalibration.

[UNST] Use the scale in a more stable position

Specications

Model H-11 H-22 H-66 H-110

Capacity 11 lb

5 kg

22 lb

10 kg

66 lb

30 kg

110 lb

50 kg

Resolution 0.005 lb

2 g

0.2 oz

0.01 lb

10 g

0.5 oz

0.02 lb

10 g

0.5 oz

0.05 lb

20 g

1 oz

Tolerance 20 g 40 g

Min. Weight 100 grams

Weighing Modes lb, kg, lb/oz

Power 2x CR2032 Batteries (included)*

*replacement requires small phillips head screwdriver

Auto-Off 60 seconds

Operating Temp. 32° - 104° F
